2A3VP-Q34BWireless Gaming Controller

XBOX(X-Input) 模式 作用：玩Steam、原生手柄游戏、XBOX串流、模拟器等。 （安卓9.0 / iOS13.0 / Win 10 及以上） 蓝牙连接 （适用于：电脑/安卓/苹果） 1. 手柄背面拨动开关：拨到 X 档 XBOX(X-Input) 模式。 2. 首次使用（开机配对） a. 按 【Pair配对键】 进行配对，LED 快闪。 b. 到系统蓝牙设备内，搜索蓝牙名为 XBOX Wireless Controller 的设备进行配对连接。 c. 连接成功 LED1 常亮。 3. 再次使用（开机回连） a. 短按 【 】 键自动回连，LED 慢闪。 b. 回连成功 LED1 常亮。 4. 按 【Pair配对键】 关机。 有线连接 手柄关机状态，在 X 档用 USB 线把手柄连接到电脑，识别成功即可用，LED1 常亮。 接收器连接 （接收器为选配） 1. 接收器插入电脑，识别为 XBOX(X-Input) 模式。 2. 手柄上按 【 O + 】键开机连接接收器。 3. 连接成功 LED1 与 LED4 常亮。 4. 按 【Pair配对键】 关机。 Q34B 功能示意图 HID 与 GamepadSpace App 模式 作用： 连接 GamepadSpace App 对手柄进行设置拓展更多玩法、OTA 固件升 级等， GamepadSpace App 直接从手机应用市场下载。 蓝牙连接 1. 手柄背面拨动开关：拨到 D 档为 HID APP 模式 2. 首次使用（开机配对） a. 按 【Pair配对键】 进行配对，LED 快闪。 b. 到系统蓝牙设备内， 搜索蓝牙名为 GamepadSpace-Q34B 的设备进行 配对连接。 c. 连接成功 LED3 常亮。 3. 再次使用（开机回连） a. 按【 】键自动回连，LED 慢闪。 b. 回连成功 LED3 常亮。 4. 按 【Pair配对键】 关机。 陀螺仪校准 关机状态下，放平手柄，按住 【 + A 】键不放开，再按【 】键 。 电性参数 DC3.7 V 10-40 mA < 5uA 工作电压 工作电流 休眠电流 （马达不工作） 规格 蓝牙传输距离 电池容量 待机时间 DC5V/500mA < 8M 400mAh 满电放置60天 Switch 模式 含 陀螺仪体感 功能，没有 NFC 功能 作用：1. 连接 NS-Switch 玩主机游戏 2. 电脑玩 Steam 游戏 蓝牙连接 1. 手柄背面拨动开关：拨到 S 档 NS-Switch 模式。 2. 首次使用（开机配对） a. 按 【Pair配对键】 进行配对，LED 快闪。 b. 在 Switch 主机， 选择 手柄 Controllers → 更改握把/顺序 Change Grip/order，进入到 Switch 主机配对界面进行配对。 c. 连接成功 LED2 常亮。 3. 再次使用（开机回连） a. 按【 】键自动回连，LED慢闪。 b. 回连成功 LED2 常亮。 4. 按 【Pair配对键】 关机。 5. 手柄的 【ABXY】 键，对应 Switch 主机的 【BAYX】 键。 QQ售后群 1013874674 公众号教程官网教程 手柄充电/休眠/唤醒功能 1. 手柄在充电时， LED 指示灯慢闪，充饱后常亮。 2. 睡眠/唤醒功能： 配对状态，2分钟 内没有配对成功会进入休眠。 回连状态，1分钟 内没有回连成功会进入休眠。 已连接蓝牙，15分钟 内不使用会进入休眠。 按 【Pair配对键】 关机。 按 【 】 直接回连。 3. 电池电量不足时，LED 指示灯快闪提示。 T 键功能 T 键为 Turbo 功能。 A/B/X/Y/LB/LT/RB/RT/L3/R3 可以设置 Turbo 连发功能。 设置方法： 如设置 【 A 】 键 Turbo 功能： 第一次按住【 A 】键 再 按【 T 】键，设置 Turbo 功能； 第二次按住【 A 】键 再 按【 T 】键，清除 Turbo 功能。 设置 Turbo 速度： 【 + T 】键：设置高速连发； 【 / + T 】键：设置中速连发； 【 + T 】键：设置低速连发。 清除所有已设置 Turbo 功能按键： 长 按【 T 】键 5 秒。 摇杆设置 摇杆校准： 手柄开机会校准摇杆，开机的时候不要碰摇杆。 摇杆画方圆切换：【 R3 + 】键 注：【R3】 键为右摇杆下压按键，默认为画圆。 摇杆死区切换：【 L3 + 】键 注：【L3】 键为左摇杆下压按键，默认无死区。 注意事项 请不要把本产品放在潮湿或高温地方存储； 不要敲击、 摔打、 棒打、 刺穿、 或试图去分解本产品， 以免对产品造成不必要的 损害； 产品内置电池，请勿和垃圾一起丢弃； 不要在靠近火或其它热源的地方对手柄进行充电； 非专业人员请勿拆卸本产品，否则不在售后保修服务内。 左摇杆/L3 键 右摇杆/R3 键 十字键 X/Y/B/A 键 View 键/- 键 开机回连键 Menu 键/+ 键 LED 1~4（从左到右） O 键 T 键 RB/RT 键 LB/LT 键 Pair 配对键 / 关机键 Type-C 接口 拨动开关 复位孔 XBOX (X-Input) Mode Function: Play Steam, native controller games, XBOX streaming, simulator, etc. (Android 9.0 / iOS13.0 / Win 10 and above) Bluetooth connection (Applicable to PC/Android/Apple) 1. Toggle switch on the back of the controller: switch to X for XBOX (X-Input) mode. 2. First use (power on pairing) a. Press [Pair Button] to pair, LED flashes quickly. b. Go to the system Bluetooth device and search for the device named XBOX Wireless Controller for pairing and connection. c. LED1 is always on when the connection is successful. 3. Use again (power on and reconnect) a. Short press [ ] button to auto matically reconnect, LED flashes slowly. b. LED1 is always on when the reconnection is successful. 