ZRCGEPBT50806ABluetooth Portable Speaker

Parts: Charge: Initial set up via Bluetooth 1. Turn on the Bluetooth™ Speaker by pressing up top control panel. 2. Wait for approximately 20 seconds,the speaker will go into pairing mode and will produce a “beep”tone.The bottom red led lig ht will flash. 3. Turn on a device such as an ipod,iphone or mp3 device and go to:Setting>General>Bluetooth.Click on the bluetooth GP-508 will then appear on the device.Click on the GP-508. The device is now connected and paired with the speaker.If the device prompts f or a pair code,enter:”0000” 4. If pairing is not successful within 150seconds,the system will search for the last paired device.To restart the pairing proc ess,turn off the speaker and repeat step 1.If the initial set up connection is succesful,the next time the speaker is turned on ,the speaker will automatically pair to the last device it was connected with. 5. Touch V+ for 1 second to increase the volume.When maximum volume has been reached, a tone indicator will sound. 6. Touch V- for 1 second to decrease the volume.When minimal volume has been reached ,a tone indicator will sound. 7. Touch for 1 second to listen to the next song. 8. Touch for 1 second to listen to the previsous song. NOTE: 1. The bluetooth speaker only connect s to one device at a time.Turn off the bluetoot h speaker in order to pair the device with another bluetooth device. 2. The maximum transmission betw een the bluetooth speaker and a device is 10 meters or 32 feet. 3. Interference may occur duri ng playback when using the bluet ooth function near other wirel ess devices. If playback through bl uetooth is problematic,move the bluetooth speaker and the playback device to a different location,or use the 3.5mm audio cable jack instead of the bluetooth function. WARNING: The built-in rechargeable battery is not replaceable.Do not remo ve or replace battery.Dispose of unit properly.Do not dispose u nit in trash or fire. BLUE TOOTH SPEAKER MANUAL 1,Previous song 2,Volum+ 3.Volum – 4,Next song 5,Audio line in jack 6,USB charge port Fully charge the speaker before use. Connect the speaker to the PC via provided USB cable. It is powered by internal rechargeable battery and it can using the conve rting cable for charging function by USB port. When the bottom RED LED flash approximately 15 times, it means the battery is low, please recharge the speaker. The solid RED LED will appear when speaker is on charged. The RED LED goes out when charge is finished Connecting with an audio cable The bluetooth connection can be switched to a wired connection by plugging in the 3.5mm audio jack. The volume key function will be disabled in the wired connection mode.Simply unplug the 3.5mm audio jack to revert back to the bluetooth connection. Power on Connect to last device Enter pass code “0000” Play music Fail to Search last device after 20s Under pairing mode Device find GP-508 Enter pass code”0000” Successful to connect Play music No device to pai r Get back search last device after 150s Remate up device Specification Output: ： 3Wx1pcs Signal To Noise Ratio: >80dB Frequency Response: 20Hz-20kHz Distortion: <10% Battery Li-ion: 3.7v Battery Capacity: 500mAh Battery Charging Voltage: 5V Charger Time: 3 hours max Last Time: 5hours (via bluetooth to play) Last Time: 7hours (via audio cable to play) Driver Unit: 40mm, 4 Ohm ,3W Dimension: 90x63mm Power Indicator Light: Blue lights Transmission Distance: 10m Work Frequency: 2.40-2.480GHz Bluetooth Model: V2.1+EDR Transmission distance: 10m Transmission Power: bluetooth class 2 GP-508 bluetooth operation Chart FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

GEP TECHNOLOGY CO.,LIMITED Date (dd/mm/yyyy) 19/7/2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, GEP TECHNOLOGY CO.,LIMITED (address: RM2103 EASEY COMMERCIAL BUILDING 253- 261 HENNESSY ROAD WANCHAI HongKong), hereby authorize Hans.hu (Company name: Global United Technology Services Co., Ltd. Address: 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong ) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 19/7/2013 Sincerely, Company Officer: ERIN ZHONG Telephone Number: 852-81219610 Email: [email protected]

GEP TECHNOLOGY CO.,LIMITED Date (dd/mm/yyyy) 19/7/2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: ZRCGEPBT50806A Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, GEP TECHNOLOGY CO.,LIMITED hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: ERIN ZHONG Telephone Number: 852-81219610 Email: [email protected]

Label size Length=30mm, Width=30mm Product name: bluetooth portable speaker Model No.: GP-508 FCC ID: ZRCGEPBT50806A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.(2) This device must accept any interference received, including interference that may cause undesired operation.

Label location
