USA CANADA nFCC Information (For US customers) 1. IMPORTANT NOTICE : DO NOT MODIFY THIS PRODUCT This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modification not expressly approved by Denon may void your authority, granted by the FCC, to use the product. 2. CAUTION • To comply with FCC RF exposure compliance requirement, separation distance of at least 20 cm must be maintained between this product and all persons. • This product and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. 3. COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Product Name : HOME THEATER SYSTEM • Model: DHT-S514 • This product FCC ID: 2AAGJDHTS514 Denon Electronics (USA), LLC (a D&M Holdings Company) 100 Corporate Drive Mahwah, NJ 07430-2041 Tel. (201) 762-6665 4. NOTE This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the product OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the product into an outlet on a circuit different from that to which the receiver is connected. • Consult the local retailer authorized to distribute this type of product or an experienced radio/TV technician for help. nIC Information (For Canadian customers) 1. PRODUCT This product IC: 11154A-DHTS514 This product complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES- 003. 2. CAUTION To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. nInformations sur IC (pour les clients canadiens) 1. APPAREIL Cet appareil contiens IC: 11154A-DHTS514 Cet appareil est conforme à la norme CNR-210 du Canada. L’utilisation de ce dispositif est autorisée seulement aux deux conditions suivantes : (1) il ne doit pas produire de brouillage, et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 2. ATTENTION Afin de réduire le risque d’interférence aux autres utilisateurs, il faut choisir le type d’antenne et son gain de façon à ce que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne soit pas supérieure au niveau requis pour l’obtention d’une communication satisfaisante. For Canadian customers: CAN ICES-3(B)/NMB-3(B) nRF Exposure Information This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR). Cet équipement est conforme aux normes d’exposition aux radiations FCC/IC définies pour un environnement non contrôlé et satisfait les directives d’exposition à la radiofréquence (RF) dans le supplément C des OET65 et RSS-102 des règles d’exposition à la fréquence radio (RF) IC. Cet équipement a de très faibles niveaux d’énergie RF qui sont jugés conformes sans test de taux d’absorption spécifique (SAR). EU Notes on radio [ENGLISH] 1. DECLARATION OF CONFORMITY Our products following the provisions of EC/EU directives, that as follows; R&TTE Directive 1999/5/EC 2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT This product, when installed as indicated in the instructions contained in this manual, meets R&TTE directive requirements. Modification of the product could result in hazardous Radio and EMC radiation. 3. CAUTION Separation distance of at least 20 cm must be maintained between this product and all persons. This product and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. [DEUTSCH] 1. ÜBEREINSTIMMUNGSERKLÄRUNG Unsere Produkte unterliegen den Bestimmungen der folgenden EG/ EU-Richtlinien: R&TTE Directive 1999/5/EC 2. WICHTIGER HINWEIS: NEHMEN SIE KEINE VERÄNDERUNGEN AN DIESEM PRODUKT VOR Wenn dieses Produkt entsprechend dieser Bedienungsanleitung aufgebaut wird, entspricht es den Anforderungen der R&TTE-Richtlinie. Veränderungen am Produkt können zu gefährlicher Funk- und EMV-Strahlung führen. 3. VORSICHT Zwischen dieses Produkts und Personen muss ein Schutzabstand von 20 cm eingehalten werden. Dieses Produkt und seine Antenne dürfen nicht neben anderen Antennen oder Sendern aufgestellt oder zusammen mit ihnen verwendet werden. [FRANÇAIS] 1. DÉCLARATION DE CONFORMITÉ Nos produits sont conformes aux dispositions des directi…

Text truncated - open the document above for the full version.

