2A323-W108Wireless Charging Station

Overall Product Schematic Diagram Magnetic Wireless Charging Area for Mobile Phones Wireless Charging Area for Watches Wireless Charging Area for Headphone Charging Cases Type-C Port Indicator Light Atmosphere Night Light Atmosphere Night Light Silicone Gasket Atmosphere Night Light Touch Switch Unfolded Schematic DiagramOperating Instructions Indicator Light StatusFunction Description of the Atmosphere Night Light Product Specifications ❶This product can wirelessly charge three devices simultaneously: mobile phones, watches, and wireless headphone charging cases that support wireless charging. ❷Please connect this wireless charger to a power adapter using a Type-C fast charging cable and turn on the power. ❸Place your mobile phone on the mobile phone charging area, and it will start charging automatically. ❹Place your watch on the watch charging area, and it will start charging automatically. ❺Place your wireless headphone charging case on the headphone charging area, and the charging case will start charging automatically. Adapter Selection Please use a PD protocol adapter with a power output of 45W or higher. The maximum charging power for mobile phones is 25W. Indicator LightMode White light turns on, then switches to green light, then back to white light, and turns off after 3 seconds Power-on Light off Standby Green light turns on and turns off after 5 seconds Light off White light flashes continuously until the abnormal state is resolved Headphone Charging Case Charging Fully Charged Mobile Side FOD Protection Green light flashes continuously until the abnormal state is resolved Headphone Side FOD Protection The warm white light breathes once (fading from dim to bright, then frombright to off). Light off Power-on Standby Touch Switch Mode Toggle( ) Usage Instructions: Touch Toggle: Tap to cycle through three states: [Low Brightness] → [High Brightness] → [Light Off]. Power-on State: When powered on, the light will breathe once and then turn off. Quick Turn-off: If no operation is performed within 10 seconds while the light is on, a single touch will turn it off. Product Name: Atmosphere Night Light · Magnetic 3-in-1 Foldable Wireless Charger Product Dimensions: 70mm*70mm*73mm Conversion Efficiency: 70%-80% Effective Wireless Charging Distance (for Mobile Phone): ≤4mm Operating Frequency: 110-360KHz Material: ABS +Silicone USB-C Input: 12V⎓3.5A 15V⎓2.8A Mobile Phone Output: 25W(max) Watch Output: 2.5W(max) Headphone Outpu: 5W(max) Package List Wireless Charger × 1 Charging Cable × 1 User Manual × 1 Warning! Instruction Manual Atmosphere Night Light Magnetic 3-in-1 Foldable Wireless Charger Indicator Light Atmosphere Night Light Touch Switch When the watch is unfolded, it can only rotate 180° to the right. ❸Top View❸Top View ❶Right View❶Right View 180° 180° Folded StateAdjustable Angle: 65° 65° type-c type-c type-c When folding and storing the watch charger, it must be folded back along the original path. Precautions Applicable Devices Please check if your mobile phone supports wireless charging. This product supports fast wireless charging, which realizes short-distance wireless power transmission through coil induction. FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co‐located for operating in conjunction with any other antenna or transmitter. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. Donot place metal debris or magnetic cards on the charging pad, as this may cause the charger to heat up! When a foreign object alarm is triggered, remove the foreign object immediately! Slight heating is a normal phenomenon; the mobile phone battery will generate heat during charging! Do not place the charger near fire sources or in corrosive environments!

