2A323-CW35Car wireless charger

ModeIndicator Power on Standby Charging Full charge Foreign objects are detected Under overtemperature protection status The blue light is always on Green light breathing The lights are off Blue light to green light and then blue light The blue light flashes The blue light flashes User’s Manual Product introduction Packinglist 1.Wireless charger ×1 2.USB cable ×1 3.Air outlet clip ×1 4. Operation instructions ×1 Operation instructions 1. Put the screw nut into ball joint of , insert the air vent mount into the ball joint and tighten with screw nut. 2. Insert the air vent clip into the car air outlet vane and tighten to lock. 3. Plug in the Type-C cable, the arm clamps on both sides will automatically open, and place a mobile phone in, the arm clamps on both sides will automatically clamp the mobile phone tightly. Flashing Pattern Product parameters 3-Clamp arm 2-Air vent clip 4-Button 5-Indicator 1-Wireless charging area 6-Bottom bracket Car Wireless Charger Frequently Asked Questions (1) Please make sure your phone supports wireless charging. (2) Please check if you have used a QC3.0 car charger. (3) Please use the original cable to connect the power supply before use. (4) Please check the thickness of the phone case does not exceed 5 mm. (5) Please make sure there is no metal material, magnetic objects, credit cards or pop holders on the back of your phone between the phone and the phone case. Why doesn't this charger work ? My phone is compatible with wireless charging so why won't it charge with my wireless charger? Make sure that you are using the right adapter and there is no problem with the charging cable and try restarting your phone. Product details 1. This product has the power storage function and can open and close the arm clam ps twice after flameout to prevent the embarrassment of failing to open the arm clamp after flameout. 2. This product adopts waveform anti-skid silicone pad design, which can effectively avoid mobile phone buttons. 3. This product adopts u-shaped armlock radian and won’t slide out either even if the phone screen is placed downward. 4. This product has circulating cooling holes to protect mobile phones from heating during charging. Product description The wireless charger supports 15W fast charging and is available for both Apple and Andr oid models. Wireless charging for equipment conforming to Qi wireless charging standards. The automatic retractable clamp arm is flexible so you can easily fix the mobile phone to charge it or retrieve it This product has functions of overcurrent protection, overheat protection and short circuit protection and has product certificates of FCC, CE and ROHS. Wireless charging sensing: when the mobile phone with wireless charging approaches the charger and is sensed later on, the two arm clamps will automatically clamp the mobile phone tightly and charge it wirelessly. Foreign objects detection sensing: when the mobile phone without wireless charging approaches the charger and is sensed later on, the two arm clamps will also tightly clamp automatically, which can be used as a mobile phone mount. Description Fully Automatic wireless car phone mount Model No. CW35 Product size 110*69*52mm package size Unit Net Weight 117*80*72mm 108g Gross weight 204g Color Black Input Power 5V/2A 9V/2A Output Power 15W(MAX) Valid distance of wireless charging ≤5mm Conversion efficiency 60%~80% Operation frequency 125KHz Materials ABS+PC Why not fast charging or not charging? Please use a QC3.0 car charger for fast charging. FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help.

Letter of Declaration Company: Shenzhen Meskey Technology Co., Ltd Address: Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Product Name: Car wireless charger Trade Mark: N/A Model Number: CW35, CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S FCC Identifier: 2A323-CW35 Compliant with KDB 680106 D01 RF Exposure Wireless Charging Apps v03 section 5, b: a) Power transfer frequency is less than 1MHz. Yes, the working frequency is 125KHz. b) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power is 15 watts. c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. No, the transfer system includes only single primary coil. d) Client device is placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter. e) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, EUT is for mobile exposure conditions only. f) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Yes, EUT h-field strengths levels are less than 50% of the MPE limit. Name: Ivan zhang Date: Nov. 17, 2022 Title: Manager Signature of applicant:

< Shenzhen Meskey Technology Co., Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Nov. 17, 2022 Subject; Request for Long Term Confidentiality FCC ID: 2A323-CW35 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ivan zhang Title: Manager

Shenzhen Meskey Technology Co., Ltd Letter of Authorization Company: Shenzhen Meskey Technology Co., Ltd Address: Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Product Name: Car wireless charger Trade Mark: N/A Model Name: CW35, CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S FCC Identifier: 2A323-CW35 We authorize MiCOM LabsInc, 575 Boulder Court, Pleasanton, California94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM LabsInc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Ivan zhang Date: Nov. 17, 2022 Title: Manager Signature of applicant:

