2AAXO-ISM9025WIFI KARAOKE SYSTEM

ISM9025 INSTRUCTION MANUAL www.singingmachine.com The Singing Machine® is a registered trademark of The Singing Machine Co., Inc. IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ITM. / ART. 1945214 — E1 — Important Safety Information 1. Read these Instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all Instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the Manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. (Not applicable to UK and Europe Model) 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip- over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Do not place objects filled with water, such as a vase, on the apparatus. 16. The AC mains plug is used as the power disconnect device and it should remain readily accessible and operable during intended use. In order to completely disconnect the apparatus from power, the mains plug should be completely removed from the AC outlet socket. 17. CAUTION: To reduce the risk of fire or explosion, do not expose batteries to excessive heat such as sunshine, fire or other heat sources. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. ATTENTION: The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying this product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Warnings WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DRIPPING WARNING: This product shall not be exposed to dripping or splashing, and no objects filled with liquids, such as vases, shall be placed on the product. VENTILATION WARNING: The normal ventilation of the product shall not be impeded for intended use. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND FULLY INSERT. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance of 20cm from your body. RF Exposure Warning Statements: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled en…

Text truncated - open the document above for the full version.

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Jun. 25, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2AAXO-ISM9025 The Singing Machine Company, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Gary Atkinson Title: CEO Address: 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Tel.: 954-596-1000 Email: [email protected]

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Jun. 25, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2AAXO-ISM9025 Product Name: WIFI KARAOKE SYSTEM This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Gary Atkinson Title: CEO Address: 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Tel.: 954-596-1000 Email: [email protected] The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

TheSingingMachineCompany,Inc. 6301NW5thWay,Suite2900,FortLauderdale,Florida, 33309,UnitedStates 2.911(d)(7)USAAgentv1.5 Section2.911(d)(7)USAAgentforServiceofProcess Companyname:TheSingingMachineCompany,Inc. Address:6301NW5thWay,Suite2900,FortLauderdale,Florida,33309,United States ProductName:WIFIKARAOKESYSTEM FCCID:2AAXO-ISM9025 2.911(d)(7)USADesignatedAgentforServiceofProcess We,[TheSingingMachineCompany,Inc.](“theapplicant”)designate[TheSinging MachineCompany,Inc.] NOTE1 forthepurposeofacceptingserviceofprocesson behalfoftheapplicant. Applicantconsent:Weacknowledgeourconsenttoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipment,andatthephysicalU.S. addressandemailaddressofthedesignatedagentandacknowledgeour acceptanceofourobligationtomaintainanagentforserviceofprocessintheUnited Statesfornolessthanoneyearaftereitherwethegranteehavepermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S., orattheconclusionofanyCommission-relatedadministrativeorjudicialproceeding involvingtheequipment,whicheverislater. Agentobligation:Weacknowledgeourobligationtoacceptserviceofprocessinthe UnitedStatesformattersrelatedtotheapplicableequipmentatourphysicalU.S. addressandemailaddressfornolessthanoneyearaftereitherthegranteehas permanentlyterminatedallmarketingandimportationoftheapplicableequipment withintheU.S.,orattheconclusionofanyCommission-relatedadministrativeor judicialproceedinginvolvingtheequipment,whicheverislater. USAAgent Companyname:TheSingingMachine Company,Inc. USAAddress:6301NW5thWay,Suite 2900,FortLauderdale,Florida,33309, UnitedStates FRNNumber:0022947477 ContactName:GaryAtkinson TelephoneNo:954-596-1000 Email:[email protected] Applicant Companyname:TheSingingMachine Company,Inc. Address:6301NW5thWay,Suite2900, FortLauderdale,Florida,33309,United States GranteeFRNNumber:0022947477 FCCGranteeCode:2AAXO ContactName:GaryAtkinson TelephoneNo:954-596-1000 TheSingingMachineCompany,Inc. 6301NW5thWay,Suite2900,FortLauderdale,Florida, 33309,UnitedStates 2.911(d)(7)USAAgentv1.5 Email: [email protected] Signature: Title:CEO Signature: Title:CEO Date:2025/6/23Date:2025/6/23 NOTE1:AnapplicantlocatedintheUnitedStatesmaydesignateitselfastheagentforservice ofprocess. Reference;FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Date: 22025/6/25 Dear Sir/Madam, We, The Singing Machine Company, Inc., Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: WIFI KARAOKE SYSTEM Model no.: ISM9025, ISM9027, ISM9033, ISM9044, ISM9045, ISM9047, ISM9025XX, ISM9027XX, ISM9033XX, ISM9044XX, ISM9045XX, ISM9047XX (XX means unit color, it can be A to Z or N/A) Sincerely, Name/Title： Gary Atkinson / CEO Company: The Singing Machine Company, Inc. Address: 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Phone: 954-596-1000 Fax: 954-596-2000 E-Mail: [email protected]

