2A22V-MWS013-in-1 Wireless Charging Station

Mod Inp u Wire Wire Wire Wire LE D •1, to p •1 •2 pro p •1 R disa •2 R is d del: MIC-MW ut: DC 9V 2 eless Charg eless Charg eless Charg eless Charg D Status Ind 2 Red Stead power corre Blue Stead y Blue Steady perly. Red Flashing abled. Red Flashing isabled. WS01 2A ger Output# ger Output# ger Output# ger Output T dicator: dy Light,4 d ctly. The w y Light: Pho y Light: Ear g Light : Fo g Light : Fo #1(Phone): #2(Airpods) #3(Apple Wa Total:18W decoration g ireless char one is place rphone is pl oreign objec oreign objec 5W,7.5W,1 : 5W atch): 2W green light o rger is ready ed on the w aced on the ct detected ct detected 0W on: The cha y to charge wireless char e wireless c on phone c on earphon arging statio . rger and ch harger and charger area ne charger a on is conne harging prop charging a. Charging area. Charg ected perly. is ing •3 Touch switch on/off for decoration light •4 Decoration light FOD for mobilephone charging area 1 Red LED flashing This device complies with part 18 of the FCC Rules. Operation is subject to t he following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference recei ved, including interference that may cause undesired operation. ICID

Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) Agent Authorization Company: Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) Address: 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Product Name: 3-in-1 Wireless Charging Station Model Number(s): MIC-MWS01 Product Description: 3-in-1 Wireless Charging Station We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jul. 11, 2022 Name: Winnie He Title: Sales Company: Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch)

Letter of Declaration Company: Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) Address: 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Product Name: 3-in-1 Wireless Charging Station Model Number(s): MIC-MWS01 FCC Identifier: 2A22V-MWS01 Compliant with KDB680106 D01 RF Exposure Wireless Charging Apps v03r01 section 5,b： (1) Power transfer frequency is less than 1MHz. -The device operate in the frequency range 111.5KHz~205KHz. (2) Output power from each primary coil is less than or equal to 15 watts. -The maximum output power of the primary coil is 10W (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. - The transmission system consists of a charging system with three main coils, all of which can be powered on at the same time (4) Client device is placed directly in contact with the transmitter. -The EUT is placed directly in contact with the transmitter (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). - Yes, mobile device only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. - The EUT meet the conditions. Name: Winnie He Date: Jul. 11, 2022 Title: Sales Signature of applicant:

< Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Jul. 11, 2022 Subject; Request for Long Term Confidentiality FCC ID: 2A22V-MWS01 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Name: Winnie He Date: Jul. 11, 2022 Title: Sales Signature of applicant:

Annex A External Photos Model No.: MIC‐MWS01 Page 1 of 4 Model No.: MIC‐MWS01 Page 2 of 4 Model No.: MIC‐MWS01 Page 3 of 4 Model No.: MIC‐MWS01 Page 4 of 4

FCC ID LABEL: Ca. 5mm x 10mm Label Location FCC ID: 2A22V-MWS01

Annex B Internal Photos Model No.: MIC‐MWS01 Page 1 of 4 Antenna Model No.: MIC‐MWS01 Page 2 of 4 Model No.: MIC‐MWS01 Page 3 of 4 Model No.: MIC‐MWS01 Page 4 of 4

Page 1 of 10 Report No.: HK2203221084-2E FCC TEST REPORT Test report On Behalf of Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) For 3-in-1 Wireless Charging Station Model No.: MIC-MWS01 FCC ID: 2A22V-MWS01 Prepared For : Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: May. 23, 2022 ~ May. 30, 2022 Date of Report: May. 30, 2022 Report Number: HK2203221084-2E Page 2 of 10 Report No.: HK2203221084-2E Note: 1. For a more detailed features description, please refer to the manufactu rer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 122 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1. Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03r01 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03r01 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2. Measurement Uncertainty The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 All emissions, radiated(<30M)(9KHz-30MHz) ±3.90dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 10 Report No.: HK2203221084-2E 2.3. Test Mode EUT Mode Description ANT 1 Cell load setting 10W Cell load setting 7.5W Cell load setting 5W ANT 2 Cell Airpods setting 5W ANT 3 Cell Watch setting 2W ANT 1+ANT 2 Cell load setting 10W + Cell Airpods setting 5W ANT 1+ANT 3 Cell load setting 10W + Cell Watch setting 2W ANT 2+ANT 3 Cell Airpods setting 5W + Cell Watch setting 2W ANT1+ANT2+ANT3 Cell load setting 10W + Cell Airpods setting 5W + Cell Watch setting 2W 2.4. Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Exposure Level Te s t e r narda ELT-400 N-0231 Feb. 18, 2022 Feb. 17, 2023 Magnetic field probe 100cm 2 narda ELT probe 100cm2 M0675 Feb. 18, 2022 Feb. 17, 2023 NOTE: 1. The calibration interval of the above test instruments is 12 months. Page 4 of 10 Report No.: HK2203221084-2E 3. MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density. Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03. Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 10 Report No.: HK2203221084-2E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 Test Setup 4.2 Result Of Maximum Permissible Exposure Page 6 of 10 Report No.: HK2203221084-2E All test modes are tested, and the report shows only the worst mode: ANT1+ANT2+ANT3 H-Field Strength at 15 cm (E top side: 20cm) from the edges surrounding the EUT (A/m) Field strength Test Position A Test Position B Test Position C Test Position D Test Position E Limits (A/m) uT 0.099 0.123 0.168 0.198 0.205 / A/m 0.079 0.098 0.134 0.158 0.164 1.63 Note. Calculation: A/m=uT/1.25 For Half Load mode: H-Field Strength at 15 cm (E top side: 20cm) from the edges surrounding the EUT (A/m) Field strength Test Position A Test Position B Test Position C Test Position D Test Position E Limits (A/m) uT 0.104 0.122 0.157 0.166 0.302 / A/m 0.083 0.098 0.126 0.133 0.242 1.63 Note. Calculation: A/m=uT/1.25 For No load mode: H-Field Strength at 15 cm (E top side: 20cm) from the edges surrounding the EUT (A/m) Field strength Test Position A Test Position B Test Position C Test Position D Test Position E Limits (A/m) uT 0.118 0.123 0.257 0.271 0.324 / A/m 0.094 0.098 0.206 0.217 0.259 1.63 Note. Calculation: A/m=uT/1.25 Page 7 of 10 Report No.: HK2203221084-2E Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03r01, section 5, b). The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. The E- field evaluation conducted assuming a user separation distance of 15 cm according to the KDB 680106 D01 RF Exposure Wireless Charging App v03 section 3, c). Result: The device comply with the RF exposure requi…