4. Press [Pair Button] to shut down. Wired connection When the controller is turned off, connect the controller to the computer with a USB cable in X mode. Once it is successfully identified, it can be used and LED1 will be always on. Receiver connection (receiver is optional) 1. Insert the receiver into the computer and identify it as XBOX (X-Input) mode. 2. Press the [ O + ] button on the controller to turn on and connect the receiver. 3. If the connection is successful, LED1 and LED4 will be always on. 4. Press the [Pair Button] to turn off the controller. Q34B Functional Diagram Charging/Sleep/Wake-up 1. When the controller is charging, the LED indicator flashes slowly and stays on when fully charged. 2. Sleep/wake-up function: In pairing state, if the pairing is not successful within 2 minutes, it will enter sleep mode. In reconnection state, if the reconnection is not successful within 1 minute, it will enter sleep mode. If the controller is connected to Bluetooth, it will enter sleep mode if it is not used within 15 minutes. Press [Pair Button] to turn off the controller. Press [ ] to reconnect directly. 3. When the battery is low, the LED indicator flashes quickly to remind you. HID and GamepadSpace App mode Function: Connect GamepadSpace App to set the controller to expand more gameplay, OTA firmware upgrade, etc. GamepadSpace App can be downloaded directly from the mobile application market. Bluetooth connection 1. Toggle switch on the back of the controller: switch to D for HID APP mode. 2. First use (power on pairing) a. Press [Pair Button] to pair, LED flashes quickly. b. Go to the system Bluetooth device and search for the device named GamepadSpace-Q34B for pairing and connection. c. LED3 is always on when the connection is successful. 3. Use again (power on and reconnect) a. Press [ ] button to automatically reconnect, LED flashes slowly. b. LED3 is always on when the reconnection is successful. 4. Press [Pair Button] to shut down. Gyroscope Calibration When the device is powered off, place the controller flat, press and hold the [ + A ] button, and then press the [ ] button. Notes Please do not store this product in a humid or high temperature place; Do not knock, drop, hit, pierce, or try to disassemble this product to avoid unnecessary damage to the product; The product has a built-in battery, please do not discard it with garbage; Do not charge the handle near fire or other heat sources; Non-professionals are not allowed to disassemble this product, otherwise it will not be covered by the after-sales warranty service. Electrical Parameters DC3.7 V 10-40 mA < 5uA Working voltage Working current Sleep current (When the motor is not rotating) Specifications Bluetooth distance Battery capacity Standby time fully charged DC5V/500mA < 8M 400mAh 60 days Switch Mode Contains gyroscope somatosensory function, no NFC function Function: 1. Connect to NS-Switch to play console games 2. Play Steam games on the computer Bluetooth connection 1. Toggle the Switch on the back of the controller: switch to S for NS-Switch mode. 2. First use (power on p…

