2ABZJ-100-00111C6x

C6x Default mode of the C6x is as PTMP CPE. If PTP is required, contact your channel sales representative for purchasing a PTP license key. PTP mode regulations vary by country and may not be allowed in all frequency bands. Required Items •Mimosa N5-X series antenna •Minimum 10 AWG (5.26 mm 2 ) ground cable with pre-terminated ring terminal •Mimosa Gigabit NID (recommended) •Small flat head type screwdriver •50V Mimosa by Airspan PoE, or other 24-56VDC passive isolated PoE rated 20W or higher. 1. Attach Antenna Mount the antenna by clockwise twisting into the radio threaded collar. Hand tighten until the O-ring seal is seated in the collar. Make sure the indicator dot on the antenna is aligned with the set screw as shown in the diagram below, then tighten the set screw. If you are using the radio standalone without an antenna, remove the set screw to allow drainage of any accumulated moisture in the threaded area. Align A Tighten B 2. Mount Using 2 hose clamp type pole straps, attach the C6x to the desired mounting pole. If elevation adjustment is needed, a Mimosa Fleximount XL or J-Mount is suggested. 3. Grounding Attach ground wire (not included) to the inte- grated grounding screw. To ground CAT6/6A to device CAT6/6A to PoE injector To ground AND 4. Connect Ethernet Connect a shielded CAT6/6A Ethernet cable (not included) to the device, inserting it through the M25 cable sealing gland compo- nents and tighten by hand. 5. Unlock and Configure Visit start.mimosa.co to unlock the device. Warnings, Warranty, Compliance & Regulatory Statements Mimosa by Airspan (“Mimosa”) products are provided by Airspan Networks Inc. (“Airspan”). Export Control These commodities, technology, or software were exported from the United States in accordance with the Export Administration Regulations. Diversion contrary to U.S. law is prohibited. Important Safety and Handling Information Failure to follow any of the safety instructions in this guide, instructions on any Airspan provided packaging, and heed WARNINGS (indicated by ), could result in fire, electric shock, other injury or death, and incur damage to this product or other property and void the product’s Limited Warranty. There are no End User serviceable parts inside the equipment. Read all operating and safety instructions contained herein and accom- panying the product as provided by Airspan: Electrical Safety Information Do not operate this product in any location that can be sub- merged by water. Do not install or maintain this product during the presence of an electrical storm to avoid risk of electric shock from lightning. Fail- ure to ground the device according to the included instructions using shielded CAT6/6A Ethernet cabling could lead to serious injury or death. Installation of the product and antenna, configuration of product with antenna must comply with local and national electrical codes. Power specifications for connected devices are indicated on the device’s own label or documentation. Connecting to any power source that does not meet the voltage, frequency and current requirements listed may damage the power supply or product, and pose a fire hazard. Mandatory Grounding Instructions IMPORTANT: Failure to properly ground the device using the following instructions will violate the limited warranty conditions in this document. Required Step 1- Direct Grounding on the Device: A minimum grounding wire of 10 AWG (5.26 mm 2 ) with a secured grounding terminal, and shorter in length than 1 meter is required. It is NOT supplied with the product. 1. Ensure that NO power is being supplied to the product. 2. Locate the Ground point screw next to the Ground icon on the device 3. Remove the provided Ground Screw 4. Thread the ground wire terminal and ground wire meeting the above specifications over the screw removed in the previous step. 5. Replace and tighten the screw with the threaded ground terminal and cable at the product Ground point. 6. Secure the other end of the grounding cable to the properly grounded structure (pole, tower, mast, etc.) meeting local and national electrical regulations and codes. Required Step 2 - Use Mimosa Gigabit NID for Grounding via CAT6/6A Shielded Ethernet: The Mimosa Gigabit NID is required to provide enhanced Electrostatic Discharge (ESD) protection for devices and the premises during electri- cal events. To prevent device damage, avoid ground voltage potential difference between the device integrated ground and the Gigabit NID ground. Failure to follow all instructions provided with the separately sold Mimosa Gigabit NID will violate the product warranty and could lead to serious injury or death. End User Product Warranty Mimosa products purchased from Airspan are warranted against defects in material, and workmanship for a period of either (i) twelve (12) months from the date of activation, or (ii) thirty-six (36) months from the original date of shipment, whichever is earlier. Please go to www.mimo- sa.co/warranty to determine whether your product is in warranty. The sole responsibility of Airspan under this warranty shall be limited to the repair or replacement of in-warranty defective product, at Airspan’s sole option. Out of warranty products shipped to Airspan will not be returned. This warranty does not cover costs associated with the removal and/or reinstallation of the product for repair nor for any parts that are readily replaced in normal use. Airspan or its designated partner will repair or replace product found to be defective during the defined warranty period. The End User is responsible for delivering defective product in accordance with the Return Material Authorization (RMA) processes published at www.mimosa.co/legal/RMA Limitation of Warranty The product warranty is invalidated if the RMA product is altered or otherwise tampered with in a manner that modifies the product from its original shipping configuration and/or form factor, and could violate the End User’s authority to operate t…

