PID # 121390-109327 Rev. 120907 2.4 GHz Wireless Keyboard Model #: KB8706 User’s Manual 2 All brand name and trademarks are the property of their respective owners USER’S RECORD: To provide quality customer service and technical support, it is suggested that you keep the following information as well as your store receipt and this user’s manual. Date of Purchase: ________________________________ Model Number: ________________________________ Product Rev Number (located below the UPC on the package): ____________________ PACKAGE CONTENTS: Your new wireless keyboard will ship with the following items. - 2.4GHz Wireless Keyboard - Nano USB Receiver - User’s Manual & Warranty Information - 2AAA Batteries For the Keyboard SYSTEM REQUIREMENTS: Please be sure that you meet all of the system requirements below to avoid difficulties during installation. - PCs & Mac ® Compatibles - Windows ® XP, Vista, 7 and 8 - Mac ® OS 10.3 and Above - An Available USB Port SYSTEM SPECIFICATIONS: Your new wireless keyboard complies with the following specifications. - USB Interface - 2.4 GHz Wireless Technology INSTALLING THE BATTERIES: 1. Release the latch at the bottom of your keyboard and remove the Battery Compartment Cover from your keyboard. 2. Install two AAA batteries into your keyboard following the battery orientation guide in the battery bay. 3. Replace the Battery Compartment Cover back onto your keyboard until it securely locks. The LED indicator on your keyboard will light up for 2 seconds after the batteries are installed successfully. (Note: The LED indicator on the keyboard will blink when the battery is low.) 3 CONNECTING TO A COMPUTER: 1. Turn on your computer. 2. Make sure batteries for your keyboard have been properly installed, refer to the Installing the batteries section in this manual if necessary. Power on your keyboard, a red LED indicator in the right of the keyboard will light on, and then ESC+Q will search to link. 3. Insert the enclosed receiver into an available USB port on your computer. 4. Your computer will detect and install the necessary drivers automatically Switch 5. Your wireless keyboard is now ready to be used. 4 KEYBOARD SPECIAL FUNCTION KEYS: E-mail Open Default Mail Software. Home Open Internet Explorer’s default home page. Favorite Open “My Favorite”. Play/Pause Play/pause currently playing multimedia file Volume up Turn volume up. Volume down Turn volume down. Mute Mute volume. Back Turn the page back Forward Turn the page forward Stop Stop the page 5 FCC WARNNING: 6

Shenzhen Kingree Electronic Co.,Ltd PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 13.09.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Jack Kang Position EMC Manager Company Name Shenzhen TCT Testing Technology Co.,Ltd Address 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China Tel / Fax +86-0755-27363466 E-Mail +86-0755-27673332 to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Wireless Keyboard Model Name KB8706 Brand Name N/A We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Huang Tian Liang Position Manager Company Name Shenzhen Kingree Electronic Co., Ltd Address 3-6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Tel / Fax 0755-29570180/0755-29570160 E-Mail [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Shenzhen Kingree Electronic Co., Ltd Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Shenzhen Kingree Electronic Co., Ltd FCC ID: ZX3KB8706 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☐ Bill Of Materials Parts list of the product for the radio device ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Huang Tian Liang Position Manager Company Name Shenzhen Kingree Electronic Co., Ltd Address 3-6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Tel / Fax 0755-29570180/0755-29570160 E-Mail [email protected]

Wireless Keyboard FCC ID: ZX3KB8706 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation FCC LABEL SIZE=60*35MM FCC ID Label Location

Shenzhen TCT Testing Technology Co., Ltd. FCC ID TEST REPORT for Wireless Keyboard Model: KB8706 FCC ID: ZX3 KB8706 Prepared for : Shenzhen Kingree Electronic Co.,Ltd 3-6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Prepared by: Shenzhen TCT Testing Technology Co.,Ltd 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China TEL: +86-0755-27363466 FAX: +86-0755-27673332 Report Number：TCS1209004-1 Date of Test： September 10~14, 2012 Date of Report： September 14, 2012 Note: This report is considered invalidated without the Special Seal for Inspection of the TCT. This report shall not be altered, increased or deleted. The results shown in this test report does not apply to the bulk, but the sample(s) tested only. Without written approval of TCT, this test report shall not be copied except in full and published as advertisement. Shenzhen TCT Testing Technology Co., Ltd. FCC ID: ZX3KB8706 Report Number: TCS1209004-1 Special Statement： The testing quality ability of our la boratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our la boratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC i s maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report f iled with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-01. Shenzhen TCT Testing Technology Co., Ltd. FCC ID: ZX3KB8706 Report Number: TCS1209004-1 Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 6 3.1 Summary of Test Results..................................................................................... 6 3.2 Test Standards.................................................................................................. 6 4.0 EUT Modification............................................................................................. 6 5.0 Power Line Conducted Emission Test...................................................................... 7 5.1 Schematics of the Test........................................................................................ 7 5.2 Test Method and Test Procedure............................................................................ 7 5.3 EUT Operating Condition....................................................................................7 5.4 Test Equipment............................................................................................. 7 5.5 Conducted Emission Limit................................................................................... 8 5.6 Photo documentation of the test set-up ................................................................ 8 5.7 Test specification.............................................................................................. 8 5.8 Test result...................................................................................................... 8 6.0 Radiated Emission test...................................................................................... 11 6.1 Test Method and Test Procedure............................................................................ 11 6.2 EUT Operating Condition....................................................................................12 6.3 Radiated Emission Limit.................................................................................... 13 6.4 Photo documentation of the test set-up.................................................................... 13 6.5 Test Equipment................................................................................................ 13 6.6 Test specification.............................................................................................. 13 6.7 Test result..................................................................................................... 14 7.0 Band Edge..................................................................................................... 22 8.0 Antenna Requirement............................................................................ 27 9.0 20dB Bandwidth Measurement...…
