2A7VPC6401ASmart String Lights

Thank you for choosing the C6401-B. In order to optimize the us er experience, please read this manual carefully before operation, and keep this manual properly for future use. Download Free APP: Smart Life Download on the GET IT ON Google Play App Store Model:C6401-B Warning: 1. This product is not a toy. To avoid fire, burns, personal in jury or electric shock, please install out of the reach of children.2. In order to ensure the normal operation of the lamp, please use the voltage indicated on the package.3. Please do not modify the lamps during the warranty period.4. Do not install near gas or electric heaters, fires, candles or any dangerous objects.5. Before installation, please check whether the lamps and vari ous parts are in good condition.6. Be sure to cut off the power before installation.7. Do not expose the lamp to corrosive conditions.8. If the power cord is damaged, please cut off the power immed iately and stop using it. dĞĐŚŶŝĐĂů^ƉĞĐŝĮĐĂƟŽŶ͗ Connection method: 2.4G Wifi&BluetoothControl method: APP/Voice/ButtonAdapter input voltage:100-240VACAdapter output voltage: 12VDC/3ARated working voltage: DC12VRated power: 30WLamp color: RGB Memory function: yesWorking temperature: -20 ~+40 Controller levels of protection:IP20Lamps levels of protection: IP65Work with Amazon Alexa and Google Assistant. 1. C015 Controller * 12. Remote Control * 13. Waterproof power supply 12V/3A wall plug horizontal American standard UL (IP44) * 14. Christmas LED String Lights * (100 pixels)5. Copy of the manual * 16. After sales service card * 1 WĂĐŬŝŶŐůŝƐƚ͗ DĂŶƵĂůŽĨŽŶƚƌŽůůĞƌ͗ Button Instruction:Switch : Short press is on/off. When the device is on, long press in 5 seconds is reset to pairing mode. Light will blink in red. WƌŽĚƵĐƚǁŝƌŝŶŐĚŝĂŐƌĂŵ͗ 1500mm 4.92ft 130mm 0.42ft 12870mm42.22ft Total lights:100pcs 1500mm 4.92ft 1000mm 3.28ft ^ŝnjĞ͗ 33mm1.29ft 11mm0.43ft7mm0.27ft Custom modeYou can DIY your favorite color sceneCollection modeLong press the icon to collect your favorite dynamic scenes, or long press the icon to delete the dynamic scenes you don't need Select a scene list to select different scene types Set name for DIY mode to reserve.It supports gradient, jump, breathing, flashing, flowing water, rainbow and othermodes DIY.Slide the slider to adjust the brightness of the lampClick "+" to add your favorite colorIntact:set the lamp to one colorSection:divide the light into multiple segments and set them to different colors Switching between local microphone mode and mobilemusic mode Different music scenesand sensitivity modulation Add color with one clickAdd color individuallyErase ColorAdd pointsColor light and white light adjustmentSwipe the brightnessbar to adjust the light brightness in thecurrent static mode color adjustmentYou can move the color dialclockwise or counterclockwiseto adjust your preferred color to the white circle, which canbe adjusted left or right to adjust the color fullness C6401-B APP Intelligent operation introduction: APP Download. Search the Smart Life from Google Play or App Store. You can also scan the QR code from below.1.Download the APP and Log In with existing account or Sign Up the new account. Pairing Instruction: iOS App Store Android Google Play 2.Power on the device, confirm the device is blinking rapidly i n white. Turn on the Bluetooth and Wi-Fi of phone. Please make sure the phone is connecting the 2.4GHz Wi-Fi router. 3.Tap Add Device or the plus icon (+) in the top-right corner on the Home page to go to the device adding page. 4.Enter the Wi-Fi password and click Next. Make sure the Wi-Fi is 2.4GHz not the 5GHz. Because the Wi-Fi chip is 2.4GHz. Wait about twen ty seconds and the device will be added completely. C6401-B C6401-B C6401-B 6.Click the edit icon in the upper right corner to show more ga meplay. 5.Then the device can be found in home page. Now you can play i t with your imagination. 1. Please make sure to perform network pairing in 2.4G wifi or hotspot mode;2. If the connection times out or the network connection cannot be reached, please reconnect to a strong signal location; EŽƟĐĞ͗ Modify device name Linkage with other equipment Share control with family Linkage with other devices to achieve one-click execution and automation C6401-B C6401-B 2. This warranty does not include:(1) Malfunction or damage caused by improper use, repair or mod ification. (2) Failure or damage due to falling.(3) Failure or damage caused by fire, earthquake, flood, lightn ing and other natural disasters.1. Unable to connect to your Wi-Fi network.(1). Please ensure that the correct Wi Fi password is entered d uring use. (2). Ensure that the connection is 2.4G wifi and that the devic e currently does not support 5G wifi,(3). Check if there are any issues with your internet connectio n. If the Wi Fi signal is too weak, please move to a place with a strong sig nal or reset the wireless router and try again.2. The installer is not working properly.(1)Then close all applications running in the background and re open the Smart Life APP.(2) Uninstall and reinstall the Smart Life app and repeat.3. The smart string light is not responding.(1) Check whether the smart string light is turned off. If yes, turn them on and wait until the smart light strip reconnects to The wireless network works automatically.(2) Check if there is any problem with your internet connection . If neces- sary, reset the wireless router and try again. ůƵĞƚŽŽƚŚĐŽŶƚƌŽůƐƚĞƉƐNote: The device has already joined my app normally (2.4GWIFI+B lue- tooth is required for the first connection),Bluetooth control i s generally used for devices with poor WIFI signals or disconnected network connections;1. Turn off the phone's WiFi;2. Turn on Bluetooth and open the device on the APP;Then the device can be controlled through Bluetooth; ŽŵŵŽŶƉƌŽďůĞŵƐĂŶĚƐŽůƵƟŽŶƐ͗'ƵĂƌĂŶƚĞĞ͗1. During the warranty period, we provide services including re funds or free replacement for those who use the device for its intende…

