2A64B-ZJ2622Floor Cleaning Robot

平面印刷品基本技术要求 科沃斯机器人股份有限公司 物料名称 莎士比亚S-美国-水箱版（顶配/高配/标配）-完整 版英文说明书 尺 寸145*210mm 型 号ZJ2583印刷颜色单色K 物料编码451-2583-0508装订方式骑马钉 版 次A阶 段A 材 质157g哑粉纸+80g双胶纸页 数36p 变更记录： 设计审核批准 ECOVACS：机密图档 PLD 2026.6.29 彭召艳 Instruction Manual Instruction Manual ���������������������������������������������������������������������������������������������EN I P03 3EN 1� Do not allow to be used as a toy� Close attention is necessary when used by or near children� 2� Clear the area to be cleaned� Remove power cords and small objects from the floor that could entangle the Appliance� Tuck rug fringe under the rug base, and lift items such as curtains and tablecloths off the floor� 3� If there is a drop off in the cleaning area due to a step or stairs, you should operate the Appliance to ensure that it can detect the step without falling over the edge� It may become necessary to place a physical barrier at the edge to keep the unit from falling� Make sure the physical barrier is not a trip hazard� 4� Only use as described in this manual� Only use attachments recommended or sold by the manufacturer� 5� Do not handle plug or appliance with wet hands� 6� Non-rechargeable batteries are prohibited� 7� Do not use without Dust Bin and/or Filters in place� 8� Do not operate the vacuum in an area where there are lit candles or fragile objects on the floor to be cleaned� 9� Do not use and store in extremely hot or cold environments (below -5 ̊C /23 ̊F or above 40 ̊C/104 ̊F)� Please charge the robot in temperature above 0°C/32°F and below 40°C/104°F� 10� Keep hair, loose clothing, fingers, and all parts of body away from any openings and moving parts� 11� Do not operate the Appliance in a room where an infant or child is sleeping� 12� For INDOOR use ONLY� Do not use the Appliance in outdoor, commercial or industrial environments� Do not use Appliance on wet surfaces or surfaces with standing water� 13� Do not allow the Appliance to pick up large IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. When using an electrical appliance, basic precautions should always be followed, including the following: WARNING: Read all safety warnings and instructions� Failure to follow the warnings and instructions may result in electric shock, fire, or serious injury� WARNING: To Reduce the Risk of Fire and Electric Shock – Use only ECOVACS cleaning products intended for use with this machine� See the Cleaning Fluid section of this manual� 4EN objects like stones, large pieces of paper, or any item that may clog the Appliance� 14� Do not use to pick up flammable or combustible materials such as gasoline, printer, or copier toner, or use in areas where they may be present� 15� Do not pick up anything that is burning or smoking, such as cigarettes, matches, hot ashes, or anything that could cause a fire� 16� Do not put any object into openings� Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce air flow� 17� Take care not to damage the power cord� Do not pull on or carry the Appliance or Docking Station by the power cord, use the power cord as a handle, close a door on the power cord, or pull power cord around sharp edges or corners� Do not run Appliance and Docking Station over the power cord� Keep power cord away from hot surfaces� Do not unplug by pulling on cord� To unplug, grasp the plug, not the cord� 18� If the power cord is damaged, it must be replaced by the manufacturer or its service agent in order to avoid a hazard� 19� Do not use with a damaged power cord or plug� Do not use the Appliance or Docking Station if it is not working properly, has been dropped, damaged, left outdoors, or come in contact with water� It must be repaired by the manufacturer or its service agent in order to avoid a hazard� 20� Turn OFF the power switch before cleaning or maintaining the Appliance� Turn off all controls before unplugging� Always turn off this appliance before connecting or disconnecting motorized nozzle� 21� Turn OFF the Power Switch before removing the Dust Bin� 22� Remove the Appliance from the Docking Station, and turn OFF the power switch to the Appliance before removing the battery for disposal of the Appliance� 23� The battery must be removed and discarded according to local laws and regulations before disposal of the Appliance� 24� Please dispose of used batteries according to local laws and regulations� 25� Do not incinerate the Appliance even if it is severely damaged� The batteries can explode in a fire� 26� When not using the Docking Station, unplug from outlet when not in use and before servicing� 27� The Appliance must be used in accordance with the directions in this Instruction Manual�Ecovacs 5EN Home Service Robotics cannot be held liable or responsible for any damages or injuries caused by improper use� 28� Prevent unintentional starting� Ensure the switch is in the off position before connecting to battery pack, picking up or carrying the appliance� 29� When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws, or other small metal objects, that can make a connection from one terminal to another� Shorting the battery terminals together may cause burns or a fire� 30� Under abusive conditions, liquid may be ejected from the battery; avoid contact� If contact accidentally occurs, flush with water� If liquid contacts eyes, additionally seek medical help� Liquid ejected from the battery may cause irritation or burns� 31� Do not use a battery pack or appliance that is damaged or modified� Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury� 32� Do not expose a battery pack or appliance to fire or excessive temperature� Exposure to fire or temperature above 130°C may cause explosion� The temperature of 130°C can be replaced by the temperature of 265°F� 33� Follow all charging instructions and do not charge the battery…

Text truncated - open the document above for the full version.

