2AA9WV2003WCDMA Digital Mobile Phone

1 Table of Contents 1.Foreword .......................................................... 2 2.Getting to know your touch phone ................. 5 3.Starting up the device ...................................... 6 4.Introduce the basic phone function ................ 8 5.Technical Specifications ................................ 14 6.SAR ................................................ 16 2 Foreword Safety In order to ensure the phone is used safely and correctly, please read the precautions below carefully before use. 1.1 General precaution ·Your phone is only suitable for the battery and charger approved by our company or else it may cause the battery to leak, overheat, explode or even catch fire. ·Do not knock, vibrate or throw the phone heavily to avoid malfunction, fire, overheating, explosion or fire. ·If there are abnormal phenomena, like temperature rising, color change or distortion during the usage, charging or storage of the battery, please stop using it and replace it with a new battery. ·It may burn the skin if liquid in the battery leaks onto skin or clothes. If this happens please flush with plenty of clean water immediately and go to a hospital at once. ·Please keep the battery away from fire to avoid fire and explosion if the battery leaks or emits a strange smell. ·Do not place expose the battery to moisture or it may cause overheating, fumes and corrosion. ·Do not use or place the battery under direct sunlight, or in hot places, it may cause leakage and overheating, thus reducing performance and shortening the lifespan. ·Do not charge the battery for over 24 hours continuously. ·Use careful with the earphone maybe possible excessive sound presure from earphones and headphones can cause hearing loss. 1.2 Precaution for the use of charger ·Do not cause short circuit to the charger, or it may cause electric shock, fumes and damage to the charger. ·Do not use the charger if the power wire is broken, or it may cause fire and electric shock. ·Please remove accumulated dust on the power plug. ·Do not put water containers next to the power supply to avoid overheating, fire, electric shock and malfunction in case they come into contact. ·Do not disassemble or tamper with the charger or it may cause personal injury, electric shock, fire and the damage of the charger. ·Do not use the charger in places of high humidity, like bathrooms, or it may cause electric shock, fire and damage of charger. 3 ·Do not touch the charger, power cord or power plug with wet hands or it can cause electric shock. ·Do not put heavy objects on the power cord or change the power cord or it may cause electric shock and fire. ·Please unplug the power socket before cleaning and maintenance. ·Please hold the charger to unplug the socket as pulling the power cord may damage the power wire and cause electric shock and fire. 1.3 Cleaning and maintenance ·As the phone, battery and charger are not waterproof, do not use them in places of high humidity and avoid them being wet by rain. ·Please clean the battery and charger with a soft dry cloth. ·Never use alcohol, thinner or solutions, like benzene, to wipe the phone. ·Dirty sockets can cause poor contact and power down, and even make recharging unavailable. So, please clean them periodically. 1.4 Common Precaution Mobile Phone: ·Please use the phone in an environment with temperature between -10°C- 55°Cand humidity of ≤80%. ·Please use the phone far away from regular telephones, TV sets, radio sets and office automation equipment, to avoid affecting the normal use of these equipments and mobile phone. Battery: ·Store the battery in cool and ventilated place without direct sunlight. ·The battery has a limited lifespan. The usage of battery will be shortened progressively due to frequent charging. Once the battery is out of use, it means that its lifespan has ended, and you will need to replace it with an approved new battery. ·Do not dispose of old batteries as household waste. Give them to specified disposal places and follow any stipulated instructions for disposal. CAUTION:RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCYIONS. Charger: ·Do not charge under following conditions: -- places with direct sunlight -- places with ambient temperature less than -10°C or over 55°C, 4 wet or dusty places with strong vibrations (it may cause malfunction) -- places near electrical appliances (it may affect the image and sound) like TV set, radio, etc -- Adapter shall be installed near the equipment and shall be easily accessible. The plug considered as disconnect device of adapter. 5 Getting to know your touch phone 6 Starting up the device To remove the back cover ·Make sure your device is turned off. ·Firmly hold the device with the front panel facing down. ·Slide your finger into the groove at the top of the phone and gently pull open the back cover. To install the SIM card ·Remove the battery if it is installed. ·Locate the SIM card slot, and then insert the SIM card with its gold contacts facing down and its cut-off corner facing out of the card slot as shown in the diagram. ·Slide the SIM card completely into the slot. Note: The phone can support one SIM card. The card will support 2G card and 3G card. To install a memory card To have additional storage for your images, videos, music and files, you can purchase a memory card and install it in your device. Locate the memory card slot on the upper part of the exposed right panel. Insert the memory card into the slot with its gold contacts facing down until it clicks into place To install the battery 1. Align the battery’s exposed copper contacts with the battery connectors at the bottom part of the battery compartment. 2. Insert the contacts side of the battery first and then gently push the battery into place. Replace the back cover. Charging the Battery New batteries are shipped partially charged. Before you start using your device, it is recommended that…

Text truncated - open the document above for the full version.

