2ABHT2110002Silent Herdsman collar sensor, model 2110002

SILENT HERDSMAN® USER GUIDE Version 2.7 Issue 2.7 2 1. Table of Contents 1. Table of Contents ................................................................................................ 3 2. About this Guide .................................................................................................. 5 3. Introduction .......................................................................................................... 7 4. Installation ........................................................................................................... 8 4.1. Overview ....................................................................................................... 8 4.2. Silent Herdsman ® Management Computer ................................................... 8 4.3. Management Computer Installation ............................................................ 11 4.4. Data Gathering Base Station....................................................................... 11 5. Silent Herdsman ® Collar .................................................................................... 12 5.1. Standard assembly ..................................................................................... 12 5.2. Collar sensor ............................................................................................... 12 5.3. Buckle ......................................................................................................... 13 5.4. Weight ......................................................................................................... 13 6. Silent Herdsman ® Management Computer ........................................................ 14 6.1. Start up ....................................................................................................... 14 6.2. Overview ..................................................................................................... 15 6.3. On Screen Keyboard ................................................................................... 18 7. Activity Monitoring .............................................................................................. 20 7.1. Overview ..................................................................................................... 20 7.2. Oestrus Prediction ....................................................................................... 20 7.3. Oestrus Detection Threshold....................................................................... 23 7.4. Future Oestrus Events ................................................................................ 23 7.5. Calving Date Indicator ................................................................................. 25 7.6. Changing Time Period on Activity Graphs .................................................. 26 8. Alerts ................................................................................................................. 28 8.1. Overview ..................................................................................................... 28 8.2. Multiple Alerts .............................................................................................. 30 8.3. System Alerts .............................................................................................. 30 8.4. Alert Beacon................................................................................................ 30 8.5. Alerts and Activity ........................................................................................ 31 8.6. Annotations ................................................................................................. 33 8.7. Email Alerts ................................................................................................. 35 9. Collars ............................................................................................................... 36 9.1. Introduction ................................................................................................. 36 Issue 2.7 4 9.2. Attaching collars to cows ............................................................................. 37 9.3. Detaching Collars from Cows ...................................................................... 38 9.4. Finding Collars ............................................................................................ 40 9.5. Deleting Collar ............................................................................................. 40 9.6. Saving List of Attached Cows...................................................................... 41 10. Cow Information Table ....................................................................................... 42 10.1. Overview .................................................................................................. 42 10.2. Importing Herd Information ...................................................................... 43 10.3. Cow Groups ............................................................................................. 44 11. Settings .............................................................................................................. 45 11.1. Overview .................................................................................................. 45 11.2. Activity Display ......................................................................................... 45 11.3. System Settings ....................................................................................... 46 11.4. Group Settings ......................................................................................... 47 11.5. Data Exchange ........................................................................................ 48 11.6. Data Backup ............................................................................................ 51 11.7. Reports .................................................................................................... 51 12. System Functions ......…

Text truncated - open the document above for the full version.

10 th January 2014 TRaC Global Ltd. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: FCC Labelling Requirements FCC ID: 2ABHT2110002 The following label information is required by the FCC Rules and Regulations for certified devices. Also marketing information available on company website that is required by the FCC Rules and Regulations. Thank you for your attention to these matters. Yours faithfully Embedded Technology Solutions Ltd Ivan Andonovic Director E M B E D D E D T E C H N O L O G Y S O L U T I O N S L T D L A D Y W E L L B U S I N E S S C EN T R E | 9 4 D U K E S T | G L A S G O W , G 4 0 U W | U N I T E D K I N G D O M T E L ( U K ) : 0 1 4 1 2 3 7 1355 W W W . E M B E D D E D T E C H . C O .UK R E G I S T R A T I O N S C 3 3 3 487 – 2 – January 17, 2014 ETS2110002 FCC Label Artwork and position All labelling is laser etched into the sensor enclosure Figure 1 – Example of laser etching of FCC ID FCC ID 2ABHT2110002