451-2583- ZJ2583 yeedi莎士比亚S-美-水箱版标配黑 -主机铭牌（卷装） 注： 1.单位：mm 2.流水号与年周号以物控下单为准！ 3.颜色以封样件为准！ 4.文字字体\排版以电子档确认为准！ 科沃斯机器人股份有限公司 第一视角 设计 标记 处数 分区变更单号材料 见技术要求 物料名称 型 号 物料编码 见技术要求 1:1 质量 比例 版次 阶段 第1页 共1页 审核批准 版次变更内容日期 尺寸展开区 位置示意图 1.尺寸公差：±0.5mm； 2.印刷套印清晰，内容准确、文字不缺笔断画、细微部无明显虚迹； 3.版面整洁，印张空白部分无油腻、墨污、墨杠、手形等污迹； 4.背面清洁无粘脏污迹； 5.无明显的划伤、翘曲、污垢； 6.无模切后的残留渣； 7.物料平整、无异物突出感觉、无卷曲现象； 8.70度高温下168小时不起翘、不脱落、不起泡； 9.通过酒精测试后不起翘、不脱落、不起泡； 表面处理 铭牌标贴基本技术要求 一、材质、工艺 二、质量要求 三、环保要求 零部件环保要求符合ECOVACS《特定有害物质限制标准》 印刷颜色 材 质 四、存储条件 适宜温度：0°C-40°C 适宜湿度：50-60%RH A A 单色K 背胶 型号 网纹背胶 GT69-142/雅得#9D4/金利宝HTYL75(EB)-C5 是否局部去胶粘贴表面 ABS否 75#压花马拉纸 长(mm) 宽(mm) 110 31 2-2.52-2.5 卷装底纸留白宽度为2.0mm—2.5mm 备注：品质QE反馈工厂打印机设备要求 哑膜 Label Location 粘贴位置 Conforms to UL Std.1017 Certied to CSA Std. C22.2 NO.243 5025506 YEEDI M16 PRO Floor Cleaning Robot/ Robot-nettoyeur de plancher/ Robot limpia pisos 材料要过UL认证 Model/Modèle/Modelo: ZJ2640 Rated Input/Entrée nominale/Entrada clasicada: 17.8V 2A Docking Station/Station d'accueil/Estación de carga: CH2603 For use only with Ecovacs Home Service Robotics Co., Ltd. CH2603 charger./ À utiliser uniquement avec le chargeur Ecovacs Home Service Robotics Co., Ltd. CH2603./ Solo para uso con los cargadores CH2603 de Ecovacs Home Service Robotics Co., Ltd. This Device Complies with DHHS Radiation Rules, 21 CFRChapter 1, Subchapter J./Cet appareil est conformeau x règles deradiationdu DHHS, 21CFR chapitre 1, sous-chapitre J. Th is device complies with part 15 ofthe FCC Rules. Operation is subject to the following twoconditions: (1) This device may not cause harmful interference, and (2) this device mustacceptany interfer ence received, including interference th at may cause undesired operation. CAN ICES (B)/NMB (B) FCC ID:2A64B-ZJ2622 IC:25893-ZJ2622 MADE IN CHINA/FAIT EN CHINE/HECHO ENCHINA R=3 mm 二维码尺寸：10*10mm 二维码内容-SN规则： XXXXXXXXXXXX00000000 20位，同ID，同二维码 第1位（黄色）：供应商代号（统一用M代替） 第2-12（绿色）：物料ID，十一位 第12-20（蓝色）：统一八个零代替 备注：二维码印刷需清晰可识别。 用途：仅厂内绑定追溯用。 110 mm 31 mm 生产日期按照实际订单要求由 工厂自行打印， 格式MM(月份)/YYYY（年份），比如12/2025

FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Setup FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622

