ZOQAT-100Dongle connecting to the automotive OBD port. Dongle has GSM radio, GPS receiver, Bluetooth radio. Primary usage is automobile tracking.

Quick Start Guide This guide provides an overview of the basic functions of your devices and simple step-by-step installation instructions. Welcome W Welcome to In-Drive ® , an in-vehicle system that offers a suite of connected services within the Drive Safe & Save ™ program. Central to the In-Drive solution is the use of a simple self-installed device that collects essential vehicle data, and based on your driving behavior, can offer you insurance discounts. Getting started with the Drive Safe & Save with In-Drive program is easy. Install Your Devices Drive SafelyWatch your Discounts Grow! Table of Contents 1 Table of Contents Before You Begin Checklist In-Drive Visor Clip Overview In-Drive Communicator Overview Installing Your Devices Charging Your In-Drive Visor Clip Pairing your mobile phone with the In-Drive Visor Clip (Optional) Pairing Your Android Smartphone with the In-Drive Communicator Device (Optional) Help & Contact Before you begin, make sure you: Enrolled with your State Farm agent or online Have your State Farm login information ready: Ensure all contents are in the box › In-Drive Communicator › In-Drive Visor Clip › In-Drive Visor Clip Car Charger › Quick Start Guide Charge your In-Drive Visor Clip in your vehicle Review the Help Section in this guide 1 2 2 3 3 4 4 Back Username Password 2 Device Overview Phone Button Press to connect or disconnect hands free phone calls Emergency Button Press to connect to Emergency Assistance State Farm Button Press to connect to Roadside Assistance or a State Farm Representative Bluetooth Connection Indicator Illuminates to confirm Bluetooth connection Battery Indicator Solid green when charged; blinks red when low battery +/- Buttons Press to adjust speaker volume Microphone For two-way communication Speaker For two-way communication Charging Port Connects to car charger OBD II Plug Fit’s into vehicle On-Board Diagnostic port. Connection Indicator Illuminates at ignition on to confirm successful connection Hands Free On/Off Button When switched off, you CANNOT use hands free calling In-Drive Connect Package Customers: • The In-Drive Visor Clip is an optional component that can be paired with your Bluetooth capable mobile phone and used as a speakerphone for safe, hands free talking. 1 • The Emergency and State Farm Buttons are inactive for In-Drive Connect customers. • If you choose NOT to pair the In-Drive Visor Clip with your mobile phone, please store your In-Drive Visor Clip in its box for safe- keeping, should you decide to upgrade to the In-Drive Guardian Package. 2 In-Drive Guardian Package Customers: • The In-Drive Visor Clip is a required component that connects you to emergency and roadside assistance. 1 • The In-Drive Visor Clip can also be paired with your Bluetooth capable mobile phone and used as a speakerphone for safe, hands free talking. 1 In-Drive Visor Clip In-Drive Communicator The In-Drive Visor Clip must be in the vehicle with the In-Drive Communicator in order for the hands free calling and assistance buttons to function. However, if you are an In-Drive Connect customer and do not wish to use hands free calling, you do not need to install the In-Drive Visor Clip. You will also be required to return the hardware should you decide to opt out of the program. 