Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A66I-D18 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 2 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2A66I-D18 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 2 Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] BLE_1M Ant1 2402 1.13 0.5 1 -5.25 1.5 1.41 2.79 BLE_1M Ant1 2440 1.66 1 1 -5.25 2 1.58 2.75 BLE_1M Ant1 2480 1.62 1 1 -5.25 2 1.58 2.72 BLE_2M Ant1 2402 0.23 -0.5 1 -5.25 0.5 1.12 2.79 BLE_2M Ant1 2440 1.26 1 1 -5.25 2 1.58 2.75 BLE_2M Ant1 2480 1.51 1 1 -5.25 2 1.58 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

1 深圳市迎丰天线技术有限公司 客 户 凌安无线 D18 Test Report 1 产 品 D18 工程师 徐勇 电 话 15195746167 邮 箱 [email protected] 日 期 2025-11-28 2 深圳市迎丰天线技术有限公司 测试设备 样机外观 匹配参数 网分调试天线S参数 整机自由场效率 整机自由场场型 拉距测试 调试总结 报告目录 3 深圳市迎丰天线技术有限公司 •1.S参数测量 •2.设备:网络分析仪(Agilent E5062A),微波暗室，MT8852B •3.项目:阻抗，回波损耗，VSWR，效率，增益，辐射场型,灵敏度，功率 ,频偏 有源数据TRP TIS 测试条件 4 深圳市迎丰天线技术有限公司 D18 Appearance Overall appearance P CBA 深圳市迎丰天线技术有限公司 No. 型号 规格 厂商 料号 公差 1 O n-board 2 NC 3 Capacitor 10PF/0402 村田 ±0.1PF Matching parameters (on-board ring) 5 4 NC 5 6 深圳市迎丰天线技术有限公司 remote control Network division debugging antenna S parameters Debugging waveform 7 深圳市迎丰天线技术有限公司 Remote control efficiency Freq(MHz)Gain(dBi)Efficiency(dB) Efficiency(%) 2400 -5.638819625-9.082557591 12.35219789 2410-5.525699349-8.98747733 12.62560701 2420-5.483687137-8.97032589 12.67556746 2430 -5.470403454-8.915894575 12.83543354 2440 -5.34501599-8.763098944 13.295054 2450 -5.411438619-8.776286544 13.25474404 2460 -5.590595727-8.914002735 12.84102603 2470 -5.520103724-8.812247635 13.14544331 E fficiency of the whole machine in free field 7 2480 -5.28507728-8.69594234 13.50223822 2490-5.36207069-8.765474855 13.28778261 2500-5.25685849-8.702283996 13.48253637 13 深圳市迎丰天线技术有限公司 F ield diagram Y 一 X F ree-field configuration of the whole machine Z 13 14 深圳市迎丰天线技术有限公司 1.Do not run the battery wire through the antenna area. Summary 15 深圳市迎丰天线技术有限公司 Thanks for Your Attention

Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 1 of 33 Appendix Test Data for BLE (Conducted Measurement) Product Name: Bluetooth remote control Trade Mark: Qring Test Model: D18 FCC ID: 2A66I-D18 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: DTS Bandwidth Test Result Test Mode Antenna Frequency [MHz] DTS BW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict BLE_1M Ant1 2402 0.700 2401.652 2402.352 0.5 PASS BLE_1M Ant1 2440 0.696 2439.660 2440.356 0.5 PASS BLE_1M Ant1 2480 0.668 2479.672 2480.340 0.5 PASS BLE_2M Ant1 2402 1.248 2401.368 2402.616 0.5 PASS BLE_2M Ant1 2440 1.152 2439.448 2440.600 0.5 PASS BLE_2M Ant1 2480 1.144 2479.440 2480.584 0.5 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 2 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 3 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 4 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 5 of 33 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict BLE_1M Ant1 2402 1.0277 2401.4917 2402.5194 --- --- BLE_1M Ant1 2440 1.0294 2439.4924 2440.5218 --- --- BLE_1M Ant1 2480 1.0232 2479.4944 2480.5176 --- --- BLE_2M Ant1 2402 2.0762 2400.9890 2403.0652 --- --- BLE_2M Ant1 2440 2.0575 2438.9943 2441.0518 --- --- BLE_2M Ant1 2480 2.0634 2478.9929 2481.0563 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 