Text truncated - open the document above for the full version.

(Shenzhen Jindian Zhiguang Lighting Co.,Ltd) (Jun. 29, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2A7VPC6401A) [Shenzhen Jindian Zhiguang Lighting Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Chengzhou Pan (Shenzhen Jindian Zhiguang Lighting Co.,Ltd) (Jun. 29, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2A7VPC6401A) [Shenzhen Jindian Zhiguang Lighting Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Chengzhou Pan

Attestation Statements (Jun. 29, 2023) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID:2A7VPC6401A) (Shenzhen Jindian Zhiguang Lighting Co.,Ltd), the undersigned, hereby authorize (SOUTH BAY INNOVATION LLC) to act as our designated U.S. agent for service of process, (Shenzhen Jindian Zhiguang Lighting Co.,Ltd) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (SOUTH BAY INNOVATION LLC) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: Shenzhen Jindian Zhiguang Lighting Co.,Ltd Contact Name: Chenzhou Pan Address: D402, Shengyang Industrial Zone, No.3, Shunv Road, Longhua District, Shenzhen Telephone No: 13538214502 Email: [email protected] U.S. Agent Information: Company Name: SOUTH BAY INNOVATION LLC Address: 23545 CRENSHAW BLVD STE 106 Torrance, CA 90505 Contact Name: Yueting Zhu Telephone No: 4243769142 Email: [email protected] FRN: 0033401811 Applicant Signature: Agent Signature: Applicant printed name: Chenzhou Pan Agent printed name: Yueting Zhu