Text truncated - open the document above for the full version.

Mimosa Networks, Inc. 777 Yamato Road, Boca Raton, FL 33431 USA Date: 08/02/2022 FCC ID: 2ABZJ-100-00111 Model Number: C6x, iBridge C6x To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Mimosa Networks, Inc. declare that this EUT (FCC ID: 2ABZJ-100-00111) will conduct FCC compliance testing, the sDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.). 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Please contact me if you have any question. Sincerely, (Signed) Name: Syed Aon Mujtaba Phone: 408-398-2927 Fax: 408-628-1276 Email: [email protected] Company Name: Mimosa Networks, Inc.

469 El Camino Real • Suite 100 • Santa Clara, CA 95050 mimosa.co Date: November, 20, 2018 Subject: Mimosa Networks, Inc. Acquired by Airspan Networks, Inc. To Whom It May Concern, Effective November 20, 2018, Airspan Networks, Inc. has acquired Mimosa Networks, Inc. All assets of Mimosa Networks, Inc., including but not limited to all intellectual property, rights to manufacture, and Technical Bureau Certifications have been assigned and transferred to Airspan Networks, Inc. Airspan Networks, Inc. is fully authorized to manufacture Mimosa Networks, Inc. products under the Airspan brand, and utilize without limitation all current Mimosa Networks, Inc. product Technical Bureau Certifications (e.g. FCC, ETSI/CE, IC, UL, etc.) for import/export and technical compliance purposes. Best regards, Jaime Fink Chief Technology Officer & Co-Founder Mimosa Networks Inc.

Rev 11/20/07 (Mimosa Networks, Inc.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (2ABZJ-100-00111). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (ie- Block Diagram, Schematics, Operational Description, Parts List, Tune Up Info) (ie- “1100_schematics.pdf”) Schematic Diagram Block Diagram Operational Description FCC Software Security Requirements for UNII devices Schematic Diagram Block Diagram Operational Description FCC Software Security Requirements for UNII devices The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application, requests short- term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Exhibit Type File Name (ie- External Photos, Internal Photos, Test Setup Photos, Manual) (ie- “1100_external photos.pdf”) External Photos Test Setup Photos Internal Photos User Manual External Photos Test Setup Photos Internal Photos User Manual Sincerely, (signature) (printed name): Syed Aon Mujtaba Date: 08/02/2022 Company Name: Mimosa Networks, Inc.

Mimosa Networks, Inc. Family models difference declaration Product Name: C6x Trade Name: Model Name: C6x, iBridge C6x FCC ID: 2ABZJ-100-00111 Difference declaration: All the model are the same circuit and RF module, except the model names. Regards, Signature Name: Syed Aon Mujtaba Date: 2022-08-02 Company Name: Mimosa Networks, Inc.

(Mimosa Networks, Inc.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 08/02/2022 SUBJECT: FCC Application for FCC ID: 2ABZJ-100-00111 To Whom It May Concern: We, the undersigned, hereby authorize Alex Li at Shenzhen NTEK Testing Technology Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen NTEK Testing Technology Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (signature) (printed name): Syed Aon Mujtaba Company Name: Mimosa Networks, Inc.

