The statements should be displayed in the user manual: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. WS-SQB938 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
SCS-F18:ProjectandProductCertificationRepresentativeAuthorizationLetterPage1of2Rev5.0 775MontagueExpressway Milpitas,CA95035 Tel:408-526-1188 Fax:408-526-1088 Email:[email protected] ProjectandProduct CertificationRepresentative AuthorizationLetter ReasonforAmendment(current/obsolete) RevisionHistory ApprovedDate FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 Revisedwording(obsolete)1.02.0Sept–25-2007 Updatedcompanytemplate(obsolete)2.03.0Jan-31-2012 Updatedletterinformation(obsolete)3.04.0May-23-2014 AddedFCCIDfield(current)4.05.0Sept162014 SCS-F18:ProjectandProductCertificationRepresentativeAuthorizationLetterPage2of2Rev5.0 (AnkerTechnologyCo.,Limited) (2015-07-24) To:SIEMIC,INC. 775MontagueExpressway, Milpitas,CA95035 USA DearSir/Madam, Re:ProductCertificationRepresentativeAuthorizationLetter We,_____AnkerTechnologyCo.,Limited_____herebyauthorizeSIEMIC,Inc.toactasa CertificationBodyforcertifyingforthefollowingproject(s): Productdescription:BluetoothSelfieStick Modelname:A7134 FCCID:2AB7K-A7134 Sincerely, Client’ssignature SimonZhang/ProductManager CompanyName:AnkerTechnologyCo.,Limited Address:Room1318-19,HollywoodCommercialCenter,610NathanRoad,Mongkok,Kowloon, Hongkong Email:[email protected]
SCS-F19:ConfidentialityRequestLetterPage 1 of 2 Rev4.0 775MontagueExpressway Milpitas,CA95035 Tel:408-526-1188 Fax:408-526-1088 Email:[email protected] Confidentiality RequestLetter ReasonforAmendment(current/obsolete) RevisionHistory ApprovedDate FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 AddingCFR2.459(obsolete)1.02.0August–11-2008 Updatedcompanytemplate&Addedtextbox (obsolete) 2.03.0Jan-31-2012 AddedICconfidentialityletterform(current)3.04.0March-26-2015 SCS-F19:ConfidentialityRequestLetterPage 2 of 2 Rev4.0 (AnkerTechnologyCo.,Limited) (2015-07-24) To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD Subject:PermanentConfidentialityRequestforFCCID:2AB7K-A7134 Weherebyrequestconfidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: -BlockDiagram -Schematics -OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic.The publicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. TheapplicantunderstandsthatpursuanttoSection0.457&0.459oftheRules,disclosureofthisapplicationand allaccompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerely, Client’ssignature SimonZhang/ProductManager CompanyName:AnkerTechnologyCo.,Limited Address:Room1318-19,HollywoodCommercialCenter,610NathanRoad,Mongkok,Kowloon,Hongkong Email:[email protected]
Figure1 The EUT-Top View Figure2 The EUT-BottomView Figure3 The EUT-FrontView Figure4 The EUT-BackView Figure5 The EUT-RightView Figure6 The EUT-Left View
LabelLocationOnEUT
ProductName:BluetoothSelfieStick ModelNo.:A7134 FCCID:2AB7K-A7134
Figure7 The EUT-InsideView Figure8 The EUT-InsideView Figure9 The EUT-InsideView Figure10 PCBof the EUT -FrontView Figure11 PCBof the EUT -BackView Figure12 PCBof the EUT -FrontView Antenna Figure13 PCBof the EUT -BackView Figure14 PCBof the EUT -FrontView Figure15 PCBof the EUT -BackView
RFEXPOSUREEVALUATION FCCID : 2AB7K-A7134 AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b): RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualifyforTCBapproval. Mode:BDR Themaximumoutputpowerforlowchannelis:1.065dBm=1.278mW Tuneuptoleranceis:1.065 ± 1dBm TheMax.TuneupPower=2.065dBm=1.61mW Thecalculationresults=1.61/5*√2.402=0.499 < 3 Themaximumoutputpowerformiddlechannelis:1.257dBm=1.336mW Tuneuptoleranceis:1.257 ± 1dBm TheMax.TuneupPower=2.257dBm=1.68mW Thecalculationresults=1.68/5*√2.441=0.525 < 3 Themaximumoutputpowerforhighchannelis:1.665dBm=1.467mW Tuneuptoleranceis:1.665 ± 1dBm TheMax.TuneupPower=2.665dBm=1.85mW Thecalculationresults=1.85/5*√2.480=0.583 < 3 Mode:EDR Themaximumoutputpowerforlowchannelis:0.976dBm=1.252mW Tuneuptoleranceis:0.976 ± 1dBm TheMax.TuneupPower=1.976dBm=1.58mW Thecalculationresults=1.58/5*√2.402=0.490 < 3 Themaximumoutputpowerformiddlechannelis:1.197dBm=1.317mW Tuneuptoleranceis:1.197 ± 1dBm TheMax.TuneupPower=2.197dBm=1.66mW Thecalculationresults=1.66/5*√2.441=0.519 < 3 Themaximumoutputpowerforhighchannelis:1.650dBm=1.462mW Tuneuptoleranceis:1.650 ± 1dBm TheMax.TuneupPower=2.650dBm=1.84mW Thecalculationresults=1.84/5*√2.480=0.580 < 3 TestResults:PASS.
