2A9PI-LIXELL2Mobile Lidar Scanner

Lixel L2 PRO User Manual User Manual Contents Product Overview ........................................................................................................................................... 1 About Lixel L2 PRO ..................................................................................................................................... 1 Operation .......................................................................................................................................................... 2 Batteries Installation .............................................................................................................................. 2 Tripod Installation ................................................................................................................................... 3 Function Button ....................................................................................................................................... 3 Indicator Description ............................................................................................................................. 4 Data Copy Description .......................................................................................................................... 4 Battery Charging ..................................................................................................................................... 5 Maintenance .................................................................................................................................................... 6 Storage....................................................................................................................................................... 6 Note for Use ............................................................................................................................................. 6 The Appendix .................................................................................................................................................. 7 Specifications ........................................................................................................................................ 7-8 1 Product Overview Lixel L2 PRO, a highly integrated and lightweight handheld 3D reconstruction device. With the 3D real-time reconstruction algorithm, Lixel L2 PROcan directly obtain the true color point cloud. The results are calculated in real time and can be viewed and used immediately. About Lixel L2 PRO 2 Operation Battery installation 1.Open the lever. 2.Insert the battery into the bottom of the device along the guide dovetail slot. Ensure that the battery is inserted into the correct position. 3.Press the lever back and lock the battery tightly. Note: An unsecured battery may cause the device to slip. 3 Tripod Installation The bottom of the battery has threaded holes. Screw the tripod in and place the device in a flat position. Function Button Function Operation State Open Long press 4 seconds The indicator light turns from slow blinking blue light to steady green light; Close Long press 4 seconds Indicator light off; Start Scanning Double Click When the device is in standby state, double-click the indicator. The indicator status changes from steady green to blinking green at short intervals and then to blinking green at long intervals. And the lidar starts to rotate, that is, the scan is started successfully. Stop Scanning Double Click When scanning, double click the button, the indicator state will change from green slow flashing to green quick flashing and then to steady green. Meanwhile, the lidar will stop rotating and the scanning will be stopped successfully. 4 Note: 1 Please put the device on the flat table before starting the scan. After starting the scan, the device can be moved for scanning only after the lidar rotates. 2 It takes about 10 seconds to start scanning. 3 During the scanning stop, if the indicator blinks green quickly, scanned files are being stored. If the power is off at this time, files may be lost or saved incompletely. 4 After the scan is stopped, the waiting time for stored files may be long, it’s depending on the size of the scene being scanned. Indicator Light Description Indicator blinking status Significance None The device is not started. The blue light blinking slowly The device is starting up. Blue light normally on USB disk mode Green light normally on The device is in standby state The green light blinking fast The scan is being started/stopped The green light blinking slowly Scanning Yellow light normally on The device is not activated Red light normally on Serious device failure Data Copy Description Use the USB cable that matches the device. Connect the device to the computer in standby mode and turn on the USB mode in the App. After identifying the device, the data can be copied. Note: 1 The USB mode is automatically disabled after a restart. 2 After turning on the USB mode, you need to manually turn off the USB mode if you want to continue scanning without shutting down or power off. 3 Using a non-standard USB cable may cause slow data copy. Or may cause forward insertion can be used, reverse insertion can not be used. 5 Battery Use the standard charging cable and connect the charging adapter to the battery to charge the battery. Charging time: about 2 hours. During the charging process, the indicator light will show the current electric quantity. Please refer to the following table for details. Indicator blinking status electricity Only one green light on 0-24% Two green lights on 25%-49% Three green lights on 50%-74% Four green lights on 75%-99% 6 Maintenance The storage status of the device is as shown in the figure below. After use, remove the battery and put it back into the storage box according to the figure. Note: It is a precision device, not storing as required may cause damage to the device. Matters needing attention 1.Lixel L2 PRO i…

Text truncated - open the document above for the full version.