FCC ID: 2ABZJ-100-00111 Model Name: C6x External Photographs Photo1 Photo2 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo3 Photo4 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo5 Photo6 External (Screw on) Cassegrain Antenna FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo7 External (Screw on) Cassegrain Antenna Photo8 External (Screw on) Cassegrain Antenna FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo9 External (Screw on) Cassegrain Antenna Photo10 External (Screw on) Cassegrain Antenna FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo11 Photo12 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo13 Photo14 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo15 Photo16 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo17

REVISIONS REVDESCRIPTIONDATEBY 1For Initial ReleaseFEB 26, 2021JF 4 A 123 BB A 2134 airspan networks 469 El Camino Real Santa Clara, CA 95050 TOLERANCES: MATERIAL: THIRD ANGLE PROJECTION: PRODUCT LABEL, C6x ENCLOSURE, MIMOSA 2 1 DO NOT SCALE DRAWING TEMPLATE # 903-00001 WS DIMENSIONS ARE IN MILLIMETERS. ANGULAR: 1 X: 1 X.X: 0.3 X.XX:0.13 X.XXX:0.080 HOLE TO HOLE: 0.13 HOLE : +0.08/-0.05 MODEL-DERIVED FEATURES: 0.3 KG0.00 WEIGHT: DESCRIPTION: FINISH: DRAWN BY: SIZE: B DWG. NO.:REV: SCALE: 1 SHEET: AS LABELED 615-00349 PROPRIETARY & CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MIMOSA NETWORKS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT WRITTEN PERMISSION OF MIMOSA NETWORKS IS PROHIBITED. 1 OF 1 FCC ID: 2ABZJ-100-00111 IC: 11823A-10000111 Airspan Networks Inc. Boca Raton, FL, USA 615-00349 615-00350 PRINT ART TO SCALE 1:1 1. To be used with 615-00350, S/N LABEL, C6x, Mimosa/RIL DIMENSIONS AND LAYOUT ONLY SCALE 2:1 3.33 1.34 25.00 ±0.20 47.00 ±0.20 3X R2.00 29.00 ±0.20 14.00 ±0.20 2X R1.50 2.80 4.70 2X R2.50 3X R2.50 3.33 1.34 25.00 ±0.20 47.00 ±0.20 3X R2.00 29.00 ±0.20 14.00 ±0.20 2X R1.50 2.80 4.70 2X R2.50 3X R2.50 NOTES: NOTES: 1. YELLOW MEANS TRANSPARENT WITH NO ADHESIVE 2. ALL PRINT ON LABEL BLACK (DARKEST POSSIBLE) 3. LABEL MATERIAL BRIGHT WHITE - SAMPLE PROVIDED BY MIMOSA 2. Place 615-00350 on C6x ENCLOSURE in designated pocket then apply 615-00349 on top of it with transparent window showing the sub-label Label Sample S/N LABEL, C6x, MIMOSA/RIL 615-00350 WEIGHT: SHEET 1 OF 1SCALE:1:1 DWG NO. TITLE: REVISION DO NOT SCALE DRAWING MATERIAL: DATE SIGNATURE NAME FINISH: ADHESIVE: MATERIAL: 617-00018 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS SURFACE FINISH: TOLERANCES: LINEAR: ANGULAR: Q.A MFG APPV'D CHK'D Jaime 1 2/25/2021 28mm +/- 0.15mm 13mm +/- 0.15mm Code 128 Barcode embedded with XXYYYYYYYY Serial number XX-YYYY-YYYY MAC XX:XX:XX:XX:XX:XX MAC Address to be provided by Mimosa Font: Avenir Book R1.5 R1.0 S/N: XX-YYYY-YYYY MAC: XX:XX:XX:XX:XX:XX Model: C6x Assembled in Malaysia NOTES: APPLY SEALANT BETWEEN RADOME AND TOP ENCLOSURE 3 6 13 2X 14 12 7 16 2X2X2X 17 10 18 15 2X2X2X 4 2 7X 8 5 13X 11 2X2X2X 1 TORQUE 10 KGF*CM FOLLOW SEQUENCE IN SHEET 2 TORQUE 20 KGF*CM PCBA MODEL IS FOR REFERENCE ONLY TORQUE <2 KGF*CM TORQUE 3 KGF*CM