Text truncated - open the document above for the full version.

CoveredEquipmentCertificationAttestationLetter 2025.09.12 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA ATTN.:ReviewingEngineer FCCID:2A3VP-Q34B ShenZhenShanWanTechnologyCo.,Ltd(“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Note:Iftheequipmentforwhichtheapplicantseeksauthorizationisproducedby anyoftheentitiesidentifiedonthecurrentCoveredList,theapplicantshould includeanexplanationonwhytheequipmentisnot“covered”equipment. ShenZhenShanWanTechnologyCo.,Ltd(“theapplicant”)certifiesthat,asofthedateof thefilingoftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. ShenZhenShanWanTechnologyCo.,Ltd(“theapplicant”)certifiesthattheequipment forwhichauthorizationissoughtdoesnotincludecybersecurityoranti-virussoftware producedorprovidedbyKasperskyLab,Inc.oranyofitssuccessorsandassignees, includingequipmentwithintegratedKasperskyLab,Inc.(oranyofitssuccessorsand assignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01 CoveredEquipmentGuidancesectionB(2a). Signed: Printedname:XiaoChenHu Title:manager CompanyName:ShenZhenShanWanTechnologyCo.,Ltd Date:2025.09.12

version01 ShenZhenShanWanTechnologyCo.,Ltd Modeldifferencestatement Itisherebydeclaredthattheproduct FCCID:2A3VP-Q34B ProductName:WirelessGamingController Model(s):Q34B,Q34,Q34BK,Q34BKM,Q34K,Q34M Mark:/ Thedifferencebetweendifferentmodelsisthatinthisapplication,duetodifferentsaleschannelsand differentmodelnames. Sincerely, Signature Name:XiaoChenHu Title:manager ApplicantCompany:ShenZhenShanWanTechnologyCo.,Ltd

2025.09.12 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID:2A3VP-Q34B ProductName:MobileGameController RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommission’srules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...) Schematics Blockdiagram  Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. Name:XiaoChenHu Title:manager Company:ShenZhenShanWanTechnologyCo.,Ltd

2025.09.12 FederalCommunicationsCommission Authorization&EvaluationDivision 7345OaklandMillsRoad Columbia,Maryland21046 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorizeShenzhenBangceTestingTechnologyCo.,Ltd.toacton ourbehalfinallmattersrelatingtoapplicationforequipmentauthorization,includingthesigningofall documentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothedenialof benefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21 U.S.C.853(a). Sincerely, Name:XiaoChenHu Title:manager Company:ShenZhenShanWanTechnologyCo.,Ltd

ReportNo.:CISRR25081914801 Page 39 of 60 7.EXTERNALANDINTERNALPHOTOS 7.1.ExternalPhotos ReportNo.:CISRR25081914801 Page 40 of 60 ReportNo.:CISRR25081914801 Page 41 of 60

FCCID:2A3VP-Q34B Label Size:10mm*8mm FCCID:2A3VP-Q34B LabelLocation

ReportNo.:CISRR25081914801 Page 42 of 60 7.2.InternalPhotos ReportNo.:CISRR25081914801 Page 43 of 60 ANT ReportNo.:CISRR25081914801 Page 44 of 60 ReportNo.:CISRR25081914801 Page 45 of 60

