2AAC4-31990Notification Bracelet

Case-Mate, Inc.

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Mar 18, 2015
Application Purpose: Original Equipment
Date of Application: Mar 18, 2015
Equipment Note: Notification Bracelet
Frequency Range: 2402.00000000 - 2480.00000000
Company: Case-Mate, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: 2AAC4-31990 IC: 12369A-CM031990 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 14-0408 Manufacturer: Case-Mate, Inc. Model: CM031990 NOTIFICATION BRACELET COMPATIBILITY The CM x Rebecca Minkoff Notification Bracelet is compatible with the following Apple devices with iOS 7.1 or above installed: GETTING STARTED What’s Included iPhone 6 PlusiPhone 6iPhone 5/5s/5ciPhone 4/4s charging port Before You Begin Your Notification Bracelet must be fully charged before first use. Lift the cover of the charging port on the side of the Bracelet and connect the included micro USB charging cable. Then connect the USB side of the cable to an available USB port on your computer or USB wall adapter. Notification BraceletCharging CableQuick Start Guide 1 Pairing with Your Device Bluetooth pairing with your device must completed through the RM Wearables companion app. Simply open the app and follow the on-screen instructions to guide you through the pairing process. Download and Install the Companion App Device pairing and contact setup requires the download of the “RM Wearables” app from the iOS App Store. Once you have the app installed on your device, check for any available updates in the Settings tab and make sure you have the latest version installed. 2 SETTING UP YOUR CONTACTS The Notification Bracelet lets you create your own Inner Circle and select up to 25 of your most important contacts that you’d like to receive notifications from. The RM Wearables companion app makes contact setup a breeze by pairing with your device’s address book. Follow the on- screen instructions to guide you through contact setup and the Bracelet will gently vibrate when you receive a call or text from your Inner Circle. SILENCING NOTIFICATIONS If you wish to silence vibrations for incoming calls or texts, simply press the button on the side of the bracelet. silence notifications 3 BATTERY LIFE & POWER Battery Life The Notification Bracelet features a rechargeable battery that lasts up to 30 days between charges with normal use. You can check the battery level of your Bracelet in the RM Wearables companion app. charging port Charging the Notification Bracelet The Notification Bracelet features a concealed micro USB port for easy charging. Simply lift the cover and connect the included micro USB cable to the Bracelet and a USB power source such as a computer or USB wall outlet. A full charge will take approximately four hours. Once the Bracelet has been fully charged, the battery will last for up to 30 days depending on use. UPDATING THE BRACELET New updates and features may be available for your Notification Bracelet. Please allow push notifications for the RM Wearables app so it can notify you when updates are available. You can also manually check for updates in the Settings tab of the app. 4 WARRANTY INFORMATION The Notification Bracelet includes a 1-year warranty from date of purchase. For detailed warranty information, please visit www.case-mate.com/warranty or contact Case-Mate customer service at: (866) 689-3432 support.case-mate.com Monday - Friday, 9am to 6pm (EST) USA: Federal Communications Commission (FCC) Statement Name: Notification Bracelet Model: CM031990 FCC ID: 2AAC4-31990 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced technician for help. FCC Warning: Changes or modifications to this device not expressly approved by Case-Mate, Inc. could void the user’s authority to operate the equipment. Case-Mate, Inc. 2048 Weems Rd. Tucker, GA 30084 U.S.A. +1 (866) 689-3432 REGULATORY AND SAFETY NOTICES 5 Canada: Industry Canada (IC) Statement Name: Notification Bracelet Model: CM031990 IC: 12369A-CM031990 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. l’appareil ne doit pas produire de brouillage, et 2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and i…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: 11/12/14 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: 2AAC4-31990 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Saumil Mody Title: Director - Engineering & Sourcing

Cover Letter(s)

