AIP‐W511 ultra compact wireless adapter Quick Installation Guide Package Content Thank you for choosing ALFA ultra compact wireless adapter. Before installing the adapter, please verify contents inside the product box. □ AIP‐W511 ultra compact wireless adapter □ Quick Installation Guide NOTE: If any item in this package is missing or damaged, please contact the distributor immediately. Product Outlook WPS button Power LAN WLAN Mode Switch Reset button Installation  Default operation mode is USB wireless adapter  Insert the ultra compact wireless adapter into the USB port of PC or your laptop computer.  Click “Setup.exe” when window’s auto‐play menu is prompted. Click Yes or Allow when windows User Account Control window pop‐up. Please wait till driver of ultra compact wireless adapter is installed on your computer. Open your web browser, and insert http://alfasetup.com in the address bar. NOTE: in this mode, Windows and MAC OS X (10.6 or later) drivers are supported.  Understand Product Operation Modes, and make selection Default operation mode of ultra compact wireless adapter is wireless adapter.  Wireless adapter mode In this mode, ultra compact wireless adapter performs as a 802.11n wireless adapter for WLAN access. Just connect ultra compact wireless adapter to your laptop or desktop PC, WLAN access is ready to use. NOTE: in this mode, Windows and MAC OS X (or later) drivers are supported.  Hotel AP / Router Mode ONLY DSL modem/cable existed in your network, ultra compact wireless adapter is very convenient to convert Ethernet to wireless signals. It acts as a wireless AP/router for WLAN access, and Internet sharing. Just connect Ultra compact wireless adapter to DSL modem via Ethernet/RJ‐45 cable, it will do the tasks for you. NOTE: in this mode, ultra compact wireless adapter can be powered by PC/laptop or mobile power bank.  Ethernet adapter mode In this mode, easily connect your laptop or computer to an Ethernet network with the ultra compact wireless adapter. Stylish and compact, it connects to the USB 2.0 port of your laptop or computer and provides an RJ‐45 connector that supports 10/100BASE‐T network access.  Product Configurations In default mode, ultra compact wireless adapter is WLAN client. To start the product configurations, connect USB cable to ultra compact wireless adapter.. Open web browser, and enter http://alfasetup.com, product setting page will appear as below: WLAN client mode: Click on Next, insert SSID of wireless AP manually or perform a Site Survey to scan the available wireless AP nearby. Click on Next to select, and insert suitable wireless security to connect to target wireless AP. Click on Finished, the ultra compact wireless adapter shall now connect to wireless AP, and you may start Internet browsing.  WLAN AP (Access Point) mode: Open web browser, and enter http://alfasetup.com, product setting page will appear as below: Please select AP in mode selection tab. Click on TCP/IP menu, to change or keep LAN IP parameters in wireless AP mode. Click on Wireless ‐‐ > Basic Settings menu, to change or keep LAN IP parameters in wireless AP mode. Click on Wireless ‐‐ > Security Settings menu, there is a default security config in this page. To change or keep wireless security parameters, please change the values in this page. NOTE: To apply the changes, please reboot the router to activate the new configurations in the WLAN AP setting menu.  WLAN Router mode: Open web browser, and enter http://alfasetup.com, product setting page will appear as below: Please select Router in mode selection tab. Click on Setup Wizard menu, refer to the screen instructions to fill‐in required parameters for Internet access. NOTE: default IP address in router mode is 192.168.11.1 FURTHER INFORMATION The steps above introduce simple installation for ultra compact wireless adapter. For further configuration of the Wi‐Fi Protected Setup (WPS), Software AP etc, please refer to the user’s manual. Any further questions, please contact the local dealer or distributor where you purchased this product. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. Th e device can be used in portable exposure condition without restriction. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC ID: 2AB87511 Model No.: AIP-W511 Model name: 802.11n 150M Ultra Wireless LAN Router This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Iconnect SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Iconnect SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/4/22 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Iconnect hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： 802.11n 150M Ultra Wireless LAN Router Model Name： AIP-W511, AIP-W511H, UR24, UR24H, FR24, FR24H FCC ID： 2AB87511 We affirm that between SIEMIC and ___ Iconnect__, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Johnson Wang Title: Manager Tel: 886-2-27968477 Company: Iconnect

Iconnect SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 Iconnect SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2014/4/22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AB87511 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Johnson Wang Title: Manager Tel: 886-2-27968477 Company: Iconnect

Date:2014-4-23 FCC ID: 2AB87511 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Johnson Wang Title: Manager Tel: 886-2-27968477 Company: Iconnect

Iconnect Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2014/4/24 SUBJECT: FCC Application for ( FCC ID: 2AB87511) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Name: Johnson Wang Title: Manager Tel: 886-2-27968477 Company: Iconnect