RFExposureevaluation FCCID2A3VP-Q34B ProductNameWirelessGamingController ModelNo.Q34B ListedModel(s)Q34、Q34BK、Q34BKM、Q34K、Q34M ExposurecategoryGeneralpopulation/uncontrolledenvironment EUTTypeProductionUnit DeviceTypePortableDevice 1.Reference ANSIC95.1–1999:IEEEStandardforSafetyLevelswithRespecttoHumanExposureto RadioFrequencyElectromagneticFields,3kHzto300GHz. FCCKDBpublication447498D01GeneralRFExposureGuidancev06:MobileandPortable DevicesRFExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1093:Radiofrequencyradiationexposureevaluation:portabledevices 2.Requirement AccordingtoKDB447498D01GeneralRFExposureGuidancev06Section4.3.1Standalone SARtestexclusionconsiderations:“UnlessspecificallyrequiredbythepublishedRFexposure KDBprocedures,standalone1-gheadorbodyand10-gextremitySARevaluationforgeneral populationexposureconditions,bymeasurementornumericalsimulation,isnotrequired whenthecorrespondingSARTestExclusionThresholdcondition,listedbelow,issatisfied. Thesetestexclusionconditionsarebasedonsource-basedtime-averagedmaximum conductedoutputpoweroftheRFchannelrequiringevaluation,adjustedfortune-uptolerance, andtheminimumtestseparationdistancerequiredfortheexposureconditions.22The minimumtestseparationdistanceisdeterminedbythesmallestdistancefromtheantenna andradiatingstructuresoroutersurfaceofthedevice,accordingtothehostformfactor, exposureconditionsandplatformrequirements,toanypartofthebodyorextremityofauser orbystander(see5)ofsection4.1).ToqualifyforSARtestexclusion,thetestseparation distancesappliedmustbefullyexplainedandjustifiedbytheoperatingconfigurationsand exposureconditionsofthetransmitterandapplicablehostplatformrequirements,typicallyin theSARmeasurementorSARanalysisreport,accordingtotherequiredpublishedRF exposureKDBprocedures.WhennootherRFexposuretestingorreportingisrequired,a statementofjustificationandcompliancemustbeincludedintheequipmentapproval,inlieuof theSARreport,toqualifyfortheSARtestexclusion.Whenrequired,thedevicespecific conditionsdescribedintheotherpublishedRFexposureKDBproceduresmustbesatisfied beforeapplyingtheseSARtestexclusionprovisions;forexample,handheldPTTtwo-way radios,handsets,laptops&tabletsetc.23” [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSARand≤7.5for10-gextremitySAR,where: •f(GHz)istheRFchanneltransmitfrequencyinGHz •PoweranddistanceareroundedtothenearestmWandmmbeforecalculation •Theresultisroundedtoonedecimalplaceforcomparison •3.0and7.5arereferredtoasthenumericthresholdsinthestep2below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingto5)insection4.1isappliedto determineSARtestexclusion. Whenoneofthefollowingtestexclusionconditionsissatisfiedforallcombinationsof simultaneoustransmissionconfigurations,furtherequipmentapprovalisnotrequiredto incorporatetransmittermodulesinhostdevicesthatoperateinthemixedmobileandportable hostplatformexposureconditions.Thegranteeisresponsiblefordocumentingthisaccording toClassIpermissivechangerequirements.AntennasthatqualifyforstandaloneSARtest exclusionmustapplytheestimatedstandaloneSARtodeterminesimultaneoustransmission testexclusion. a)The[∑of(thehighestmeasuredorestimatedSARforeachstandaloneantenna configuration,adjustedformaximumtune-uptolerance)/1.6W/kg]+[∑ofMPEratios]is≤ 1.0. b)TheSARtopeaklocationseparationratiosofallsimultaneouslytransmittingantennapairs operatinginportabledeviceexposureconditionsareall≤0.04,andthe[∑ofMPEratios]is≤ 1.0. 3.ConductedPeakOutputPower ModulationPacketTypeChannel PeakOutput Power (dBm) PeakOutput Power (mW) GFSKDH5 04.272.67 394.512.82 784.863.06 π/4DQPSK2-DH5 05.003.16 395.213.32 785.503.55 8DPSK3-DH5 04.372.74 394.632.90 784.983.15 ModulationPacketTypeChannel PeakOutput Power (dBm) PeakOutput Power (mW) GFSKBLE1M 03.992.51 194.172.61 394.582.87 4.ManufacturingTolerance BR/EDR DH5 ChannelChannel0Channel39Channel78 Target(dBm)444 Tolerance±(dB)1.01.01.0 2DH5 ChannelChannel0Channel39Channel78 Target(dBm)555 Tolerance±(dB)1.01.01.0 3DH5 ChannelChannel0Channel39Channel78 Target(dBm)444 Tolerance±(dB)1.01.01.0 BLE 1M ChannelChannel0Channel19Channel39 Target(dBm)344 Tolerance±(dB)1.01.01.0 5.EvaluationResult Band/Modef(GHz) Antenna Distance (mm) RFoutputpower SARTest Exclusion Threshold SARTest Exclusion dBmmW BR/EDR2.48056 3.98 1.2539<3.0Yes BLE2.48055 3.16 0.9960<3.0Yes Remark: 1.Outputpowerincludingtuneuptolerance; 2.Whentheminimumtestseparationdistanceis<5mm,adistanceof5mmaccordingtof)in section4.1isappliedtodetermineSARtestexclusion. 6.Conclusion ThemeasurementresultscomplywiththeFCCLimitper47CFR2.1093fortheuncontrolled RFExposureandSARExclusionThresholdperKDB447498D01V06. ------Endofthereport------

