2A9PI-L1Mobile Lidar Scanner

Lixel L1 User Manual User Manual Contents 目录 Product Overview ......................................................................................................................................................... 1 Operation .......................................................................................................................................................................... 2 1、Battery installation .................................................................................................................................................. 2 2、Tripod Installation ........................................................................................................................................................ 3 3、Function Button ............................................................................................................................................................ 3 1）Download the APP ................................................................................................................................................. 3 2） Activate equipment................................................................................................................................................ 4 3） Equipment connection process ........................................................................................................................... 5 4、 Equipment scanning process ............................................................................................................................... 7 Indicator Light Description ............................................................................................................................................... 8 Data Copy Description ....................................................................................................................................................... 9 Battery ............................................................................................................................................................................... 10 Maintenance .................................................................................................................................................................. 11 Matters needing attention ................................................................................................................................................ 11 Appendix .................................................................................................................................................................... 12 Specification ...................................................................................................................................................................... 12 FCC Warning ....................................................................................................................................................................... 13 1 Product Overview Lixel L1, a highly integrated and lightweight handheld 3D reconstruction device. With the 3D real-time reconstruction algorithm, Lixel L1 can directly obtain the true color point cloud. The results are calculated in real time and can be viewed and used immediately. Lixel L1 provides a variety of optional accessories, such as 5G module, RTK, UAV onboard pail, carrying system, etc. It is easier to operate and applies to various scenarios. About Lixel L1 2 Operation 1、Battery installation 1. Turn the battery lock switch counterclockwise. 2. Insert the battery into the bottom of the device along the guide dovetail slot. Ensure that the battery is inserted into the correct position. 3. Turn the battery lock switch clockwise to lock the battery. Note: An unsecured battery may cause the device to slip. 3 2、Tripod Installation The bottom of the battery has threaded holes. Screw the tripod in and place the device in a flat position. 3 、Function Button 1）Download the APP We need to download a specific APP-Lixel Go on our mobile phone before starting it. See below for the connection: LixelGo_debug 1.0.3.221028.alpha.apk.1 （1）Click on the software, and first complete the login/registration operation. See the picture below for details. Login interface 4 （2）After successful login, enter the home page, and there is no device connection at this time. (without device connection) 2）Activate equipment To use Lingguang Lixel L1 for the first time, you need to connect your mobile phone and activate it through APP(Lixel Go).Install the equipment according to items 1 and 2 of the description title. （1）Open：Press and hold the power-on button for about 4 seconds.The indicator light flashes slowly by the blue light.When the blue light turns green, the boot is successful. （2）Open the Lixel Go APP on your mobile phone, click "device"-"activate device", and scan the QR code of the body-activation succeeded. 5 Note: When activating the device, it is necessary to connect the device once after successful activation to complete the whole activation process. If only half of the activation process is completed, the device can only be activated by the mobile phone scanning the activation code. If this phone can't be used for special reasons, please contact customer service. 3）Equipment connection process Click the middle key "Device" below-search for a device.The APP will pop up an interface "Please connect your device WIFI" Open the WLAN interface of the mobile phone and find the WiFi name of the device: Lixel- (the last 6 digits of the device code) such as Lixel-bdf8df. Click Connect，Enter the password xgrids3d set by the factory to connect.（The last 6 digits of the code can be seen on the APP when it is activated.） See the picture below for details. Go back to the APP interface and click the "Connect button" on the pop-up box to use it. 6 Function Operation State Open Long press 4 seconds The indicator light turns from slow blinking blue light to …

Text truncated - open the document above for the full version.

SHENZHEN XGRIDS-INNOVATION CO., LTD 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: SHENZHEN XGRIDS-INNOVATION CO., LTD Address: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN, China Product Name: Mobile Lidar Scanner FCC ID: 2A9PI-L1 Model(s): Lixel, L1 2.911(d)(5)(i) Equipment Type We, [SHENZHEN XGRIDS-INNOVATION CO., LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Zhixin Chen Date: 2023.02.22 Title and Company name: Project Manager / SHENZHEN XGRIDS-INNOVATION CO., LTD NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

