OPERATIONAL DESCRIPTION OF U-660 -2 T he equipment under test (EUT) is the transmitter of U-660-2 a Four-band (850/900/1800/1900) GSM/GPRS mobile phone. The transmitter operates in a duplex system according to the GSM standards. The majority of the phone circuitry consists : the RF7170 Power Amplifier and the AD6548 RF Receiver and the MT6516 Baseband Processor. There is also a combination NAND Flash Memory/PSRAM IC. The system is powered by a rechargeable lithium-ion battery with a nominal voltage of 3.7 volts. The receiver consists of two distinct parts, the RF receiver front-end and the IF section. The RF receiver front-end amplifies the GSM850 (869-894MHZ), E-GSM900 (925-960 MHz), DCS1800 (1805-1880 MHz), PCS1900(1930-1990MHZ) aerial signal, converts the chosen channel down to a low IF of 0 kHz, and provides in addition more than 35 dB image suppression. Two LNAs are available on-chip and can be configured to allow 4-band functionality. The switched LNA will be used for roaming in different countries. Some selectivity is provided at this stage by an on-chip low-pass filter, and channel selectivity is provided by means of a high performance integrated band-pass filter. The IF section further amplifies the wanted channel performs gain control to tune the output level to the desired value and rejects DC. This DC rejection is realised with an active high pass circuit and operates either continuously or keeps the acquired offset correction during the burst depending on the programming. The transmitter is fully differential using a direct up conversion architecture. It consists of a single side band power up mixer. Gain is controlled by 4 dB via 3-wire serial bus programming. The fully integrated VCO and the power mixer are designed to achieve LO suppression, quadrature phase error, quadrature amplitude balance and low noise floor specifications. Output balun components are integrated to drive a standard 50 ohms single ended load. The local oscillator (LO) signals required are provided by an on chip VCO for operation of the receive and transmit sections. The VCO is fully integrated and self calibrating to reduce manufacturing tolerances. It consists of 64 differents frequency ranges that are selected internally depending on frequency programming. The frequencies of the RF VCO are set by an internal fractional N synthesiser PLL circuit, which are programmable via a 3-wire serial bus. Comparison frequency is 26 MHz (24 Hz step programmability) derived from the 26 MHz reference signal which is generated from the semi integrated reference oscillator. The quadrature phase RF LO si gnals required for IQ mixers are generated internally. 