2AAWE-SB80Fitness Band

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Fitness Band Model Name SB80 Brand Name SOUL Applicant Soul Electronics Limited Address 6/F, Enterprise Square Three, 39 Wang Chui Road, Kowloon Bay, Hong Kong. Standard(s) FCC Part 15, Subpart B: 2013 ANSI C63.4-2009 Report(s) BTL-FCCE-1-1501C043 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, Yang-Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

Project No.: 1501C043 Page 2 of 8 Project No.: 1501C043 Page 3 of 8 Project No.: 1501C043 Page 4 of 8

Project No.: 1501C043 Page 5 of 8 Project No.: 1501C043 Page 6 of 8 Project No.: 1501C043 Page 7 of 8 Project No.: 1501C043 Page 8 of 8

FCC RF EXPOSURE REPORT FCC ID: 2AAWE-SB80 Project No. : 1501C043 Equipment : Fitness Band Model : SB80 Applicant : Soul Electronics Limited Address : 6/F, Enterprise Square Three, 39 Wang Chui Road, Kowloon Bay, Hong Kong. According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Table for Filed Antenna Ant. Brand Model NameAntenna TypeConnector Gain(dBi) 1 WALSIn N/A Printed N/A 2.00 GENERAL CONCULUSION: Maximum measured transmitter power: OutputPower (dBm) Output Power (mW) Limit (mW) 0.44 1.11 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 1.11mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Report No.: BTL-FCCP-1-1501C043 Page 1 of 64 FCC Radio Test Report FCC ID:2AAWE-SB80 This report concerns (check one): Original Grant Class II Change Project No. : 1501C043 Equipment : Fitness Band Model Name : SB80 Applicant : Soul Electronics Limited Address : 6/F, Enterprise Square Three, 39 Wang Chui Road, Kowloon Bay, Hong Kong. Date of Receipt : Jan. 06, 2015 Date of Test : Jan. 06, 2015 ~ Jan. 20, 2015 Issued Date : Jan. 22, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-1-1501C043 Page 2 of 64 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's l ogo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1501C043 Page 3 of 64 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 13 4.1.5 EUT OPERATING CONDITIONS 13 4.1.6 EUT TEST CONDITIONS 13 4.1.7 TEST RESULTS 13 4.2 RADIATED EMISSION MEASUREMENT 14 4.2.1 RADIATED EMISSION LIMITS 14 4.2.2 TEST PROCEDURE 15 4.2.3 DEVIATION FROM TEST STANDARD 15 4.2.4 TEST SETUP 16 4.2.5 EUT OPERATING CONDITIONS 17 4.2.6 EUT TEST CONDITIONS 17 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 17 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 18 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 18 5 . BANDWIDTH TEST 19 5.1 APPLIED PROCEDURES / LIMIT 19 5.1.1 TEST PROCEDURE 19 5.1.2 DEVIATION FROM STANDARD 19 5.1.3 TEST SETUP 19 5.1.4 EUT OPERATION CONDITIONS 19 5.1.5 EUT TEST CONDITIONS 19 5.1.6 TEST RESULTS 19 6 . MAXIMUM OUTPUT POWER TEST 20 6.1 APPLIED PROCEDURES / LIMIT 20 Report No.: BTL-FCCP-1-1501C043 Page 4 of 64 Table of Contents Page 6.1.1 TEST PROCEDURE 20 6.1.2 DEVIATION FROM STANDARD 20 6.1.3 TEST SETUP 20 6.1.4 EUT OPERATION CONDITIONS 20 6.1.5 EUT TEST CONDITIONS 20 6.1.6 TEST RESULTS 20 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 21 7.1 APPLIED PROCEDURES / LIMIT 21 7.1.1 TEST PROCEDURE 21 7.1.2 DEVIATION FROM STANDARD 21 7.1.3 TEST SETUP 21 7.1.4 EUT OPERATION CONDITIONS 21 7.1.5 EUT OPERATION CONDITIONS 21 7.1.6 TEST RESULTS 21 8 . POWER SPECTRAL DENSITY TEST 22 8.1 APPLIED PROCEDURES / LIMIT 22 8.1.1 TEST PROCEDURE 22 8.1.2 DEVIATION FROM STANDARD 22 8.1.3 TEST SETUP 22 8.1.4 EUT OPERATION CONDITIONS 22 8.1.5 EUT TEST CONDITIONS 22 8.1.6 TEST RESULTS 22 9 . MEASUREMENT INSTRUMENTS LIST 23 10 . EUT TEST PHOTO 25 ATTACHMENT A - CONDUCTED EMISSION 29 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 32 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 34 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 41 ATTACHMENT E - BANDWIDTH 54 ATTACHMENT F - MAXIMUM OUTPUT POWER TEST 57 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 58 ATTACHMENT H - POWER SPECTRAL DENSITY TEST 62 Report No.: BTL-FCCP-1-1501C043 Page 5 of 64 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1501C043 Original Issue. Jan. 22, 2015 Report No.: BTL-FCCP-1-1501C043 Page 6 of 64 1. CERTIFICATION Equipment : Fitness Band Brand Name : SOUL Model Name : SB80 Applicant : Soul Electronics Limited Manufacturer : R.E.A.C. ELECTRONICS CO., LTD. Address : 7/F, O.T.B BUILDING, 259-264 DES VOEUX ROAD CENTRAL, HONG KONG Factory : REAC INDUSTRIAL CO., LTD. Address : ZHONGFANG GONG YE QU. SHATOU GUAN LI QU, CHANGAN TOWN, DONGGUAN CITY, GUANGDONG, P.R.CHINA Date of Test : Jan. 06, 2015 ~ Jan. 20, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C :2013 (15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1501C043) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-1-1501C043 Page 7 of 64 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emissi…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1501C043 Page 25 of 64 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1501C043 Page 26 of 64 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FCCP-1-1501C043 Page 27 of 64 Radiated Measurement Photos 30M to 1000MHz Report No.: BTL-FCCP-1-1501C043 Page 28 of 64 Radiated Measurement Photos Above 1000MHz