SHENZHEN XGRIDS-INNOVATION CO., LTD 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: SHENZHEN XGRIDS-INNOVATION CO., LTD Address: 987, SERANGOON ROAD, SINGAPORE, Singapore Product Name: Mobile Lidar Scanner FCC ID: 2A9PI-L1 Model(s): Lixel, L1 2.911(d)(5)(ii) Applicant filing We, [SHENZHEN XGRIDS-INNOVATION CO., LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Zhixin Chen Date: 2023.02.22 Title and Company name: Project Manager / SHENZHEN XGRIDS-INNOVATION CO., LTD NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

SHENZHEN XGRIDS-INNOVATION CO., LTD U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 02-22-2023 Re f: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2A9PI-L1 SHENZHEN XGRIDS-INNOVATION CO., LTD (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC (“ the agent”) is our designated U.S. agent for service of process for the above reference FCC ID. The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges it is our responsibility to inform the FCC whenever the agent information changes. THR EE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: SHENZHEN XGRIDS-INNOVATION CO., LTD Signature: Address: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN, China Contact Person: Zhixin Chen Tel: +86-1 8825284823 Email: [email protected]

FCC Software Configuration Control Declaration Rev1.1 SHENZHEN XGRIDS-INNOVATION CO., LTD FCC Software Configuration Control Declaration Date: February 23, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product Name: Mobile Lidar Scanner Model Number: Lixel, L1 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Zhixin Chen Date: February 23, 2023 Title: Project Manager Signature of applicant

SHENZHEN XGRIDS-INNOVATION CO., LTD Agent Authorization Company: SHENZHEN XGRIDS-INNOVATION CO., LTD Address: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN, China Product Name: Mobile Lidar Scanner Model Number(s): Lixel, L1 Product Description: Mobile Lidar Scanner We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.02.22 Name: Zhixin Chen Title: Project Manager Company: SHENZHEN XGRIDS-INNOVATION CO., LTD

SHENZHEN XGRIDS-INNOVATION CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 22, 2023 Subject; Request for Confidentiality FCC ID: 2A9PI-L1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure FCC Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zhixin Chen Title: Project Manager

SHENZHEN XGRIDS-INNOVATION CO., LTD Model Difference Statement Dear Sir/Madam, Added models L1 basis of the original product Lixel. The color of appearance and model name of series models listed are different from the main model, but the circuit and the electronic construction are the same, declared by the manufacturer. Sincerely, Name: Zhixin Chen Title: Project Manager Company name: SHENZHEN XGRIDS-INNOVATION CO., LTD Address: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN, China

FCC ID: 2A9PI-L1 EUT PHOTO(External Photos)

Label and Information FCC Label Sample FCC Label Specifications Text is Black in color and is justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Where the EUT is constructed in two or more sections connected by wires and marketed together, the above statement is required to be affixed only to the main control unit. When the EUT is so small or for such use that it is not practicable to place the statement on it, the above information shall be placed in a prominent location in the instruction manual or pamphlet supplied to the user or, alternatively, shall be placed on the container in which the device is marketed. FCC Label Location

FCC ID: 2A9PI-L1 EUT PHOTO(Internal Photos) ANT. 2 ANT. 1 ※※※※※ END OF REPORT ※※※※※