26 MHz is the reference frequency. It is turned on when the supply voltage VTCXO is applied. After buffering a reference clock of 26 MHz is supplied to the other parts of the system through the pin XBUF. The circuit can be powered-up into four different modes: RX, TX, SYN or REF mode, depending on supply voltages applied, the logical level at pin CTRL and the 3-wire bus serial programming. In RX (TX) mode, all sections required for receive (transmit) are turned on. The SYN mode is used to power-up the synthesiser and the RF-VCO prior to the RX or TX mode. In the SYN mode, some internal LO buffers are also powered-up such that VCO pulling is minimized when switching on the receiver or the transmitter. The reference oscillator (REF mode) is turned on by applying the supply voltage. Additionally band selection is done using the 3-wire bus serial programming allowing the proper enabling of the LNAs. The RF part also includes the blue tooth (blue tooth built-in baseband MT6616) , WIFI chip MT5921, analog television +FM chip ATV168H. D evice features: Bluetooth Features
Fully compliant with Bluetooth 2.1 + EDR (1Mpbs, 2Mbps, and 3Mbps)
On-chip integrated balun
Receiver of -93dBm sensitivity
Hardware AGC dynamically adjusting receiving performance
Fully integrated power amplifier with 7dBm maximum power
Low transmitting out-of-band spurious emissions supporting simultaneous operation with GPS, GSM/GPRS worldwide radio systems
Fractional-N PLL synthesizer supporting crystal frequencies from 12MHz to 52MHz WIFI Features
Host interface : SDIO / eHPI16 / eHPI8
Support Orthogonal Frequency Division Multiplexing (OFDM), Complementary Code Keying (CCK), and Direct Sequence Spread Spectrum(DSSS) to provide a variety of data rates
Support ad-hoc and infrastructure modes
IEEE 802.11g (OFDM 54Mbps) and IEEE 802.11b (DSSS 11Mbps)
Support Bluetooth co-existence
Support low power consumption sleep mode via 32 kHz clock
IEEE 802.11i (AES, TKIP, 802.1X) for advanced security
IEEE 802.11e QoS support for multimedia applications
Wakeup by specific packet (pattern search)
64/128-bit Wired Equivalent Privacy (WEP)
Shared clock, EEPROM, and full RF front ends integrated for WiFi
40MHz crystal embedded
OS support WinCE/Win Mobile (V6.0/V6.1) and Linux The MT5921 support IEEE 802.11b/g standard and it can provide up to 54Mbps for IEEE 802.11g, 11Mbps for 802.11b to connect your wireless LAN. Analog TV+FM Features
Built-in CMOS RF tuner
Supports VHF-I, FM, VHF-III, and UHF bands
Worldwide FM stereo support
Worldwide PAL, NTSC, and SECAM support
Supports all NTSC standards: NTSC-M, NTSC-J, NTSC-4.43
Supports all PAL standards: B, B1, D, D1, G, H, I, K, K1, M, N, Nc
Supports SECAM B, D, G, K, K1
Fully integrated VCOs, PLL loop filter, and crystal oscillator
Dual automatic and programmable AGC for RF and IF gain saves power and reduces host processor overhead
I2C control interface
BT.601/656 8-bit parallel video interface for seamless compatibility with popular baseband processors
I2S audio interface
Analog audio interface
Includes device drivers for all popular processors and operating systems The ATV18H is a PAL/NTSC/SECAM/FM receiver that implements the RF tuner and digital demodulator on the same die. NMI601 receives an input …

Text truncated - open the document above for the full version.

