2AAC4-CMPOWERDISCPower Disc Wireless Charger

Score/Fold: Trim: Substrate: 250gsm, C2S Safety: Filename: PM042203 User Guide - Power Disc Wireless Charger File Date: 12.03.2019 Artwork Scale: 100% Printing Inks / Foils PANTONE BLACK C Finishes MATTE PP COATING 7000 Central Parkway, Suite 1050 Atlanta, Georgia, 30328 ©Case-Mate Inc. USER GUIDE MODE D'EMPLOI SAFETY AND PRECAUTIONS Wireless charging may not work eciently or at all if you have a thick case attached to your device. For best results, remove your case prior to wireless charging. Only use the included wall adapter for ideal charging performance and safety. For indoor use only. Keep charger and power adapter away from humid conditions. Do not place metal or any foreign objects on the wireless charging base. Device and base may get warm during wireless charging. This is normal behavior and both will cool down after the device is charged. SÉCURITÉ ET PRÉCAUTIONS La recharge sans fil peut ne pas fonctionner ecacement ou pas du tout si vous avez un boîtier épais attaché à votre appareil. Pour de meilleurs résultats, retirez votre étui avant la recharge sans fil. N'utilisez que l'adaptateur mural fourni pour une performance de charge et une sécurité optimales. Pour une utilisation en intérieur uniquement. Maintenez le chargeur et l'adaptateur secteur à l'abri des conditions humides. Ne placez pas de métal ou d'objets étrangers sur la base de chargement sans fil. L'appareil et la base peuvent chauer pendant le chargement sans fil. Ce comportement est normal et les deux se refroidissent une fois l'appareil chargé. SPECIFICATIONS Qi Inductive Coupling Wireless Charging Qi EPP Certified 1.2.4 Dimensions : 3.8in diameter x 0.35in Operating Temperature Range: -10C to 60C Input Power: DC 5V 2A / 9V 2A (MAX) Output Power: 10W (MAX) CARACTÉRISTIQUES Couplage inductif Qi sans fil Certifié Qi EPP 1.2.4 Dimensions: 3,8 po de diamètre x 0,35 po Plage de température de fonctionnement: -10C à 60C Puissance d'entrée: DC 5V 2A / 9V 2A (MAX) Puissance de sortie: 10W (MAX) FCC STATEMENT DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Case-Mate Inc., of 7000 Central Parkway, Suite 1050, Atlanta, GA 30328, declare under our sole responsibility that the Power Pad Wireless Charger product, to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try and correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the distance between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from the that to which the receiver is connected. • Consult the dealer or an experienced radio /TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Raditation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC RF exposure compliance requirements, please follow operation instructions as documented in this guide. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. IMPORTANT NOTE: Industry Canada Statement This device complies with RSS-216 of the Industry Canada Rules. Operation is subject to the two conditions: 1) This device may not cause interference, and 2) This device must accept any interference, including interference that may cause undesired operation of the device. Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 10cm between the radiator and your body. Innovation, Science and Economic Development Canada Statement: This digital appartus complies with CAN ICES-3(B)/NMB-3 (B). DÉCLARATION DE LA FCC DÉCLARATION DE CONFORMITÉ AUX RÈGLES DE LA FCC CONCERNANT LA COMPATIBILITÉ ÉLECTROMAGNÉTIQUE NOUS, CASE-MATE INC., DE 7000 CENTRAL PARKWAY, SUITE 1050, ATLANTA, GA 30328, DÉCLARONS SOUS NOTRE SEULE RESPONSABILITÉ QUE LE PRODUIT POWER PAD WIRELESS CHARGER, AUQUEL SE RAPPORTE CETTE DÉCLARATION, EST CONFORME À LA PARTIE 15 DES RÈGLES DE LA FCC. SON FONCTIONNEMENT EST SOUMIS AUX DEUX CONDITIONS SUIVANTES: (1) CET APPAREIL NE DOIT PAS CAUSER D'INTERFÉRENCES NUISIBLES, ET (2) CET APPAREIL DOIT ACCEPTER TOUTE INTERFÉRENCE REÇUE, Y COMPRIS LES INTERFÉRENCES POUVANT PROVOQUER UN FONCTIONNEMENT INDÉSIRABLE. DÉCLARATION D'INTERFÉRENCE DE LA FEDERAL COMMUNICATIONS COMMISSION CET ÉQUIPEMENT A ÉTÉ TESTÉ ET DÉCLARÉ CONFORME AUX LIMITES D'UN APPAREIL NUMÉRIQUE DE CLASSE B, CONFORMÉMENT À LA PARTIE 15 DES RÈGLES DE LA FCC. CES LIMITES SONT CONÇUES POUR FOURNIR UNE PROTECTION RAISONNABLE CONTRE LES INTERFÉRENCES NUISIBLES DANS UNE INSTALLATION RÉSIDENTIELLE. CET ÉQUIPEM…

Text truncated - open the document above for the full version.