Authority to Act as Agent Date: 2015/8/04 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: East China Institute of Telecommunications / Yaqiong Wang is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ____12 months__ By: __________________________ _______ Amit Verma __ (Signature 1 ) (Print name) Title: Director of Test Engineering On behalf of: VSN Technologies Inc. d/b/a VSN Mobil _ (Company Name) 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. Amit Verma

Request for Confidentiality Date: 2015/11/17 Subject: Confidentiality Request for: 2AA9WV2003 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ______ VSN Technologies Inc. d/b/a VSN Mobil _____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _____ _ _____ Amit Verma _____ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

I15D00109 External Photo

IMEI:XXXXXXXXXXXXX DIGITAL CELLULAR PHONE/ TELÉFONO CELULAR DIGITAL BRAND/MARCA: V. MODELO: V.45S MODEL NUMBER/NÚMERO DE MODELO: V2003 ELECTRICAL SPECIFICATIONS/ ESPECIFICACIONES ELÉCTRICAS: 3.8 Vcc FCC ID: 2AA9WV2003 SKU: V2003MXWNEXS COLOR: XXXXX S/N:XXXXXXXXXXXXX ARTWORK COMPOSITE Change Log: V.45S IMEI Label 1 SIM -NII Artwork-WHITE Pr oduction Graphics VER.1 August 3, 2015 PRINT BLACK ON WHITE LABEL NEED INFO FILLED IN AND BARS CORRECT BEFORE PRINTING MANUFACTURER/FABRICANTE: VSN MOBIL Made In China/Hecho en China

I15D00109 Internal Photo Charger Charger

Full TEST REPORT No. I15D00109-RFB For Client : VSN Technologies Inc. d/b/a VSN Mobil Production : WCDMA Digital Mobile Phone Model Name : V.45s Model Number: V2003 FCC ID: 2AA9WV2003 Hardware Version: V01 Software Version: V04_20150629_UP39_H456_ NEXTEL_SINGLE_MP Issued date: 2015-11-25 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of ECIT Shanghai. Test Laboratory: ECIT Shanghai, East China Institute of Telecommunications Add: 7-8F, G Area, No.668, Beijing East Road, Huangpu District, Shanghai, P. R. China Tel: (+86)-021-63843300, E-Mail: [email protected] RF Test Report Report No.: I15D00109-RFB East China Institute of Telecommunications Page Number : 2 of 73 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : Nov, 25, 2015 Revision Version Report Number Revision Date Memo I15D000109-RFB 00 2015-08-24 Initial creation of test report I15D000109-RFB 01 2015-11-25 Second creation of test report RF Test Report Report No.: I15D00109-RFB East China Institute of Telecommunications Page Number : 3 of 73 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : Nov, 25, 2015 CONTENTS 1. TEST LABORATORY ............................................................................................... 5 1.1. TESTING LOCATION ............................................................................................... 5 1.2. TESTING ENVIRONMENT ....................................................................................... 5 1.3. PROJECT DATA ...................................................................................................... 5 1.4. SIGNATURE ............................................................................................................. 5 2. CLIENT INFORMATION ........................................................................................... 6 2.1. APPLICANT INFORMATION ................................................................................... 6 2.2. MANUFACTURER INFORMATION ......................................................................... 6 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............ 7 3.1. ABOUT EUT ............................................................................................................. 7 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ...................... 7 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ......................... 7 4. REFERENCE DOCUMENTS ................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING .......................................................... 8 5. SUMMARY OF TEST RESULTS.............................................................................. 9 5.1. NOTES .................................................................................................................... 10 5.2. STATEMENTS ........................................................................................................ 10 6. TEST RESULT ........................................................................................................ 11 6.1. PEAK OUTPUT POWER-CONDUCTED ............................................................... 11 6.2. FREQUENCY BAND EDGES-CONDUCTED ........................................................ 16 6.3. CONDUCTED EMISSION ...................................................................................... 23 6.4. RADIATED EMISSION ........................................................................................... 33 6.5. TIME OF OCCUPANCY (DWELL TIME) ............................................................... 47 6.6. 20DB BANDWIDTH ............................................................................................... 58 6.7. CARRIER FREQUENCY SEPARATION ............................................................... 63 RF Test Report Report No.: I15D00109-RFB East China Institute of Telecommunications Page Number : 4 of 73 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : Nov, 25, 2015 6.8. NUMBER OF HOPPING CHANNELS ................................................................... 66 7. TEST EQUIPMENTS AND ANCILLARIES USED FOR TESTS ........................... 71 8. TEST ENVIRONMENT ........................................................................................... 72 ANNEX A. DEVIATIONS FROM PRESCRIBED TEST METHODS ............................. 73 RF Test Report Report No.: I15D00109-RFB East China Institute of Telecommunications Page Number : 5 of 73 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : Nov, 25, 2015 1. Test Laboratory 1.1. Testing Location Company Name: ECIT Shanghai, East China Institute of Telecommunications Address: 7-8F, G Area, No. 668, Beijing East Road, Huangpu District, Shanghai, P. R. China Postal Code: 200001 Telephone: (+86)-021-63843300 Fax: (+86)-021-63843301 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -10/+55°C Relative Humidity: 20-75% 1.3. Project data Project Leader: Wang Yaqiong Testing Start Date: 2015-07-28 Testing End Date: 2015-08-21 1.4. Signature Shi Hongqi (Prepared this test report) Liu Jianquan (Reviewed this test report) Zheng Zhongbin Director of the laboratory (Approved this test report) RF Test Report Report No.: I15D00109-RFB East China Institute of Telecommunications Page Number : 6 of 73 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : Nov, 25, 2015 2. Client Information 2.1. Applicant Information Company Name: VSN Technologies Inc. d/b/a VSN Mobil Address: 1975 E. Sunrise Blvd. Suite 400, Fort Lauderdale FL Telephone: 954-609-4912 Postcode: 33304 2.2. Manufacturer Information Company Name: Mobiwire Mobiles (Ningbo) Co., Ltd Address: No.999,Dacheng East Road,Fenghua City,Zhejiang Telephone: +86-0574-59550618 Postcode: 315500 RF Test Report Report No.: I15D00109-…

Text truncated - open the document above for the full version.

Test Photograph Description: Conducted Emission Test Setup Description: Radiated Emission Test Setup (30-1000MHz) Description: Radiated Emission Test Setup (1-18GHz) Description: Radiated Emission Test Setup (Above 18GHz)