序号 物料型号 物料描述 使用位置 单板数 量 1 EECEP0F333Y 后备电池 焊 盘垂 直型 , 直径 3.8 BB601 1 1 PZ5D4V2H Zener Diode ZD602 1 1 RB521S-30C 肖特基二极管 D603,D604 2 1 RB551V-30(ROHM) 肖特基二极管 D602 1 1 BF1608-L2R4DABT/LF 2.4G 1608 BANDFILTER FL801 1 1 AD6548BCPZ1C ADI Q-band TRISCEIVER RF IC U104 1 1 MT6516A/B MTK Baseband processor U201 1 1 K524G2GACB-A050 4G+2G Flash+DDR(1CS) U301 1 1 ADXL345 LowG Sensor U304 1 1 AW9676QNR 升压式6路共阴共阳背光驱动 U403 1 1 APL3206AQB 充电OVP U501 1 1 SGM4890YG/TR Audio amplifier U502 1 1 MT6326 Power Mamagement IC U602 1 1 BL1608-20B2450 2.4G 1608 BALANCE BANDFILTER U801 1 1 HWS408 TV RF Switch U802 1 1 SST12LP14E-QX8E 2.4G PA 2*2 QFN8 U803 1 1 MT5921A WIFI IC U804 1 1 MT6616 蓝牙IC U805 1 1 RFBPB2012090AM1T61 蓝牙 SAW FILTER for 6612 U806 1 1 7M26000018 3225 26MHz CRYSTAL,CP=10.5-11.5pF,for AD6548 X101 1 2 SSP-T7-F 12.5PF 32.768KHz晶体,SIZE 3215, OSC 12.5pF,±20ppm X201 1 3 TZ1596A 3225 40MHz Crystal，CL=10- 11pF，<15ppm,for MT5921 X801 1 4 TZ1402A 26MHz for 6616,，9.3- 9.7pF,10ppm X802 1 5 RF7176 RFMD的四频PA U101 1 6 SAWEN1G84CV0F00R14 1 IN 4 OUT,1814,50-150欧姆, 1800/1900MHz DIPLEXER SAWIN FOR GSM1800 U102 1 7 SAWEN881MCY0F00R14 1 IN 4 OUT,1814,50-150欧姆, 850/900MHz DIPLEXER SAWIN FOR GSM900 U103 1 8 WR04X000PTL(WALSIN) RES,0R±5%,1/16W,0402 LCR101,LCR801,LCR804,R313,R314,R315,R410,R412,R504,R602,R603,R604,R606,R620,R622,R801,R808,R818,R831,R833,R834,R838,R840 23 9 WR04X471JTL(WALSIN) RES,470R±5%,1/16W,0402 R210 1 10 WR04X102JTL(WALSIN) RES,1K±5%,1/16W,0402 R110,R501,R505,R508,R509,R510 , R516 , R517 , R617 , R624 10 11 WR04X152JTL(WALSIN) RES,1.5K±5%,1/16W,0402 R502,R506,R518 3 12 WR04X222JTL(WALSIN) RES,2.2K±5%,1/16W,0402 R105,R106,R107,R108 4 13 WR04X472JTL(WALSIN) RES,4.7K±5%,1/16W,0402 R309,R310,R615,R616 4 14 WR04X103JTL RES,10K±5%,1/16W,0402 R101,R211,R402,R403,R513 5 15 WR04X104JTL(WALSIN) RES,100K±5%,1/16W,0402 R206,R207,R208,R209,R212,R213,R214,R215,R216,R507,R520,R803,R804,R805,R806,R809,R810,R811,R812,R813,R814,R815,R842 23 16 WR04X105JTL(WALSIN) RES,1M±5%,1/16W,0402 R202,R204 2 17 WR04X221JTL(WALSIN) RES,220R±5%,1/16W,0402 R514,R515 2 18 WR04X510JTL(WALSIN) RES,51R±5%,1/16W,0402 R109,R816 2 19 WR04X100JTL（WALSIN) RES,10R±5%,1/16W,0402 R614,R807 2 20 WR06X100JTL(WALSIN) RES,10R±5%,1/10W,0603 R401 1 21 WR04X153JTL(WALSIN) RES,15K±5%,1/16W,0402 R846 1 22 WR04X203JTL(WALSIN) RES,20K±5%,1/16W,0402 R102,R512 2 23 WR04X512JTL(WALSIN) RES,5.1K±5%,1/16W,0402 R205 1 24 WR04X473JTL(WALSIN) RES,47K±5%,1/16W,0402 R301,R404,R405,R406,R407,R408,R409 7 25 WR04X360JTL(WALSIN) RES,36R±5%,1/16W,0402 R103 1 26 WR04X682JTL(WALSIN) RES,6.8K±5%,1/16W,0402 R415 1 27 WR04X270JTL(WALSIN) RES,27R±5%,1/16W,0402 R104 1 28 B72590T8140S160(EPCOS) VAR,18VDC,10pF,0402 V401,V402,V403,V404,V405,V406,V501,V502,V503,V504,V505,V506,V507,V508,V509,V510,V511,V512,V513,V601,V901,V902,V903,V904,V905,V906,V907,V908,V909,V910,V911,V912,V913,V914,V915,V916,V917,V918,V919,V920,V921,V922,V923,V924,V925,V926 , V927 47 29 GRM1555C1H120JZ01D(MURATA) CAP,12pF±5%,50V,0402 C801,C805 2 30 GRM1555C1H220JZ01D(MURATA) CAP,22pF±5%,50V,0402 C102,C105,C106,C107,C109,C227,C228,C813 