Differences Description We Iconnect state: Product name: 802.11n 150M Ultra Wireless LAN Router Model: AIP-W511, AIP-W511H, UR24, UR24H, FR24, FR24H All model’s the function, software and electric circuit are the same , only with a product color and model named different. Signatory Signature Name: Johnson Wang Title: Manager Tel: 886-2-27968477 Company: Iconnect

Full View Top View Bottom View Rear View Label Left View Right View Front View

Label: Label Location FCC ID: 2AB87511 Iconnect Model No.: AIP-W511 Model name: 802.11n 150M Ultra Wireless LAN Router This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label

Top View Top View Antenna Top View Bottom View

FCC ID: 2AB87511 RF EXPOSURE TEST FCC ID: 2AB87511 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2AB87511 Maximum measured transmitter power. 802.11B frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 9.24 8.39 2437 9.18 8.27 2462 8.97 7.88 802.11G frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 8.03 6.35 2437 8.25 6.68 2462 7.96 6.25 802.11N20 frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 7.88 6.13 2437 7.75 5.95 2462 7.58 5.72 FCC ID: 2AB87511 802.11N 40M frequency range Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2412 7.09 5.11 2437 6.85 4.84 2462 6.47 4.43 The max.output power E.I.R.P is 9.24dBm=8.39mW, Frequency is 2.412GHz So (8.39/5)* √2.412=2.605≤ 3.0 Note: √2.412 =1.553 Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: 2AB87511 Product： 802.11n 150M Ultra Wireless LAN Router Trade Name： ALFA Model Name： AIP-W511, AIP-W511H, UR24, UR24H, FR24, FR24H Serial Model： N/A Report No.： NTEK-2014NT04210948 Prepared for Iconnect No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City 114,Taiwan Prepared by NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 74 Report No.: NTEK-2014NT04210948 TEST RESULT CERTIFICATION Applicant’s name ................. : Iconnect Address ................................. : No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City 114,Taiwan Manufacture's Name ............ : Iconnect Address ................................. : No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City 114,Taiwan Product description Product name ........................... : 802.11n 150M Ultra Wireless LAN Router Model and/or type reference : AIP-W511,AIP-W511H,UR24,UR24H,FR24,FR24H Serial Model ............................. : N/A DIFF .......................................... : All model’s the function, software and electric circuit are the same , only with a product color and model named different. Test sample model: AIP-W511 Standards ............................. : FCC Part15.247 Test procedure .............................. : ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test .......................................... : Date (s) of performance of tests ............. : 01 June. 2013 ~07 June. 2013 Date of Issue ........................................ : 22 April. 2014 Test Result ............................................ : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 74 Report No.: NTEK-2014NT04210948 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 36 4 . POWER SPECTRAL DENSITY TEST 52 4.1 APPLIED PROCEDURES / LIMIT 52 4.1.1 TEST PROCEDURE 52 4.1.2 DEVIATION FROM STANDARD 52 4.1.3 TEST SETUP 52 4.1.4 EUT OPERATION CONDITIONS 52 4.1.5 TEST RESULTS 53 5 . BANDWIDTH TEST 61 5.1 APPLIED PROCEDURES / LIMIT 61 Page 4 of 74 Report No.: NTEK-2014NT04210948 Table of Contents Page 5.1.1 TEST PROCEDURE 61 5.1.2 DEVIATION FROM STANDARD 61 5.1.3 TEST SETUP 61 5.1.4 EUT OPERATION CONDITIONS 61 5.1.5 TEST RESULTS 62 6 . PEAK OUTPUT POWER TEST 70 6.1 APPLIED PROCEDURES / LIMIT 70 6.1.1 TEST PROCEDURE 70 6.1.2 DEVIATION FROM STANDARD 70 6.1.3 TEST SETUP 70 6.1.4 EUT OPERATION CONDITIONS 70 6.1.5 TEST RESULTS 71 7 . ANTENNA REQUIREMENT 72 7.1 STANDARD REQUIREMENT 72 7.2 EUT ANTENNA 72 8 . EUT TEST PHOTO 73 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 74 Report No.: NTEK-2014NT04210948 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 74 Report No.: NTEK-2014NT04210948 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 74 Report No.: NTEK-2014NT04210948 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment 802.11n 150M Ultra Wireless LAN Router Trade Name ALFA Model Name AIP-W511,AIP-W511H,UR24,UR24H,FR24,FR24H Serial Model N/A Model Difference All model’s the function, software and electric circuit are the same , only with a product color and model named different. Test sample model: AIP-W511 Product Description The EUT is a 802.11n 150M Ultra Wireless LAN Router Operation Frequency: 802.11b/g/n 20:2412~2462 MHz 802.11n 40: 2422~2452MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/…