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States June 25, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2AAXO-ISM9025 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of 45 days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOM in the event information regarding the product or the product is made available to the public before the requested period has expired. ⎯ User Manual ⎯ Internal Photos ⎯ External Photos ⎯ Test Setup Photos Sincerely, Title: CEO Address: 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Tel.: 954-596-1000 Email: [email protected]

The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States June 25, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2AAXO-ISM9025 I, the undersigned, hereby authorize Shenzhen Tongzhou Testing Co.,Ltd. to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by Shenzhen Tongzhou Testing Co.,Ltd. shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with The Singing Machine Company, Inc.. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Gary Atkinson CEO Tel: 954-596-1000 Fax: 954-596-2000 Email: [email protected]

FCC ID: 2AAXO-ISM9025 Page 1 of 5 Exterior Photographs of EUT Fig.1 Fig.2 FCC ID: 2AAXO-ISM9025 Page 2 of 5 Fig.3 Fig.4 FCC ID: 2AAXO-ISM9025 Page 3 of 5 Fig.5 Fig.6 FCC ID: 2AAXO-ISM9025 Page 4 of 5 Adapter: K25E150150U Fig.7 FCC ID: 2AAXO-ISM9025 Page 5 of 5 Adapter: RY36A150150US

Label Location FCC ID: 2AAXO-ISM9025

FCC ID: 2AAXO-ISM9025 Page 1 of 9 Interior Photographs of EUT Fig.1 Fig.2 FCC ID: 2AAXO-ISM9025 Page 2 of 9 Fig.3 Fig.4 FCC ID: 2AAXO-ISM9025 Page 3 of 9 Fig.5 Fig.6 Bluetooth Antenna FCC ID: 2AAXO-ISM9025 Page 4 of 9 Fig.7 Fig.8 FCC ID: 2AAXO-ISM9025 Page 5 of 9 Fig.9 Fig.10

FCC ID: 2AAXO-ISM9025 Page 6 of 9 Fig.11 Fig.12 Receiver Antenna Wifi Antenna FCC ID: 2AAXO-ISM9025 Page 7 of 9 Fig.13 Fig.14 FCC ID: 2AAXO-ISM9025 Page 8 of 9 Fig.15 Fig.16 FCC ID: 2AAXO-ISM9025 Page 9 of 9 Fig.17

