2AB87792111ax Module

Introduction AWM27921EU is the 802.11ax WiFi module. It supports 2.4 GHz, 5 GHz.It is backward compatible with 802.11 a/b/g/n/ac devices. Specifications WiFi Standards IEEE 802.11a IEEE 802.11 b IEEE 802.1 1 g IEEE 802.11 n IEEE 802.11ac IEEE 802.11ax Wir eless Data Rate 2 .4 GHz rate: up to 287 Mbps 5 GHz rate : up to 601 Mbps Wireless Security WEP, WPA, WPA2, WPA3 Operating System Windows 10, 11 / Linux ©2023 ALFA NETWORK Inc. All right reserved. ALFA NETWORK are trademarks of ALFA NETWORK Inc. registered in the US, Europe, and other countries. Other product and company names mentioned herein may be trademarks other respective companies Learn More Visit https://www.alfa.com.tw for more information. CCR 0 RoHS ! Y61-02嵓ML0001-00000 © ALFA Network Inc. | | [ ^LE^」 AWM27921EU 1.Hardware installation Insert to AWM27921EU to M2. interface to your Notebook 2.Driver installation Downland, the driver from www.alfa.com unzip the driver, double-dick the Setup.exe, and then follow the installation t o setup. 3.Network connection settings Click the wireless network icon in the lower right corner. The computer will display the connectable wireless; click the wireless network you want to connect to and enter the password to connect o . ontemet � ALFA Network Inc. 2.4G � � LFA N � twork Inc. SG Secured Enter the network security key l Cancel � ALFA Networlt Inc. � alfanetwo改ac2g 3 kpo g s aco 蜊Mob邸 tt ab od exet 缸 m ch 令 ． tw ＆ g tw 5 ¢ 0N AWM27921EU Specifications [email protected] www.alfa.com.tw ChipsetMediaTek MT7921AUN IEEE 802.11 standardsa/b/g/n/ac/ax Frequency 2.4 GHz 5 GHz Data rate 11b: 1, 2, 5.5, 11 Mbps 11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps 11n: up to 150 Mbps 11ac: up to 433 Mbps 11ax: up to 601 Mbps Form factorM.2 E-key (USB bus) Antenna connector 2x IPEX (Wi-Fi) Dimensions 30x 42 x 4.12 mm Operating temperature -25°C - 75°C Operation voltage 3.3V Power consumption 755mA (max.) Operating systems Microsoft Windows 10/11 Linux © ALFA Network Inc. / AWM27921EU datasheet Specifications and descriptions may change at any time without prior notice FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Regulatory Module Integration Instructions 2.2 List of applicable FCC rules CFR 47 FCC PART 15 SUBPART C&E has been investigated. It is applicable to the modular. 2.3 Specific operational use conditions This module is stand-alone modular. If the end product will involve the Multiple simultaneously transmitting condition or different operational conditions for a stand-alone modular transmitter in a host, host manufacturer have to consult with module manufacturer for the installation method in end system. The module is limited to OEM installation ONLY.The OEM integrators are responsible for ensuring that the end-use has no manual or instructions to remove or install module. 2.4 Limited module procedures : Not applicable 2.5 Trace antenna designs : Not applicable 2.6 RF exposure considerations This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. If the device built into a host as a portable usage, the additional RF exposure evaluation may be required as specified by 2.1093. 2.7 Antennas This radio transmitter FCC ID:2AB877921 has been approved by Federal Communications Commission to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. Antenna type:Dipole Antenna Maximum Antenna gain: 2.4G WIFI /1.76 dBi, 5G WIFI/1.47dBi 2.8 Label and compliance information The final end product must be labeled in a visible area with the following " Contains FCC ID: 2AB877921” 2.9 Information on test modes and additional testing requirements Host manufacturer is strongly recommended to confirm compliance with FCC requirements for the transmitter when the module is installed in the host. 2.10 Additional testing, Part 15 Subpart B disclaimer Host manufacturer is responsible for compliance of the host system with module installed with all other applicable requirements for the system such as Part 15 B.

Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan Tel: 886-2-27968477 Fax: 886-2-27968478 Email: [email protected] ATTESTATION STATEMENT Date: 2024-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 R ef: Attestation Statements Part 2.911(d)(5)(i), (ii) Filing FCC ID: 2AB877921 I connect, certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. And Iconnect, certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. S incerely, Printed name: Johnson Wang Title: Manager S ignature:

U.S. AGENT LETTER OF ATTESTATION Date: 2024-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AB877921 Iconnect certifies that, as of the date of the filing of the application, Y5Shop LLc. is our designated U.S. agent for service of process for the above referenced FCC ID. Iconnect accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Y5Shop LLc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Y5Shop LLc. Address: 2725 AUTUMN LN,FRISCO,TEXAS,USA FRN: 0033834391 Tel.: 469 636 2888 Email: [email protected] Signed by (printed name): Wang Chiang-Sheng Signature: Applicant: Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan FRN: 0023545262 Tel: 886-2 -27968477 Fax: 886-2-27968478 Email: [email protected] Signed by Printed name: Johnson Wang Signature:

Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist.,Taipei City,Taiwan Tel:886-2-27968477 Fax:886-2-27968478 Email: [email protected] Attestation Letter Date: 2024-04-29 FEDERAL COMMUNICATIONS COMMISSION Auth o rization and Evaluation Division 7 4 3 5 Oakland Mills Road Columbia, M D 2 1046 Dear S ir or Madam: We, Iconnect , hereby declare that the product: 11ax Module,FCC ID: 2AB877921, model:AWM27921EU,AWM27921U,AWM27921BU,AMLGA7921,AMST7921,AMST7921U,AWSP 7 921U,AWM27921XX, AMLGA7921XX, AMST7921XX, AWSP7921XX(X:stands for Any alphanumeric character or blank) which was tested by CHINA CERTIFICATION ICT CO.,LTD(DONGGUAN) The product supports SISO in all modes for 2.4G WIFI:2412-2462 MHz(802.11b/g/n ht20/ax hew20) 2422-2452 MHz(802.11n ht40/ax hew40), 5G WIFI (5150-5250MHz,5250-5350MHz,5470-5725MHz,57 25-5850MHz,802.11a/n ht20/ac vht20/ax hew20/802.11n ht40/ac vht40/ax hew40/802.11ac vht80/ax hew80). Although EUT has dual-link antenna, it doesn't support MIMO. The other was disabled and the end user has n o capacity to activate it . Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Printed Name: Johnson Wang Title: Manager

QA-FR-170-B Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan Tel: 886-2-27968477 Fax: 886-2-27968478 Email: [email protected] FCC Authorization Date: 2024-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 O akland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , Iconnect, Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed name: Johnson Wang Title: Manager

QA-FR-171- A Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan Tel: 886-2-27968477 Fax: 886-2-27968478 Email: [email protected] FCC Confidential Authorization Date:2024-05-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:2AB877921 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Iconnect, hereby requests long- term confidential treatment of information accompanying this application as outlined below: •Block Diagram •Schematics • Operation Description U-NII Device Security Declaration The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Sign ature: Printed name: Johnson Wang Title: Manager •

Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist.,Taipei City,Taiwan Tel:886-2-27968477 Fax:886-2-27968478 Email: [email protected] Module Approval Letter Date:2024-05-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, Iconnect, hereby request Modular Approval for Product: 11ax Module,model : AWM27921EU,AWM27921U,AWM27921BU,AMLGA7921,AMST7921,AMST7921U, AWSP7921U, AWM27921XX, AMLGA7921XX, AMST79 21XX, AWSP7921XX, FCC ID:2AB877921). The EUT meets all of the requirement for module approval as detailed in FCC 15.212. the requirements is described below: 1.The module has RF shielding, please refer to the EUT photo. 2.The module transmitter has buffered modulation/data inputs, Buffered data inputs stage has been integrated in chip (Model: MT7921AUN). 3.The module transmitter has its own power supply regulation. Please refer to the schematic. 4. Comply with the antenna requirements of Section 15.203 and 15.204(c), the module have two dipole antennas which use a unique type of connector to attach to the EUT,the maximum gain is 1.76 dBi for 2.4G antenna and 1.47dBi for 5G antenna. 5. The EUT was tested in a stand-alone configuration, please refer to setup photos exhibit for details. 6. The module labeled with its own FCC ID. 7. Comply with any specific rules or operating requirements that ordinarily apply toa complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The necessary explanation to be complied with this requirement is contained in the user manual, band please refers to the User Manual. 8.Comply with FCC15.247 &15.407 §1.1310 and §2.1091 RF exposure requirements in its final configuration. Sincerely, Signature: Printer Name: Johnson Wang Title: M anager