2.911(d)(5)(i)EquipmentTypeAttestationv1.2 ShenzhenMeskeyTechnologyCo.,Ltd Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ShenzhenMeskeyTechnologyCo.,Ltd Address:Room802,Building1,WestDistrict,HonghuScienceandTechnologyPark, No.22,Ping'anRoad,ZhangxiCommunity,GuanhuStreet,LonghuaDistrict,Shenzhen,China ProductName:WirelessChargingStation FCCID:2A323-W108 Model(s):W108,W108A,W103,W103PRO,W98MAXPRO,W93,W93QI2.2 2.911(d)(5)(i)EquipmentType We,[ShenzhenMeskeyTechnologyCo.,Ltd](“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot: Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules. Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:IvanZhangDate:December03,2025 TitleandCompanyname:Manager;ShenzhenMeskeyTechnologyCo.,Ltd NOTE1 “CoveredList ” ;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911(d)(5)(ii)ApplicantAttestationv1.2 ShenzhenMeskeyTechnologyCo.,Ltd Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:ShenzhenMeskeyTechnologyCo.,Ltd Address:Room802,Building1,WestDistrict,HonghuScienceandTechnologyPark, No.22,Ping'anRoad,ZhangxiCommunity,GuanhuStreet,LonghuaDistrict,Shenzhen,China ProductName:WirelessChargingStation FCCID:2A323-W108 Model(s):W108,W108A,W103,W103PRO,W98MAXPRO,W93,W93QI2.2 2.911(d)(5)(ii)Applicantfiling We,[ShenzhenMeskeyTechnologyCo.,Ltd](“theapplicant”)certifythat,asofthedateofthefiling oftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,established pursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:IvanZhangDate:December03,2025 TitleandCompanyname:Manager;ShenzhenMeskeyTechnologyCo.,Ltd NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenMeskeyTechnologyCo.,Ltd AgentAuthorization Company:ShenzhenMeskeyTechnologyCo.,Ltd Address:Room802,Building1,WestDistrict,HonghuScienceandTechnology Park, No.22,Ping'anRoad,ZhangxiCommunity,GuanhuStreet,LonghuaDistrict, Shenzhen,China ProductName:WirelessChargingStation ModelNumber(s):W108,W108A,W103,W103PRO,W98MAXPRO,W93,W93QI2.2 ProductDescription:WirelessChargingStation WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:December03,2025 Name:IvanZhang Title:Manager Company:ShenzhenMeskeyTechnologyCo.,Ltd

ShenzhenMeskeyTechnologyCo.,Ltd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:December03,2025 Subject;RequestforLongTermConfidentiality FCCID:2A323-W108 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,weare requestingtheCommissiontowithholdthefollowingattachment(s)asconfidentialdocumentsfrom publicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredasproprietary informationinoperationoftheequipment.Thepublicdisclosureofthesedocumentsmightbeharmfulto ourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatandcorrespondenceduring thecertificationreviewprocesscannotbegrantedasconfidentialdocumentsandthisinformationwillbe availableforpublicreviewoncethegrantofequipmentauthorizationisissued. Sincerely, Signature: Name:IvanZhang Title:Manager

ShenzhenMeskeyTechnologyCo.,Ltd ModelDifferenceDeclaration ToWhomItMayConcern, We,ShenzhenMeskeyTechnologyCo.,Ltd Productname:2A323-W108 Tradename:meskey Modelname:W108,W108A,W103,W103PRO,W98MAXPRO,W93,W93QI2.2 Allmodelethefunctioneofhuareandelectriccircuitarethesame,onlywitha productcolorandmodelnameddifferentTestsamplemodel:W108 Pleasecontactmeifyouhaveanyquestion. Name:IvanZhang Date:December03,2025 Title:Manager Signatureofapplicant:

Model:W108 Model:W108 Model:W108 Model:W108 Model:W108 Model:W108 Model:W108

LabelandLocation FCCID:2A323-W108

Model:W108 Model:W108 Model:W108 Model:W108 Model:W108 Model:W108 Model:W108

Page 1 of 17 ReportNo.:UNIA25102115ER-62 FCCMPETESTREPORT FCCID:2A323-W108 Sample:WirelessChargingStation TradeMark:meskey MainModel:W108 AdditionalModel:W108A,W103,W103PRO,W98MAX PRO,W93,W93QI2.2 ReportNo.:UNIA25102115ER-62 Preparedfor ShenzhenMeskeyTechnologyCo.,Ltd Room802,Building1,WestDistrict,HonghuScienceandTechnologyPark, No.22,Ping'anRoad,ZhangxiCommunity,GuanhuStreet,LonghuaDistrict, Shenzhen,China Preparedby ShenzhenUnitedTestingTechnologyCo.,Ltd. D101&D401,No.107,KaichengHigh-TechPark,TaoyuanCommunity, DalangSub-District,LonghuaDistrict,Shenzhen,Guangdong,China Page 2 of 17 ReportNo.:UNIA25102115ER-62 TESTRESULTCERTIFICATION Applicant...................................: ShenzhenMeskeyTechnologyCo.,Ltd Address ...................................... : Room802,Building1,WestDistrict,HonghuScienceand TechnologyPark,No.22,Ping'anRoad,ZhangxiCommunity, GuanhuStreet,LonghuaDistrict,Shenzhen,China Manufacturer ............................ : ShenzhenMeskeyTechnologyCo.,Ltd Address......................................: Room802,Building1,WestDistrict,HonghuScienceand TechnologyPark,No.22,Ping'anRoad,ZhangxiCommunity, GuanhuStreet,LonghuaDistrict,Shenzhen,China Productdescription Product.......................................: WirelessChargingStation TradeMark.................................: meskey ModelName .............................. : W108,W108A,W103,W103PRO,W98MAXPRO,W93,W93QI2.2 Standards.............................: FCCKDB680106D01WirelessPowerTransferv04 ThisdevicedescribedabovehasbeentestedbyShenzhenUnitedTestingTechnologyCo.,Ltd., andthetestresultsshowthattheequipmentundertest(EUT)isincompliancewiththeFCC requirements.Anditisapplicableonlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofUNI,thisdocument maybealteredorrevisedbyShenzhenUnitedTestingTechnologyCo.,Ltd.,personnelonly,and shallbenotedintherevisionofthedocument. DateofTest Date(s)ofperformanceoftests...............:October24,2025~November19,2025 DateofIssue .............................................. :November19,2025 TestResult..................................................:Pass Preparedby: JasonYe/Editor Reviewer: KellyCheng/Supervisor Approved&AuthorizedSigner: Liuze/Manager Page 3 of 17 ReportNo.:UNIA25102115ER-62 TableofContentsPages 1TESTSUMMARY4 1.1TESTPROCEDURESANDRESULTS4 1.2TESTFACILITY5 1.3MEASUREMENTUNCERTAINTY6 1.4ENVIRONMENTALCONDITIONS6 2GENERALINFORMATION7 2.1GENERALDESCRIPTIONOFEUT7 2.2TESTMODE8 2.3DESCRIPTIONTESTPERIPHERALANDEUTPERIPHERAL9 2.4TESTINSTRUMENTS9 3MAXIMUMPERMISSIBLEEXPOSURE10 3.1MAXIMUMPERMISSIBLEEXPOSURE10 3.2TESTPROCEDURE11 3.3TESTSETUP11 3.4RESULTOFMAXIMUMPERMISSIBLEEXPOSURE12 3.5TESTPHOTO15 Page 4 of 17 ReportNo.:UNIA25102115ER-62 1TESTSUMMARY 1.1TESTPROCEDURESANDRESULTS FCCKDB680106D01WirelessPowerTransferv04 FCCCFR47 StandardSectionTestItemResultRemark FCCCFR47part1, 1.1310KDB680106 D01v04 ElectricFieldStrength(E)(V/m)N/A-- MagneticFieldStrength(H)(A/m)PASS-- Note:“N/A”denotestestisnotapplicableinthisTestReport. Compliantwith FCCKDB680106D01WirelessPowerTransferv04 section5.2: 1)Thepowertransferfrequencyisbelow1MHz. Yes,theworkingfrequencyis: 110-360kHz . 