2AAAL-T019-315-FR01RF Wireless Remote Controller for LED controller

User manual There are four keys on the product,and each key stand for a sole code with the carrier of 315MHz. For example: If you press k1 button,the transmitter will transmit a serial code with the carrier of 315MHz,and it is sole，we called it channel 1.and at the same time,the receiver which have the same code with the transmitter,received the code ,it will take some action,just for example,control the relay,led,beep,and so on. K2 stand for channel 2,and has the same usage with K1 which describe above. And so do k3,k4... FCC Statement： This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFEREN CE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

Dalian Seaside Door Controlling System Co. Ltd. SAMPLE LETTER OF AUTHORIZATION Type the following letter on your company letterhead: DATE: 2015-03-05 To whom it may concern: We the undersigned, hereby authorize < Shenzhen Huatongwei International Inspection Co., LTD.> to act as our authorized agent on our behalf in all manners relating to application for FCC equipment authorization, including signing of all documents relating to these matters. Any individual within this entity may act on our behalf. Any and all acts carried out by < Shenzhen Huatongwei International Inspection Co., LTD..> on our behalf shall have the same effect as acts of our own. This authorization is valid until further written notice from < Dalian Seaside Door Controlling System Co. Ltd.>. Sincerely, (Name and Title) :Wei Zhao/ Technical Manager 2015-03-05

Dalian Seaside Door Controlling System Co. Ltd. 2015-03-05 FO023_FCC Sample Confidentiality Form, Confidentiality form.docx FO023 – FCC SAMPLE CONFIDENTIALITY FORM Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Dalian Seaside Door Controlling System Co. Ltd.would like the following documents regarding this submission for FCC ID: 2AAAL-T019-315-FR01to be kept confidential. 1. operation .pdf. 2. block diagram .pdf 3. sch .pdf The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Wei Zhao / Technical Manager 2015-03-05