Iconnect Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City,Taiwan TEL:886-2-27968477 FAX: 886-2-27968478 E-mail:[email protected] DECLARATION OF SIMILARITY Date: 2024-04-29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: We, Iconnect, hereby declare that the product: 11ax Module, FCC ID: 2AB877921, model: AWM27921U,AWM27921BU,AMLGA7921,AMST7921,AMST7921U,AWSP7921U,AWM27921XX, AMLGA7921XX, AMST7921XX, AWSP7921XX (X: Any alphanumeric character or blank)are electrically identical with the model: AWM27921EU which was tested by China Certification ICT Co., Ltd (Dongguan) with the same electromagnetic emissions and electromagnetic compatibility characteristics. A description of the difference s between these models and that are declared similar are as follows: They are the same product, and just the different model names for different distribution chains, XX for different country, the rest are the same. Please contact me should there be need for any additional clarification or information. Best Regards, Signature: Printed Name: Johnson Wang Title: Manager

China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐EXP Page 1 of 5 EUT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐EXP Page 2 of 5 China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐EXP Page 3 of 5 port ANT1 ANT2 Not use China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐EXP Page 4 of 5 ANT1 China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐EXP Page 5 of 5 ANT2

China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐INP Page 1 of 2 EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (DongGuan) No.:2403S73093E‐RF‐INP Page 2 of 2

RF EXPOSURE EVALUATION Applicant: Iconnect Address: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist.,Taipei City,Taiwan FCC ID: 2AB877921 Product Name: 11ax Module Standard(s): 47 CFR §1.1307, 47 CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2403S73093E-RF-00D Date Of Issue: 2024/6/27 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: 2403S73093E-RF-00D Page 2 of 6 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403S73093E-RF-00D Page 3 of 6 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2403S73093E-RF-00D Original Report 2024/6/27 China Certification ICT Co., Ltd (Dongguan) Report No.: 2403S73093E-RF-00D Page 4 of 6 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test (EUT) EUT Name: 11ax Module EUT Model: AWM27921EU Multiple Model: AWM27921U, AWM27921BU, AMLGA7921, AMST7921, AMST7921U, AWSP7921U, AWM27921XX, AMLGA7921XX, AMST7921XX, AWSP7921XX (X: Any alphanumeric character or blank) Rated Input Voltage: DC 5V Serial Number: 2KOD-1 EUT Received Date: 2024/4/28 EUT Received Status: Good Note: The multiple models are electrically identical with the test model. Please refer to the declaration letter for more detail, which was provided by manufacturer. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403S73093E-RF-00D Page 5 of 6 2. RF EXPOSURE EVALUATION 2.1 Applicable Standard According to §1.1307(b)(3)(i) (C) Or using Table 1 and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). Table 1 to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . 2.2 Measurement Result Radio Frequency (MHz) λ/2Π (mm) Distance (mm) Exemption ERP (mW) Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) ERP dBm mW 2.4G Wi-Fi 2412-2462 19.80 200 768 21 1.76 20.61 115.08 5.2G Wi-Fi 5180-5240 9.22 200 768 14 1.33 13.18 20.80 5.3G Wi-Fi 5260-5320 9.08 200 768 14.5 1.47 13.82 24.10 5.6G Wi-Fi 5500-5720 8.68 200 768 15 1.20 14.05 25.41 5.8G Wi-Fi 5745-5825 8.31 200 768 14 0.03 11.88 15.42 Note: 1. The Maximum Conducted Power including Tune-up Tolerance was declared by manufacturer. 2. The 2.4G Wi-Fi and 5G Wi-Fi cannot transmit simultaneously. Result: The device compliant the MPE-Based Exemption at 20cm distances. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403S73093E-RF-00D Page 6 of 6 3. EUT PHOTOGRAPHS Please refer to the attachment 2403S73093E-RF-EXP EUT EXTERNAL PHOTOGRAPHS and 2403S73093E-RF-INP EUT INTERNAL PHOTOGRAPHS ===== END OF REPORT =====

