ZRCGEPBT50309ABluetooth Portable Speaker

Parts: Charge: Initial set up via Bluetooth 1. Turn on the Bluetooth™ Speaker by pressing up top control panel.and slide shift button to bluetooth icon. 2. Wait for approximately 20 seconds,the speaker will go into pairing mode and will produce a “beep”tone.The top red and blue l ed light will alternately flash. 3. Turn on a device such as an ipod,iphone or mp3 device and go to:Setting>General>Bluetooth.Click on the bluetooth GP-503 will then appear on the device.Click on the GP-503. The device is now connected and paired with the speaker.If the device prompts f or a pair code,enter:”0000” 4. If pairing is not successful within 150seconds,the system will search for the last paired device.To restart the pairing proc ess,turn off the speaker and repeat step 1.If the initial set up connection is succesful,the next time the speaker is turned on ,the speaker will automatically pair to the last device it was connected with. 5. GP-503 don't have volume control function,please adjust volume via music device. NOTE: 1. The bluetooth speaker only connect s to one device at a time.Turn off the bluetoot h speaker in order to pair the device with another bluetooth device. 2. The maximum transmission betw een the bluetooth speaker and a device is 10 meters or 32 feet. 3. Interference may occur duri ng playback when using the bluet ooth function near other wirel ess devices.If playback through blu etooth is problematic,move the bluetooth speaker and the playback device to a different location,or use the 3.5mm audio cable jack instead of the bluetooth function. WARNING: The built-in rechargeable battery is not replaceable.Do not remo ve or replace battery.Dispose of unit properly.Do not dispose u nit in trash or fire. BLUE TOOTH SPEAKER MANUAL 1,USB charge port 2,Shift button Fully charge the speaker before use. Connect the speaker to the PC C via provided USB cable. It is powered by internal rechargeable battery and it can using the converting cable for charging function by USB port. When the top RED LED flash approximately 15 times, it means the battery is low, please recharge the speaker. The soli d RED LED will appear when speaker is on charged. The RED LED goes out when charge is finished Connecting with an audio cable To slide shift button to audio input icon and connect the bottom extented 3.5mm audio jack to music device. Power on Connect to last device Enter pass code “0000” Play music Fail to Search last device after 20s Under pairing mode Device find GP-503 Enter pass code”0000” Successful to connect Play music No device to pai r Get back search last device after 150s Remate up device Specification Output: ： 2.5Wx1pcs Signal To Noise Ratio: >86dB Frequency Response: 100Hz-20kHz Distortion: <10% Battery Li-ion: 3.7v Battery Capacity: 500mAh Battery Charging Voltage: 5V Charger Time: 3 hours max Last Time: 4hours (via bluetooth to play) Last Time: 5hours (via audio cable to play) Driver Unit: 36mm, 4 Ohm ,2.5W Dimension: 70x53mm Power Indicator Light: Blue lights Transmission Distance: 10m Work Frequency: 2.40-2.480GHz Bluetooth Model: V2.1+EDR Transmission distance: 10m Transmission Power: bluetooth class 2 GP-503 bluetooth operation Chart FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

GEP TECHNOLOGY CO.,LIMITED Date (dd/mm/yyyy) 19/7/2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, GEP TECHNOLOGY CO.,LIMITED (RM2103 EASEY COMMERCIAL BUILDING 253-261 HENNESSY ROAD WANCHAI HongKong), hereby authorize Hans.hu (Company name: Global United Technology Services Co., Ltd. Address: 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong ) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 19/7/2013 Sincerely, Company Officer: ERIN ZHONG Telephone Number: 852-81219610 Email: [email protected]

GEP TECHNOLOGY CO.,LIMITED Date (dd/mm/yyyy) 19/7/2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: ZRCGEPBT50309A Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, GEP TECHNOLOGY CO.,LIMITED hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: ERIN ZHONG Telephone Number: 852-81219610 Email: [email protected]

Label size Length=30mm, Width=30mm Product name: bluetooth portable speaker Model No.: GP-503 FCC ID: ZRCGEPBT50309A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.(2) This device must accept any interference received, including interference that may cause undesired operation.

Label location

Global United Technology Services Co., Ltd. Report No: GTSE12050052801 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS International Electrical Approvals or testing done by GTS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by GTS International Electrical Approvals in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover Page FCC Report Applicant: GEP TECHNOLOGY CO.,LIMITED Address of Applicant: RM2103 EASEY COMMERCIAL BUILDING 253-261 HENNESSY ROAD WANCHAI HongKong Equipment Under Test (EUT) Product Name: bluetooth portable speaker Model No.: GP-503 FCC ID: ZRCGEPBT50309A Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2010 Date of sample receipt: May 28, 2012 Date of Test: July 16-18, 2012 Date of report issued: July 18, 2012 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: GTSE12050052801 Global United Technology Services Co., Ltd. Project No.: GTSE120500528RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 48 2 Version Version No. Date Description 00 July 18, 2012 Original Prepared By: Date: July 18, 2012 Project Engineer Check By: Date: July 18, 2012 Reviewer Report No: GTSE12050052801 Global United Technology Services Co., Ltd. Project No.: GTSE120500528RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 48 3 Contents Page 1 COVER PAGE..............................................................................................................................................................1 2 VERSION.......................................................................................................................................................................2 3 CONTENTS...................................................................................................................................................................3 4 TEST SUMMARY.........................................................................................................................................................4 5 GENERAL INFORMATION........................................................................................................................................5 5.1 CLIENT INFORMATION............................................................................................................................................5 5.2 GENERAL DESCRIPTION OF E.U.T........................................................................................................................5 5.3 TEST MODE............................................................................................................................................................7 5.4 TEST FACILITY.......................................................................................................................................................7 5.5 TEST LOCATION.....................................................................................................................................................7 5.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER.......................................................................................7 5.7 DESCRIPTION OF SUPPORT UNITS........................................................................................................................7 5.8 TEST INSTRUMENTS LIST.......................................................................................................................................8 6 TEST RESULTS AND MEASUREMENT DATA.....................................................................................................9 6.1 ANTENNA REQUIREMENT:......................................................................................................................................9 6.2 CONDUCTED EMISSIONS.....................................................................................................................................10 6.3 CONDUCTED PEAK OUTPUT POWER..................................................................................................................13 6.4 20DB EMISSION BANDWIDTH..............................................................................................................................17 6.5 CARRIER FREQUENCIES SEPARATION................................................................................................................21 6.6 HOPPING CHANNEL NUMBER..............................................................................................................................26 6.7 DWELL TIME..................................................................................................…