8 31 GRM1555C1H330JZ01D(MURATA) CAP,33pF±5%,50V,0402 C502,C503,C505,C506,C521,C523,C527,C529,C530,C531,C606 , C652 , C902 13 32 GRM1555C1H470JZ01D(MURATA) CAP,47pF±5%,50V,0402 C104,C112,C125 3 33 GRM1555C1H560JZ01D(MURATA) CAP,56pF±5%,50V,0402 C829 1 34 GRM1555C1H820JZ01D(MURATA) CAP,82pF±5%,50V,0402 C119,C121 2 35 GRM155R71H102KA01D(MURATA) CAP,1nF±10%,50V,0402 C123,C135,C624,C625 4 36 GRM155R71C103KA01D(MURATA) CAP,10nF±10%,16V,0402 C103 1 37 GRM155R71A104KA01D(MURATA) CAP,100nF±10%,10V,0402 C113,C114,C118,C128,C132,C134,C202,C204,C206,C208,C210,C211,C213,C215,C219,C220,C222,C223,C224,C226,C302,C303,C305,C405,C407,C409,C510,C511,C519,C524,C525,C605,C615,C621,C650,C802,C803,C808,C809,C810,C822,C823,C824,C834,C835,C847,C848,C850,C901 49 38 GRM155R71C224KA88D(MURATA)//C1005X5R1A224KT(TDK)//CM05X5R224K16AH(AVX)//CL05A224KP5NNNC(SAMSUNG)//0402X224K100CT(WALSIN)//CC0402KRX5R6BB224(YAGEO) CAP,220nF±10%,10V,0402 C133 1 39 GRM155R60J105KE19D(MURATA) CAP,1uF±10%,6.3V,0402 C203,C205,C221,C225,C229,C401,C403,C414,C417,C508,C522,C602,C608,C616,C617,C630,C634,C636,C637,C638,C639,C641,C644,C648,C649,C807,C831,C832,C833,C846 , C849 31 40 GRM1555C1H390JZ01D(MURATA) CAP,39pF±5%,50V,0402 C129,C131 2 41 GRM1555C1H150JZ01D(MURATA) CAP,15pF±5%,50V,0402 C812,C814,C815,C818 4 42 GRM1555C1H101JZ01D(MURATA) CAP,100pF±5%,50V,0402 C501,C514,C515,C526,C819 5 43 GRM1555C1H1R0CZ01D(MURATA) CAP,1pF±0.25pF,50V,0402 C820 1 44 GRM1555C1H8R2DZ01D(MURATA) CAP,8.2pF±0.5pF,50V,0402 C816,C817 2 45 GRM188R60J475KE19D(MURATA) CAP,4.7uF±10%,6.3V,0603 C411 1 46 GRM155R71H221KA01D(MURATA) CAP,220pF±10%,50V,0402 C108 1 47 GRM1555C1HR50CZ01D(MURATA) CAP,0.5pF±0.25pF,50V,0402 C110,C111 2 48 GRM1555C1H1R2CZ01D(MURATA) CAP,1.2pF±0.25pF,50V,0402 C825 1 49 LQG15HS12NJ02D(MURATA） IND,12nH±5%,250mA,0402 L804 1 50 LQG15HS27NJ02D(MURATA） IND,27nH±5%,200mA,0402 L805 1 51 LQG15HS1N0S02D(MURATA） IND,1nH±0.3nH,300mA,0402 L802 1 52 LQG15HS82NJ02D(MURATA） IND,82nH±5%,100mA,0402 L811 1 53 LQG15HSR10J02D(MURATA） IND,100nH±5%,100mA,0402 B511 1 54 LQG15HS4N7S02D(MURATA） IND,4.7nH±0.3nH,300mA,0402 L801,L803 2 55 LQG15HS18NJ02D(MURATA） IND,18nH±5%,200mA,0402 L112 1 56 LQG15HS3N9S02D(MURATA） IND,3.9nH±0.3nH,300mA,0402 L101 1 57 BLM15BB750SN1D(MURATA） Bead,75R/68R,100MHz,0402 B101,B102,B201,B202,B203,B204,B205,B401,B501,B502,B503,B504,B505,B506,B509,B510,B512,B604,B605 19 58 BLM18PG221SN1D Bead,220R,100MHz,0603,DCR=0.15 R , 1000mA B601,B602 2 59 F930J107MAA TAN,100uF±20%,6.3V,1206 C623 1 60 GRM219R60J106MA01L(MURATA) CAP,10uF±10%,6.3V,0805,H0.85m m C101 1 61 JMK107BJ225KV-T（TaiyoYuden） CAP,2.2uF±10%,6.3V,0603 C301,C306,C404,C416,C418,C520,C614,C618,C622,C804,C836,C903 12 62 EMK107BJ105KG-T(TaiyoYuden) CAP,1uF±10%,16V,0603 C509 1 63 GRM155R71C333KA01D(MURATA) CAP,33nF±10%,16V,0402 C115 1 64 GRM188R60J475KE19D(MURATA) CAP,4.7uF±10%,6.3V,0603 C201,C207,C209,C212,C214,C216,C217,C218,C406,C408,C410,C419,C507,C512,C513,C516,C517,C601,C603,C604,C607,C613,C6…

Text truncated - open the document above for the full version.
