MTI CAMLOCK™ 1 MTI P/N 063-00431 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 CamLock Kit BATTERY Battery Caution Do not ingest the battery, Chemical Burn Hazard. Keep new and used batteries away from children. The product contains a lithium coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. If the battery compartment does not close securely, stop using the product and keep it away from children. CAUTION: Risk of fire or explosion if the battery is replaced by an incorrect type. -battery type: CR 2477 (non-rechargeable) -chemical system of the battery: Lithium CR 2477 Coin Cell Battery Not included 003-00036 - For battery door Key Starter Set – 185-00459 VERSA KE Y ™ x5 AUTHORIZATION VERSA KE Y ™ x2x1 Connect Card - 401-00008User Key Bulk (x5) Pack - 185-00460 x1 NETWORK PAIRING No. 2 Philips Screwdriver - Cam Mounting CR 2477 Coin Cell Battery SmartLock 2 MTI P/N 063-00431 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 NETWORK MODE - Versa EX or Managed Access KEY REGISTRATION (Standard Mode) - Complete Before Installation Swipe Authorization card again to close enrollment mode. Enrollment mode times out after 3 minutes of no activity. Lock will emit 4 fast beeps when enrollment has timed out. Swipe each User card to lock. A double beep tone indicates a card is now enrolled. Repeat for each user card, up to 250 user cards. If a card fails to be recognized, the lock will emit 4 fast beeps. Swipe Authorization card to enter enrollment mode. You will hear a double beep tone, indicating enrollment mode has been entered. VERSA KE Y ™ System Status Network PowerReset tattatm Stataatuaa 12 NE TW ORK P AIRING Swipe Pairing card to lock. Lock will start slowly beeping confirming it is looking for Connect ® network. Upon successfully pairing the lock will emit a double beep. Lock will automatically download key whitelist from network. 12 Place Pairing Card over the RFID icon to place Versa EX in pairing mode. LED will be flashing blue. NE TW ORK P AIRING Swipe Pairing card to lock. Lock will start slowly beeping confirming it is looking for Versa EX network. Upon successfully pairing the lock will emit a double beep. Lock will automatically download key whitelist from Versa EX. Full Connect Hub programming can be found in guide 063-00210 Insert Intellikey into Connect ® hub. After 10 seconds, the System Status LED will be flashing blue, indicating it is in pairing mode. It will automatically time out after 15 minutes. Full Versa EX programming can be found in guide 063-00393 23 1 MTI CAMLOCK™ 3 CAM Lock Installation and Use MTI P/N 063-00431 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 1 3 2 (20mm) .78in (19mm) .75in (20mm) .78in Minimum Setback (20mm) .78in (19mm) .75in (20mm) .78in Minimum Setback Determine if lock will be mounted vertical or horizontally. Now is time to determine if CAM will contact edge, or top of fixture when in the locked position. Steps assume horizontal mounting. Drill 3/4 inch (19m) hole. Ensure hole is drilled square to the surface of the door. Measure setback from side and top edge based on where selected cam will engage with fixture. Cam may extend past edge of door or sit even. Some fixtures may have a pocket cam engages into, or it may engage with an internal bracket. Once location is determined, mark center location for hole. 5 4 6 Clean surface of door with alcohol wipe, in the area where lock will contact. Allow to dry thoroughly. Peel red liner from VHB tapeApply lock to door, ensuring it is straight. Apply pressure to VHB for 10 seconds to ensure complete adhesion. Setback Options - Came proturiding, or Cam Flush MTI CAMLOCK™ 4 CamLock Installation MTI P/N 063-00431 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 Attach large nut to threaded bushing on inside of door. 78 Tighten nut with wrench until nut is firmly in place. ATTACHING CAM 1 Do Not overtighten nut to avoid damaging door surface 23Slide Cam adapter onto CamLock shaft. It will engage with mating square “keyway”. Attach CAM to Cam shaft with phillips screw and serrated washer with No 2 screwdriver. Check to ensure Cam is oriented in the correct lock/unlocked position before tightening screw. Pocket location for Cam is determined by max distance vs door thickness. Door thickness may de- termine pocket depth (C) Straight or offset Cams may be used to accomodate different engagement depths. If there is no pocket, a small metal bracket (not included) can be installed to the correct depth. A C B A - B = C Offset CamStraight Cam MTI CAMLOCK™ 5 Using CamLock MTI P/N 063-00431 rev A ©2023 MTI All Rights Reserved Correct Disposal of Product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of used devices contact MTI Global Services Contact Center at 503-648-6500 or contact local recycling company for proper recycling instructions for electronic devices. 12 Swipe Versa User Card on lock. Lock will emit double beep if card is accepted. Motor will cycle to unlock state. User manually unlocks the lock by twisting knob. VERSA KE Y ™ 3 When finished, close door and twist lock to locked posi- tion. Lock will emit a single beep when it is locked. If lock is not returned to locked position, it will start alarming after 5 minutes of being unlocked MTI CAMLOCK™ 6 Powering lock with dead battery MTI P/N 063-00431 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 12 Flip up dust cover on power port. Insert USB-C from 5V USB-C power supply or e…
Text truncated - open the document above for the full version.