Model Difference Declaration To Whom It May Concern, We, Shenzhen Meskey Technology Co., Ltd Product name: Car wireless charger Trade name: N/A Model name: CW35, CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: CW35. Please contact me if you have any question. Date: 2022.11.17 Name: Ivan zhang Title: Manager Company: Shenzhen Meskey Technology Co., Ltd

Model: CW35 Model: CW35 Model: CW35 Model: CW35

FCC ID LABEL: Label Location: FCC ID: 2A323-CW35 Product Name: Car wireless charger Model Name: CW35 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Long: 3cm Width: 2cm

Model: CW35 Model: CW35 Model: CW35 Model: CW35 Coil Antenna

FCC MPE TEST REPORT FCC ID: 2A323-CW35 Sample： Car wireless charger Trade Name： N/A Main Model： CW35 Additional Model： CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S Report No.： UNIA22110312ER-62 Prepared for Shenzhen Meskey Technology Co., Ltd Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China TEST RESULT CERTIFICATION Applicant ............................... : Shenzhen Meskey Technology Co., Ltd Address .................................. : Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Manufacturer ........................ : Shenzhen Meskey Technology Co., Ltd Address .................................. : Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Product description Product ....................................... : Car wireless charger Trade Name ........................... : N/A Model Name ........................... : CW35, CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S Test Methods ........................ : FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............ : Nov. 03, 2022 ~ Nov. 15, 2022 Date of Issue ......................................... : Nov. 17, 2022 Test Result ............................................. : Pass Prepared by: Kahn yang/Supervisor Reviewer: Kelly Cheng/Supervisor Approved & Authorized Signer: Liuze/Manager Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Channel List Channel Frequency(KHz) Channel Frequency(MHz) 01 125 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 1. SUMMARY OF TEST RESULTS 1.1 Test procedures according to the technical standards: FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01 v03(3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS Compliant with KDB680106 D01 RF Exposure Wireless Charging Apps v03 section 5, b: a) Power transfer frequency is less than 1MHz. Yes, the working frequency is 125KHz. b) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power is 15 watts. c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. No, the transfer system includes only single primary coil. d) Client device is placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter. e) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, EUT is for mobile exposure conditions only. f) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Yes, EUT h-field strengths levels are less than 50% of the MPE limit. 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Radiated Measurement (9KHz-30MHz) ±2.50dB 2 Temperature ±0.5°C 3 Humidity ±2% 1.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Until Broadband Field Meter NARDA NBM-550 –– Jan. 01, 2023 Magnetic Field Meter NARDA ELT-400 1–400kHz Jan. 01, 2023 Magnetic Probe NARDA HF-3061 300kHz–30MHz Jan. 01, 2023 Magnetic Probe NARDA HF-0191 27–1000MHz Jan. 01, 2023 Broadband Field Meter NARDA NBM-550 –– Jan. 01, 2023 Electric Field Meter COMBINOVA EFM 200 5Hz–400kHz Jan. 01, 2023 E-Field Probe NARDA EF-0391 100kHz–3GHz Jan. 01, 2023 E-Field Probe NARDA EF-6091 100MHz–60GHz Jan. 01, 2023 NOTE: The calibration interval of the above test instruments is 12 months. Page 5 / 10 2. MAXIMUM PERMISSIBLE EXPOSURE 2.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density. 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v…

Text truncated - open the document above for the full version.