SHENZHEN XGRIDS-INNOVATION CO., LTD 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN China Date: 2024-06-22 FCC ID: 2A9PI-LIXELL2 Dear Sir/Madam, We, { SHENZHEN XGRIDS-INNOVATION CO., LTD } Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, s tructure and internal of these model(s) are the same, Only model number is different for these model: Product name: Mobile Lidar Scanner Model no.: Lixel L2 PRO-16, Lixel L2 PRO-32 Sincerely, Name/Title： Zhixin Chen/Project Manager Company: SHENZHEN XGRIDS-INNOVATION CO., LTD Address: 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK BUILDING 1, SHENZHEN China Phone: +86-18825284823 Fax: +86-18825284823 E-Mail: [email protected]

FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of Adapter

FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Appendix I Label Appendix II Label Location Mobile Lidar Scanner FCC ID: 2A9PI-LIXELL2 Model: Lixel L2 PRO-16 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 9 Internal of EUT Photo 10 Internal of EUT FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 15 Appearance of PCB Photo 16 Appearance of PCB FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 17 Appearance of PCB Photo 18 Appearance of PCB FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 19 Appearance of Antenna Photo 20 Appearance of PCB WLAN/RLAN WLAN/RLAN/BT FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 21 Appearance of PCB Photo 22 Appearance of PCB FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Photo 23 Appearance of PCB Photo 24 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202402-0069-4 Page: 1 of 4 TB-RF-074-1.0 1 A/F., Building.6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao’an, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: 2A9PI-LIXELL2 1. Client Information Applicant : SHENZHEN XGRIDS-INNOVATION CO., LTD Address : 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK, BUILDING 1, SHENZHEN, CHINA Manufacturer : SHENZHEN XGRIDS-INNOVATION CO., LTD Address : 2207, SHENZHEN OVERSEAS STUDENTS INCUBATOR PARK, BUILDING 1, SHENZHEN, CHINA 2. General Description of EUT EUT Name : Mobile Lidar Scanner Model(s) No. : Lixel L2 PRO-16, Lixel L2 PRO-32 Model Difference : All these models are identical in the same PCB, layout and electrical circuit, the only difference is model name for commercial. Operation Frequency: Bluetooth&LE:2402MHz~2480MHz 2.4GWiFi:2412MHz~2462MHz U-NII-1: 5180MHz~5240MHz U-NII-3: 5745MHz~5825MHz Antenna Gain: -0.69dBi FPC Antenna for 2402~2480MHz -0.69dBi FPC Antenna 1&2 for 2412~262MHz 0.79dBi FPC Antenna1&2 for U-NII-1 5180MHz~5240MHz 0.79dBi FPC Antenna1&2 for U-NII-3 5745MHz~5825MHz Product Description : Modulation Type: GFSK, Pi/4-DQPSK, 8-DPSK 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (QPSK, BPSK, 16QAM, 64QAM) 802.11a: OFDM (QPSK, BPSK, 16QAM, 64QAM) 802.11ac: OFDM (QPSK, BPSK, 16QAM, 64QAM, 256QAM) Power Supply : Battery Charger (Model: FY1682000): Input: 100-240V~50/60Hz 1.5A 80VA Output: 16.8V⎓2.0A 33.6W Li-ion Polymer Battery : DC 14.4V 3.25Ah 46.8Wh Rechargeable Li-ion battery Software Version : 1.1.2 Hardware Version : P2 Remark: The above antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Note: More test information about the EUT please refer the RF Test Report. Report No.: TBR-C-202402-0069-4 Page: 2 of 4 TB-R F-07 4-1. 0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR 2. Summary simultaneous transmission for SAR Exclusion The SAR exemption limits outlined in clause 4.3.2(b) of KDB 447498 have been derived based on an approximate SAR value of 0.4 W/kg using half-wave dipole antennas Footnote 1. As such, when simultaneous transmitter SAR evaluations include transmitters that have been exempt from routine SAR evaluation, the SAR must be estimating based on the ratio between the maximum tune-up tolerance limit of the transmitter that has been exempt and the exemption limit at the specific distance and frequency for that transmitter. This ratio must be multiplied by 0.4 W/kg (2.0 W/kg for controlled use and 1.0 W/kg for limb worn devices) in order to calculate the estimated SAR level. The estimate SAR value is calculated based the following equation: (maximum power level including tune-up tolerance for transmitter A / maximum power level of exemption at the same frequency and distance) * 0.4W/kg The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. Report No.: TBR-C-202402-0069-4 Page: 3 of 4 TB-R F-07 4-1. 