FCC ID: 2A9PI-L1 RF Exposure Evaluation Report 1. Standalone SAR Test Exclusion Considerations According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition is satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison For standalone SAR test exclusion, the result as below: Transmission Mode Max Conducted Power (dBm) Tune-up (dBm) Max Power (mW) Frequency (MHz) Distance (mm) Result Limit 2.4GHz WLAN_ANT1 9.87 9(±1) 10 2412 20 0.7765 3.0 2.4GHz WLAN_ANT2 11.21 11(±1) 15.849 2412 20 1.2307 3.0 5.2GHz WLAN_ANT1 6.13 6(±1) 5.012 5180 20 0.5704 3.0 5.2GHz WLAN_ANT2 5.97 5(±1) 3.98 5180 20 0.4529 3.0 5.8GHz WLAN_ANT1 6.45 6(±1) 5.01 5785 20 0.6025 3.0 5.8GHz WLAN_ANT2 6.47 6(±1) 5.01 5785 20 0.6025 3.0 So a SAR test is not required. 2. Simultaneous Transmission SAR Test Exclusion Considerations According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093, Simultaneous transmission SAR test exclusion is determined for each operating configuration and exposure condition according to the reported standalone SAR of each applicable simultaneously transmitting antenna. When the sum of 1-g or 10-g SAR of all simultaneously transmitting antennas in an operating mode and exposure condition combination is within the SAR limit, SAR test exclusion applies to that simultaneous transmission configuration. When an antenna qualifies for the standalone SAR test exclusion of section 1 and also transmits simultaneously with other antennas, the standalone SAR value must be estimated according to the following to determine the simultaneous transmission SAR test exclusion criteria: 1) [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)]·[√f(GHz)/x] W/kg, for test separation distances ≤ 50 mm; where x = 7.5 for 1-g SAR and x = 18.75 for 10-g SAR. 2) 0.4 W/kg for 1-g SAR and 1.0 W/kg for 10-g SAR, when the test separation distance is > 50 mm. For simultaneous transmission analysis, WLAN SAR is estimated as below: Transmission Mode Max. Power (mW) Frequency (MHz) Distance (mm) X SAR(1g) W/kg 2.4GHz WLAN_ANT1 10 2412 20 7.5 0.1035 2.4GHz WLAN_ANT2 15.849 2412 20 7.5 0.1641 5.2GHz WLAN_ANT1 5.012 5180 20 7.5 0.076 5.2GHz WLAN_ANT2 3.98 5180 20 7.5 0.0604 5.8GHz WLAN_ANT1 5.01 5785 20 7.5 0.0803 5.8GHz WLAN_ANT2 5.01 5785 20 7.5 0.0803 The maximum SAR summation is calculated based on the simultaneous transmission configurations. No. Configurations ANT 0 SAR W/kg ANT 1 SAR W/kg Sum SAR W/kg 1 2.4GHz WLAN_ANT1+2.4GHz WLAN_ANT2 0.1035 0.1641 0.2676 2 5.2GHz WLAN_ANT1+5.2GHz WLAN_ANT2 0.076 0.0604 0.1364 3 5.8GHz WLAN_ANT1+5.8GHz WLAN_ANT2 0.083 0.083 0.166 The sum of SAR is less than the limit of 0.4W/kg, So a simultaneous transmission SAR test is not required.