MTI PLUNGER LOCK™ 1 MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 PlungerLock Kit 003-00036 - For battery door x2x1 22mm Wrench - For Bushing Mounts BATTERY Battery Caution Do not ingest the battery, Chemical Burn Hazard. Keep new and used batteries away from children. The product contains a lithium coin/button cell battery. If thecoin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. If the battery compartment does not close securely, stop using the product and keep it away from children. CAUTION: Risk of fire or explosion if the battery is replaced by an incorrect type. -battery type: CR 2477 (non-rechargeable) -chemical system of the battery: Lithium Not included Key Starter Set – 185-00459 VERSA KEY ™ x5 AUTHORIZATION VERSA KEY ™ Connect Card - 401-00008 User Key Bulk (x5) Pack - 185-00460 x1 NETWORK PAIRING CR 2477 Coin Cell Battery SmartLock Bushing Mount (Included) 2 MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 NETWORK MODE - Versa EX or Managed Access KEY REGISTRATION (Standard Mode) - Complete Before Installation Swipe Authorization card again to close enrollment mode. Enrollment mode times out after 3 minutes of no activity. Lock will emit 4 fast beeps when enrollment has timed out. Swipe each User card to lock. A double beep tone indicates a card is now enrolled. Repeat for each user card, up to 250 user cards. If a card fails to be recognized, the lock will emit 4 fast beeps. Swipe Authorization card to enter enrollment mode. You will hear a double beep tone, indicating enrollment mode has been entered. VERSA KEY ™ System Status Network PowerReset tattatm Stataatuaa 12 NETWORK PAIRING Swipe Pairing card to lock. Lock will start slowly beeping confirming it is looking for Connect ® network. Upon successfully pairing the lock will emit a double beep. Lock will automatically download key whitelist from network. 12 Place Pairing Card over the RFID icon to place Versa EX in pairing mode. LED will be flashing blue. NETWORK PAIRING Swipe Pairing card to lock. Lock will start slowly beeping confirming it is looking for Versa EX network. Upon successfully pairing the lock will emit a double beep. Lock will automatically download key whitelist from Versa EX. Full Connect Hub programming can be found in guide 063-00210 Insert Intellikey into Connect ® hub. After 10 seconds, the System Status LED will be flashing blue, indicating it is in pairing mode. It will automatically time out after 15 minutes. Full Versa EX programming can be found in guide 063-00393 23 1 MTI PLUNGER LOCK™ 3 Plunger Lock Installation MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 1 3 2 (38mm) 1.5in (25mm) 1in (10-19mm) .39-.75in Determine if lock will be mounted vertical or horizontally. Measure total thickness of both doors plus door gap. This will determine which plunger, or plunger + extension to use. Plunger must be long enough to engage back sliding door, and clear it when the lock is open. Lock travel is 10mm Measure Door Overlap (A) plus diameter of hole for plunger. Will range from 10-19mm. For Plunger only a 10mm clearace hole is needed. If usiing optional thread- ed bushing mount, drill a 19mm hole. Edge of hole should be even with edge of door overlap. 