0 3. Calculation: Test separation: 5mm Worst MPE Result Test Mode Antenna Max. Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshold Value Bluetooth / 8.345 8±1 9 7.943 2.502 3.0 Ant1 4.96 5±1 6 3.981 1.249 3.0 2.4G b Ant2 5.20 5±1 6 3.981 1.249 3.0 Ant1 4.54 5±1 6 3.981 1.249 3.0 2.4G g Ant2 5.19 5±1 6 3.981 1.249 3.0 Ant1 5.05 5±1 6 3.981 1.249 3.0 2.4G n20 Ant2 4.46 5±1 6 3.981 1.249 3.0 Ant1 5.06 5±1 6 3.981 1.249 3.0 2.4G n40 Ant2 4.33 5±1 6 3.981 1.249 3.0 Ant1 5.18 5±1 6 3.981 1.922 3.0 5G a Ant2 4.00 5±1 6 3.981 1.922 3.0 Ant1 4.76 5±1 6 3.981 1.922 3.0 5G n20 Ant2 4.12 5±1 6 3.981 1.922 3.0 Ant1 4.67 5±1 6 3.981 1.922 3.0 5G n40 Ant2 4.12 5±1 6 3.981 1.922 3.0 Ant1 4.43 5±1 6 3.981 1.922 3.0 5G ac20 Ant2 4.35 5±1 6 3.981 1.922 3.0 Ant1 4.67 5±1 6 3.981 1.922 3.0 5G ac40 Ant2 3.99 4±1 5 3.162 1.526 3.0 Ant1 4.46 5±1 6 3.981 1.922 3.0 5G ac80 Ant2 4.73 5±1 6 3.981 1.922 3.0 Note: The Frequency used Highest Frequency for bluettooth&2.4G/5G WiFi. Simultaneous Transmission for SAR Exclusion Simultaneous Transmission for SAR Exclusion Ant1 Ant2 Total Calculation Value Limit 0.641 0.641 0.801 1.0 ∑ of (the highest measured or estimated SAR Ant1 +SAR Ant2 )/1.6 = (0.641 +0.641)/1.6 = 0.801 < 1.0; Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. Report No.: TBR-C-202402-0069-4 Page: 4 of 4 TB-R F-07 4-1. 0 -----END OF REPORT-----

QR/RD-P01-06B SPECIFICATION ShenzhenFeixinWirelessCommunicationCo.,Ltd. 2.4G/5.8FPCantenna Productspecification CustomerFrequency2400MHz——2500MHz RFdesign XIAOBIN VersionA1 Technical director ANDYdate2023-12-14 Customerconfirmation: Whethertheassemblymeetsyourcompany'srequirements ：□ OK □ NG Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page2 Directory Cover.......................................................................................................1 1、Directory...........................................................................2 2、Productpictures...............................................................................3 3、S11data.................................................................................4 4、Antennatestdata(gain,efficiency,applechart)...............4 5、Productstructuredrawing..........................................................7 Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page3 1、Productpictures 2、Productparameters Producttestingparameters 产品名称(Name) 2.4GWIFI 产品型号(ModelType) FX-2.4/5.8-QYCX-F PC-V1.2 电性能指标 (ElectricalSpecifications) 频率范围(FrenquencyRange) 2400-2500MHZ 5200-5800MHz 极化方式（Polarization） vertical 输入阻抗(Impedance) 50Ω 辐射方向 Omnidirectional 驻波比（VSWR）≦3.0功率容量(Power) 50W 增益(Gain) 2.74dBi 带宽(Bandwidth 100/600MHz 机械指标 (MechanicalSpecifications) 尺寸(Dimensions)29.6*10.4±0.15mm外壳颜色(ANTColor) black 连接器型号(Connector) IPEX4 引线长度(CableLength)110±3mm 外壳材料RadomeMaterial FPC 工作温度 (WorkingTemperature) -40°C-+85°C 存放温度 (LimitTemperature) -40°C-+85°C Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page4 3.VSWR,ReturnlossandSmithdata Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page5 4、Antennatestdata(gain,efficiency,applechart) Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page6 Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page7 5、Productstructuredrawing 1 1 0 ± 3 M M Confidentialityrequirements Ourcompanyalreadypossessestheproprietarytechnologyprovided,andtheseproprietaryinformationshouldbestrictlykept confidential.WithoutthepriorwrittenconsentofShenzhenFeixinWirelessCommunicationCo.,Ltd.,itisnotallowedtobe disclosedtoanyoneorthecompany. http://www.flxant.comhttp://www.fly-core.com Page8