Report N Date of T Date of is To t a l n um Te s t R e su Testing L Address Applican Address Manufac Address Test spec Standard Test proc Non-stan Test Rep Test Rep Master T This devi test (EU T identified This rep o be altered Product n Tradema Model/Ty Ratings .. umber. ......... Test ............... ssue ............. mber of page ult ................ Laboratory. . ................... nt's name .. ................... cturer's nam ................... cification: ................... cedure .......... dard test me port Form No port Form(s) TRF ............. ce described T) is in comp in the repor t ort shall not b d or revised name ............ rk ............... ype reference .................... .................... .................... .................... s ................. .................... .................... .................... .................... .................... me ............... .................... .................... .................... ethod ......... o. ................ ) Originator .................... d above has liance with t h t. be reproduce by ZKT, pers .................... .................... e .................. .................... TEST FCC I .... : ZKT-22 ...... Novemb .... : Februar ..... 95 .... : PASS .... : Shenz h .... : 1/F, No . Avenue .... : SHEN Z .... : 2207, S BUILDIN .... : SHEN Z .... : 2207, S BUILDIN .... : FCC C F ANSI C KDB 7 8 RSS-24 RSS-Ge .... : / .... : N/A .... : TRF-E L .... : ZKT Te s .... : Dated: 2 been tested he FCC requ ed except in f sonal only, an .... : Mobile .... : XGRIDS .... : Lixel, L 1 .... : DC 14. 4 T REP ID:2A 1125L8869E ber 23, 2022 ry 24, 2023 hen ZKT Tec . 101, Buildin , Fuhai Stree ZHEN XGRID SHENZHEN O NG 1, SHEN ZHEN XGRID SHENZHEN O NG 1, SHEN FR Title 47 P 63.10:2013 89033 D02 v0 47 Issue 2 en Issue 5 L-113_V0 sting 2020-01-06 by ZKT, an d uirements. An full, without t nd shall be n Lidar Scann S 1 4V by battery PORT A9PI-L E-2 2 toFebruary chnology Co ng B, No. 6, T et, Bao'an Di DS-INNOVAT OVERSEAS NZHEN, Chin DS-INNOVAT OVERSEAS NZHEN, Chin Part 15 Subpa 01r02 d the test res nd it is applic the written ap noted in the r ner y, DC 17V ch Project No T L1 24, 2023 o., Ltd. Tangwei Com istrict, Shenz TION CO., LT STUDENTS na TION CO., LT STUDENTS na art C Section ults show tha cable only to pproval of ZK revision of th harging by ad o.: ZKT-2211 P mmunity Indu zhen, China TD S INCUBATO TD S INCUBATO n 15.407 at the equipm the tested s KT, this docu he document dapter 25L8869E-2 Page 1 of 95 ustrial OR PARK OR PARK ment under ample ument may . 2 5 Testing pro Testing L Address Tested b Review e Approve ocedure and Laboratory ... .................... y (name + si er (name + si d (name + s i d testing loca .................... .................... ignature) ..... gnature) ...... ignature) ..... ation: ............... : ............... : ............... : ............... : ............... : Shenzhen Z 1/F, No. 101 Industrial Av Shenzhen, Tom Zou Jackson Fang Lake Xie ZKT Technol 1, Building B venue, Fuha China g Project No ogy Co., Ltd B, No. 6, Tang ai Street, Bao o.: ZKT-2211 P . gwei Commu o'an District, 25L8869E-2 Page 2 of 95 unity 2 5 1. VE 2.SUM 2.1 2.2 3. GE 3.1 3.3 3.4 3.5 4.EMC 4.1 4.2 5.POW 6. 26D 7.MAX RSION MMARY O 1 TEST FAC 2 MEASUR ENERAL IN 1 GENERAL 3 BLOCK D 4 DESCRIP 5 EQUIPME C EMISSIO 1 CONDUC 4.1.1 PO W 4.1.2 TEST 4.1.3 DEV 4.1.4 TES T 4.1.5 EUT 4.1.6 TES T 2 RADIATE 4.2.1 APP 4.2.2 CO N 4.2.3 MEA 4.2.4 TEST 4.2.5 TEST 4.2.6 TEST WER SPE 5.1 APPLI 5.2 TEST 5.3 DEVI A 5.4 TEST S 5.5 EUT O 5.6 TEST DB & 6DB 6.1 APPLI 6.2 TEST 6.3 EUT O 6.4 TEST XIMUM CO OF TEST R CILITY EMENT U N NFORMAT L DESCRIP DIGRAM SH PTION OF S ENTS LIST ON TEST TED EMISS WER LINE C T PROCED IATION FR T SETUP OPERATI N T RESULT: D EMISSI O LICABLE S NFORMANC ASURING IN T CONFIGU T PROCED T RESULT CTRAL DE ED PROCE PROCEDU ATION FRO SETUP OPERATION RESULTS &99% EM ED PROCE PROCEDU OPERATION RESULTS ONDUCTE Table of RESULTS NCERTAINT TION PTION OF E HOWING TH SUPPORT U FOR ALL T SION MEAS CONDUCTE DURE ROM TEST S NG CONDIT ON MEASU STANDARD CE LIMIT NSTRUMEN URATION DURE ENSITY TE EDURES / L RE M STAND A N CONDITIO MISSION B EDURES / L RE N CONDITIO ED OUTPU f Contents TY EUT HE CONFIG UNITS(CON TEST ITEM SUREMEN ED EMISSIO STANDARD TIONS REMENT D NTS EST LIMIT ARD ONS BANDWIDT LIMIT ONS UT POWER GURATION NDUCTED S T ON LIMITS D TH R Project No OF SYSTE MODE) S o.: ZKT-2211 P EM TESTED 25L8869E-2 Page 3 of 95 Page 5 6 7 7 8 8 D 10 10 10 13 13 13 13 13 14 14 15 17 17 17 17 18 19 20 26 26 27 27 27 27 28 39 39 39 39 40 56 2 5 e 8.OUT 9.SPU 10.FR 10 10 10 10 10 11.AN 12. TE 13. EU 7.1 PPLIE 7.2 TEST 7.3 DEVI A 7.4 TEST S 7.5 EUT O 7.6 TEST T OF BAN 8.1 APPLI 8.2 TEST 8.3 DEVI A 8.4 TEST S 8.5 EUT O 8.6 TEST URIOUS R 9.1 CONFO 9.2 MEAS 9.3 TEST S 9.4 TEST 9.5 TEST REQUENC .1 LIMIT .2 TEST P R .3 TEST SE .4 EUT OPE .5 TEST RE NTENNA R EST SETU UT CONST D PROCED PROCEDU ATION FRO SETUP OPERATION RESULTS ND EMISSI CABLE ST PROCEDU ATION FRO SETUP OPERATION RESULTS RF CONDU ORMANCE URING INS SETUP PROCEDU RESULTS CY STABIL ROCEDURE ETUP LAYO ERATION D ESULTS REQUIREM UP PHOTO TRUCTION Table of DURES / LI RE M STAND A N CONDITIO ONS TANDARD RE M STAND A N CONDITIO UCTED EM E LIMIT STRUMENT RE LITY MEAS ES OUT DURING TE MENT O NAL DETA f Contents MIT ARD ONS ARD ONS MISSIONS TS SUREMEN EST AILS NT Project Noo.: ZKT-2211 P 25L8869E-2 Page 4 of 95 Page 56 56 57 57 57 58 59 59 59 59 59 60 60 70 70 70 70 70 70 83 83 83 83 83 83 94 95 95 2 5 e 1. VER Re ZKT-22 RSION eportNo. 21125L8869E E-2 Version Rev.01 Desc Initial issu Project No cription ue of report o.: ZKT-2211 P F 25L8869E-2 Page 5 of 95 Approved February 24, 2023 2 5 2.SUM Te s t p r o c FCC FCC p FCC p FCC p FC RSS- FCC p RSS- 2 RSS- FCC FCC p FCC p RSS-2 FCC p FCC p RSS- FCC p FCC p RSS-2 FCC FC RSS- NOTE: (1) ” MMARY OF T cedures acco Standard Section C part 15.209 part 15.407 ( part 15.407 ( part 15.407 ( CC part 15.20 -Gen Section art 15.407 (a 15.1049 247 Section 5 …

