ZUE16000Chorus

we-vibe.com/chorus-how-to Chorus has two adjustment points Avoid twisting/ bending of silicone and unnatural movements Do not bend or contort remote We-Connect TM Bluetooth ® Ankorlink™ Apple, the Apple logo and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Android and Google Play are trademarks of Google Inc. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is done under license by WOW Tech Canada Ltd. Make sure remote is connected and in range 2h External/clitoral stimulator Control button Charging pins Internal/G-spot stimulator 2s chorus Hold the control button for 5 seconds to pair your Chorus to your phone through the remote Function button/Lock button Toggle between manual remote and squeeze remote Next mode Increase vibration/ Hold for maximum Decrease vibration/ Hold turns off Chorus Previous mode Press down on the function button to enter Squeeze Control Chorus comes paired to the remote. If you need to re-pair, follow the illustrated steps below Press down on the control button on your Chorus to connect to the remote Press down the function button on the remote to connect to your Chorus 5s 10s SQUEEZE CONTROL Decrease base level Increase base level Press the function button to lock your prefered vibration level or to turn off squeeze control Squeeze area MA-00056_ rev B direttiva 2011/65/CE (RoHS). Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Web: we-vibe.com/legal WAARSCHUWING Verkocht als novelty voor volwassenen. Niet voor medisch gebruik. Buiten bereik van kinderen houden. Dit apparaat is niet bedoeld voor gebruik door kinderen of personen met verminderde lichamelijke, zintuiglijke of geestelijke vermogens. Gebruik de oplader niet in de buurt van water ter voorkoming van elektrische schokken. Niet op gezwollen of ontstoken gedeelten van de huid gebruiken. Gebruik niet op of rondom de nek. Stop met het gebruik als het ongemakkelijk aanvoelt. Jouw origineel We-Vibe ® -product wordt geleverd met een garantie van twee jaar. Hierbij verklaart WOW Tech ™ Canada Ltd. dat het type radioapparatuur [Niet-specifieke korteafstandsapparatuur] voldoet aan de Richtlijn 2014/53/EG. WOW Tech ™ Canada Ltd. verklaart dat het product ook voldoet aan Richtlijn 2011/65/EG (BGS). De volledige tekst van de EU- conformiteitsverklaring is beschikbaar via het volgende internetadres: we-vibe.com/legal VARNING Säljs som leksaksliknande erotisk produkt Ej avsedd för medicinsk användning. Förvaras utom räckhåll för barn. Enheten är inte avsedd för barn eller personer med fysiska, sensoriska eller mentala handikapp. På grund av risken för elektriska stötar ska laddaren inte användas i närheten av vatten. Använd inte enheten på svullen eller inflammerad hud. Använd inte enheten i området runt halsen. Avbryt användningen om den känns obekväm eller olustig. Din äkta We-Vibe ® -produkt har två års garanti. Härmed förklarar WOW Tech ™ Canada Ltd. att radioutrustningen av typen [Non-Specific Short Range Device] är förenlig med Direktivet2014/53/EU. WOW Tech ™ Canada Ltd. förklarar att produkten också är förenlig med Direktivet 2011/65/EC (RoHS). Den fullständiga texten till EU- WARNING Sold as adult novelty. Not for medical use. Keep out of reach of children. This appliance is not intended for use by children or persons with reduced physical, sensory or mental capabilities. To avoid electric shock, do not use charger near water. Do not use on swollen or inflamed areas of skin. Do not use on neck area. Discontinue use if discomfort occurs. Your authentic We-Vibe ® product comes with a two-year warranty. Hereby, WOW Tech ™ Canada Ltd. declares that the radio equipment type [Non-Specific Short Range Device] is in compliance with Directive 2014/53/EU. WOW Tech ™ Canada Ltd. declares that the product is also compliant with Directive 2011/65/ EC (RoHS). The full text of the EU declaration of conformity is available at the following internet address: we-vibe.com/legal AVERTISSEMENT Vendu en tant que gadget pour adultes. Non recommandé pour usage médical. Tenir hors de la portée des enfants. Cet appareil n’est pas destiné à être utilisé par des enfants ou des personnes ayant des capacités physiques, sensorielles ou mentales réduites. Pour éviter tout choc électrique, n’utilisez pas le chargeur à proximité d’une source d’eau. Ne pas l’utiliser sur des zones enflées ou enflammées de la peau. Ne l’utilisez pas dans la région du cou. Cesser l’utilisation en cas d’inconfort. AVotre We-Vibe ® authentique est garanti deux années. WOW Tech ™ Canada Ltd. déclare par les présentes que le type d’équipement radio [Appareil à courte portée non spécifique] est conforme à la Directive 2014/53/EU. WOW Tech ™ Canada Ltd. déclare que le produit est également conforme à la Directive 2011/65/EC (RoHS). Le texte intégral de la déclaration UE de conformité est disponible à l’adresse internet suivante : we-vibe.com/legal ACHTUNG Wird als Vergnügungsartikel für Erwachsene verkauft. Nicht für den medizinischen Gebrauch. Außer Reichweite von Kindern aufbewahren. Dieses Produkt ist nicht zur Verwendung durch Kinder oder Personen mit eingeschränkten körperlichen, sensorischen oder geistigen Fähigkeiten bestimmt. Um einen Stromschlag zu vermeiden, nutze das Ladegerät nicht in der Nähe von Wasser. Nicht auf geschwollenen bzw. entzündeten Hautpartien anwenden. Nicht im Bereich des Halses anwenden. Unterbreche die Anwendung, falls Beschwerden auftreten. Dein authentisches Produkt von We-Vibe ® steht zwei Jahre unter Garantie. WOW Tech ™ Canada Ltd. erklärt hiermit, dass der Funkgerätetyp für die Kurzstrecken- Kommunikation [Non-Specific Short Range Device] die Anforderungen der Richtlinie 2014/53/EU erfüllt. WOW Tech ™ Canada Ltd. erklärt, dass das Produkt außerdem die Anforderungen der Richtlinie 2011/65/EG (RoHS) erfüllt. Der vollständige Text der EU-Konformität…