2)Theoutputpowerfromeachtransmittingelement(e.g.,coil)islessthanorequalto15watts. No,themaximumoutputpoweris25watts. 3)Aclientdeviceprovidingthemaximumpermittedloadisplacedinphysicalcontactwiththe transmitter(i.e.,thesurfacesofthetransmitterandclientdeviceenclosuresneedtobeinphysical contact) Yes,themaximumpermittedloadisplacedinphysicalcontactwiththetransmitter. 4)Only$2.1091-Mobileexposureconditionsapply(i.e.,thisprovisiondoesnotcover$2.1093-Portabl eexposureconditions). Yes,thisprovisiondoesnotcover$2.1093-Portableexposureconditions. 5)TheH-fieldstrengths,atandbeyond20cmsurroundingthedevicesurface,aredemonstratedtobe lessthan50%oftheapplicableMPElimit,perKDB447498,Table1.Thesemeasurementsshallbe takenalongtheprincipalaxesofthedevice,withoneaxisorientedalongthedirectionofthe estimatedmaximumfieldstrength,andforthreepointsperaxisoruntila1/d(inversedistancefrom theemitterstructure)fieldstrengthdecayisobserved.Symmetryconsiderationsmaybeusedfor testreductionpurposes.Thedeviceshallbeoperatedindocumentedworst-casecompliance scenarios(i.e.,theonesthatleadtothemaximumfieldcomponents),andwhilealltheradiating structures(e.g.,coilsorantennas)thatbydesigncansimultaneouslytransmitareenergizedattheir nominalmaximumpower. Yes,TheH-fieldstrengths,atandbeyond20cmsurroundingthedevicesurface,aredemonstrated tobelessthan50%oftheapplicableMPElimit;coilsorantennas)thatbydesigncansimultaneously transmitareenergizedattheirnominalmaximumpower. Page 5 of 17 ReportNo.:UNIA25102115ER-62 6)Forsystemswithmorethanoneradiatingstructure,theconditionsspecifiedin(5)mustbemetwhen thesystemisfullyloaded(i.e.,clientsabsorbingmaximumpoweravailable),andwithalltheradiating structuresoperatingatmaximumpoweratthesametime,asperdesignconditions.Ifthedesign allowsoneormoreradiatingstructurestobepoweredatahigherlevelwhileotherradiating structuresarenotpowered,thenthosecasesmustbetestedaswell.Forinstance,adevicemayuse threeRFcoilspoweredat5W,oronecoilpoweredat15W:inthiscase,bothscenariosshallbe tested. Yes,Forsystemswithmorethanoneradiatingstructure,theconditionsspecifiedin(5)mustbemet whenthesystemisfullyloaded(i.e.,clientsabsorbingmaximumpoweravailable),andwithallthe radiatingstructuresoperatingatmaximumpoweratthesametime. 1.2TESTFACILITY TestFirm:ShenzhenUnitedTestingTechnologyCo.,Ltd. Address:D101&D401,No.107,KaichengHigh-TechPark,TaoyuanCommunity, DalangSub-District,LonghuaDistrict,Shenzhen,Guangdong,China Thetestingqualityabilityofourlaboratorymeetwith"QualityLawofPeople'sRepublicof China"Clause19.ThetestingqualitysystemofourlaboratorymeetswithISO/IEC-17025 requirements.ThisapprovalresultisacceptedbyMRAofAPLAC. Ourtestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: A2LACertificateNumber:4747.01 TheEMCLaboratoryhasbeenaccreditedbyA2LA,andincompliancewithISO/IEC 17025:2017Gene…