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 3 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 3 Results EDR: RF Exposure at Separation distance (cm): 20 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] DH5 Ant1 2402 -0.78 -1.5 1 0 -0.5 0.89 3060.00 DH5 Ant1 2441 -3.89 -4.5 1 0 -3.5 0.45 3060.00 DH5 Ant1 2480 -6.14 -6.5 1 0 -5.5 0.28 3060.00 2DH5 Ant1 2402 -0.88 -1.5 1 0 -0.5 0.89 3060.00 2DH5 Ant1 2441 -4 -4.5 1 0 -3.5 0.45 3060.00 2DH5 Ant1 2480 -6.35 -7 1 0 -6 0.25 3060.00 3DH5 Ant1 2402 -0.67 -1 1 0 0 1.00 3060.00 3DH5 Ant1 2441 -3.92 -4.5 1 0 -3.5 0.45 3060.00 3DH5 Ant1 2480 -6.21 -6.5 1 0 -5.5 0.28 3060.00 2.4G: RF Exposure at Separation distance (cm): 20 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] 11B Ant1 2412 10.47 10 1 5.5 14.35 27.23 3060.00 11B Ant1 2437 10.46 10 1 5.5 14.35 27.23 3060.00 11B Ant1 2462 10.18 9.5 1 5.5 13.85 24.27 3060.00 11G Ant1 2412 10.38 10 1 5.5 14.35 27.23 3060.00 11G Ant1 2437 11.02 10.5 1 5.5 14.85 30.55 3060.00 11G Ant1 2462 10.08 9.5 1 5.5 13.85 24.27 3060.00 11N20SISO Ant1 2412 10.23 9.5 1 5.5 13.85 24.27 3060.00 11N20SISO Ant1 2437 11.11 10.5 1 5.5 14.85 30.55 3060.00 11N20SISO Ant1 2462 10.09 9.5 1 5.5 13.85 24.27 3060.00 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 3 5.2G: RF Exposure at Separation distance (cm): 20 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] 11A Ant1 5180 7.37 7 1 3.17 9.02 7.98 3060.00 11A Ant1 5200 8.54 8 1 3.17 10.02 10.05 3060.00 11A Ant1 5240 9.27 9 1 3.17 11.02 12.65 3060.00 11N20SISO Ant1 5180 7.17 6.5 1 3.17 8.52 7.11 3060.00 11N20SISO Ant1 5200 8.22 7.5 1 3.17 9.52 8.95 3060.00 11N20SISO Ant1 5240 9.05 8.5 1 3.17 10.52 11.27 3060.00 11AC20SISO Ant1 5180 7.28 7 1 3.17 9.02 7.98 3060.00 11AC20SISO Ant1 5200 8.26 8 1 3.17 10.02 10.05 3060.00 11AC20SISO Ant1 5240 9.11 8.5 1 3.17 10.52 11.27 3060.00 5.8G: RF Exposure at Separation distance (cm): 20 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR-based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] 11A Ant1 5745 9.06 8.5 1 3.39 10.74 11.86 3060.00 11A Ant1 5785 8.48 8 1 3.39 10.24 10.57 3060.00 11A Ant1 5825 7.39 7 1 3.39 9.24 8.39 3060.00 11N20SISO Ant1 5745 8.75 8.5 1 3.39 10.74 11.86 3060.00 11N20SISO Ant1 5785 8.32 8 1 3.39 10.24 10.57 3060.00 11N20SISO Ant1 5825 7.26 7 1 3.39 9.24 8.39 3060.00 11AC20SISO Ant1 5745 9.84 9.5 1 3.39 11.74 14.93 3060.00 11AC20SISO Ant1 5785 8.97 8.5 1 3.39 10.74 11.86 3060.00 11AC20SISO Ant1 5825 8.16 7.5 1 3.39 9.74 9.42 3060.00 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 1 of 36 Appendix Test Data for WLAN(2. 4G) (Conducted Measurement) Product Name: WIFI KARAOKE SYSTEM Trade Mark: singing machine Test Model: ISM9025 FCC ID: 2AAXO-ISM9025 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.120 2406.920 2417.040 0.5 PASS 11B Ant1 2437 10.040 2431.960 2442.000 0.5 PASS 11B Ant1 2462 10.080 2456.960 2467.040 0.5 PASS 11G Ant1 2412 16.320 2403.840 2420.160 0.5 PASS 11G Ant1 2437 16.000 2428.840 2444.840 0.5 PASS 11G Ant1 2462 16.000 2454.120 2470.120 0.5 PASS 11N20SISO Ant1 2412 16.920 2403.480 2420.400 0.5 PASS 11N20SISO Ant1 2437 16.160 2428.600 2444.760 0.5 PASS 11N20SISO Ant1 2462 15.280 2454.840 2470.120 0.5 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 2 of 36 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 3 of 36 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 4 of 36 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 5 of 36 11N20SISO-Ant1-2462-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 6 of 36 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 14.920 2404.5444 2419.4644 --- --- 11B Ant1 2437 14.685 2429.5849 2444.2699 --- --- 11B Ant1 2462 14.835 2454.6273 2469.4623 --- --- 11G Ant1 2412 16.798 2403.6347 2420.4327 --- --- 11G Ant1 2437 16.719 2428.6494 2445.3684 --- --- 11G Ant1 2462 16.768 2453.6556 2470.4236 --- --- 