1 2 1. Install your In-Drive Communicator (Figure A) › Locate your vehicle’s On-Board Diagnostic (OBD) II port. − This port is usually located under the dash, beneath the steering wheel. › Plug the In-Drive Communicator into the OBD II Port. › The green light will illuminate confirming successful installation. 2. Install your In-Drive Visor Clip 1 (Figure B) › Place the In-Drive Visor Clip on the driver’s side visor. Charging Your In-Drive Visor Clip › The In-Drive Visor Clip is shipped 75% charged; the battery indicator will blink green while charging and turn solid green when the battery is fully charged. › Allow two hours to fully charge. › Fully charged Visor Clip offers approximately six weeks of standby time or 16 hours of hands free talk time. › When the battery is low, the indicator will blink red. Please note: Switching your hands free on/off button to the off position will extend battery life to four months while maintaining the availability of emergency and roadside calling features. Installing Your Devices 3 The In-Drive Visor Clip is optional for In-Drive Connect customers. 1 A B Pairing your mobile phone with the In-Drive Visor Clip You can use your In-Drive Visor Clip as a speakerphone so you can talk hands free while you drive. › Turn your mobile phone’s Blue,tooth feature on – review your mobile phone’s manual for details. › Set your phone to search for Bluetooth devices. › Select “In-Drive Visor Clip” from the search results on your phone – then select OK. › If prompted for the PIN, enter 0000. › The flashing blue light will turn solid, indicating your phone has been paired successfully. Pairing Your Android Smartphone with the In-Drive Communicator Device [For In-Drive Connect with Smartphone Package Customers Only] The In-Drive Connect with Smartphone package allows customers to download an Android app that collects their real-time driving statistics, using the Android phone’s data plan 2 . › Download the smartphone application from the Android Market. › Open the Android app and login with the email and PIN you designated during the program registration process. › Select “Pair your phone with In-Drive Communicator” from the app menu. › The app will perform a search and produce a list of nearby devices. › Select “In-Drive Communicator” and click OK. › A message will appear confirming the device has been paired. Pairing Your Devices (Optional) 4 The In-Drive Connect with Smartphone package is only available on Android capable mobile phones. This will require use of your cell phone data plan and is dependent upon your cellular network coverage. 2 Take a Drive › During your first trip, the In-Drive Communicator will begin collecting your drivin…

Text truncated - open the document above for the full version.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by Hughes Telematics, Inc. could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. #1087_8_23 The internal / external antennas used for this mobile transmitter must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Exposure to Radio Frequency (RF) Signals: The wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limit for exposure to radio frequency (RF) energy set by the OET Bulletin 65 Supplement C. These limits are part of comprehensive guidelines and established permitted levels of RF energy for the general population. These guidelines are based on the safety standards previously set by international standard bodies. These standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general public exposure limits specific in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE Std. 1528-2003 Decem- ber 2003. © 2011 Hughes Telematics, Inc. In-Drive is a registered trademark of Hughes Telematics, Inc.

Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/21/2011 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: ZOQAT-100 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Bryant Elliott Director of Engineering Hughes Telematics Incorporated

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 6/21/2011 Request for Confidentiality Company name: Hughes Telematics Incorporated FCC ID: ZOQAT-100 FCC Part 15 Certification Gentlemen, In accordance with 0.459 of CFR 47, Hughes Telematics Incorporated hereby requests confidentiality of following attachments: Block Diagrams, Circuit Description, Schematics, Parts List, Operational Description for the subject application. These documents contain detailed system and equipment description and related information about the product which Hughes Telematics Incorporated considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Hughes Telematics Incorporated considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature Bryant Elliott Director of Engineering Hughes Telematics Incorporated 2002 Summit Blvd Suite 1800 Atlanta, GA 30319 USA

Provided by Eurofins Product Service GmbH v.0.2 Declaration concerning Antenna Specification It is hereby declared that the product Model No.: AT-100 FCC ID: ZOQAT-100 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: GSM Antenna: Pulse W3628 Bluetooth Antenna: Pulse W3008K Type of antenna: GSM Antenna: PIFA, soldered to PCB Bluetooth Antenna: Chip type, soldered to PCB Gain of the antenna: GSM Antenna: 850MHz Band: 0.2dBi 1900MHz Band: 1.5dBi Bluetooth Antenna: 2 dBi Frequency range: GSM Antenna: 850MHz Band: 824 to 894 MHz 1900MHz Band: 1850 to 1990 MHz Bluetooth Antenna: 2400 to 2483.5MHz The mounting of the antenna(s) are fixed to the radio module and no other antenna(s) should be used. Company name: Hughes Telematics Incorporated Address: 2002 Summit Blvd Suite 1800 City: Atlanta ZIP / Postal code: 30319 Country: USA Place: Date: Signature:

Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos EUT FRONT EUT BACK Page 35 of 157 Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT SIDE VIEW Page 36 of 157

DC BA 4321 DC BA 4321 Title Unless Otherwise Specified, All Dimensions are in Millimeters. TOL on Angles +/- 1 ° 0 Place +/- 0.5 1 Place +/- 0.2 Per ASME Y14.5M-1994 Hughes Telematics, Inc.2002 Summit Blvd. Suite 1800Atlanta, GA 30319 Drawn Approved Drawing Number Rev Scale Sheet CONFIDENTIAL HUGHES TELEMATICS, INC. owns this document and does not permit reproducing, copying, distributing, or divulging thereof without written consent. © Hughes Telematics, Inc. 2010 Size Revision History Rev Description Date App’d A00 Initial Release 110825 LAJ LAJ LAJ 09-10137 A00 A 2 : 1 1 of 1 in-Drive AT-100 Blank Label,Bar Code 29.8 21.8 Made in Mexico AT-100 MODEL PVN-REV 001-A01 12V 2A Max FCC ID: ZOQAT-100IC: 9734A-AT100 3.60 4.19 4.19 38.18 25.40 Material: Flexcon Thermfilm 21940 with L-344 adhesive Thickness: 0.05 to 0.08mm (including backer) Color: White Gloss Finish Media Type: Non-Continuous (translucent separation between labels) Corner Radii: 0.9mm Core Inner Diameter: 76.2mm Roll Outer Diameter: 203.2mm Maximum Unwind: Outside Label Orientation: Landscape Finish Product Feed Direction S/N: 358111040000013

Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT OPEN EUT OPEN SIDE VIEW Page 37 of 157 Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany PCB 1 FRONT PCB 1 BACK Page 38 of 157 Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany PCB 2 FRONT PCB 2 FRONT WITHOUT SHIELDING Page 39 of 157 Test Report No.: G0M-1105-1155-P-15 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany PCB 2 BACK PCB 2 BACK WITHOUT SHIELDING Page 40 of 157

Quantity Designator Description HTI Part Number Digikey Manufacturer #1 Manufacturer #2 Part Number #1 Part Number #2 1 ANT1 Pulse W3008K Bluetooth Ceramic Chip Anten n 39 ‐ 10007 Pulse W3008K 1 ANT2 Pulse W3010E GPS Ceramic Chip Antenna 39 ‐ 10008 Pulse W3010E 15 C1, C4, C13, C14, C18, C25, C30, C31, C32, C40, C CAP,SMD,0.01uF,50V,10%,0402,Cer,X7R 31 ‐ 10021 490 ‐ 4762 ‐ 2 ‐ ND Murata Taiyo Yuden GRM155R71H103KA88D UMK105B7103KV ‐ F 2 C2, C3 CAP CER 4.7UF 50V X7R 1210 31 ‐ 10059 399 ‐ 5612 ‐ 2 ‐ ND Kemet Murata C1210X475K5RACTU GRM32ER71H475KA88L 1 C5 CAP CER .47UF 25V 10% X7R 1206 31 ‐ 10044 490 ‐ 1784 ‐ 1 ‐ ND Murata AVX GRM319R71E474KA01D 12063C474KAT2A 4 C6, C7, C8, C9 CAP CER 10UF 50V X7R 10% 2220 31 ‐ 10058 445 ‐ 3492 ‐ 2 ‐ ND TDK C5750X7R1H106K 17 C10, C23, C39, C45, C49, C52, C84, C85, C88, C9 0 CAP,SMD,0.1uF,16V,10%,0402,Cer,X7R 31 ‐ 10002 490 ‐ 3261 ‐ 2 ‐ ND Murata Taiyo Yuden GRM155R71C104KA88D EMK105B7104KV ‐ F 2 C11, C17 CAP CER 2.2UF 10V 10% X7R 0805 31 ‐ 10037 490 ‐ 1696 ‐ 1 ‐ ND Murata Taiyo Yuden GRM21BR71A225KA01L LMK212B7225KG ‐ T 2 C12, C20 CAP CER 47UF 16V X5R 1210 31 ‐ 10013 490 ‐ 3888 ‐ 2 ‐ ND Murata Taiyo Yuden GRM32ER61C476ME15L EMK325BJ476MM ‐ T 4 C15, C99, C104, C105 CAP,100pF, 50V,0402,NPO, +/ ‐ 5% 31 ‐ 10011 490 ‐ 4756 ‐ 2 ‐ ND Murata Taiyo Yuden GRM1555C1H101JA01D UMK105CG101JV ‐ F 1 C16 CAP CER 470PF 50V 5% C0G 0603 31 ‐ 10041 490 ‐ 1443 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1885C1H471JA01D UMK107CG471JZ ‐ T 41 C19, C26, C27, C41, C47, C48, C55, C56, C57, C5 8 CAP CER 56PF 50V 5% C0G 0402 31 ‐ 10032 490 ‐ 1288 ‐ 2 ‐ ND Murata Taiyo Yuden GRM1555C1H560JD01D UMK105CH560JV ‐ F 1 C21 CAP,SMD,1uF,100V,10%,1206,Cer,X7R 31 ‐ 10012 490 ‐ 3909 ‐ 2 ‐ ND Murata Taiyo Yuden GRM31CR72A105KA01L HMK316B7105KL ‐ T 4 C22, C38, C44, C107 CAP CER 10UF 10V X7R 1206 31 ‐ 10038 490 ‐ 3371 ‐ 1 ‐ ND Murata Taiyo Yuden GRM31CR71A106KA01L LMK316B7106KL ‐ TD 4 C24, C33, C87, C94 CAP CER 10UF 6.3V X7R 0805 31 ‐ 10062 490 ‐ 3904 ‐ 1 ‐ ND Murata AVX GRM21BR70J106KE76L 08056C106KAT2A 2 C28, C29 CAP CER 2.2UF 6.3V X7R 10% 0603 31 ‐ 10063 490 ‐ 5316 ‐ 1 ‐ ND Murata AVX GCM188R70J225KE22D 06036C225KAT2A 5 C34, C35, C37, C115, C116 CAP CERAMIC 15PF 50V C0G 0402 31 ‐ 10045 490 ‐ 3117 ‐ 1 ‐ ND Murata Taiyo Yuden GJM1555C1H150JB01D UMK105CG150JV ‐ F 1 C36 CAP CERAMIC 2.7PF 50V C0G 0402 31 ‐ 10074 490 ‐ 3093 ‐ 1 ‐ ND Murata Johanson GJM1555C1H2R7CB01D 500R07S2R7CV4T 1 C42 CAP CERAMIC 9PF 50V C0G 0402 31 ‐ 10047 490 ‐ 3111 ‐ 1 ‐ ND Murata Taiyo Yuden GJM1555C1H9R0CB01D UMK105 CG090CV ‐ F 1 C43 CAP CER 27PF 50V 5% C0G 0402 31 ‐ 10048 490 ‐ 1284 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H270JA01D UMK105CH270JV ‐ F 3 C50, C53, C93 CAP CER 33PF 50V C0G 0402 31 ‐ 10043 