Text truncated - open the document above for the full version.

产品承认书书 规格编号 HG2025041001 生效日期 客户名称 二维四象智能科技有限责任公司 产品类型QI2线圈 宏贵料号 43.5*0.8 开双槽带孔背白胶 /0.08*80 丝包线 客户料号 【 □ √√ 新版发行 ,□ 版本修订】【本规范含目录共 2 页】【 RoHSCompliantParts 】 编制审核批准 彭建基 安福宏贵电子有限公司 本承认书在客户收到一星期内，请务必签章返回，逾期视为生产时按此承认书的标准 执行。 【客户核准】日期: 承认状态：□完全承认□条件承认□拒绝承认 批准审核 复检检查 说明: 产品规格书 客户名称二维四象智能科技有限责任公司客户料号 宏贵料号 43.5*0.8开双槽带孔0.08*80股丝包线 规格编号 HG2025041001 版本 01 ♦、外形尺寸 ♦、电气特性: (单位:mm) A 43.5±0.5 B 40.0±1 C20.5±0.5 D2.1±0.2 E110±2 F2.0±1 G (1)线径:0.08*80P丝包自粘铜线 (2)绕线圈数:11TS (3)起尾线是否交叉:是 (4)线圈包6mm宽高温胶带 (5)线圈与磁片需粘贴居中 (6)线圈中间贴直径20MM厚度1.0MM圆片 (7)磁片背圆双面胶 参数规格测试条件测试仪器 L07.9±0.3μH 100KHz/1V ■TH1816B ■TH1816B ■CH-502BC Q>30min 100KHz/1V DCR<60mΩ @25°C 操作温度 -40°C~125°C ♦、材料清单: 序号 1 品名材料规格供应商备注 2 磁片20*1.0圆片PC95猛锌 3 磁片43.5*0.8开双槽带孔PC95猛锌 4 铜线0.08*80P丝包自粘铜线 5 高温胶带 6MM 环保胶带 6 锡高温锡条千岛环保锡 7 胶白胶环保胶水 8 白胶 42 圆双面胶 编制审核 批准 彭建基

深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 1 页 产品规格书 PRODUCTSPECIFICATIONFORAPPROVAL 客户名称： CUSTOMER 产品名称： PRODUCTNAME A11 线圈 物料编码： PARTNo. 产品规格： PRODUCTSPEC 感量：6.3uH±10% 磁片规格：43.5*5.3*1双槽 线材规格：0.08*105*10Ts/出线18mm 贴背胶 日期： DATE 2022年10月07日 版本型号： VERSION REV1.0 版本 Revision 变更内容 ModifiedContent 责任人 Principle 日期 Date 备注 Note REV1.0首次发布薛磊2022-10-07 制定/PREPAREDBY审核/CHECKEDBY核准/APPROVEDBY 客户认可签名及盖章 Authorizedsignature& companychop 附上的是产品规格书，有任何疑问，请及时反馈给我们，谢谢 ! 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 2 页 产品规格 SPECIFICATION 一、产品尺寸 磁片直径 A 43.5±0.5mm 线圈外径B42±1mm 线圈内径C20.5±0.5mm 产品厚度D<2.5mm 出线长度E18mm±3mm 焊锡长度F2-5mm 磁片开孔直径G5±0.3mm 磁片厚度1±0.1mm 磁片形状圆形双槽 背胶厚度普通双面胶 防碎黑膜不 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 3 页 二、原理图 三、绕线参数 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection SF 丝包线 0.08*105P 10TsCCW 四、电气特性： 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS IND.S-F 6.3uH±10% 100KHz/1.0VLCZMETER1062B 五、产品图片 深圳市宸兴电子技术有限公司 公司名称：深圳市宸兴电子技术有限公司 工厂地址：深圳市宝安区新安街道大宝路51号新柯城科技工业园1栋5楼 第 4 页 六、包装说明： 珍珠棉尺寸为35*24.5*6.2cm,每 个珍珠棉共有40个格子，每个格 子装6PCS产品，共240PCS产品 每箱装三层珍珠棉； 纸箱尺寸为：36.5*25.5*21CM， 每箱装720PCS产品。