FCC ID: 2AAC4-CMPOWERDISC

Label Location On EUT Label Product Name: Power Disc Wireless Charger Model No.: CM042200 FCC ID: 2AAC4-CMPOWERDISC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AAC4-CMPOWERDISC ANT

version01 Case-Mate.Inc. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: CM042200, C-077, C-129 FCC ID : 2AAC4-CMPOWERDISC fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: CM042200 Type of antenna:Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range:110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Case-Mate.Inc. Address: 7000 Central Pkwy., Ste. 1050 Atlanta GA 30328-4590 United States City:ATLANTA ZIP / Postal code: N/A Country:UNITED STATES Place:UNITED STATESDate: 2020-04-13 Signature:

Report No.: 18220WC00010802FCC ID: 2AAC4-CMPOWERDISCPage 1 of 13 Code:AB-RF-05-a FCC TEST REPORT Client Name: Case-Mate.Inc. Address: 7000 Central Pkwy., Ste. 1050 Atlanta GA 30328-4590 United States Product Name: Power Disc Wireless Charger Date: Apr. 13, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00010802FCC ID: 2AAC4-CMPOWERDISCPage 2 of 13 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 5 2. Measurement and Result ..................................................................................................................................... 6 2.1. Requirements .............................................................................................................................................. 6 2.2. Test Setup .................................................................................................................................................... 7 2.3. Test Procedure ............................................................................................................................................ 7 2.4. Test Result ................................................................................................................................................... 7 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 7 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 .................................................................................................................................................................. 9 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00010802FCC ID: 2AAC4-CMPOWERDISCPage 3 of 13 Code:AB-RF-05-a TEST REPORT Applicant: Case-Mate.Inc. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Power Disc Wireless Charger Model No.: CM042200, C-077, C-129 Trade Mark: ,, Rating(s): Input: DC 5V, 2A/DC 12V, 1.5A(via adapter input:AC 100~240V,50/60Hz ,0.5A;output:12V 1.5A) Wireless output: 5W/7.5W/10W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptFeb. 28, 2020 Date of TestFeb. 28~Mar. 16, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00010802FCC ID: 2AAC4-CMPOWERDISCPage 4 of 13 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Power Disc Wireless Charger Model No.: CM042200,C-077,C-129 (Note: All samples are the same except the model appearance, so we prepare "CM042200" for test only.) Trade Mark: ,, Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:ASK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Case-Mate.Inc. Address: 7000 Central Pkwy., Ste. 1050 Atlanta GA 30328-4590 United States Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Factory: Dongguan Tyjin Electronics Co., Ltd. Address : Shitouling Industrial Zone, Wulian Village, Fenggang Town, Dongguan, China Report No.: 18220WC00010802FCC ID: 2AAC4-CMPOWERDISCPage 5 of 13 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Tyjin M/N: C-040 S/N: 201202102100876 Input: 100-240V~ 50/60Hz, 0.5A Output: DC 3.6-6V, 3A/DC 6-9V, 2A/DC 9-12V, 1.5A 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 23, 2019 1 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Horizontal) Ur = 3.8 dB (Vertical) Conduction Uncertainty: Uc = 3.4 dB 1…

Text truncated - open the document above for the full version.

Report No.: 18220WC00010801FCC ID: 2AAC4-CMPOWERDISCPage 1 of 28 Code:AB-RF-05-a FCC TEST REPORT Client Name: Case-Mate.Inc. Address: 7000 Central Pkwy., Ste. 1050 Atlanta GA 30328-4590 United States Product Name: Power Disc Wireless Charger Date: Apr. 13, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00010801FCC ID: 2AAC4-CMPOWERDISCPage 2 of 28 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 13 4.3. Test Procedure .......................................................................................................................................... 14 4.4. Test Data .................................................................................................................................................... 15 5. Antenna Requirement ......................................................................................................................................... 19 5.1. Test Standard and Requirement ............................................................................................................ 19 5.2. Antenna Connected Construction .......................................................................................................... 19 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 20 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 22 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 26 Report No.: 18220WC00010801FCC ID: 2AAC4-CMPOWERDISCPage 3 of 28 Code:AB-RF-05-a TEST REPORT Applicant: Case-Mate.Inc. Manufacturer: Dongguan Tyjin Electronics Co., Ltd. Product Name: Power Disc Wireless Charger Model No.: CM042200, C-077, C-129 Trade Mark: ,, Rating(s): Input: DC 5V, 2A/DC 12V, 1.5A(via adapter input:AC 100~240V,50/60Hz ,0.5A;output:12V 1.5A) Wireless output: 5W/7.5W/10W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptFeb. 28, 2020 Date of TestFeb. 28~Mar. 16, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00010801FCC ID: 2AAC4-CMPOWERDISCPage 4 of 28 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: Case-Mate.Inc. A…

Text truncated - open the document above for the full version.

FCC ID: 2AAC4-CMPOWERDISC Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