ShanWan 1.BasicInformation 1.1Testprinciple Antenna data sheet s ShanWan 1.2TestingFacility name model equipmentnumber manufacturer Dateofcalibration Nextcal- ibrationdate RayZone- 5000 OTAtestmacro RFI-LAB-RF-D00GTS2021.3.222023.3.21 networkanalyzer networkanalyzer E5071C E5071C RFI-LAB-RF-C02 RFI-LAB-RF-D01 KEYSIGHT KEYSIGHT 2022.5.13 2022.5.13 2023.5.12 2023.5.12 1.3TestingEnvironment Relativehumid- ityofambient temperature atmosphericpressure 23.7°C 58%RH 100.14kPa ShanWan 2.Photoofsampleitem 3.Sampletestplacementdiagram frontview ShanWan 3.TestResult 3.1TestBasis ObjectnameParametername antennapattern antennagain Methodname Accordingtothestandard number MobilecommunicationantennaGeneraltechnicalspecificationsformobilecommunicationantennas GB/T9410-2008 voltagestanding-waveratio Circularityofdirectiondiagram Gainanddirectionality radiationefficiency impedance ANSI/IEEEStd 149-1979 antenna IEEEantennateststandardprocess 3.2TestUncertainty UncertaintyiscalculatedbasedonISO's"GuidetotheExpressionofUncertaintyinMeasurement" (GUM),usingaK=2inclusionfactoranda95%confidenceleveltorepresenttheextendeduncertainty. project standing-wavera- tio Uncerta- inty±0.3 Gain,efficiency ±0.72dB ShanWan 3.3testdata 3.3.1Networkanalyzertest 3.3.2standing-waveratio frequency/MHz 240224402480 voltagestanding-waveratio 1.39101.46622.0735 3.3.3Gainandefficiency frequency/MHz maximumgain/dBi productiveness/ % 2402 2.85 2410 2.88 2420 2.79 2430 2.77 2440 2.69 2450 2.52 2460 2.46 2470 2.41 2480 2.03 44.9845.3444.9345.7446.0045.1445.5644.4940.81 3.3.4CircularityofDirectionDia- gram HTheta=90/d Frequency/MHz 2402 2410 2420 2430 2440 2450 2460 2470 2480 B 14.2214.4314.3113.6813.3813.3013.1813.3113.58 QP030-41 Page8of10 ShanWan 3.3.5DirectionalDiagram (1)X-Zplane(unit:dBi): (2)Y-Zplane(unit:dBi): ShanWan (3)X-Yplane(unit:dBi): (4)3DDirectionChartof2410MHz(unit:DBi): -------------------------------------------------End------------------------------------------------ (Thefollowingisblank)

