2A3OOH777HTwo Way Radio

H777H Two Way Radio USER'S MANUAL 02 02 04 05 06 20 FordownloadingfuDžherresources: Brochures,Software/Firmware,Manualetc,Pleasecontact yourdirectresellerǁrstORgotowebsiteretevis.comand check“suppoDž”intheeachproductlinktodownloadit. CONTENT Getting Familiar ---------------------------- Basic Operation ---------------------------- TechnicalSpeciǁcations-------------------- Frequency Table (FRS 16H) ----------------- Warning ----------------------------------- Guarantee Card----------------------------- EN(1-09) ES(10-19) FR(20-29) FeatureOvedžiew MonitorFunction ScanFunction Voice-Activated(VOX)Function EmergencyAlarmFunction Flashlight High/LowPowerSelection BusyChannelLockout BatteLjSave LowBatteLjAleDž Time-OutTimer One-TouchFrequencyPairing AnalogCTCSS/DigitalDCSTones Charging Instructions (I) LithiumbatteriesarenotchargedatthefactoLj.Pleasechargethematan ambienttemperatureof5-40°Cbeforeuse. Afterpurchaseorafterlong-termstorage(morethantwomonths),theǁrst chargewillnotallowthelithiumbatteLjtoreachitsfullcapacity.After repeatedcharging/dischargingtwoorthreetimes,thebatteLjwillachieve normalchargingpeDŽormanceandenergycapacity. Beforecharging,pleaseturnoƺthewalkie-talkiepoweredbythelithium batteLj.Donotusethewalkie-talkieduringchargingasitaƺectsnormal chargingandmaycauseaccidents. Oncefullycharged,removethebatteLjfromthecharger(ordisconnectthe USBchargingplug).AvoidoverchargingasitcanshoDženthebatteLj'slife. If,aftercorrectcharging,thelithiumbatteLjdoesnotincreaseoperating time,itindicatesthatthebatteLjlifehasended.Pleasereplaceitwithanew one. Charging Instructions (II) First,inseDžthesmallplugofthe"Adapter"intothechargersocket,thenplug theadapterintoa110~220VACpowersource.Thechargerwilllightup green. PlacethelithiumbatteLjorthewalkie-talkiewiththebatteLjinthecharger, ensuringcontactwiththechargingterminals.Whencharging,aredlight indicatescharginghasstaDžed;itturnsgreenwhenfullycharged. Note:Thiswalkie-talkiecanbechargedusingacradlechargerordirectly withtheadapter.Fordirectchargingwiththeadapter,plugitintoa 110~220VACpowersource,theninseDžthesmalloutputplugdirectlyinto thewalkie-talkie'sUSBchargingpoDž.Whentheredlightturnson,charging begins.Whenfullycharged,theredlightwillturnoƺ. 01 Getting Familiar A.PTT B.UP C.DOWN D.LEDTorch E.Speaker F.MIC G.Speaker/MicrophoneJacks H.ChannelSwitch I.PowerSwitch/VolumeControl J.LedIndicator K.Type-C Basic Operation Power Switch / Volume Control ●Turnthepower/volumeknobclockwiseuntilyouheara"click"toturnonthe walkie-talkie.Turnitcounterclockwisetothe"click"toturnitoƺ. ●Intheonstate,adjustthevolumebyturningthevolumecontrol. Channel Selection ●Turnthechannelknobclockwisetoincreasethechannelnumber.When voiceisenabled,itwillannouncethecurrentchannel.Turnitcounterclockwise todecreasethechannelnumber(Channels1—16whenturningclockwise; 16—1whenturningcounterclockwise). ●Whenapropersignalisreceived,thesignallightwillilluminateandthe speakerwillemitsound. PTT Transmission Button Pressandholdthe"PTT"buttonwhilespeakingintothemicrophonefrom3-8 cmawayusinganormaltoneofvoicetoensuretherecipientreceivesoptimal soundquality. Monitor Function Listentoconversationsonaspeciǁcchannelwithoutdisturbingotherusers.In I J 02 theonstate,pressthe【UP】keybrieǃytoturnon,pressagaintoturnoƺ. Scan Function Intheonstate,the【UP】or【DOWN】sidekeycanbesetviasoftwareto "Scan."Holdthesidekeyfor2.5secondsuntilitprompts"On,"anditwill automaticallybeginscanningfromchannel1to16.Ifnosignalisreceived within4secondsafterscanningachannel,itwillcontinuescanning.Toexitthe scanmode,holdthesidekeyfor2.5secondsuntilitprompts"Oƺ."(Note: ScanningcannotbepeDŽormediflessthantwowalkie-talkiesareaddedvia thesoftware). ●"CarrierScanning":Thewalkie-talkiestopsscanningandstaysonthesame frequencywhenasignalisdetectedandwillwaitfor4secondsafterthesignal isgonebeforeresumingscanning. Voice-Activated (VOX) Function VOXallowsforhands-freetransmissionbyspeakingintothewalkie-talkie withoutpressingthePTTbutton.Withthedeviceturnedon,holdthe【DOWN 】buttonfor2.5secondsuntilyouheartheEnglishvoiceprompt"VOX- ON/OFF." ●TheVOXgainlevelindicatesthesensitivityofthewalkie-talkietothe speakingvoice.Thegainlevelcanbesetfrom1-9usingthesoftware.Ifsetto "Oƺ,"theVOXfunctioncannotbemanuallyactivated;"9"isthemostsensitive setting. Emergency Alarm Function Inanemergency,holdthe【UP】keyfor2.5secondstoactivatethealarm. Thecorrespondingchannel'sdeviceswillreceivethealarmsignal,andthe alarmsoundwillbeemittedfromthedevice.PressPTTtoexitthealarmmode. Flashlight Pressthe【DOWN】keybrieǃytoturnontheLEDlight.Pressagainforone secondtoturnitoƺ. High/Low Power Selection Switchbetweenhighandlowpowersettingsviasoftware. Busy Channel Lockout ThisfunctionpreventsinteDŽerencewithconversationsonbusychannels.Users needtosetthisfeatureinthesoftwarebyselecting"Yes"or"No";if"Yes"is selected,pressingthePTTbuttononabusychannelwillnotallow transmissionandwillemitabeep;if"No,"thiswillnotoccur. BatteLjSave ThebatteLjsavefunctionallowsthewalkie-talkietoreducepower consumptionwhennosignalsarereceived,therebyextendingtheusagetime onasinglecharge.Thisfunctioncanbeenabledinthesoftwareunderthe "BatteLjSave"option. 03 LowBatteLjAleDž WhenthebatteLjlevelislow,thewalkie-talki…