USA CANADA nFCC Information (For US customers) 1. IMPORTANT NOTICE : DO NOT MODIFY THIS PRODUCT This product,when installed as indicated in the instructions contained in this manual,meets FCC requirements. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2. CAUTION • To comply with FCC RF exposure compliance requirement, separation distance of at least 20 cm must be maintained between this product and all persons. • This product and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. 3. COMPLIANCE INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Product Name : HOME THEATER SYSTEM • Model: DHT-S514 • This product FCC ID: 2AAGJDHTS514 (soundbar) 2AAGJDHTS514A (subwoofer) Denon Electronics (USA), LLC (a D&M Holdings Company) 100 Corporate Drive Mahwah, NJ 07430-2041 Tel. (201) 762-6665 4. NOTE This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the product OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the product into an outlet on a circuit different from that to which the receiver is connected. • Consult the local retailer authorized to distribute this type of product or an experienced radio/TV technician for help. nIC Information (For Canadian customers) 1. PRODUCT This product IC: 11154A-DHTS514 (soundbar) 11154A-DHTS514A (subwoofer) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-3(B)/NMB-3(B) 2. CAUTION To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. nInformations sur IC (pour les clients canadiens) 1. APPAREIL Cet appareil IC: 11154A-DHTS514 (soundbar) 11154A-DHTS514A (subwoofer) Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-3(B)/NMB-3(B) 2. ATTENTION Afin de réduire le risque d’interférence aux autres utilisateurs, il faut choisir le type d’antenne et son gain de façon à ce que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne soit pas supérieure au niveau requis pour l’obtention d’une communication satisfaisante. For Canadian customers: CAN ICES-3(B)/NMB-3(B) nRF Exposure Information This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR). Cet équipement est conforme aux normes d’exposition aux radiations FCC/IC définies pour un environnement non contrôlé et satisfait les directives d’exposition à la radiofréquence (RF) dans le supplément C des OET65 et RSS-102 des règles d’exposition à la fréquence radio (RF) IC. Cet équipement a de très faibles niveaux d’énergie RF qui sont jugés conformes sans test de taux d’absorption spécifique (SAR). Notes on radio DHT-S514E2E3_Notes on radio_Final_1205.indd 12013/12/05 19:10:29 Bulgarian Български Cнастоящето, Denon декларира, че това безжично устройство е в съответствие със съществените изисквания и другите приложими разпоредби на Директива 1999/5/EC. Czech Česky Denon tímto prohlašuje, že tento Radio LAN device je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Danish Dansk Undertegnede Denon erklærer herved, at følgende udstyr Radio LAN device overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Estonian Eesti Käesolevaga kinnitab Denon seadme Radio LAN device vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. Finnish Suomi Valmistaja Denon vakuuttaa täten että Radio LAN device tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Greek Ελληνική με την παρουσα Denon δηλωνει οτι radio LAN device συμμορφωνεται προσ τισ ουσιωδεισ απαιτησεισ και τισ λοιπεσ σχετικεσ διαταξεισ τησ οδηγιασ 1999/5/εκ. Hungarian Magyar Alulírott, Denon nyilatkozom, hogy a Radio LAN device megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Latvian Latviski Ar šo Denon deklarē, ka Radio LAN dev…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1310C090 Page 3 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 4 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 5 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 6 of 17

System Model: SC-S514 DVR NO. Suki.Deng 注記： 1、所有零部件都需经超声工程师确定后才可生产. 2、有 標記的尺寸為重要管制(IQC必檢)尺寸. 3、有◆標記的尺寸為客戶重要管制(IQC必檢)尺寸. 4、未標示的尺寸請參照 3D CAD. 5、產品材質應符合RoHS. 6、拔模斜度最大为1,除另行通知外. 7、图中未标注的半径应为0.2mm。 8、材質: 9、表面处理: 10、請使用超聲工程提供的美工稿直接制板. 11、禁止更改客戶的美工稿(不可在客戶的美工稿上作任何修改動作,超聲工程部有書面通知除外). 12、未標注公差的尺寸參照IT15. （重量: 體積： mm ） 2 F176-0705C 01 Rating Label For Soundbar DHT-S514 Soundbar Suki.Deng2013-11-22 黑底白字，过哑膜 铜版纸FASSON-AW5209 109.4mm 27.4mm ANMATVE28-J210/11 YLBA11004-0002 YLBA11004-X002 135 0.8g “MODEL NO.””Model:”Suki.Deng2013-12-3 DHT-S514 DVR NO. Suki.Deng 注記： 1、所有零部件都需经超声工程师确定后才可生产. 2、有 標記的尺寸為重要管制(IQC必檢)尺寸. 3、有◆標記的尺寸為客戶重要管制(IQC必檢)尺寸. 4、未標示的尺寸請參照 3D CAD. 5、產品材質應符合RoHS. 6、拔模斜度最大为1,除另行通知外. 7、图中未标注的半径应为0.2mm。 8、材質: 9、表面处理: 10、請使用超聲工程提供的美工稿直接制板. 11、禁止更改客戶的美工稿(不可在客戶的美工稿上作任何修改動作,超聲工程部有書面通知除外). 12、未標注公差的尺寸參照IT15. （重量: 體積： mm ） 2 F176-0705C 00 Caution Label For Soundbar DHT-S514 Soundbar(US) Suki.Deng2013-12-3 黑底白字，过哑膜 铜版纸FASSON-AW5209 109.4mm 27.4mm ANMATVE28-J210 YLBA16010-0001 YLBA16010-X001 45 0.8g Label location

Neutron Engineering Inc. Project No.: 1310C090 Page 7 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 8 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 9 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 10 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 11 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 12 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 13 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 14 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 15 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 16 of 17 Neutron Engineering Inc. Project No.: 1310C090 Page 17 of 17