11N20SISO Ant1 2412 17.956 2403.0473 2421.0033 --- --- 11N20SISO Ant1 2437 17.861 2428.0186 2445.8796 --- --- 11N20SISO Ant1 2462 17.907 2453.1014 2471.0084 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 7 of 36 Test Graphs 11B-Ant1-2412 11B-Ant1-2437 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 8 of 36 11B-Ant1-2462 11G-Ant1-2412 11G-Ant1-2437 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 9 of 36 11G-Ant1-2462 11N20SISO-Ant1-2412 11N20SISO-Ant1-2437 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 10 of 36 11N20SISO-Ant1-2462 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 11 of 36 Appendix C: Maximum Average conducted output power Test Result Test Mode Antenna Frequency [MHz] Result [dBm] Limit [dBm] Gain [dBi] EIRP [dBm] EIRP Limit [dBm] Verdict 11B Ant1 2412 10.47 ≤30.00 5.50 15.97 ≤36.00 PASS 11B Ant1 2437 10.46 ≤30.00 5.50 15.96 ≤36.00 PASS 11B Ant1 2462 10.18 ≤30.00 5.50 15.68 ≤36.00 PASS 11G Ant1 2412 10.38 ≤30.00 5.50 15.88 ≤36.00 PASS 11G Ant1 2437 11.02 ≤30.00 5.50 16.52 ≤36.00 PASS 11G Ant1 2462 10.08 ≤30.00 5.50 15.58 ≤36.00 PASS 11N20SIS O Ant1 2412 10.23 ≤30.00 5.50 15.73 ≤36.00 PASS 11N20SIS O Ant1 2437 11.11 ≤30.00 5.50 15.61 ≤36.00 PASS 11N20SIS O Ant1 2462 10.09 ≤30.00 5.50 15.59 ≤36.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) + Duty Cycle Factor(dB) Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 12 of 36 Appendix D: Maximum Average power spectral density Test Result TestMod e Antenna Frequency[MHz] RawData[dBm/3kHz] DcFactor Result[dBm/3k Hz] Limit[dBm/3kH z] Verdict 11B Ant1 2412 -20.24 0.14 -20.10 ≤8.00 PASS 11B Ant1 2437 -19.78 0.00 -19.78 ≤8.00 PASS 11B Ant1 2462 -19.85 0.17 -19.68 ≤8.00 PASS 11G Ant1 2412 -19.99 0.26 -19.73 ≤8.00 PASS 11G Ant1 2437 -19.50 0.26 -19.24 ≤8.00 PASS 11G Ant1 2462 -20.36 0.29 -20.07 ≤8.00 PASS 11N20SI SO Ant1 2412 -19.62 0.41 -19.21 ≤8.00 PASS 11N20SI SO Ant1 2437 -19.46 0.41 -19.05 ≤8.00 PASS 11N20SI SO Ant1 2462 -21.13 0.45 -20.68 ≤8.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) + Duty Cycle Factor(dB) Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 13 of 36 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 14 of 36 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 15 of 36 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 16 of 36 11N20SISO-Ant1-2462-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 17 of 36 Appendix E: Band edge measurements Test Result TestMode Antenn a ChNam e Frequency[MH z] RefLevel[dB m] Result[dB m] Limit[dBm ] Verdic t 11B Ant1 Low 2412 0.31 -46.07 ≤-29.69 PASS 11B Ant1 High 2462 1.01 -48.79 ≤-28.99 PASS 11G Ant1 Low 2412 -0.34 -40.42 ≤-30.34 PASS 11G Ant1 High 2462 -1.82 -48.96 ≤-31.82 PASS 11N20SIS O Ant1 Low 2412 -1.28 -37.36 ≤-31.28 PASS 11N20SIS O Ant1 High 2462 -0.48 -47.98 ≤-30.48 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 18 of 36 Test Graphs 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AAXO-ISM9025 Report No.: TZ0029250503FRF03 Page 19 of 36 11G-Ant1-2412-PASS 11G-Ant1-2462-PASS 11N20SIS…

Text truncated - open the document above for the full version.

This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 1 of 39 TEST REPORT Report Number : TZ0029250503FRF03 Product Name : WIFI KARAOKE SYSTEM Model/Type reference : ISM9025, ISM9027, ISM9033, ISM9044, ISM9045, ISM9047, ISM9025XX, ISM9027XX, ISM9033XX, ISM9044XX, ISM9045XX, ISM9047XX (XX means unit color, it can be A to Z or N/A) FCC ID : 2AAXO-ISM9025 Prepared for : The Singing Machine Company, Inc. 6301 NW 5th Way, Suite 2900, Fort Lauderdale, Florida, 33309, United States Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10: 2013 Date of Test : 2025-04-30 ~ 2025-05-12 Date of Issue : 2025-06-06 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.:TZ0029250503FRF03 Page 2 of 39 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version No…