Ecovacs Home Service Robotics Co., Ltd. RF TEST REPORT Report Type: FCC Part 15.247 & ISED RSS-247 RF report Model: ZJ2622, ZJ2640 REPORT NUMBER: 2606B2012SHA-002 ISSUE DATE: April 7, 2026 DOCUMENT CONTROL NUMBER: TTRF15.247-03_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd. Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-03_V1 © 2018 Intertek Page 2 of 36 Report no.: 2606B2012SHA-002 Applicant: Ecovacs Home Service Robotics Co., Ltd. No.518 Songwei Road,Wusongjiang industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China. Manufacturer: Same as applicant Factory: Ecovacs Home Service Robotics Co., Ltd. No.518 Songwei Road, Wusongjiang industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China. FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2024): Radio Frequency Devices (Subpart C) ANSI C63.10 (2020) +Cor.1(2023) +C63.10a (2024) +Errata to C63.10a(2024): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices RSS-247 Issue 4 (July 2025): Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence- Exempt Local Area Network (LE-LAN) Devices RSS-Gen Issue 5 (April 2018) +A1(March 2019) +A2(February 2021): General Requirements for Compliance of Radio Apparatus PREPARED BY: REVIEWED BY: Project Engineer Eric Li Reviewer Wakeyou Wang Report No.: 2606B2012SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 3 of 36 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 7 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 7 1.3 ANTENNA INFORMATION....................................................................................................................................... 8 1.4 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 8 2 TEST SPECIFICATIONS ................................................................................................................................... 9 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................... 9 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................... 9 2.3 TEST SOFTWARE LIST .......................................................................................................................................... 10 2.4 TEST PERIPHERALS LIST ....................................................................................................................................... 10 2.5 TEST ENVIRONMENT CONDITION: .......................................................................................................................... 10 2.6 INSTRUMENT LIST .............................................................................................................................................. 11 2.7 MEASUREMENT UNCERTAINTY ............................................................................................................................. 12 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 13 3.1 LIMIT .............................................................................................................................................................. 13 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 13 3.3 TEST CONFIGURATION ........................................................................................................................................ 13 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ....................................................................................................... 13 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 14 4.1 LIMIT .......................................................................................................…

Text truncated - open the document above for the full version.

Ecovacs Home Service Robotics Co., Ltd. RF TEST REPORT Report Type: FCC Part 15.247 & ISED RSS-247 RF report Model: ZJ2622, ZJ2640 REPORT NUMBER: 2606B2012SHA-001 ISSUE DATE: July 7, 2026 DOCUMENT CONTROL NUMBER: TTRF15.247-02_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd. Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-02_V1 © 2018 Intertek Page 2 of 33 Report no.: 2606B2012SHA-001 Applicant: Ecovacs Home Service Robotics Co., Ltd. No.518 Songwei Road,Wusongjiang industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China. Manufacturer: Same as applicant Factory: Ecovacs Home Service Robotics Co., Ltd. No.518 Songwei Road, Wusongjiang industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China. FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2024): Radio Frequency Devices (Subpart C) ANSI C63.10 (2020) +Cor.1(2023) +C63.10a (2024) +Errata to C63.10a(2024): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices RSS-247 Issue 4 (July 2025): Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence- Exempt Local Area Network (LE-LAN) Devices RSS-Gen Issue 5 (April 2018) +A1(March 2019) +A2(February 2021): General Requirements for Compliance of Radio Apparatus PREPARED BY: REVIEWED BY: Project Engineer Eric Li Reviewer Wakeyou Wang Report No.: 2606B2012SHA-001 TEST REPORT TTRF15.247-02_V1 © 2018 Intertek Page 3 of 33 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 7 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 7 1.3 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 8 2 TEST SPECIFICATIONS ................................................................................................................................... 9 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................... 9 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................... 9 2.3 TEST SOFTWARE LIST .......................................................................................................................................... 10 2.4 TEST PERIPHERALS LIST ....................................................................................................................................... 10 2.5 TEST ENVIRONMENT CONDITION: .......................................................................................................................... 10 2.6 INSTRUMENT LIST .............................................................................................................................................. 11 2.7 MEASUREMENT UNCERTAINTY ............................................................................................................................. 12 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 13 3.1 LIMIT .............................................................................................................................................................. 13 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 13 3.3 TEST CONFIGURATION ........................................................................................................................................ 13 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ....................................................................................................... 13 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 14 4.1 LIMIT .............................................................................................................................................................. 14 4.2 MEASUREMENT PROCEDURE .............................................................................…

Text truncated - open the document above for the full version.

FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Appendix B of 2606B2012SHA-002: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 9.080 2407.440 2416.520 0.5 PASS 11B Ant1 2437 9.040 2432.000 2441.040 0.5 PASS 11B Ant1 2462 8.560 2457.480 2466.040 0.5 PASS 11G Ant1 2412 16.320 2403.840 2420.160 0.5 PASS 11G Ant1 2437 16.320 2428.840 2445.160 0.5 PASS 11G Ant1 2462 16.320 2453.840 2470.160 0.5 PASS 11N20SISO Ant1 2412 16.640 2403.840 2420.480 0.5 PASS 11N20SISO Ant1 2437 17.520 2428.240 2445.760 0.5 PASS 11N20SISO Ant1 2462 17.520 2453.240 2470.760 0.5 PASS 11N40SISO Ant1 2422 35.120 2404.480 2439.600 0.5 PASS 11N40SISO Ant1 2437 34.720 2419.880 2454.600 0.5 PASS 11N40SISO Ant1 2452 35.200 2434.560 2469.760 0.5 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 14.838 2404.5748 2419.4128 --- --- 11B Ant1 2437 14.877 2429.5783 2444.4553 --- --- 11B Ant1 2462 14.874 2454.5505 2469.4245 --- --- 11G Ant1 2412 16.930 2403.4763 2420.4063 --- --- 11G Ant1 2437 17.095 2428.5343 2445.6293 --- --- 11G Ant1 2462 16.968 2453.5212 2470.4892 --- --- 11N20SISO Ant1 2412 18.083 2402.9798 2421.0628 --- --- 11N20SISO Ant1 2437 18.065 2427.9680 2446.0330 --- --- 11N20SISO Ant1 2462 18.049 2452.9890 2471.0380 --- --- 11N40SISO Ant1 2422 35.911 2404.0702 2439.9812 --- --- 11N40SISO Ant1 2437 35.891 2419.0853 2454.9763 --- --- 11N40SISO Ant1 2452 35.837 2434.1067 2469.9437 --- --- FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs 11B-Ant1-2412 11B-Ant1-2437 11B-Ant1-2462 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11G-Ant1-2412 11G-Ant1-2437 11G-Ant1-2462 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N20SISO-Ant1-2412 11N20SISO-Ant1-2437 11N20SISO-Ant1-2462 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N40SISO-Ant1-2422 11N40SISO-Ant1-2437 11N40SISO-Ant1-2452 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Maximum conducted output power Test Result Average Test Mode Ant Frequency [MHz] Average power [dBm] Duty Cycle [%] DC Factor [dBm] Result [dBm] Limit [dBm] Gain [dBi] EIRP [dBm] EIRP Limit [dBm] Verdict 11B Ant1 2412 16.49 99.04 0.04 16.53 ≤30.00 1.10 17.63 ≤36.00 PASS 11B Ant1 2437 16.20 69.46 0.05 16.25 ≤30.00 1.10 17.35 ≤36.00 PASS 11B Ant1 2462 16.60 98.81 0.05 16.65 ≤30.00 1.10 17.75 ≤36.00 PASS 11G Ant1 2412 13.94 92.79 0.32 14.26 ≤30.00 1.10 15.36 ≤36.00 PASS 11G Ant1 2437 15.76 95.37 0.21 15.97 ≤30.00 1.10 17.07 ≤36.00 PASS 11G Ant1 2462 14.75 91.96 0.36 15.11 ≤30.00 1.10 16.21 ≤36.00 PASS 11N20SISO Ant1 2412 14.08 91.43 0.39 14.47 ≤30.00 1.10 15.57 ≤36.00 PASS 11N20SISO Ant1 2437 15.68 92.75 0.33 16.01 ≤30.00 1.10 17.11 ≤36.00 PASS 11N20SISO Ant1 2462 14.64 92.31 0.35 14.99 ≤30.00 1.10 16.09 ≤36.00 PASS 11N40SISO Ant1 2422 11.06 87.04 0.60 11.66 ≤30.00 1.10 12.76 ≤36.00 PASS 11N40SISO Ant1 2437 12.10 84.68 0.72 12.82 ≤30.00 1.10 13.92 ≤36.00 PASS 11N40SISO Ant1 2452 11.82 86.24 0.64 12.46 ≤30.00 1.10 13.56 ≤36.00 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs Average 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -14.92 ≤8.00 PASS 11B Ant1 2437 -13.83 ≤8.00 PASS 11B Ant1 2462 -14.43 ≤8.00 PASS 11G Ant1 2412 -16.97 ≤8.00 PASS 11G Ant1 2437 -15.24 ≤8.00 PASS 11G Ant1 2462 -16.16 ≤8.00 PASS 11N20SISO Ant1 2412 -17.10 ≤8.00 PASS 11N20SISO Ant1 2437 -15.55 ≤8.00 PASS 11N20SISO Ant1 2462 -16.50 ≤8.00 PASS 11N40SISO Ant1 2422 -21.32 ≤8.00 PASS 11N40SISO Ant1 2437 -20.59 ≤8.00 PASS 11N40SISO Ant1 2452 -20.22 ≤8.00 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Band edge measurements Test Result TestMode Antenna ChName Frequency [MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 7.67 -34.12 ≤-22.33 PASS 11B Ant1 High 2462 7.18 -48.07 ≤-22.82 PASS 11G Ant1 Low 2412 2.57 -32.92 ≤-27.43 PASS 11G Ant1 High 2462 3.17 -47.04 ≤-26.83 PASS 11N20SISO Ant1 Low 2412 2.83 -32.81 ≤-27.17 PASS 11N20SISO Ant1 High 2462 3.59 -44.17 ≤-26.41 PASS 11N40SISO Ant1 Low 2422 -2.67 -40.23 ≤-32.67 PASS 11N40SISO Ant1 High 2452 -1.35 -42.96 ≤-31.35 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2462-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2452-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Conducted Spurious Emission Test Result TestMode Antenna Frequency [MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 0~Reference 7.24 7.24 --- PASS 11B Ant1 2412 30~1000 7.24 -62.35 ≤-22.76 PASS 11B Ant1…