CONFIDENTIALITY REQUEST Federal Communications Commission Date: 11/12/14 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: CASE-MATE, INC. respectfully requests confidentiality of certain materials provided with the submission of the CM031990 Notification Bracelet under FCC ID: 2AAC4-31990 in accordance with 47 CFR 0.457(d) and 47 CFR 0.459. contained in this filing and included in the following files. 14-0408 – Schematics.pdf 14-0408 – System Block Diagram.pdf 14-0408 – Theory of Operation.pdf The CM031990 Notification Bracelet has been developed at considerable effort and expense by CASE-MATE, INC. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Saumil Mody Signature: Title: Director - Engineering & Sourcing Date: 11/12/14 The confidentiality request applies to the (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 December 18, 2014 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: 2AAC4-31990 To Whom It May Concern: The following application is submitted on behalf of our client, Case-Mate, Inc., for evaluation of their model CM031990 for certification under FCC Part 15.249. The CM031990 is a wearable, battery powered bracelet that connects to a smartphone using Bluetooth LE protocols. The CM031990 pairs to a smartphone and produces a vibration pattern when a text or phone call is received by the paired smartphone. The CM031990 was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: 2AAC4-31990 IC: 12369A-CM031990 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Report Number: 14-0408.W06.1B Manufacturer: Case-Mate, Inc. Model: CM031990 Test Begin Date: November 10, 2014 Test End Date: November 26, 2014 Report Issue Date: January 16, 2014 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 15 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1GENERAL .............................................................................................................................................. 3 1.1PURPOSE............................................................................................................................................ 3 1.2PRODUCT DESCRIPTION..................................................................................................................... 3 1.3TESTMETHODOLOGY ANDCONSIDERATIONS................................................................................... 3 2TEST FACILITIES ................................................................................................................................ 4 2.1LOCATION......................................................................................................................................... 4 2.2LABORATORYACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS.................................................. 4 2.3RADIATEDEMISSIONSTESTSITEDESCRIPTION................................................................................ 5 2.3.1Semi-Anechoic Chamber Test Site ........................................................................................... 5 2.3.2Open Area Tests Site (OATS) ................................................................................................... 6 2.4CONDUCTEDEMISSIONSTESTSITEDESCRIPTION............................................................................ 7 3APPLICABLE STANDARD REFERENCES ..................................................................................... 7 4LIST OF TEST EQUIPMENT.............................................................................................................. 8 5SUPPORT EQUIPMENT ...................................................................................................................... 9 6EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ............................................................ 9 7SUMMARY OF TESTS ....................................................................................................................... 10 7.1ANTENNAREQUIREMENT–FCC15.203......................................................................................... 10 7.2POWERLINECONDUCTEDEMISSIONS–FCC15.207;ICRSS-GEN8.8 ......................................... 10 7.2.1Measurement Procedure ........................................................................................................ 10 7.2.2Measurement Results.............................................................................................................. 10 7.320DB/99%BANDWIDTH–FCC15.215;ICRSS-210A8.1(A) ...................................................... 11 7.3.1Measurement Procedure ........................................................................................................ 11 7.3.2Measurement Results.............................................................................................................. 11 7.4FUNDAMENTALFIELDSTRENGTH–FCC15.249(A);ICRSS-210A2.9(A) .................................... 13 7.4.1Measurement Procedure ........................................................................................................ 13 7.4.2Measurement Results.............................................................................................................. 13 7.5RADIATEDSPURIOUSEMISSIONS–FCC15.249(A)(D)(E);ICRSS-2102.2,RSS-GEN8.9/8.10 .... 14 7.5.1Measurement Procedure ........................................................................................................ 14 7.5.2Measurement Results.............................................................................................................. 14 7.5.3Sample Calculation: ............................................................................................................... 15 8CONCLUSION ..................................................................................................................................... 15 Model: CM031990FCC ID: 2AAC4-31990IC: 12369A-CM031990 ACS Report: 14-0408.W06.1BAdvanced Compliance SolutionsPage 3 1GENERAL 1.1Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210 for Certification. 1.2Product description The EUT is a wearable BLE device in the form of a bracelet. It pairs to a smartphone and produces a vibration pattern when a text or phone call is received by the paired smartphone. Technical Information: DetailDescription Frequency Range2402 -2480 MHz Number of Channels40 Modulation FormatGFSK Operating Voltage3.0 VDC (Internal Battery) / 5.0 VDC (USB) Antenna Type / GainCeramic chip antenna / 1.7 dBi Manufacturer Information: Case-Mate, Inc. 2048 Weems Road Tucker, GA 30084 EUT Serial Numbers: ACS#1 Test Sample Condition: The test samples were provided in good working ord…

Text truncated - open the document above for the full version.

Test Setup Photos