TEST REPORT Applicant: Iconnect Address: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist.,Taipei City,Taiwan FCC ID: 2AB877921 Product Name: 11ax Module Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2403S73093E-RF-00A Date Of Issue: 2024/7/8 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan,Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.:2403S73093E-RF-00A Page 2 of 81 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.:2403S73093E-RF-00A Page 3 of 81 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 8 1.2.1 EUT Operation Condition: ............................................................................................................................. 8 1.2.2 Support Equipment List and Details .............................................................................................................. 9 1.2.3 Support Cable List and Details ...................................................................................................................... 9 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 9 1.3 MEASUREMENT UNCERTAINTY ........................................................................................................ 11 2. SUMMARY OF TEST RESULTS .......................................................................................... 12 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 13 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 13 3.1.1 Applicable Standard ..................................................................................................................................... 13 3.1.2 EUT Setup.................................................................................................................................................... 14 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 14 3.1.4 Test Procedure ............................................................................................................................................. 15 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 16 3.2.1 Applicable Standard ..................................................................................................................................... 16 3.2.2 EUT Setup.................................................................................................................................................... 16 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 17 3.2.4 Test Procedure ............................................................................................................................................. 18 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 18 3.3 MINIMUM 6 DB EMISSION BANDWIDTH ........................................................................................... 19 3.3.1 Applicable Standard ..................................................................................................................................... 19 3.3.2 EUT Setup.................................................................................................................................................... 19 3.3.3 Test Procedure .................................................................................................................................…

Text truncated - open the document above for the full version.

© A LFA Network Inc. / ARS-NT2 datasheet ver. 1 Specifications and descriptions may change at any time without prior notice Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan [email protected] www.alfa.com.tw 2.4 GHz + 5 GHz Dual-band Dipole Antenna General Specifications RF Specifications ARS-NT2 Frequency (MHz) Gain (dBi) 2400 1.10 2450 1.76 2500 -0.30 5150 1.02 5250 1.33 5350 1.47 5425 1.20 5550 1.15 5725 -0.56 5850 0.03 Frequency Range 2400 – 2500 MHz 5150 – 5850 MHz V.S.W.R ≤ 2.0 Radiation Toroidal Polarization Linear Impedance 50 Ω Connector RP-SMA Female Dimensions 108.5 x Ø13 mm 4.27 x Ø0.51 inches Weight g Operating Temperature -40 °C to 65 °C -40°F to 149°F © AL FA Network Inc. / ARS-NT2 datasheet ver. 1 Specifications and descriptions may change at any time without prior notice Add: No.9, Aly. 58, Ln. 112, Ruiguang Rd., Neihu Dist., Taipei City, Taiwan [email protected] www.alfa.com.tw ARS-NT2 Antenna Report H-Plane E-Plane

China Certification ICT Co., Ltd (DongGuan) Report No.:2403S73093E‐RF‐00A Page 1 of 4 TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View China Certification ICT Co., Ltd (DongGuan) Report No.:2403S73093E‐RF‐00A Page 2 of 4 Radiated Emission 30 MHz-1 GHz View Radiated Emission 9 kHz-30 MHz Parallel View China Certification ICT Co., Ltd (DongGuan) Report No.:2403S73093E‐RF‐00A Page 3 of 4 Radiated Emission 9 kHz-30 MHz Perpendicular View Radiated Emission 9 kHz-30 MHz Ground-parallel View China Certification ICT Co., Ltd (DongGuan) Report No.:2403S73093E‐RF‐00A Page 4 of 4 Radiated Emission 1-18GHz View Radiated Emission 18-25GHz View