490 ‐ 3220 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H330JA01D UMK105CG330JV ‐ F 2 C51, C54 CAP CER 10PF 50V 5% C0G 0402 31 ‐ 10034 490 ‐ 1278 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H100JA01D UMK105CG100DV ‐ F 1 C98 CAP CER 200PF 50V C0G 0402 31 ‐ 10052 490 ‐ 3232 ‐ 2 ‐ ND Murata Panasonic GRM1555C1H201JA01D ECU ‐ E1H201JCQ 1 C106 CAP CERAMIC 4.7PF 50V C0G 0402 31 ‐ 10071 490 ‐ 3100 ‐ 2 ‐ ND Murata Johanson GJM1555C1H4R7CB01D 500R07S4R7BV4T 1 C110 CAP CER 22000PF 16V X7R 0402 31 ‐ 10050 490 ‐ 3256 ‐ 2 ‐ ND Murata Taiyo Yuden GRM155R71C223KA01D EMK105B7223KV ‐ F 1 D1 RECTIFIER GPP 50V 3A SMB 35 ‐ 10015 S3AB ‐ FDICT ‐ ND Diodes S3AB ‐ 13 ‐ F 1 D2 DIODE SCHOTTKY 3A 60V SMA 35 ‐ 10003 B360ADITR ‐ ND Diodes Inc. Vishay B360A ‐ 13 ‐ F B360A ‐ E3/61T 2 D3, D4 DIODE SCHOTTKY 8V 50MA SC ‐ 79 35 ‐ 10010 863 ‐ 1109 ‐ 2 ‐ ND Skyworks SMS3922 ‐ 079LF 1 D5 LED GREEN CLEAR 0603 RT ANG SMD 46 ‐ 10013 160 ‐ 1478 ‐ 2 ‐ ND LiteOn LTST ‐ S270KGKT 1 D6 LED Yellow CLEAR 0603 RT ANG SMD 46 ‐ 10014 160 ‐ 1480 ‐ 2 ‐ ND LiteOn LTST ‐ S270KSKT 1 D7 LED RED CLEAR 0603 RT ANG SMD 46 ‐ 10015 160 ‐ 1479 ‐ 1 ‐ ND LiteOn LTST ‐ S270KRKT 1 D8 DIODE SW 75V 200MA HS SOT23 35 ‐ 10009 568 ‐ 1596 ‐ 2 ‐ ND NXP OnSemi BAS16,215 BAS16LT3G 1 D9 LED 468NM RA BLUE CLEAR 0603 SMD 46 ‐ 10016 160 ‐ 1650 ‐ 2 ‐ ND LiteOn LTST ‐ S270TBKT 1 F1 PTC Fuse, 1A 44 ‐ 10000 MF ‐ SM100CT ‐ ND Bourns MF ‐ SM100 ‐ 2 2 FB1, FB5 FERRITE CHIP 390 OHM 2000MA 1206 49 ‐ 10006 490 ‐ 5229 ‐ 2 ‐ ND Murata Steward BLM31PG391SN1L MI1206L391R ‐ 10 3 FB2, FB3, FB4 FERRITE CHIP POWER 600 OHM SMD 49 ‐ 10000 240 ‐ 2371 ‐ 2 ‐ ND Steward TDK MI0603J601R ‐ 10 MPZ1608S601A 1 J1 Header, 6.35mm , 2 row, 20 pins per row 40 ‐ 10037 NA Samtec TFC ‐ 120 ‐ 02 ‐ F ‐ D ‐ A ‐ K ‐ TR 2 J2, J3 Header 0.50 2 row 5 pins per row" 40 ‐ 10039 NA Samtec TFC ‐ 105 ‐ 02 ‐ F ‐ D ‐ A ‐ K ‐ TR 1 L1 INDUCTOR 10UH 900MA 1210 SMD 33 ‐ 10018 587 ‐ 2167 ‐ 2 ‐ ND Taiyo Yuden BRL3225T100K 1 L2 INDUCTOR POWER 10UH 4A SMD 33 ‐ 10003 IHLP2525CZER100M11 ‐ ND Vishay Mag Layers IHLP2525CZER100M11 MMD ‐ 06CZ ‐ 100M ‐ V2 ‐ RU 1 L3 INDUCTOR 22UH 250MA 1210 33 ‐ 10011 490 ‐ 4061 ‐ 6 ‐ ND Murata Coilcraft LQH32CN220K53L ME3215 ‐ 223KLC 1 L4 INDUCTOR 15NH 460MA 0402 33 ‐ 10012 490 ‐ 1148 ‐ 2 ‐ ND Murata Coilcraft LQW15AN15NJ00D 0302CS ‐ 15NXJLW 1 L5 Inductor, 1000uH, 40mA 33 ‐ 10005 587 ‐ 2041 ‐ 2 ‐ ND Taiyo Yuden LB3218T102K 1 MTG1 AT100 PS Shield Fence 51 ‐ 10031 Laird HUG ‐ LT10AM4731F 1 MTG2 GSM Shield Top 51 ‐ 10032 Laird HUG ‐ LT10AM4731C 1 MTG3 AT100 BT Shield Fence 51 ‐ 10033 Laird HUG ‐ LT10AM4732F 1 MTG4 AT100 GPS BT Shield Top 51 ‐ 10034 Laird HUG ‐ LT10AM4732C 7 Q1, Q3, Q4, Q5, Q6, Q10, Q11 Transistor, NPN, SC ‐ 75 36 ‐ 10000 BC847BTT1GOSTR ‐ ND OnSemi NXP BC847BTT1 BC847BT 1 Q2 MOSFET P ‐ CH 12V 6A SSOT ‐ 636 ‐ 10005 FDC606PTR ‐ ND Fairchild Vishay FDC606P SI3473DV ‐ T1 ‐ E3 3 Q7, Q8, Q9 MOSFET N ‐ CH 60V 115MA SOT ‐ 323 36 ‐ 10006 2N7002WCT ‐ ND Fairchild OnSemi 2N7002W 2N7002WT1G 14 R1, R5, R8, R18, R19, R23, R24, R28, R33, R38, R RES 100K OHM 1/16W 5% 0402 SMD 32 ‐ 10088 311 ‐ 100KJTR ‐ ND Yageo Rohm RC0402JR ‐ 07100KL MCR01MZPJ104 1 R2 RES 15K OHM 1/10W 5% 0603 SMD 32 ‐ 10083 311 ‐ 15KGCT ‐ ND Yageo Rohm RC0603JR ‐ 0715KL MCR03EZPJ153 1 R3 RES 40.2K OHM 1/16W 1% SMD 0402 32 ‐ 10087 9T04021A4022FBHF3 ‐ ND Yageo Rohm RC0402FR ‐ 0740K2L MCR01MZPF4022 1 R4 RES 40…

Text truncated - open the document above for the full version.