ReportNo.:CISRR25081914802 Thetestresultsrelateonlytothetestedsamples. ThetestreportshouldnotbereproducedexceptinfullwithoutthewrittenapprovalofShenzhenBangce TestingTechnologyCo.,Ltd. Page1of43 TESTREPORT ReportNo.CISRR25081914802 ProjectNo.CISR250819148 FCCID2A3VP-Q34B ApplicantShenZhenShanWanTechnologyCo.,Ltd Address 5/F,building33,chentianIndustrialZone,chentiancommunity,Xixiang street,Bao'anDistrict,Shenzhen,Guangdong,China ManufacturerShenZhenShanWanTechnologyCo.,Ltd Address 5/F,building33,chentianIndustrialZone,chentiancommunity,Xixiang street,Bao'anDistrict,Shenzhen,Guangdong,China ProductNameWirelessGamingController TrademarkN/A Model/TypereferenceQ34B ListedModel(s) Q34、Q34BK、Q34BKM、Q34K、Q34M Standard 47CFRPart15.247 TestdateAugust20,2025toAugust23,2025 IssuedateAugust26,2025 TestresultComplied Preparedby:LucasHuangApprovedby:GenryLong ReportNo.:CISRR25081914802 Page 2 of 43 Contents 1.REPORTVERSION..........................................................................................................................................3 2.TESTDESCRIPTION.......................................................................................................................................4 3.SUMMARY........................................................................................................................................................5 3.1.ProductDescription*..................................................................................................................................5 3.2.RadioSpecificationDescription*..............................................................................................................5 3.3.ModificationofEUT.....................................................................................................................................6 3.4.Deviationfromstandards...........................................................................................................................6 3.5.TestingSite...................................................................................................................................................6 4.TESTCONFIGURATION.................................................................................................................................7 4.1.Testfrequencylist.......................................................................................................................................7 4.2.Descriptionsoftestmode...........................................................................................................................7 4.3.Supportunitusedintestconfiguration....................................................................................................7 4.4.Testsampleinformation.............................................................................................................................7 4.5.Environmentalconditions...........................................................................................................................7 4.6.Statementofthemeasurementuncertainty.............................................................................................8 4.7.EquipmentUsedduringtheTest................................................................................................................8 5.TESTRESULTS.............................................................................................................................................10 5.1.EvaluationResults(Evaluation)...............................................................................................................10 5.1.1.AntennaRequirement............................................................................................................................10 5.2.RadioSpectrumMatterTestResults(RF)...............................................................................................11 5.2.1.ConductedEmissionatACpowerline.................................................................................................11 5.2.2.6dBBandwidth........................................................................................................................................14 5.2.3.MaximumConductedOutputPower.....................................................................................................15 5.2.4.PowerSpectralDensity..........................................................................................................................16 5.2.5.Conductedbandedgeandspuriousemission...................................................................................17 5.2.6.Radiatedbandedgeemission...............................................................................................................18 5.2.7.RadiatedSpuriousEmission(below1GHz).........................................................................................24 5.2.8.RadiatedSpuriousEmission(Above1GHz)........................................................................................28 6.TESTSETUPPHOTOS..................................................................................................................................36 7.EXTERNALANDINTERNALPHOTOS........................................................................................................36 7.1.ExternalPhotos.........................................................................................................................................36 7.2.InternalPhotos...........................................................................................................................................36 8.APPENDIXREPORT......................................................................................................................................36 ReportNo.:CISRR25081914802 Page 3 of 43 1.REPORTVERSION VersionNo.IssuedateDescription 00August26,2025Original ReportNo.:CISRR25081914802 Page 4 of 43 2.TESTDESCRIPTION No.TestItemStandardRequirementResu…

Text truncated - open the document above for the full version.

ReportNo.:CISRR25081914801 Page 37 of 60 6.TESTSETUPPHOTOS ConductedEmissionatACpowerline Radiatedbandedgeemission RadiatedSpuriousEmission(Above1GHz) ReportNo.:CISRR25081914801 Page 38 of 60 RadiatedSpuriousEmission(below1GHz)