客户代码版次编制日期承制方 A02022.11.08金晟智能 第 1 页 拟制审核批准 何雪松陈金凤茹威 开发/工程 审核 审核批准 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 承认书 SPECIFICATIONFORAPPROVAL 客户名称 深圳市星科微数码科技集团有限公司 物料描述 发射线圈 承制方型号 17.2x26.2x0.08x105px9T-引线20mmG50磁片 承认书编号 客户代码 W14903 日期 2022.11.08 生产料号 版本/页码 A0 承制方确认使用方确认 客户在收到产品后十天内需验收完毕，并将验收结果书面通知供货方，否则视为已验收合格。 承制方： 广东金晟智能有限公司 地址：东莞市东城街道温周路289号B栋2楼 电话：0769-22252827 邮箱:[email protected] 客户代码版次编制日期承制方 A02022.11.08金晟智能 第 2 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 变更记录 序号版次 日期更改内容更改人 1A0 2022.11.08新规格承认何雪松 客户代码版次编制日期承制方 A02022.11.08金晟智能 第 3 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 结构尺寸 1.外形尺寸: （单位：mm） 17.2±0.5 2 0 ± 3 3 ± 1 . 5 38±1 50±1 5±0.5 1.2±0.1(线圈厚度不含进线) 2.7MAX(总厚度不含离型纸) 普通背胶 4 8 ± 1 2 6 . 2 ± 1 2.电气性能（L）： 项目 标准测式条件测试仪器备注 电感 3.6 ± 5% 100KHZ,1VTH2817B+线圈测式 电感16.5±10%100KHZ,1VTH2817B+带磁片测式 3.外观要求： 1)产品形状尺寸要严格控制。 2)产品表面无油污，杂质，毛刺等。 3)不经客户确认，材料不能随意更改 4)产品必须符合ROSH要求 客户代码版次编制日期承制方 A02022.11.08金晟智能 第 4 页 广东金晟智能有限公司 GuangdongJinshengintelligentCo.,Ltd 材料清单 Billofmaterials（材料清单表） 序号 number 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 1 线材0.08*105P丝包线 2 磁片 50x5.0x1.0H带孔 3 胶布8MM茶色高温胶带 4 白胶工业专用硅酮胶

Page 1 of 22 Report No.: UNIA22110312ER-61 FCC RADIO TEST REPORT FCC ID: 2A323-CW35 Sample： Car wireless charger Trade Name： N/A Main Model： CW35 Additional Model： CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S Report No.： UNIA22110312ER-61 Prepared for Shenzhen Meskey Technology Co., Ltd Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 22 Report No.: UNIA22110312ER-61 TEST RESULT CERTIFICATION Applicant .............................. : Shenzhen Meskey Technology Co., Ltd Address ................................. : Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Manufacturer ........................ : Shenzhen Meskey Technology Co., Ltd Address ................................. : Room 401, Yuanshuo Science Park, Guihua Community, Guanlan, Longhua, Shenzhen, China Product description Product ....................................... : Car wireless charger Trade Name ........................... : N/A Model Name .......................... : CW35, CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.209 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : Nov. 03, 2022 ~ Nov. 15, 2022 Date of Issue .......................................... : Nov. 17, 2022 Test Result.............................................. : Pass Prepared by: Kahn yang/Supervisor Reviewer: Kelly Cheng/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 22 Report No.: UNIA22110312ER-61 Table of Contents Page 1 TEST SUMMARY 4 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE 7 2.4 TEST SETUP 7 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.6 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RADIATED EMISSION 14 4.1 TEST LIMIT 14 4.2 TEST SETUP 16 4.3 TEST PROCEDURE 17 4.4 TEST RESULT 17 5 ANTENNA REQUIREMENT 20 6 PHOTO OF TEST 21 6.1 RADIATED EMISSION 21 6.2 CONDUCTED EMISSION 22 Page 4 of 22 Report No.: UNIA22110312ER-61 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 COMPLIANT RADIATED EMISSION FCC Part 15.209 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 0027159896 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 22 Report No.: UNIA22110312ER-61 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 150KHz 2.96 150KHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 6000MHz 4.13 Page 6 of 22 Report No.: UNIA22110312ER-61 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: Car wireless charger Trade Name: N/A Main Model: CW35 Additional Model: CW36, CW37, CW38, CW39, CW40, CW41, CW42, CW43, CW44, CW45, CW46, CW47, CW48, CW49, CW28, CW29, CW30, CW31, CW32, CW33, CW34, CW19S Model Difference: All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: CW35. FCC ID: 2A323-CW35 Operation Frequency: 125KHz Number of Channels: 1CH Modulation Type: ASK Antenna Type: Coil Antenna Antenna Gain: 0dBi Battery: N/A Adapter: N/A Power Source: DC 5V/9V from adapter with AC 120(240)V/60Hz Page 7 of 22 Report No.: UNIA22110312ER-61 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency (KHz) 01 125 2.3 TEST MODE The EUT was programmed to be in transmitting mode. Channel List Test Channel Test Frequency (KHz) 01 125 2.4 TEST SETUP Operation of EUT during testing: E-3 EUT Adapter Page 8 of 22 Report No.: UNIA22110312ER-61 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an…

Text truncated - open the document above for the full version.

Model: CW35 Radiated Emission test Model: CW35 Conducted Emission test
