ZNL-PD1101-K318MADSL router

PD1101- ADSL Router User Manual K318M ADSL Router USER MANUAL NOTICE This document contains proprietary information protected by copyright, and this Manual and all the accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No part of this document may be photocopied or reproduced by mechanical, electronic, or other means in any form. The manufacturer does not warrant that the hardware will work properly in all environments and applications, and makes no warranty or representation, either expressed or implied, with respect to the quality, performance, merchantability, or fitness for a particular purpose of the software or documentation. The manufacturer reserves the right to make changes to the hardware, software, and documentation without obligation to notify any person or organization of the revision or change. All brand and product names are the trademarks of their respective owners. © Copyright 2011 All rights reserved. Content 1 OVERVIEW ................................................................................................................................ 1 1.1 FEATURES ............................................................................................................................. 1 1.2 PACKET CONTENTS ............................................................................................................... 3 1.3 SYSTEM REQUIREMENTS ....................................................................................................... 3 1.4 FACTORY DEFAULTS .............................................................................................................. 4 1.5 WARNINGS AND CAUTIONS .................................................................................................... 4 2 HARDWARE DESCRIPTION ................................................................................................... 5 3 HARDWARE INSTALLATION ................................................................................................. 7 4 PC CONFIGURATION GUIDE ................................................................................................. 8 4.1 LOCAL PC CONFIGURATION IN WINDOWS 95, 98, ME, XP .................................................... 8 4.2 LOCAL PC CONFIGURATION IN WINDOWS 2000 ..................................................................... 8 5 WEB-BASED MANAGEMENT GUIDE.................................................................................... 9 5.1 LAN SETTING PAGE ............................................................................................................... 9 5.2 INTERNET ACCESS CONFIGURATION ...................................................................................... 9 5.3 MANAGEMENT ...................................................................................................................... 21 APPENDIX: FREQUENT ASKED QUESTIONS...................................................................... 24 ADSL Router USER MANUAL 1 1 Overview Thank you for choosing our product. The ADSL Router uses Broadcom’s CPE solution that fully complies with ADSL, ADSL2，ADSL2+ standards. It will provide your SOHO with convenient Internet access. 1.1 Features 1.1.1 Data rate  Downstream data rate up to 24 Mbps,  Upstream data rate up to 3.5Mbps (With AnnexM enabled) 1.1.2 ADSL Compliance  ITU G.992.1 (G.DMT)  ITU G.992.2 (G.Lite)  ITU G.994.1 (G.hs)  ITU G.992.3 (G.DMT.BIS)  ITU G.992.4 (G.lite.bis)  ITU G.992.5  Compatible with all T1.413 issue 2 (full rate DMT over analog POTS), and CO DSLAM equipment  TR-069 compliant with ACS 1.1.3 Network Protocol and Features  Ethernet to ADSL Self-Learning Transparent Bridging  Internet Control Message Protocol (ICMP)  IP Static Routing  Routing Information Protocol (RIP, RIPv2)  Network Address Translation (NAT)  Virtual Server, Port Forwarding ADSL Router USER MANUAL 2  Dynamic Host Configuration Protocol (DHCP)  DDNS  Simple Network Time Protocol (SNTP)  VPN pass-through (IPSec/PPTP/L2TP)  Parent control 1.1.4 ATM Capabilities  RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant  RFC 2364 PPP over ATM compliant  RFC 2516 PPP over Ethernet compliant  ATM Forum UNI3.1/4.0 PVC  VPI Range: 0-255  VCI Range: 32-65535  UNI 3.0 & 3.1 Signaling  ATM AAL5 (Adaption Layer type 5)  OAM F4/F5 1.1.5 FIREWALL  Built-in NAT  MAC Filtering  Packet Filtering  Stateful Packet Inspection (SPI)  Denial of Service Prevention (DoS)  DMZ 1.1.6 Management Support  Web Based GUI ADSL Router USER MANUAL 3  Upgrade or update via FTP/HTTP  Command Line Interface via Telnet  Diagnostic Test  Firmware upgrade-able for future feature enhancement 1.1.7 Operating System Support  WINDOWS 98/SE/ME/2000/XP/VISTA/7  Macintosh  LINUX 1.1.8 Environmental  Operating humidity: 10%-90% non-condensing  Non-operating storage humidity: 5%-95% non-condensing 1.2 Packet Contents The packet contents are as the following:  ADSL ROUTER x 1  External Splitter x 1  Power Adapter x 1  Telephone Line x 1  Ethernet Cable x 1  CD x 1 1.3 System Requirements Before using this ROUTER, verify that you meet the following requirements:  Subscription for ADSL service. Your ADSL service provider should provide you with at least one valid IP address (static assignment or dynamic assignment via dial-up connection).  One or more computers, each contains an Ethernet 10/100M Base-T network interface card (NIC). ADSL Router USER MANUAL 4  A hub or switch, if you are connecting the device to more than one computer.  For system configuration using the supplied web-based program: A web browser such as Internet Explorer v5.0 or later, or Netscape v4.7 or later. 1.4 Factory Defaults The device is configured with the following factory defaults:  IP Address: 192.168.1.1  Subnet Mask: 255.255.255.0  Encapsulation: LLC/SNAP-BRIDGING or VC/MUX  VPI/VCI: According to local information 1.5 Warnings and Cautions  Never i…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOGRAPHS OF EUT External View of EUT-1 External View of EUT-2 External View of EUT-3 External View of EUT-4

FCC Label Location

INTERNAL PHOTOGRAPHS OF EUT Internal View of EUT-1 Internal View of EUT-2 Internal View of EUT-3 Internal View of EUT-4

Test Setup Photo CONDUCTED EMISSION TEST SETUP RADIATED EMISSION TEST SETUP
