ZX3WS5406Wireless Mouse

Functions 1. 2.4G Hz Free moving in 6-10 meters 2.Receiver storage space and carrying easily 3.Resolution frequency (800cpi–1 ,200cpi–1,600cpi) conversion through CPI button. Specification 1. Wireless carrier frequency: 2,403MHz-2,479MHz 2.39 wireless working channels, automatic frequency jumping 3. Rated working current: 25mA 4. Maximum acceleration: 14 inches per second 5. Resolution: 800CPI-1200-1600CPI Mouse install way as below: First. Take the mouse（as picture one）out。 Second.Open the mouse battery cover，pu t 2×AAA battery，close the battery cover。 1.Use big pollex press and move the battery cover back as picture one and two 2.Inside the battery as picture 3,the polarity as the battery box noted。 Picture 1 picture 2 3. Close the battery as picture4 Picture 3 Picture 4 Third. C onnect computer with receiver。 1. The computer will be freely after insert the rec eiver to computer and the operation system is WINDOWS2000 or above。 Fourth、 Connect mouse to receiver。 1.Connect Nano receiver to Computers. 2.not need to connect again when replace battery。 Fifth、press mouse DPI key will be switch 800CPI-1200CPI- 1600CPI。 FCC WARNNING This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation

Shenzhen Kingree Electronic Co.,Ltd PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 13.09.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Jack Kang Position EMC Manager Company Name Shenzhen TCT Testing Technology Co.,Ltd Address 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China Tel / Fax +86-0755-27363466 /+86-0755-27673332 E-Mail [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Wireless mouse Model Name WS5406 Brand Name N/A We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Huang Tian Liang Position Manager Company Name Shenzhen Kingree Electronic Co., Ltd Address 3-6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Tel / Fax 0755-29570180/0755-29570160 E-Mail [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Shenzhen Kingree Electronic Co., Ltd Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Shenzhen Kingree Electronic Co., Ltd FCC ID: ZX3WS5406 FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☐ Bill Of Materials Parts list of the product for the radio device ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Huang Tian Liang Position Manager Company Name Shenzhen Kingree Electronic Co., Ltd Address 3-6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Tel / Fax 0755-29570180/0755-29570160 E-Mail [email protected]

FCC LABEL SIZE=20*15MM Wireless mouse Model number: WS5406 FCC ID: ZX3WS5406 Made in China FCC ID Label Location

Shenzhen TCT Testing Technology Co., Ltd. FCC ID TEST REPORT for Wireless Mouse Model: WS5406 FCC ID: ZX3WS5406 Prepared for : Shenzhen Kingree Electronic Co.,Ltd 3‐6F, 70 Building,Bohua Tech Park, Shangwei Industrial Area, Zhangkeng jing,Guanlan Street,Shenzhen,China. Prepared by: Shenzhen TCT Testing Technology Co.,Ltd 1F, Building 1, Yibaolai Industrial Park, Qiaotou Village, Fuyong Town, Baoan District, Shenzhen, Guangdong, China TEL: +86-0755-27363466 FAX: +86-0755-27673332 Report Number：TCS1209003-1 Date of Test： September 10~14, 2012 Date of Report： September 14, 2012 Note: This report is considered invalidated without the Special Seal for Inspection of the TCT. This report shall not be altered, increased or deleted. The results shown in this test report does not apply to the bulk, but the sample(s) tested only. Without written approval of TCT, this test report shall not be copied except in full and published as advertisement. Shenzhen TCT Testing Technology Co., Ltd. FCC ID: ZX3WS5406 Report Number: TCS1209003-1 Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 899988. IC- Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration IC No.: 5205A-01. Shenzhen TCT Testing Technology Co., Ltd. FCC ID: ZX3WS5406 Report Number: TCS1209003-1 Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 5 3.0 Technical Details............................................................................................. 6 3.1 Summary of Test Results..................................................................................... 6 3.2 Test Standards.................................................................................................. 6 4.0 EUT Modification............................................................................................. 6 5.0 Power Line Conducted Emission Test...................................................................... 7 5.1 Schematics of the Test........................................................................................ 7 5.2 Test Method and Test Procedure............................................................................ 7 5.3 EUT Operating Condition....................................................................................7 5.4 Test Equipment............................................................................................. 7 5.5 Conducted Emission Limit................................................................................... 8 5.6 Photo documentation of the test set-up ................................................................ 8 5.7 Test specification.............................................................................................. 8 5.8 Test result...................................................................................................... 8 6.0 Radiated Emission test...................................................................................... 11 6.1 Test Method and Test Procedure............................................................................ 11 6.2 EUT Operating Condition....................................................................................13 6.3 Radiated Emission Limit.................................................................................... 14 6.4 Photo documentation of the test set-up.................................................................... 14 6.5 Test Equipment................................................................................................ 14 6.6 Test specification.............................................................................................. 14 7.0 Band Edge..................................................................................................... 27 8.0 Antenna Requirement............................................................................ 32 9.0 20dB Bandwidth Measurement...................................................................... 33 10.0 FCC ID label........................................…