Quantity Designator Description HTI Part Numbe r Digikey Manufacturer #1 Manufacturer #2 Part Number #1 Part Number #2 1 SE1 FW, U6, AT ‐ 100 GSM Board ATMEGA, 30 ‐ 100 0 08 ‐ 10000 HTI 1 SE2 FW, U1, AT ‐ 100 SL6087 Sierra Wireless Releas 08 ‐ 10005 HTI 1 SE3 SW, U1, AT ‐ 100 SL6087 Application Code Rele a 08 ‐ 10006 HTI 3 P2, P6, P7 in ‐ Drive AT ‐ 100 OBD Connector Short pin 09 ‐ 10031 NA HTI 4 P10, P14, P15, P1 6 in ‐ Drive AT ‐ 100 OBD Connector Long pin 09 ‐ 10032 NA HTI 2 P4, P5 in ‐ Drive AT ‐ 100 OBD Connector GND pin 09 ‐ 10033 NA HTI 1M1 in ‐ Drive AT ‐ 100 GSM Antenna Adhesive 09 ‐ 10105 NA HTI 1 U6 IC, Microcontroller, AVR, 16 MHz, MLF ‐ 4 4 30 ‐ 10006 ATMEGA162 ‐ 16MUR ‐ ND Atmel ATmega162 ‐ 16MU 1 U20 IC QUAD BUS BUFF GATE 3ST 14 ‐ QFN 30 ‐ 10012 SN74LV125ARGYRG4 ‐ ND TI TI SN74LV125ARGYRG4 SN74AHC125RGYRG4 1 U22 I.C., differential transceiver, SOIC ‐ 830 ‐ 10015 296 ‐ 1279 ‐ 2 ‐ ND TI SN75LBC176DR 2 U19, U21 I.C., ISO 9141 transceiver, SOIC ‐ 8 30 ‐ 10016 NA Vishay Siliconix Si9243AEY ‐ T1 ‐ E3 1 U17 I.C., CAN transceiver, SOIC ‐ 830 ‐ 10017 MAX13050ASA+T ‐ ND Maxim NXP MAX13050ESA+T TJA1040T/VM 1 U14 I.C., CAN Controller, TSSOP ‐ 20 30 ‐ 10018 MCP2515 ‐ I/ST ‐ ND Microchip MCP2515 ‐ I/S T 1 U5 AT&T M2M Soldered SIM, SLM75CF3201P, Pr o 30 ‐ 10023 G&D Oberthur PQ ‐ AX ‐ 0001 IO149 VQFN8 1U8 IC 8 ‐ BIT TRNSLTR 15KV ESD 20 ‐ QFN 30 ‐ 10035 296 ‐ 21528 ‐ 2 ‐ ND TI TXB0108RGYR 1U3 IC REG ULDO 300MA 3.3V SOT23 ‐ 530 ‐ 10065 497 ‐ 4257 ‐ 2 ‐ ND ST Micro On Semi LDS3985M33R NCP603SN330T1G 1 U29 IC COMPARATOR OPEN ‐ DRAIN SC70 ‐ 530 ‐ 10069 ADCMP370AKSZ ‐ REEL7TR ‐ ND Analog Devices ADCMP370AKSZ ‐ REEL7 1U7 IC BUS BUFF TRI ‐ ST DL 8VSSOP 30 ‐ 10071 296 ‐ 13265 ‐ 2 ‐ ND TI NXP SN74LVC2G125DCUR 74LVC2G125DC 1 U1 IC, GSM Radio Sierra Wireless 30 ‐ 10077 Sierra Wireless SL6087 (SKU 1101370) 2 U9, U16 IC SINGLE INVERTER GATE SC70 ‐ 530 ‐ 10078 296 ‐ 11600 ‐ 2 ‐ ND TI Diodes Inc SN74LVC1G04DCKR 74LVC1G04SE ‐ 7 1U4 IC INVERTER DUAL SCHMITT SC70 ‐ 630 ‐ 10079 296 ‐ 13011 ‐ 2 ‐ ND TI Fairchild SN74LVC2G14DCKR NC7WZ14P6X 1U2 IC iPod Authentication Coprocesso r 30 ‐ 10099 Apple MFI341S2162 1 U10 IC ACCELERATOR SMBUS DL SC70 ‐ 630 ‐ 10100 LTC4311ISC6#TRPBF ‐ ND Linear Tech LTC4311ISC6#TRMPBF 24 C1, C4, C6, C7, C12, C32, C37, C39, C44, C45, C 4 CAP,SMD,0.1uF,16V,10%,0402,Cer,X7R 31 ‐ 10002 490 ‐ 3261 ‐ 2 ‐ ND Murata Taiyo Yuden GRM155R71C104KA88D EMK105B7104KV ‐ F 11 C11, C23, C24, C38, C50, C76, C77, C85, C89, C 1 CAP,SMD,0.01uF,50V,10%,0402,Cer,X7 R 31 ‐ 10021 490 ‐ 4762 ‐ 2 ‐ ND Murata Taiyo Yuden GRM155R71H103KA88D UMK105B7103KV ‐ F 23 C8, C9, C10, C13, C18, C19, C20, C21, C22, C27, CAP CER 56PF 50V 5% C0G 040 2 31 ‐ 10032 490 ‐ 1288 ‐ 2 ‐ ND Murata Taiyo Yuden GRM1555C1H560JD01D UMK105CH560JV ‐ F 5 C17, C43, C51, C54, C8 6 CAP CER 10PF 50V 5% C0G 040 2 31 ‐ 10034 490 ‐ 1278 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H100JA01D UMK105CG100DV ‐ F 2 C90, C91 CAP CER 22PF 50V 5% C0G 040 2 31 ‐ 10036 490 ‐ 1283 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H220JZ01D UMK105CG220JV ‐ F 1 C25 CAP