Text truncated - open the document above for the full version.

Page 1 of 21 Report No.: HK2203221084-1E FCC TEST REPORT Test report On Behalf of Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) For 3-in-1 Wireless Charging Station Model No.: MIC-MWS01 FCC ID: 2A22V-MWS01 Prepared For : Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: May. 23, 2022 ~ May. 30, 2022 Date of Report: May. 30, 2022 Report Number: HK2203221084-1E Page 2 of 21 Report No.: HK2203221084-1E TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) Address.................................. : 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Manufacture's Name ............ : Shenzhen DXR Electronic Technology Co., Limited (Dongguan Branch) Address.................................. : 4th Floor, #5 Building, #189, Yongji Industrial, Zhuweitian, Fenggang Town, Dongguan, China Product description Trade Mark: MERKURY Product name ............................ : 3-in-1 Wireless Charging Station Model and/or type reference : MIC-MWS01 Standards ............................. : FCC CFR 47 PART 18 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : May. 23, 2022 ~ May. 30, 2022 Date of Issue ........................................... : May. 30, 2022 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 21 Report No.: HK2203221084-1E Table of Contents Page 1 . TEST SUMMARY 5 1.1 . Test Procedures And Results 5 1.2 . Information of the Test Laboratory 5 1.3 . Measurement Uncertainty 5 2. GENERAL INFORMATION 6 2.1. General Description of EUT 6 2.2. Carrier Frequency of Channels 7 2.3. Operation of EUT during testing 7 2.4. Test Mode 7 2.5. Description of Test Setup 8 2.6. Measurement Instruments List 9 3. CONDUCTED EMISSION TEST 10 3.1. Block Diagram of Test Setup 10 3.2. Conducted Power Line Emission Limit 10 3.3. Test Procedure 10 4. RADIATED EMISSIONS 13 4.1. Block Diagram of Test Setup 13 4.2. Rules and specifications 13 4.3. Test Procedure 14 4.4. Test Result 14 5. ANTENNA REQUIREMENT 18 6. PHOTOGRAPH OF TEST 19 7. PHOTOS OF THE EUT 21 Page 4 of 21 Report No.: HK2203221084-1E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release May. 30, 2022 Jason Zhou Page 5 of 21 Report No.: HK2203221084-1E 1. TEST SUMMARY 1.1. Test Procedures And Results DESCRIPTION OF TEST SECTION NUMBERRESULT CONDUCTED EMISSIONS TEST 18.307 COMPLIANT RADIATED EMISSION TEST 18.305 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. Information of the Test Laboratory Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 21 Report No.: HK2203221084-1E 2. GENERAL INFORMATION 2.1. General Description of EUT Equipment: 3-in-1 Wireless Charging Station Model Name: MIC-MWS01 Series Models: N/A Model Difference: N/A Trade Mark: MERKURY FCC ID: 2A22V-MWS01 Antenna Type: Coil Antenna Antenna Gain: 0dBi Operation frequency: 111.5KHz~205KHz Test frequency: 122KHz Number of Channels: 1 Modulation Type: ASK Power Source: Input: DC 9V 2A Wireless Charger Output #1 (Phone): 5W, 7.5W, 10W Wireless Charger Output #2 (Airpods): 5W Wireless Charger Output #3 (Apple Watch): 2W Wireless Charger Output Total: 18W Power Rating: Input: DC 9V 2A Wireless Charger Output #1 (Phone): 5W, 7.5W, 10W Wireless Charger Output #2 (Airpods): 5W Wireless Charger Output #3 (Apple Watch): 2W Wireless Charger Output Total: 18W Page 7 of 21 Report No.: HK2203221084-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency 1 122KHz 2.3. Operation of EUT during testing Operating Mode The mode is used: Transmitting mode 2.4. Test Mode EUT Mode Description ANT 1 Cell load setting 10W Cell load setting 7.5W Cell load setting 5W ANT 2 Cell Airpods setting 5W ANT 3 Cell Watch setting 2W ANT 1+ANT 2 Cell load setting 10W + Cell Airpods setting 5W ANT 1+ANT 3 Cell load setting 10W + Cell Watch setting 2W ANT 2+ANT 3 Cell Airpods setting 5W + Cell Watch setting 2W ANT1+ANT2+ANT3 Cell load setting 10W + Cell Airpods setting 5W + Cell Watch setting 2W Page 8 of 21 Report No.: HK2203221084-1E 2.5. Description of Test Setup Operation of EUT during testing: AC Plug Watch information Model: Watch Input: DC 5V Earphone information Model: Airpods Input: DC 5V Adapter information Model:UP0920…

Text truncated - open the document above for the full version.

MIC-MWS01 Radiated Emission Conducted Emission