Text truncated - open the document above for the full version.

FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Appendix A of 2606B2012SHA-001 DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.724 2401.640 2402.364 0.5 PASS BLE_1M Ant1 2440 0.720 2439.640 2440.360 0.5 PASS BLE_1M Ant1 2480 0.708 2479.640 2480.348 0.5 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 1.0377 2401.4949 2402.5326 --- --- BLE_1M Ant1 2440 1.0367 2439.4953 2440.5320 --- --- BLE_1M Ant1 2480 1.0445 2479.4916 2480.5361 --- --- FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 BLE_1M-Ant1-2480 FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Maximum conducted output power Test Result Peak TestMode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] EIRP[dBm] EIRP Limit[dBm] Verdict BLE_1M Ant1 2402 5.05 ≤30 6.15 ≤36 PASS BLE_1M Ant1 2440 5.00 ≤30 6.10 ≤36 PASS BLE_1M Ant1 2480 5.46 ≤30 6.56 ≤36 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs Peak BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -10.34 ≤8.00 PASS BLE_1M Ant1 2440 -10.35 ≤8.00 PASS BLE_1M Ant1 2480 -10.10 ≤8.00 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Band edge measurements Test Result TestMode Antenna ChName Frequency [MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 3.85 -48.67 ≤-16.16 PASS BLE_1M Ant1 High 2480 4.22 -47.77 ≤-15.78 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Conducted Spurious Emission Test Result TestMode Antenna Frequency [MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 0~Reference 4.17 4.17 --- PASS BLE_1M Ant1 2402 30~1000 4.17 -62.41 ≤-15.83 PASS BLE_1M Ant1 2402 1000~26500 4.17 -38.26 ≤-15.83 PASS BLE_1M Ant1 2440 0~Reference 4.06 4.06 --- PASS BLE_1M Ant1 2440 30~1000 4.06 -62.04 ≤-15.94 PASS BLE_1M Ant1 2440 1000~26500 4.06 -26.46 ≤-15.94 PASS BLE_1M Ant1 2480 0~Reference 4.64 4.64 --- PASS BLE_1M Ant1 2480 30~1000 4.64 -63.2 ≤-15.36 PASS BLE_1M Ant1 2480 1000~26500 4.64 -37.4 ≤-15.36 PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 Test Graphs BLE_1M-Ant1-2402-0~Reference-PASS BLE_1M-Ant1-2402-30~1000-PASS BLE_1M-Ant1-2402-1000~26500-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 BLE_1M-Ant1-2440-0~Reference-PASS BLE_1M-Ant1-2440-30~1000-PASS BLE_1M-Ant1-2440-1000~26500-PASS FCC ID: 2A64B-ZJ2622 IC: 28593-ZJ2622 BLE_1M-Ant1-2480-0~Reference-PASS BLE_1M-Ant1-2480-30~1000-PASS BLE_1M-Ant1-2480-1000~26500-PASS

Ecovacs Home Service Robotics Co., Ltd. MPE ASSESSMENT REPORT Report Type: FCC Part §2.1091 and §1.1307(b) assessment report Model: ZJ2622, ZJ2640 REPORT NUMBER: 2606B2012SHA-003 ISSUE DATE: July 8, 2026 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-01_V1 © 2018 Intertek Intertek Testing Services (Shanghai FTZ) Co., Ltd. Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or da…

Text truncated - open the document above for the full version.
