2AAC4-POWERDISCV1Power Disc Wireless Charger

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licenceexempt RSS(s). Operation is subject to the following two conditions: CAN RSS-216 / CNR-216. CAN RSS-216 / CNR-216.

Differences Description We Case-Mate, Inc. state: FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1 Product name: Power Disc Wireless Charger Model: CM044810, CM044886 All model’s the function, software and electric circuit are the same, only to different guest with the appearance, shape and model name. Signature: Date: 2020.09.24 Signatory Name Saumil Mody Position Director of Engineering Company Name Case-Mate, Inc. Address 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. Tel (765) 409-3883 Fax (770) 888-8695 Email [email protected]

September 24, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AAC4-POWERDISCV1 Product Name: Power Disc Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date: 2020.09.24 Signatory Name Saumil Mody Position Director of Engineering Company Name Case-Mate, Inc. Address 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. Tel (765) 409-3883 Fax (770) 888-8695 Email [email protected] Case-Mate, Inc.

FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1

4.5cm 2.5cm FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1 Case-Mate, Inc. Product name: Power Disc Wireless Charger Model No.: CM044810 Label Location 4.5cm 2.5cm FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1 Case-Mate, Inc. Product name: Power Disc Wireless Charger Model No.: CM044886

FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1 ANT

FCC TEST REPORT FCC ID: 2AAC4-POWERDISCV1 On Behalf of Case-Mate, Inc. Power Disc Wireless Charger Model No.: CM044810, CM044886 Prepared for Address : Case-Mate, Inc. : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2009021-C01-R02 Date of Receipt : September 9, 2020 Date of Test : September 9, 2020-September 15, 2020 Date of Report : September 15, 2020 Version Number : V0 Page 2 of 14 Report No.: A2009021-C01-R02 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. EUT Description ....................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup .............................................................................. 13 5. Photographs of EUT .............................................................................. 14 Page 3 of 14 Report No.: A2009021-C01-R02 TEST REPORT DECLARATION Applicant Address Manufacturer Address : Case-Mate, Inc. : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. : Case-Mate, Inc.C : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. EUT Description : Power Disc Wireless Charger (A) Model No. : CM044810, CM044886 (B) Trademark : N/A Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: September 15, 2020 Page 4 of 14 Report No.: A2009021-C01-R02 Revision History Revision Issue Date Revisions Revised By V0 September 15, 2020 Initial released Issue Lucas Pang Page 5 of 14 Report No.: A2009021-C01-R02 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 14 Report No.: A2009021-C01-R02 2.EUT Description 2.1. Description of Device (EUT) EUT Name : Power Disc Wireless Charger Model No. : CM044810, CM044886 DIFF. : There is no difference except for the appearance, shape and model name. So all the test were performed on the model CM044810. Trademark : N/A Power supply : Type-C Input: DC 5V/2A, DC 9V/2A, Wireless Output: 5W, 7.5W, 10W(Max). Operation frequency : 125~200KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Page 7 of 14 Report No.: A2009021-C01-R02 Conditions requirement Answers Power transfer frequency is less than 1 MHz. After measuring the product the transfer frequency is 125-200KHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 10 watts The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. The transfer system includes only single primary. Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter. Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only. The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. After measuring the product the Max H-field Stren…

Text truncated - open the document above for the full version.

FCC TEST REPORT FCC ID: 2AAC4-POWERDISCV1 On Behalf of Case-Mate, Inc. Power Disc Wireless Charger Model No.: CM044810, CM044886 Prepared for : Case-Mate, Inc. Address : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2009021-C01-R01 Date of Receipt : September 9, 2020 Date of Test : September 9, 2020-September 15, 2020 Date of Report : September 15, 2020 Version Number : V0 Page 2 of 34 Report No.: A2009021-C01-R01 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. General Information ................................................................................. 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 7 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 7 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 7 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 7 2.6. TEST CONDITIONS ................................................................................................................................. 7 2.7. TEST FACILITY ...................................................................................................................................... 8 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 8 2.9. TEST EQUIPMENT LIST ........................................................................................................................... 9 3. Test Results and Measurement Data ................................................... 11 3.1. CONDUCTED EMISSION ........................................................................................................................ 11 3.2. RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................... 14 3.3. TEST SPECIFICATION ........................................................................................................................... 22 4. Photos of test setup .............................................................................. 24 5. Photographs of EUT .............................................................................. 26 Page 3 of 34 Report No.: A2009021-C01-R01 TEST REPORT DECLARATION Applicant : Case-Mate, Inc. Address : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. Manufacturer : Case-Mate, Inc. Address : 7000 Central Pkwy., Ste. 1050, Atlanta, GA 30328, U.S.A. EUT Description : Power Disc Wireless Charger (A) Model No. : CM044810, CM044886 (B) Trademark : N/A Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: September 15, 2020 Page 4 of 34 Report No.: A2009021-C01-R01 Revision History Revision Issue Date Revisions Revised By V0 September 15, 2020 Initial released Issue Lucas Pang Page 5 of 34 Report No.: A2009021-C01-R01 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 34 Report No.: A2009021-C01-R01 2.General Information 2.1. Description of Device (EUT) EUT Name : Power Disc Wireless Charger Model No. : CM044810, CM044886 DIFF. : There is no difference except for the appearance, shape and model name. So all the test were performed on the model CM044810. Trademark : N/A Power supply : Type-C Input: DC 5V/2A, DC 9V/2A, Wireless Output: 5W, 7.5W, 10W(Max). Operation frequency : 125~200KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Page 7 of 34 Report No.: A2009021-C01-R01 2.2. Accessories of Device (EUT) Accessories1 : Power Supply Manufacturer : SHENZHEN DISHENGHUI ELECTRONICS CO., LTD Model : DBS15Q Ratings : Input: AC 100-240V 50/60Hz 500mA, Output: DC 5V/3A, 9V/2A, 12V/1.5A 2.3. Tested Supporting System Details No. Description Manufacturer Model Serial Number Certification or SDOC 1 Wireless load -- -- -- N/A 2 USB cable -- -- -- N/A 2.4. Block Diagram of connection between EUT and simulators 2.5. Description of Test Modes Channel Frequency (KHz) 1 139 2.6. Test Conditions Items Requi…

Text truncated - open the document above for the full version.

FCC ID: 2AAC4-POWERDISCV1 IC: 12369A-POWERDISCV1 Radiated Emission Conducted Emission