CER 2.2UF 10V 10% X7R 0805 31 ‐ 10037 490 ‐ 1696 ‐ 1 ‐ ND Murata Taiyo Yuden GRM21BR71A225KA01L LMK212B7225KG ‐ T 2 C14, C15 CAP CER 10UF 10V X7R 120 6 31 ‐ 10038 490 ‐ 3371 ‐ 1 ‐ ND Murata Taiyo Yuden GRM31CR71A106KA01 L LMK316B7106KL ‐ TD 2 C80, C81 CAP CER 560PF 50V 5% C0G 0603 31 ‐ 10039 490 ‐ 1445 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1885C1H561JA01D UMK107CG561JZ ‐ T 1 C29 CAP CER .1UF 100V X7R 0805 31 ‐ 10042 490 ‐ 4789 ‐ 1 ‐ ND Murata Taiyo Yuden GCM21BR72A104KA37 L HMK212B7104KG ‐ T 5 C16, C35, C47, C53, C8 7 CAP CER 33PF 50V C0G 0402 31 ‐ 10043 490 ‐ 3220 ‐ 1 ‐ ND Murata Taiyo Yuden GRM1555C1H330JA01D UMK105CG330JV ‐ F 2 C65, C92 CAP CERAMIC 15PF 50V C0G 040 2 31 ‐ 10045 490 ‐ 3117 ‐ 1 ‐ ND Murata Taiyo Yuden GJM1555C1H150JB01D UMK105CG150JV ‐ F 2 C71, C72 CAP CERAMIC 1.3PF 50V C0G 0402 31 ‐ 10054 490 ‐ 3086 ‐ 2 ‐ ND Murata Johanson GJM1555C1H1R3CB01D 500R07S1R3BV4 T 1 C30 CAP CER 10UF 6.3V X7R 0805 31 ‐ 10062 490 ‐ 3904 ‐ 1 ‐ ND Murata AVX GRM21BR70J106KE76 L 08056C106KAT2 A 2 C5, C26 CAP CER 2.2UF 6.3V X7R 10% 0603 31 ‐ 10063 490 ‐ 5316 ‐ 1 ‐ ND Murata AVX GCM188R70J225KE22D 06036C225KAT2 A 1 R94 RES,SMD,100Kohms,1/16W,1%,0402 32 ‐ 10022 541 ‐ 100KLTR ‐ ND Vishay Yageo CRCW0402100KFKED RC0402FR ‐ 07100K L 1 R37 Res, 0 ohm 0402 32 ‐ 10030 311 ‐ 0.0JRTR ‐ ND Yageo Rohm RC0402JR ‐ 070R L MCR01MZPJ000 7 R11, R12, R64, R71, R81, R89, R93 RES 10K OHM 1/16W 5% 0402 SMD 32 ‐ 10076 311 ‐ 10KJCT ‐ ND Yageo Rohm RC0402JR ‐ 0710K L MCR01MZPJ103 1 R88 RES 100 OHM 1/10W 5% 0603 SM D 32 ‐ 10078 311 ‐ 100GCT ‐ ND Yageo Rohm RC0603JR ‐ 07100R L MCR03EZPJ101 4 R1, R5, R6, R25 RES 47K OHM 1/16W 5% 0402 SMD 32 ‐ 10079 311 ‐ 47KJCT ‐ ND Yageo Rohm RC0402JR ‐ 0747K L MCR01MZPJ473 3 R73, R75, R78 RES 10K OHM 1/10W 5% 0603 SMD 32 ‐ 10082 311 ‐ 10KGCT ‐ ND Yageo Rohm RC0603JR ‐ 0710K L MCR03EZPJ103 3 R76, R77, R82 RES 15K OHM 1/10W 5% 0603 SMD 32 ‐ 10083 311 ‐ 15KGCT ‐ ND Yageo Rohm RC0603JR ‐ 0715K L MCR03EZPJ153 2 R72, R74 RES 510 OHM 1/4W 5% 1206 SMD 32 ‐ 10085 311 ‐ 510ETR ‐ ND Yageo Rohm RC1206JR ‐ 07510R L MCR18EZPJ511 1 R15 RES 1.00M OHM 1/16W 1% 0402 SMD 32 ‐ 10086 311 ‐ 1.00MLRTR ‐ ND Yageo Rohm RC0402FR ‐ 071M L MCR01MZPF1004 12 R2, R3, R4, R7, R8, R9, R10, R13, R21, R22, R98, RES 100K OHM 1/16W 5% 0402 SMD 32 ‐ 10088 311 ‐ 100KJTR ‐ ND Yageo Rohm RC0402JR ‐ 07100K L MCR01MZPJ104 3 R79, R80, R91 RES 10 OHM 1/10W 5% 0603 SMD 32 ‐ 10089 311 ‐ 10GTR ‐ ND Yageo Rohm RC0603JR ‐ 0710R L MCR03EZPJ100 1 R87 RES 2.7K OHM 1/10W 5% 0603 SMD 32 ‐ 10102 311 ‐ 2.7KGRTR ‐ ND Yageo Rohm RC0603JR ‐ 072K7 L MCR03EZPJ272 2 R69, R70 RES 1.2K OHM 1/4W 5% 1206 SMD 32 ‐ 10103 311 ‐ 1.2KERTR ‐ ND Yageo Rohm RC1206JR ‐ 071K2 L MCR18EZHJ122 1 R92 RES 20 OHM 1/16W 5% 0402 SMD 32 ‐ 10104 311 ‐ 20JRTR ‐ ND Yageo Rohm RC0402JR ‐ 0720R L MCR01MZPJ200 1 R95 RES 3.6K OHM 1/10W 5% 0603 SMD 32 ‐ 10105 311 ‐ 3.6KGRTR ‐ ND Yageo Rohm RC0603JR ‐ 073K6 L MCR03EZPJ362 1 R97 RES 6.8K OHM 1/16W 5% 0402 SMD 32 ‐ 10106 311 ‐ 6.8KJRTR ‐ ND Yageo Rohm RC0402JR ‐ 076K8 L MCR01…

Text truncated - open the document above for the full version.

Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 EUROFINS PRODUCT SERVICE GMBH RF-EXPOSURE A SSESSMENT FCC 47 CFR 2.1091 IC RSS-102 Telematics Unit AT-100 FCC ID: ZOQAT-100 IC: 9734A-AT100 REPORT NUMBER: G0M-1105-1155-C-2 Test Report No.: G0M-1105-1155-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 2 of 15 TABLE OF CONTENTS 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 5 1.4 Application details 5 1.5 Acronyms and abbreviations 5 1.6 Reference standards 6 1.7 Test item 7 1.8 Referenced documents 7 1.9 Additional information 7 2 Exposure Assessment 8 2.1 Device Types 8 2.2 Exposure Categories 8 2.3 MPE Limits 9 2.4 Transmission modes 12 2.5 Exposure assessment 13 Test Report No.: G0M-1105-1155-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 15 1.2 Testing laboratory EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 660 DA KKS ACCREDITED TESTING LABORATORY DA KKS-REGISTRATION NUMBER: D-PL-12092-01-01 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 Test location, where different: Name : ./. Street : ./. Town : ./. Country : ./. Telephone : ./. Fax : ./. Test Report No.: G0M-1105-1155-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 15 1.3 Details of approval holder Name : Hughes Telematics, Inc. Street : 2002 Summit Blvd, Suite 1800 Town : GA 30319 Atlanta, Georgia Country : USA Telephone : +1 404 573 5848 Fax : +1 404 285 0648 Contact : Mr. Bryant Elliott Telephone : +1 404 573 5848 Manufacturer: (if applicable) Name : Hughes Telematics, Inc. Street : 2002 Summit Blvd, Suite 1800 Town : GA 30319 Atlanta, Georgia Country : USA 1.4 Application details Date of receipt of application : 14.06.2011 Date of receipt of test item : 14.06.2011 Date of assessment : 29.08.2011 1.5 Acronyms and abbreviations EUT : Equipment under Test TX : Transmission RX : Reception RBW : Measurement Resolution Bandwidth Pol : Measurement Polarization N/A : Not applicable Test Report No.: G0M-1105-1155-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 15 1.6 Reference standards Technical standards : FCC 47 CFR 1.1310 FCC 47 CFR 2.1091 FCC 47 CFR 2.1093 OET Bulletin 65 : ” Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Elec tromagnetic Fields” 1997 RSS-102 Issue 4 : “Radio Frequency (RF) Exposure Com pliance of Radiocommunication Apparatus (All Frequency Bands)”, 2010 Safety Code 6: “Limits of Human Exposure to Radiofre quency Electromagnetic Energy in the Frequency Range from 3 kHz to 300 GHz”, 2009 IEEE C95.3 : “IEEE Recommended Practice for Measure ments and Computations of Radio Frequency Electro magnetic Fields With Respect to Human Exposure to Such Fields, 100 kHz–300 GHz”, 2002 Health Canada : “Technical Guide for Interpretation and Compliance Assessment of Health Canada’s Radiofre quency Exposure Guidelines”, 2009 Test Report No.: G0M-1105-1155-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 15 1.7 Test item Description of test item : Telematics Unit Type identification : AT-100 Serial Number : Unspecified Hardware version : Rev. A Software version : 2.0.0 Radiation sources included : GSM850 / GSM1900 / Bluetooth Equipment type : End product Exposure Category : Uncontrolled / General pu…