A RADIO TEST REPORT FOR EMBEDDED TECHNOLOGY SOLUTIONS ON SILENT HEARDSMAN COLLAR DOCUMENT NO. TRA-013983-00-47-00A Total number of pages : 50 TRaC Wireless Test Report : TRA-013983-00-47-00A Applicant : Embedded Technology Solutions Apparatus : Silent Heardsman Collar Specification(s) : CFR47 Part 15.247 & RSS-210 Annex 8 Purpose of Test : Certification FCCID : 2ABHT2110002 Authorised by : : Radio Product Manager Issue Date :4 th February 2014 Authorised Copy Number : PDF TRaC Global Test Report: TRA-013983-00-47-00A 3 Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes Relating To The Assessment 7 1.7 Deviations from Test Standards 7 Section 2: Measurement Uncertainty 8 2.1 Measurement Uncertainty Values 8 Section 3: Modifications 10 3.1 Modifications Performed During Assessment 10 Appendix A: Formal Emission Test Results 11 A1 6 dB Bandwidth 12 A2 Transmitter Peak Output Power 13 A3 Transmitter Power Spectral Density 14 A4 Radiated Electric Field Emissions 15 A5 Antenna Gain 21 A6 Unintentional Radiated Electric Field Emissions 22 Appendix B: Supporting Graphical Data 27 Appendix C: Additional Test and Sample Details 38 Appendix D: Additional Information 44 Appendix E: Calculation of the duty cycle correction factor 45 Appendix F: Photographs and Figures 46 Appendix G: MPE Calculation 49 TRaC Global Test Report: TRA-013983-00-47-00A 4 Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed at: TRaC Global [ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [X] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: A Tosif, D Winstanley Report author: D Winstanley This report must not be reproduced except in full without prior written permission from TRaC Global. TRaC Global Test Report: TRA-013983-00-47-00A 5 1.2 Tests Requested By This testing in this report was requested by : Ladywell Business Centre 94 Duke Street Glasgow G4 0UW Scotland 1.3 Manufacturer As Above 1.4 Apparatus Assessed The following apparatus was assessed between 4 th and 7 th November 2013 Silent Herdsman Collar The above equipment was a DSSS transmitter operating in the 2400 MHz to 2483.5 MHz band. The equipment operates on 4 frequencies separated by 5MHz. These frequencies are 2455 MHz, 2460MHz, 2465 MHz and 2470 MHz. TRaC Global Test Report: TRA-013983-00-47-00A 6 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result Radiated spurious emissions (Restricted bands) RSS-210 Issue 8 December 2010 Annex 8, A8.5 Title 47 of the CFR: Part 15 Subpart C; 15.247 ANSI C63.10:2009 Pass Conducted spurious emissions (Non-restricted bands) RSS-210 Issue 8 December 2010 Annex 8.A4(4) Title 47 of the CFR: Part 15 Subpart C; 15.247 ANSI C63.10:2009 N/A AC Power conducted emissions RSS-GEN Issue 3 December 2010 Annex 7, 7.2.4 Title 47 of the CFR: Part 15 Subpart C; 15.207 ANSI C63.10:2009 N/A Occupied Bandwidth RSS-210 Issue 8 December 2010 Annex 8.A8.2a Title 47 of the CFR : Part 15 Subpart C; 15.247(a)(2) ANSI C63.10:2009 Pass Conducted Carrier Power RSS-210 Issue 8 December 2010 Annex 8.A4(4). Title 47 of the CFR : Part 15 Subpart C; 15.247(b) ANSI C63.10:2009 N/A Power Spectral Density RSS-210 Issue 8 December 2010 Annex 8.A8.2b Title 47 of the CFR : Part 15 Subpart C; 15.247(d) ANSI C63.10:2009 Pass Unintentional Radiated Spurious Emissions RSS-GEN Issue 3 December 2010 7.2.2(c) Title 47 of the CFR: Part 15 Subpart B; 15.109 ANSI C63.10:2009 Pass RF Safety RSS-102 Title 47 of the CFR : Part 15 Subpart C; 15.247(b)(5) - Pass Digital Modulation - Title 47 of the CFR: Part 15 Subpart C; 15.403 - Pass The Silent Heardsman Collar will only be powered by batteries Abbreviations used in the above table: ANSI C 63.10:2009 is outside the scope of the laboratories UKAS accreditation. Mod : Modification CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions TRaC Global Test Report: TRA-013983-00-47-00A 7 1.6 Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature :…

Text truncated - open the document above for the full version.