GivebirthtoArticleLetterofrecognition Book SpecificatHG20250829001 Effective Customer'sname Two-dimensionalfour-imageintelligenttechnologylimited liabilitycompany Producttype QI2Coil Hongguimaterial number 42.5*0.8 Opendoublegroovewithhole /0.08*80 Multi-stranded wire Customer materialnumber [√□Thenewversionisreleased,□Versionrevision][Thisspecificationcontains atotalof Two Page][ RoHSCompliantParts ] WeaveCheckRatify PengJianji AnfuHongguiElectronicsCo.,Ltd. Building2,NewEnergylndustrialpark,SouthAreaofAnfuHigh-techlndustrialpark,Ji’anCity,JiangxiProvince Pleasebesuretosignandreturnthisacknowledgementwithinoneweekafter thecustomerreceivesit.Overdueshallbedeemedtobeimplementedaccordingto thestandardofthisletterofrecognitionatthetimeofproduction. [Customerapproval] Date: Recognitionstatus: □ Fullyadmit □ Conditionalrecognition □ Refusetoadmit RatifyCheckRe-inspectionExamine Explain: Customer's name Two-dimensionalfour-image intelligenttechnologylimited liabilitycompany Custome r materia l number Honggui material number ♦ , Externa l 42.5*0.8Opendoublegroove hole/0.08*80Multi-stranded with wire Specifi catiHG20250829001 on number Edition (Unit:mm) A 42.5±0.5 B40.0±1 C20.5±0.5 D2.1±0.2 E15±2 F2±1 (1)Wirediameter:0.08*80Psilk- wrappedself-adhesivecopper wire (2)Thenumberofwindingcoils:11 TS (3)Whetherthestartingandending linesintersect:Yes (4)CoilpackageSixmillimetersWide high-temperaturetape (5)Thecoilandthemagneticsheet shouldbepastedinthestering. Six(6)Diameterofthemiddleofthe coil20MMThickness1.0 millimetreRoundpiece Parameter L0 Specifications 7.9±0.3μH Test conditions 100K Hz/1V Testinstrument ■TH181 Q >30minutes 100K Hz/1V ■TH181 DCR. <60MΩ Billof materials: Serials 1 Materials 2 Magneticsheet20*1.0Roundpiece PC95Strongzinc 3 Magneticsheet 42.5*0.8Doubleslotswith holes PC95Strongzinc 4 Copperwire0.08*80P Silk-wrappedself-adhesivecopperwire 5 High-temperaturet ape 6MM Eco-friendiyadhesivetape 6 TinHightemperatuertinbar Thousandislandenvironmentaltin 7 GlueWhiteglues Eco-friendlyadhesive AUTHORCHECK APPROVE pengjianji @twenty five°C ■CH-502 01