Shenzhen Jindian Zhiguang Lighting Co.,Ltd Model Difference Data：2023.06.29 Product description: Smart String Lights Model name: C6401-A, C6101-A, C6101-B, C6101-C, C6101-D, C6101-E, C6101-F, C6101-G, C6101-H, C6102-A, C6201-A, C6202-A, C6203-A, C6203-B, C6301-A, C6301-B, C6302-A, C6302-B, C6303-A, C6303-B, C6304-A, C6304-B, C6305-A, C6305-B, C6401-B, C6501-A, C6501-B, C6504-A, C6504-B, C6507-A, C6507-B, C6508-A, C6508-B, C6505-A, C6505-B, C6506-A, C6506-B, C6506-C, C6506-D, C5101-A, C5101-B, C5101-C, C5101-D, C5101-E, C5101-F, C5102-A, C5102-B, C5102-C, C5103-A, C5103-B, C5103-C, C5103-D, C5104-A, C5104-B, C5105-A, C5105-B, C5201-A, C5201-B, C5201-C, C5201-D, C5202-A, C5202-B, C5202-C, C5202-D, C5203-A, C5203-B, C5203-C, C5203-D , fbaws2811string50p, fbaws2811dc12v50p, dc12vws2811s500p, fbaws2811string500p, ws2811dc5vr, ws2811dc12vr, ws2811dc5vL, ws2811dc12vL, WS2811DC5VA, WS2811DC12VA, TB-I6W9-GVJ6, FWY-MXL-6ZX , odldc12v50p, odldc5v50p, ODLDC12V, ODLDC5V, ODLDC12V5B, ODLDC5V5B, string5v, string12v, ADDC5VR50PbLACK, ADDC5VR500P, ADDC12VR500PbLACK, ADDC5VR50P, ADDC12VR500P, ADDC12VR50P, ADDC5VR500PbLACK, ADDC12VR50PbLACK, AORDC5V, AORDC12V Trade Name:N/A FCC ID: 2A7VPC6401A All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature : Client’s name / title : Chenzhou Pan（Manager） Contact information / address：D402, Shengyang Industrial Zone, No.3, Shunv Road, Longhua District, Shenzhen

Shenzhen Jindian Zhiguang Lighting Co.,Ltd (2023.06.29) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart String Lights / C6401-A, C6101-A, C6101-B, C6101-C, C6101-D, C6101-E, C6101-F, C6101-G, C6101-H, C6102-A, C6201-A, C6202-A, C6203-A, C6203-B, C6301-A, C6301-B, C6302-A, C6302-B, C6303-A, C6303-B, C6304-A, C6304-B, C6305-A, C6305-B, C6401-B, C6501-A, C6501-B, C6504-A, C6504-B, C6507-A, C6507-B, C6508-A, C6508-B, C6505-A, C6505-B, C6506-A, C6506-B, C6506-C, C6506-D, C5101-A, C5101-B, C5101-C, C5101-D, C5101-E, C5101-F, C5102-A, C5102-B, C5102-C, C5103-A, C5103-B, C5103-C, C5103-D, C5104-A, C5104-B, C5105-A, C5105-B, C5201-A, C5201-B, C5201-C, C5201-D, C5202-A, C5202-B, C5202-C, C5202-D, C5203-A, C5203-B, C5203-C, C5203-D , fbaws2811string50p, fbaws2811dc12v50p, dc12vws2811s500p, fbaws2811string500p, ws2811dc5vr, ws2811dc12vr, ws2811dc5vL, ws2811dc12vL, WS2811DC5VA, WS2811DC12VA, TB-I6W9- GVJ6, FWY-MXL-6ZX , odldc12v50p, odldc5v50p, ODLDC12V, ODLDC5V, ODLDC12V5B, ODLDC5V5B, string5v, string12v, ADDC5VR50PbLACK, ADDC5VR500P, ADDC12VR500PbLACK, ADDC5VR50P, ADDC12VR500P, ADDC12VR50P, ADDC5VR500PbLACK, ADDC12VR50PbLACK, AORDC5V, AORDC12V / FCC ID: 2A7VPC6401A ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Chenzhou Pan Title: Manager

Shenzhen Jindian Zhiguang Lighting Co.,Ltd (2023.06.29) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Chenzhou Pan Title: Manager

External Photos

FCC ID LABEL: Label Location: FCC ID: 2A7VPC6401A Model No.: C6401-A

Internal Photos ANT

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2A7VPC6401A Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result 2.4G WIFI 802.11b&2 412 14±1 15 31.6228 1.6634 (2.21dBi) 0.0105 1 Pass BLE GFSK&LC H -1±1 0 1 1.6634 (2.21dBi) 0.0003 1 Pass