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 1 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 RF Test Data for Bluetooth(BDR+EDR) (Conducted Measurements) General Description of EUT Product Name: Mobile Lidar Scanner Test Model: Lixel L2 PRO-16 Sample ID: HC-C-202402-0069-4-01 Environmental Conditions Temperature: 23.8°C Relative Humidity: 49% Test Voltage: DC 14.4V Test Engineer: Jolin Lee Note: For a more detailed features description, please refer to the report TBR-C-202402-0069-61 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 2 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Contents 1. Duty Cycle ..........................................................................................................................................................................................3 2. Maximum Conducted Peak Output Power ......................................................................................................................................9 3. -20dB Bandwidth .............................................................................................................................................................................18 4. Occupied Channel Bandwidth ........................................................................................................................................................24 5. Band Edge ........................................................................................................................................................................................30 6. Band Edge(Hopping) .......................................................................................................................................................................37 7. Conducted RF Spurious Emission ................................................................................................................................................44 8. Restrict Band ...................................................................................................................................................................................54 9. Carrier Frequencies Separation .....................................................................................................................................................61 10. Number of Hopping Channel .....................................................................................................................................................64 11. Dwell Time ...................................................................................................................................................................................67 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 3 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT 1-DH1 2402 Ant1 30.89 5.1 2.63 NVNT 1-DH1 2441 Ant1 31.15 5.07 2.63 NVNT 1-DH1 2480 Ant1 31.15 5.07 2.63 NVNT 2-DH1 2402 Ant1 31.71 4.99 2.56 NVNT 2-DH1 2441 Ant1 31.45 5.02 2.56 NVNT 2-DH1 2480 Ant1 31.45 5.02 2.56 NVNT 3-DH1 2402 Ant1 31.71 4.99 2.56 NVNT 3-DH1 2441 Ant1 31.71 4.99 2.56 NVNT 3-DH1 2480 Ant1 31.45 5.02 2.56 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 4 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Test Graphs Duty Cycle NVNT 1-DH1 2402MHz Ant1 Duty Cycle NVNT 1-DH1 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 5 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Duty Cycle NVNT 1-DH1 2480MHz Ant1 Duty Cycle NVNT 2-DH1 2402MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 6 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Duty Cycle NVNT 2-DH1 2441MHz Ant1 Duty Cycle NVNT 2-DH1 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 7 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Duty Cycle NVNT 3-DH1 2402MHz Ant1 Duty Cycle NVNT 3-DH1 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 8 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Duty Cycle NVNT 3-DH1 2480MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 9 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 2. Maximum Conducted Peak Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT 1-DH1 2402 Ant1 8.345 21 Pass NVNT 1-DH1 2441 Ant1 7.704 21 Pass NVNT 1-DH1 2480 Ant1 7.831 21 Pass NVNT 1-DH3 2441 Ant1 6.549 21 Pass NVNT 1-DH5 2441 Ant1 7.088 21 Pass NVNT 2-DH1 2402 Ant1 6.443 21 Pass NVNT 2-DH1 2441 Ant1 5.987 21 Pass NVNT 2-DH1 2480 Ant1 6.184 21 Pass NVNT 2-DH3 24…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 40 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Band Edge(Hopping) NVNT 2-DH1 2402MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 2-DH1 2402MHz Ant1 Hopping Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 41 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Band Edge(Hopping) NVNT 2-DH1 2480MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 2-DH1 2480MHz Ant1 Hopping Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 42 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Band Edge(Hopping) NVNT 3-DH1 2402MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 3-DH1 2402MHz Ant1 Hopping Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 43 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Band Edge(Hopping) NVNT 3-DH1 2480MHz Ant1 Hopping Ref Band Edge(Hopping) NVNT 3-DH1 2480MHz Ant1 Hopping Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 44 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 7. Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH1 2402 Ant1 -57.56 -20 Pass NVNT 1-DH1 2441 Ant1 -49.06 -20 Pass NVNT 1-DH1 2480 Ant1 -54.14 -20 Pass NVNT 2-DH1 2402 Ant1 -54.98 -20 Pass NVNT 2-DH1 2441 Ant1 -54.2 -20 Pass NVNT 2-DH1 2480 Ant1 -54.7 -20 Pass NVNT 3-DH1 2402 Ant1 -51.37 -20 Pass NVNT 3-DH1 2441 Ant1 -53.89 -20 Pass NVNT 3-DH1 2480 Ant1 -54.47 -20 Pass Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 45 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Test Graphs Tx. Spurious NVNT 1-DH1 2402MHz Ant1 Ref Tx. Spurious NVNT 1-DH1 2402MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 46 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 1-DH1 2441MHz Ant1 Ref Tx. Spurious NVNT 1-DH1 2441MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 47 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 1-DH1 2480MHz Ant1 Ref Tx. Spurious NVNT 1-DH1 2480MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 48 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 2-DH1 2402MHz Ant1 Ref Tx. Spurious NVNT 2-DH1 2402MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 49 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 2-DH1 2441MHz Ant1 Ref Tx. Spurious NVNT 2-DH1 2441MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 50 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 2-DH1 2480MHz Ant1 Ref Tx. Spurious NVNT 2-DH1 2480MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 51 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 3-DH1 2402MHz Ant1 Ref Tx. Spurious NVNT 3-DH1 2402MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 52 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 3-DH1 2441MHz Ant1 Ref Tx. Spurious NVNT 3-DH1 2441MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 53 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 Tx. Spurious NVNT 3-DH1 2480MHz Ant1 Ref Tx. Spurious NVNT 3-DH1 2480MHz Ant1 Emission Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202402-0069-61 Page: 54 of 73 FCC ID: 2A9PI-LIXELL2 TB-RF-074-1.0 8. Restrict Band Condition Mode Frequency (MHz) Antenna Hopping Mode Spur Freq (MHz) Power (dBm) Gain (dBi) Duty Factor (dB) E (dBuV/m) Detector Limit (dBuV/m) Verdict NVNT 1-DH 1 2402 Ant1 No-Hopp ing 2310 -48.56 2 - 48.7 Peak 74 Pass NVNT 1-DH 1 2402 Ant1 No-Hopp ing 2310 -55.45 2 5.1 46.91 Average 54 Pass NVNT 1-DH 1 2402 Ant1 No-Hopp ing 2331.504 -44.55 2 - 52.71 Peak 74 Pass NVNT 1-DH 1 2402 Ant1 No-Hopp ing 2379.696 -54.78 2 5.1 47.58 Average 54 Pass NVNT 1-DH 1 2402 An…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202402-0069-61 Page: 1 of 43 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Radio Test Report FCC ID: 2A9PI-LIXELL2 Report No. : TBR-C-202402-0…

Text truncated - open the document above for the full version.