5 4 6 Clean surface of door with alcohol wipe, in the area where lock will contact. Allow to dry thoroughly. Drill hole in front door panel where marked in previous step. Hole size will vary depending on mounting type. If plunger extensions are needed, they simply screw into the lock plunger. Threads are M4. MTI PLUNGER LOCK™ 4 Mount Types MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 12 Mount backplates are either a simple flush mount (stan- dard) or the optional threaded bushing kit included in the kit. If using flush mount, skip to step 4 Change to bushing mount by removing four screws hold- ing flush mount plate. Use MTI Retail Tool 34 Install threaded bushing with the screws removed in step 2. Tighten until they are snug. Do not over tighten Apply VHB to back of lock. Place pressure all around VHB pad to ensure good adhesion. MTI PLUNGER LOCK™ 5 Plunger Lock Installation MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww.mobiletechinc.com | T:800.426.6844 78 9 Do Not overtighten nut to avoid damaging door surface 10 For applications usinging threaded bushing, attach nut to bushing. Tighten nut with wrench until nut is firmly in place. Peel red liner from VHB tape.Apply lock to door, ensuring it is straight. Apply pressure to VHB for 10 seconds to ensure complete adhesion. MTI PLUNGER LOCK™ 6 Using Plunger Lock MTI P/N 063-00432 rev A ©2023 MTI All Rights Reserved Correct Disposal of Product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of used devices contact MTI Global Services Contact Center at 503-648-6500 or contact local recycling company for proper recycling instructions for electronic devices. 12 Swipe Versa User Card on lock. Lock will emit double beep if card is accepted. Motor will cycle to unlock state. User manually unlocks the lock by twisting knob and it will pop the knob/plunger out. Door may now be opened. VERSA KE Y ™ 3 When finished, close door and twist lock to locked posi- tion. Lock will emit a single beep when it is locked. If lock is not returned to locked position, it will start alarming after 5 minutes of being unlocked. MTI PLUNGER LOCK™ 7 Powering Lock with Dead Battery MTI P/N 063-00432 rev A ©2023 MTI All Rights Reservedwww…
Text truncated - open the document above for the full version.
Appendix Model: CamLock CamLock Appendix Model: CamLock Appendix Model: CamLock Appendix Model: CamLock PlungerLock
Label LocaƟon
Appendix Model: CamLock Appendix Model: CamLock Appendix Model: CamLock Zigbee Antenna Appendix Model: CamLock RFID Antenna
Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 21 of 22 Radiofrequency radiation exposure evaluation This exposure evaluation is intended forFCC ID: 2AA2X-15000333 According to KDB 447498 D01v06 section 4.3.1, For frequencies below 100 MHz and test separation distances ≤ 50 mm, the Numeric threshold is determined as: Step a) [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR Step b) {[Power allowed at numeric threshold for 50mm in step a)] + [(test separation distance – 50mm) · (f(MHz)/150)]} mW Step c) 1) For test separation distances > 50mm and < 200mm, the power threshold at the corresponding test separation distance at 100MHz in step b) is multiplied by [1 + log(100/f(MHz))] Step c) 2) For test separation distances ≤ 50mm, the power threshold determined by the equation in c) 1) for 50mm and 100MHz is multiplied by ½. >> The fundamental frequency of the EUT is 125kHz, the test separation distance is ≤ 50mm. (Manufacturer specified the separation distance is: 20mm) Step a) >> Numeric threshold, mW / 50mm * √0.1GHz ≤ 3.0 Numeric threshold ≤ 474.3mW Step b) >> Numeric threshold ≤ 474.3mW + (50mm-50mm) * 100MHz/150) Numeric threshold ≤ 474.3mW Step c) 1) & c) 2) >> Numeric threshold ≤ 474.3mW * [1 + log 100/100MHz] * ½ Numeric threshold ≤ 237.15mW >> The power (calculated power + tune up tolerance) of EUT at 125kHz is: 0.00003mW Which is smaller than the Numeric threshold. Therefore, the device is exempt from stand-alone SAR test requirements. 11AppendixB–General Product Information Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 22 of 22 Power calculation (According to C63.10 chapter 9.5) ValueUnit Field Strength Measured (E) 49.93 dBμV/m Measurement Distance(D)3m Equivalent Isotropically Radiated Power (E.I.R.P in dBm) -45.23dBm Equivalent Isotropically Radiated Power(E.I.R.Pin mW)0.00003mW Remark: EIRP = E + 20log(D) −104.7 (EIRP is in dBm, E is indBμV/m, D is in meters) Reviewed by: Prepared by: ______________________ ___________________ Eric LIHosea CHAN SectionManagerEMCProject Engineer AppendixB
TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 1 of 4 RF Exposure Evaluation (Simultaneous Transmission) Model:CamLock, PlungerLock Product Type:SmartLock Applicant:Mobile Technologies Inc. Address:1050 NE 67th Ave, Hillsboro, Oregon, 97124, United States Production Facility (1) :e-BI International Technologies (Shenzhen) Co., Ltd. Address:Floor 13, Tower C, Chuangwei Building, 008 Gaoxin South First Road, High-Tech Park, Nanshan, Shenzhen, China 518057 Production Facility (2) :IBE Electronics Co., Ltd. Address:IBE Industry Mansion, TangTou No.1 Industry Estate, Shiyan Town, Bao’an District, Shenzhen, China. Production Facility (3) :VIETNAM IBE LASER TECHNOLOGY CO LTD. Address:Lot CN-34 and lot CN-39, Thuan Thanh II Industrial Park, An Binh & Mao Dien Commune, Thuan Thanh District, Bac Ninh Province, Vietnam. Test Result:nPositive Total pages including Appendices : 4 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 2 of 4 1.Product information Product:SmartLock Model no.:CamLock, PlungerLock FCC ID:2AA2X-15000333 Rating:3.0V DC (CR2477 battery) Frequency:2405MHz-2480MHz (Zigbee) 125 kHz (RFID) Antenna gain:3.5 dBi (Zigbee) 0 dBi (RFID) Antenna Type:Chip Antenna for 2.4GHz Zigbee Integrated coil antenna for 125kHz RFID Number of operated channel: 16 (Zigbee) 1 (RFID) Modulation:O-QPSK (Zigbee) AM (RFID) TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 3 of 4 2.General SAR Test Exclusion Guidance Simultaneous transmission SAR test exclusion considerations: According to KDB 447498 D01v06 section 4.3.2b, for frequencies between 100 MHz to 6GHz and test separation distances ≤ 50 mm, the Numeric threshold is determined as: 1. [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance ,mm)]·* [√f(GHz) /x] W/kg ≤ 0.4 W/kg for 1-g SAR wherex = 7.5 for 1-g SAR andx = 18.75 for 10-g SAR. 2. 0.4 W/kg for 1-g SAR and 1.0 W/kg for 10-g SAR, when thetest separation distanceis > 50 mm. For 2405 – 2480MHz and 125kHz Transmission Step a) >> The fundamental frequency of the EUT is 2405-2480MHz and 125kHz the test separation distance is ≤ 50mm. (Manufacturer specified the separation distance is: 20mm) (5mm is the worst case according to the KDB) Step b) >> Numeric threshold (2405MHz), mW / 5mm * (√2.405GHz / 7.5) ≤ 0.4 Numeric threshold (2405MHz) ≤ 3.532mW >> Numeric threshold (2440MHz), mW / 5mm * (√2.440GHz / 7.5) ≤ 0.4 Numeric threshold (2440MHz) ≤ 3.506mW >> Numeric threshold (2480MHz), mW / 5mm * (√2.480GHz / 7.5) ≤ 0.4 Numeric threshold (2480MHz) ≤ 3.478mW >> Numeric threshold (125kHz), mW / 5mm * (√0.1GHz / 7.5) ≤ 0.4 Numeric threshold (125kHz) ≤ 17.32mW TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 4 of 4 3.Conclusion for the Simultaneous Transmission The Power according to the RF Report No: 60.790.23.007.01R and 60.790.23.007.02R as below: >> The power (measured + tune up tolerance) of EUT at 2405MHz is: 3.48 dBm = 2.23mW The power (measured + tune up tolerance) of EUT at 2440MHz is: 3.06 dBm = 2.02mW The power (measured + tune up tolerance) of EUT at 2480MHz is: 3.79 dBm = 2.40mW The power (measured + tune up tolerance) of EUT at 125kHz is: -45.23 dBm = 0.0003mW Which is smaller than the Numeric threshold. Therefore, the device is exempt from simultaneous transmission SAR test requirements.
Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 1 of 22 FCC - TEST REPORT Report Number:60.790.23.007.01R02Date of Issue :5 May 2023 Model:CamLock, PlungerLock Product Type:SmartLock Applicant:Mobile Technologies Inc. Address:1050 NE 67th Ave, Hillsboro, Oregon, 97124, United States Production Facility (1) :e-BI International Technologies (Shenzhen) Co., Ltd. Address:Floor 13, Tower C, Chuangwei Building, 008 Gaoxin South First Road, High-Tech Park, Nanshan, Shenzhen, China 518057 Production Facility (2) :IBE Electronics Co., Ltd. Address:IBE Industry Mansion, TangTou No.1 Industry Estate, Shiyan Town, Bao’an District, Shenzhen, China. Production Facility (3) :VIETNAM IBE LASER TECHNOLOGY CO LTD. Address:Lot CN-34 and lot CN-39, Thuan Thanh II Industrial Park, An Binh & Mao Dien Commune, Thuan Thanh District, Bac Ninh Province, Vietnam. Test Result:nPositiveoNegative Total pages including Appendices : 22 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 2 of 22 1 Table of Contents 1 Table of Contents ............................................................................................................ 2 2 Description of Equipment Under Test ............................................................................. 3 3 Summary of Test Standards ........................................................................................... 4 4 Details about the Test Laboratory ................................................................................... 5 4.1 Test Equipment Site List ................................................................................................... 6 4.2 Measurement System Uncertainty .................................................................................... 7 5 Summary of Test Results ................................................................................................ 8 6 General Remarks ............................................................................................................ 9 7 Test Setups ................................................................................................................... 10 7.1 Radiated test setups 9kHz-30MHz .................................................................................. 10 7.2 Radiated test setups 30MHz-1GHz ................................................................................. 10 7.3 Radiated test setups Above 1GHz .................................................................................. 10 7.4 AC Power Line Conducted Emission test setups ............................................................ 11 7.5 Conducted RF test setups............................................................................................... 11 8 Emission Test Results .................................................................................................. 12 8.1 Spurious Radiated Emission ........................................................................................... 12 8.2 20dB & 99% Bandwidth .................................................................................................. 15 9 Test setup procedure .................................................................................................... 16 10 Appendix A – General Models Information ................................................................. 20 11 Appendix B – General Product Information ................................................................. 21 Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 3 of 22 2Description of Equipment Under Test Description of the Equipment Under Test Product:SmartLock Model no.:CamLock, PlungerLock FCC ID:2AA2X-15000333 Rating:3.0V DC (CR2477 battery) Frequency:125kHz(TX and RX) Modulation:AM Auxiliary Equipment Used during Test: DESCRIPTIONMANUFACTURERMODEL NO.REMARK MTI Connect HUBMTI---System Monitoring User TagsMTI---System Monitoring Auxiliary Software Used during Test: DESCRIPTION SOFTWARE NAMEVERSIONREMARK //// Report Number: 60.790.23.007.01R02 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page 4 of 22 3 Summary ofTest Standards Test Standards FCC Pa…