Text truncated - open the document above for the full version.

Report No: SSP22110041A Antenna Test Report Page 1 of 4 Antenna Test Report Test Standard: IEEE 149-1979 Manufacturer: SHENZHEN XGRIDS-INNOVATION CO., LTD Product Name: BT/Wi-Fi Antenna Model: L1 Report No.: SSP22110041A Tested Date: 2022-06-23 Issued Date: 2022-06-24 Tested By: William Liu (Engineer) Approved By: Lahm Peng (Manager) Prepared By: Shenzhen ZRLK Testing Technology Co., Ltd. 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Tel.: +86-755-33019599 Fax.: +86-755-33019599 Website: www.zrlklab.com Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen ZRLK Testing Technology Co., Ltd. Report No: SSP22110041A Antenna Test Report Page 2 of 4 1. General Information 1.1 Product Information Manufacturer Manufacturer: SHENZHEN XGRIDS-INNOVATION CO., LTD Address of Manufacturer: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN, China General Description of Antenna Product Name: BT/Wi-Fi Antenna Model No.: L1 Frequency Range: 2400MHz-2483.5MHz, 5180MHz-5825MHz Type of Antenna: FPCB Antenna Antenna Gain: 2.4G: 0dBi (Max.), 5G: 0dBi (Max.) Impedance: 50 ohm Antenna View ( 30mm*18mm) 1.2 Test Methodology All measurements contained in this report were conducted with standards IEEE 149-1979 for IEEE Standard Test Procedures for Antennas. 1.3 Test Facilities Te s ting Lab: Shenzhen ZRLK Testing Technology Co., Ltd. All measurement facilities used to collect the measurement data are located at 1F, No. 35 Building, Changxing Technology Industrial Park, Yutang Street, Guangming New District, Shenzhen City, Guangdong Province, China Report No: SSP22110041A Antenna Test Report Page 3 of 4 2. OTA Test 2.1 Gain Frequency Peak Gain (dBi) Polarity 2402MHz 0 Horizontal 2402MHz -0.66 Vertical 2442MHz -1.3 Horizontal 2442MHz -1.48 Vertical 2480MHz -1.77 Horizontal 2480MHz -1.89 Vertical 5210MHz 0 Horizontal 5210MHz -0.64 Vertical 5775MHz 0 Horizontal 5775MHz -0.97 Vertical 2.2 Radiation Pattern View Report No: SSP22110041A Antenna Test Report Page 4 of 4

FCC ID: 2A9PI-L1 EUT TEST PHOTO Radiated band emission (30MHz-1GHz): Conducted emission： Radiated band emission (Above 1GHz)：