6 of 33 Test Graphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 7 of 33 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 8 of 33 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 9 of 33 Appendix C: Maximum peak conducted output power Test Result Peak Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict BLE_1M Ant1 2402 1.13 ≤30 PASS BLE_1M Ant1 2440 1.66 ≤30 PASS BLE_1M Ant1 2480 1.62 ≤30 PASS BLE_2M Ant1 2402 0.23 ≤30 PASS BLE_2M Ant1 2440 1.26 ≤30 PASS BLE_2M Ant1 2480 1.51 ≤30 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 10 of 33 Test Graphs Peak BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 11 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 12 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 13 of 33 Appendix D: Maximum peak power spectral density Test Result Test Mode Antenna Frequency [MHz] Result [dBm/3kHz] Limit [dBm/3kHz] Verdict BLE_1M Ant1 2402 -14.58 ≤8.00 PASS BLE_1M Ant1 2440 -14.61 ≤8.00 PASS BLE_1M Ant1 2480 -12.34 ≤8.00 PASS BLE_2M Ant1 2402 -18.41 ≤8.00 PASS BLE_2M Ant1 2440 -16.45 ≤8.00 PASS BLE_2M Ant1 2480 -16.50 ≤8.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 14 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 15 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 16 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 17 of 33 Appendix E: Band edge measurements Test Result Test Mode Antenna Ch. Name Frequency [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict BLE_1M Ant1 Low 2402 1.01 -48.66 ≤-18.99 PASS BLE_1M Ant1 High 2480 0.69 -48.76 ≤-19.31 PASS BLE_2M Ant1 Low 2402 -0.25 -35.85 ≤-20.25 PASS BLE_2M Ant1 High 2480 -1.43 -49.02 ≤-21.43 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 18 of 33 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 19 of 33 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 20 of 33 Appendix F: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] Freq. Range [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict BLE_1M Ant1 2402 0~Reference 0.88 0.88 --- PASS BLE_1M Ant1 2402 30~1000 0.88 -52.79 ≤-19.12 PASS BLE_1M Ant1 2402 1000~26500 0.88 -38.03 ≤-19.12 PASS BLE_1M Ant1 2440 0~Reference 0.48 0.48 --- PASS BLE_1M Ant1 2440 30~1000 0.48 -52.66 ≤-19.52 PASS BLE_1M Ant1 2440 1000~26500 0.48 -37.23 ≤-19.52 PASS BLE_1M Ant1 2480 0~Reference 0.57 0.57 --- PASS BLE_1M Ant1 2480 30~1000 0.57 -52.42 ≤-19.43 PASS BLE_1M Ant1 2480 1000~26500 0.57 -37.28 ≤-19.43 PASS BLE_2M Ant1 2402 0~Reference -0.37 -0.37 --- PASS BLE_2M Ant1 2402 30~1000 -0.37 -56.42 ≤-20.37 PASS BLE_2M Ant1 2402 1000~26500 -0.37 -38.05 ≤-20.37 PASS BLE_2M Ant1 2440 0~Reference -2.01 -2.01 --- PASS BLE_2M Ant1 2440 30~1000 -2.01 -57.91 ≤-22.01 PASS BLE_2M Ant1 2440 1000~26500 -2.01 -37.74 ≤-22.01 PASS BLE_2M Ant1 2480 0~Reference 1.08 1.08 --- PASS BLE_2M Ant1 2480 30~1000 1.08 -58.21 ≤-18.92 PASS BLE_2M Ant1 2480 1000~26500 1.08 -37.28 ≤-18.92 PASS Note: offset(dB) in Reference test plots = cable loss(dB) + attenuator factor(dB); For spurious emissions plots from 30MHz to 26.5GHz, the cable loss and attenuator factors have been set in the 'Input Correction' of the Spectrum Analyzer during the test. Appendix Test Data of the Report No.: TZ0128251102FRF02 Page 21 of 33 Test Graphs BLE_1M-Ant1-2402-0~Reference-PASS BLE_1M-Ant1-2402-30~1000-PASS Appendix Test Data of…
