Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 4 | 15E | 5.75 GHz - 5.83 GHz | 39.60 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Output power listed is conducted. This device supports bandwidths of 20 MHz, 40 MHz, and 80 MHz. The device is an 802.11a/b/g/n/ac device in a 2x2 MIMO configuration and enabled for 2.4 and 5 GHz band operations as described in this filing. This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Compliance of this device in all final host configurations is the responsibility of the Grantee. The host integrator and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. The host integrator must follow the integration instructions provided by the module manufacturer and ensure that the composite-system end product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules and to KDB Publication 996369. The host integrator is instructed to ensure that the end user has no manual instructions to remove or install the device.