Page 1 of 27 Report No.: UNIA25102115ER-61 FCC RADIO TEST REPORT FCC ID: 2A323-W108 Sample : Wireless Charging Station Trade Mark : meskey Main Model : W108 Additional Model : W108A, W103,W103 PRO, W98 MAX PRO,W93,W93 QI2.2 Report No. : UNIA25102115ER-61 Prepared for Shenzhen Meskey Technology Co., Ltd Room 802, Building 1, West District, Honghu Science and Technology Park, No. 22, Ping 'an Road, Zhangxi Community, Guanhu Street, Longhua District, Shenzhen,China Prepared by Shenzhen United Testing Technology Co., Ltd. D101&D401, No. 107, Kaicheng High-Tech Park, Taoyuan Community, Dalang Sub-District, Longhua District, Shenzhen, Guangdong, China Page 2 of 27 Report No.: UNIA25102115ER-61 TEST RESULT CERTIFICATION Applicant .............................. : Shenzhen Meskey Technology Co., Ltd Address ................................. : Room 802, Building 1, West District, Honghu Science and Technology Park, No. 22, Ping 'an Road, Zhangxi Community, Guanhu Street, Longhua District, Shenzhen,China Manufacturer........................ : Shenzhen Meskey Technology Co., Ltd Address ................................. : Room 802, Building 1, West District, Honghu Science and Technology Park, No. 22, Ping 'an Road, Zhangxi Community, Guanhu Street, Longhua District, Shenzhen,China Product description Product .................................. : Wireless Charging Station Trade Mark ............................ : meskey Model Name .......................... : W108, W108A, W103,W103 PRO,W98 MAX PRO,W93,W93 QI2.2 Test Methods ....................... : FCC Rules and Regulations Part 15 Subpart C Section 15.209 ANSI C63.10: 2020 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test Date (s) of performance of tests ............. : October 24, 2025 ~ November 19, 2025 Date of Issue .......................................... : November 19, 2025 Test Result ............................................. : Pass Prepared by: Jason Ye/Editor Reviewer: Kelly Cheng/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 27 Report No.: UNIA25102115ER-61 Table of Contents Pages 1 TEST SUMMARY 4 1.1 TEST PROCEDURES AND RESULTS 4 1.2 TEST FACILITY 4 1.3 MEASUREMENT UNCERTAINTY 5 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 TEST MODE 7 2.3 TEST SETUP 7 2.4 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.5 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 11 3.1 TEST LIMIT 11 3.2 TEST SETUP 11 3.3 TEST PROCEDURE 12 3.4 TEST RESULT 12 4 RADIATED EMISSION 15 4.1 TEST LIMIT 15 4.2 TEST SETUP 17 4.3 TEST PROCEDURE 18 4.4 TEST RESULT 18 5 ANTENNA REQUIREMENT 24 6 PHOTO OF TEST 26 6.1 RADIATED EMISSION 26 6.2 CONDUCTED EMISSION 27 Page 4 of 27 Report No.: UNIA25102115ER-61 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS Item FCC Rules Description Of Test Result 1 FCC Part 15.207 Conducted Emission Pass 2 FCC Part 15.209(a) Radiated Emission Pass 3 FCC Part 15.203 Antenna Requirement Pass 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : D101&D401, No. 107, Kaicheng High-Tech Park, Taoyuan Community, Dalang Sub-District, Longhua District, Shenzhen, Guangdong, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 31584 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 27 Report No.: UNIA25102115ER-61 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 150KHz 2.96 150KHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 6000MHz 4.13 Page 6 of 27 Report No.: UNIA25102115ER-61 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: Wireless Charging Station Trade Mark: meskey Main Model: W108 Additional Model: W108A, W103,W103 PRO,W98 MAX PRO,W93,W93 QI2.2 Model Difference: All model’s the function, software and electric circuit are the same, only with a product color and model named different. Test sample model: W108 FCC ID: 2A323-W108 Operation Frequency: Phone: 110-360kHz TW S: 110-205kHz Watch: 326.5kHz Modulation Type: ASK Wireless Charging Output Power: Output1:Phone 25W(max) Output2:TWS 5W(max) Output3:Watch 2.5W Antenna Type: Coil Antenna Antenna Gain: 0dBi Battery: N/A Adapter: N/A Power Source: DC 12V/15V by Adapter Page 7 of 27 Report No.: UNIA25102115ER-61 2.2 TEST MODE NO. TEST MODE DESCRIPTION 1 ANT 1(Phone coil) + Full load (25W Folding mode) 2 ANT 1(Phone coil) + Half load (7.5W Folding mode) 3 ANT 1(Phone coil) + Null load (0W Folding mode) 4 ANT 1(Phone coil) + Full load (25W Before Folding mode) 5 ANT 1(Phone c…

Text truncated - open the document above for the full version.

Model:W108 RadiatedEmissiontest Model:W108 ConductedEmissiontest Model:W108 MPE Model:W108 Model:W108