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: 2AAGJDHTS514 Project No. : 1310C090 Equipment : HOME THEATER SYSTEM Model : SC-S514 Applicant : T ymphany HK Limited Address : Room 1307-8 Dominion Centre 43-59 Queen’s Road East , WanChai, Hong Kong According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand Model NameAntenna TypeConnector Gain (dBi) 1 N/A N/A PCB N/A 0 TEST RESULTS EUT: HOME THEATER SYSTEM Model Name : SC-S514 Temperature: 24 °C Relative Humidity: 58 % Pressure: 1009 hPa Test Voltage : AC120V/60Hz Test Mode : CH00/ CH39 /CH78 -1Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 3.38 2.1777 0.000433461 Complies 0 1.0000 3.78 2.3878 0.000475281 Complies 0 1.0000 3.91 2.4604 0.000489721 Complies EUT: HOME THEATER SYSTEM Model Name : SC-S514 Temperature: 24 °C Relative Humidity: 58 % Pressure: 1009 hPa Test Voltage : AC120V/60Hz Test Mode : CH00/ CH39 /CH78 -3Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 0 1.0000 3.31 2.1429 0.000426531 Complies 0 1.0000 3.56 2.2699 0.000451801 Complies 0 1.0000 3.56 2.2699 0.000451801 Complies The calculated distance is 20 cm.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 1 of 103 FCC&IC Radio Test Report FCC ID: 2AAGJDHTS514 IC: 11154A-DHTS514 This report concerns (check one): Original Grant Class II Change Issued Date : Dec. 03, 2013 Project No. : 1310C090 Equipment : HOME THEATER SYSTEM Model Name SC-S514 Applicant : Tymphany HK Limited Address : Room 1307-8 Dominion Centre 43-59 Queen’s Road East, WanChai, Hong Kong Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Oct. 25, 2013 Date of Test: Oct. 25, 2013 ~ Dec. 02, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 2 of 103 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 3 of 103 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 19 4.2.1 RADIATED EMISSION LIMITS 19 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 20 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 5 . NUMBER OF HOPPING CHANNEL 54 5.1 APPLIED PROCEDURES / LIMIT 54 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 54 5.1.2 TEST PROCEDURE 54 5.1.3 DEVIATION FROM STANDARD 54 5.1.4 TEST SETUP 54 5.1.5 EUT OPERATION CONDITIONS 54 5.1.6 TEST RESULTS 55 6 . AVERAGE TIME OF OCCUPANCY 57 Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 4 of 103 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 57 6.1.1 MEASUREMENT INSTRUMENTS LIST 57 6.1.2 TEST PROCEDURE 57 6.1.3 DEVIATION FROM STANDARD 57 6.1.4 TEST SETUP 58 6.1.5 EUT OPERATION CONDITIONS 58 6.1.6 TEST RESULTS 59 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 71 7.1 APPLIED PROCEDURES / LIMIT 71 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 71 7.1.2 TEST PROCEDURE 71 7.1.3 DEVIATION FROM STANDARD 71 7.1.4 TEST SETUP 71 7.1.5 EUT OPERATION CONDITIONS 71 7.1.6 TEST RESULTS 72 8 . BANDWIDTH TEST 76 8.1 APPLIED PROCEDURES / LIMIT 76 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 76 8.1.2 TEST PROCEDURE 76 8.1.3 DEVIATION FROM STANDARD 76 8.1.4 TEST SETUP 76 8.1.5 EUT OPERATION CONDITIONS 76 8.1.6 TEST RESULTS 77 9 . PEAK OUTPUT POWER TEST 81 9.1 APPLIED PROCEDURES / LIMIT 81 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 81 9.1.2 TEST PROCEDURE 81 9.1.3 DEVIATION FROM STANDARD 81 9.1.4 TEST SETUP 81 9.1.5 EUT OPERATION CONDITIONS 81 9.1.6 TEST RESULTS 82 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 86 10.1 APPLIED PROCEDURES / LIMIT 86 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 86 10.1.2 TEST PROCEDURE 86 10.1.3 DEVIATION FROM STANDARD 86 10.1.4 TEST SETUP 86 10.1.5 EUT OPERATION CONDITIONS 87 10.1.6 TEST RESULTS 88 11 . EUT TEST PHOTO 100 Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 5 of 103 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FICP-1-1310C090 Original Issue. Dec. 03, 2013 Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 6 of 103 1. CERTIFICATION Equipment : HOME THEATER SYSTEM Brand Name : DENON Model Name SC-S514 Applicant : Tymphany HK Limited Manufacturer : D&M Holdings Inc. Address : D&M Building, 2-1 Nissin-cho, Kawasaki-ku, Kawasaki-shi, Kanagawa, Japan Factory : Premium Loudspeakers(Huizhou) Co.,Ltd. Address : Tymphany Industrial Area, XinLian Village, XinXu Town, Huizhou City, Guangdong, P.R. China Date of Test : Oct. 25, 2013 ~ Dec. 02, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC La…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 100 of 103 11. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 101 of 103 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 102 of 103 Radiated Measurement Photos 30M~1000MHz Neutron Engineering Inc. Report No.: NEI-FICP-1-1310C090 Page 103 of 103 Radiated Measurement Photos Above 1000MHz