Text truncated - open the document above for the full version.

(WOW Tech Canada Ltd. ) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZUE16000 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Eyal Bar-Or) Rev 11/20/07

(WOW Tech Canada Ltd.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: ZUE16000 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Eyal Bar-Or)

External Photos

Label & label location Model: 16000-01 FCC ID: ZUE16000 IC: 9804A-16000

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E FCC Part 15C Test Report FCC ID: ZUE16000 Product Name: Chorus Trademark: N/A Model Name : 16000-01 Prepared For : WOW Tech Canada Ltd. Address : 330-1130 Morrison Drive, OTTAWA, Canada, K2H 9N6 Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao'an District, Shenzhen, China Test Date: Nov. 08, 2019 – Nov. 15, 2019 Date of Report : Nov. 15, 2019 Report No.: BCTC-FY191006438E Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 1 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E TEST RESULT CERTIFICATION Applicant’s name ................. : WOW Tech Canada Ltd. Address ................................. : 330-1130 Morrison Drive, OTTAWA, Canada, K2H 9N6 Manufacture's Name ............ : WOW Tech Canada Ltd. Address ................................. : 330-1130 Morrison Drive, OTTAWA, Canada, K2H 9N6 Product description Product name ........................... : Chorus Model and/or type reference : 16000-01 Serial Model .............................. : N/A Te s t Standards ....................... : FCC Part15.249 ANSI C63.10-2 013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Willem Wang Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 2 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 DEVIATION FROM TEST STANDARD 17 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 21 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 25 4.1 DEVIATION FROM STANDARD 25 4.2 TEST SETUP 25 4.3 EUT OPERATION CONDITIONS 25 4.4 TEST RESULTS 25 5 . BANDWIDTH TEST 30 5.1 APPLIED PROCEDURES / LIMIT 30 5.1.1 TEST PROCEDURE 30 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 3 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 30 5.1.3 TEST SETUP 30 5.1.4 EUT OPERATION CONDITIONS 30 5.1.5 TEST RESULTS 31 6 . ANTENNA REQUIREMENT 33 6.1 STANDARD REQUIREMENT 33 6.2 EUT ANTENNA 33 7 . EUT TEST PHOTO 34 8 . PHOTO OF THE EUT 36 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 4 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.249 (a)(2) 20dB Bandwidth PASS 15.249 Fundamental &Radiated Spurious Emission Measurement PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 5 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add. : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.38dB 5 Conducted output power uncertainty Above 1G U=1.576dB 6 Conducted output power uncertainty below 1G U=1.28dB 7 humidity uncertainty U=5.3% 8 Temperature uncertainty U=0.59°C Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 6 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Chorus Trade Name N/A Model Name 16000-01 Serial Model N/A Model Difference N/A Product Description The EUT is a Chorus Operation Frequency: 917.1-917.7MHz Modulation Type: GFSK Number Of Channel 4CH Antenna Designation: Please see Note 3. Antenna Gain (dBi) 0dBi Channel List Please refer to the Note 2. Power DC 3.7V from Battery Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List for 917.1-917.7MHz Channel Frequency (MHz…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E 7. EUT TEST PHOTO Radiated Measurement Photos Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 34 of 38 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY191006438E Conducted Measurement Photos Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 35 of 38