REVISIONS REVDESCRIPTIONDATEBY 1INITIAL RELEASEMAY 11, 2021WS 2CHANGED TO 1.5MM THERMAL PADMAY 16, 2021WS 3UPDATED ASM BOM, PCBA, ENCLOSURES, AND SCREW TORQUES; ADDED THERMAL PAD 609-00217JAN 14, 2022JPC 4REMOVED 609-00208, UPDATED 609-00165 QTY, ADDED SCREW TORQUE FOR 609-00119 AND 602-00114MAR 03, 2022JPC 5UPDATED BOM WITH REV C1 PCBA; ADDED SPEC FOR 13X BOLT PATTERN SCREW SEQUENCEMAY 13, 2022JPC 6UPDATED BOM WITH REV C2 PCBAJUN 06, 2022JPC 7UPDATED BOM WITH REV C3 PCBAJUN 13, 2022JPC ITEM NO. PART NUMBERDESCRIPTION 1004-00070-XXPCBA, C6x BD1 2602-00090SCREW, M4X12 SOCKET HEAD7 3602-00114SCREW, PAN HEAD, M4X10, SS, WITH EXTERNAL-TOOTH WASHER1 4602-00122SCREW, M3X8 SOCKET HEAD, SS 18-8, NYLON PATCH1 5602-00128SCREW, M3X8 PAN HEAD, SS 18-8, NYLON PATCH13 6606-00045TOP ENCLOSURE, C6x1 7606-00046BOTTOM ENCLOSURE, C6x1 8608-00121RADOME, C5X RADIO1 9609-00011SEALANT, RTV1 ML 10609-00119VENT, M6x0.75, BLK1 11609-00165THERMAL PAD 8 X 8 X 1.5 MM2 12609-002062.5 MM O RING, C6x1 13609-00207THERMAL PAD, 14*9*1.5 MM2 14609-00209THERMAL PAD, 11*11*1.5 MM1 15609-00210THERMAL PAD 5.5 X 5.5 X 1.5 MM2 16609-00217THERMAL PAD, 8 X 3.5 X 1.5 MM2 17615-00349PRODUCT LABEL, C6x ENCLOSURE, MIMOSA1 18615-00350S/N LABEL, C6X, MIMOSA/RIL1 4 A 123 D C B 2143 C B A D airspan networks 3150 Coronado Dr, Santa Clara, CA 95054 TOLERANCES: MATERIAL: THIRD ANGLE PROJECTION: ASSEMBLY, C6x PASSIVE POE RADIO, MIMOSA 2 1 DO NOT SCALE DRAWING TEMPLATE # 903-00001 WS DIMENSIONS ARE IN MILLIMETERS. ANGULAR: 1 X: 1 X.X: 0.3 X.XX: 0.13 X.XXX: 0.080 HOLE TO HOLE: 0.13 HOLE : +0.08/-0.05 MODEL-DERIVED FEATURES: 0.3 G WEIGHT: DESCRIPTION: FINISH: DRAWN BY: SIZE: C DWG. NO.:REV: SCALE: 7 SHEET: 2:3 010-00162 PROPRIETARY & CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MIMOSA NETWORKS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT WRITTEN PERMISSION OF MIMOSA NETWORKS IS PROHIBITED. 1 OF 2 840 Label Location 113.4 67.4 177.7 12 13 13X BOLT PATTERN SCREW SEQUENCE STAR PATTERN FOR BOLTS 1 THRU 11 FOLLOWED BY ABOVE SEQUENCE FOR 12 AND 13 4 A 123 D C B 2143 C B A D airspan networks 3150 Coronado Dr, Santa Clara, CA 95054 TOLERANCES: MATERIAL: THIRD ANGLE PROJECTION: ASSEMBLY, C6x PASSIVE POE RADIO, MIMOSA 2 1 DO NOT SCALE DRAWING TEMPLATE # 903-00001 WS DIMENSIONS ARE IN MILLIMETERS. ANGULAR: 1 X: 1 X.X: 0.3 X.XX: 0.13 X.XXX: 0.080 HOLE TO HOLE: 0.13 HOLE : +0.08/-0.05 MODEL-DERIVED FEATURES: 0.3 G WEIGHT: DESCRIPTION: FINISH: DRAWN BY: SIZE: C DWG. NO.:REV: SCALE: 7 SHEET: 2:3 010-00162 PROPRIETARY & CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF MIMOSA NETWORKS. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT WRITTEN PERMISSION OF MIMOSA NETWORKS IS PROHIBITED. 2 OF 2 840

FCC ID: 2ABZJ-100-00111 Model Name: C6x Internal Photographs Photo1 Photo2 FCC ID: 2ABZJ-100-00111 Model Name: C6x Photo3 Photo4 WLAN 5G Antenna

FCC ID: 2ABZJ-100-00111 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result Operation Frequency: U-NII-1: 5180-5240MHz for 802.11ac/ax(20MHz); 5190-5230MHz for 802.11ac/ax(40MHz); 5210MHz for 802.11ac/ax(80MHz); 5250MHz for 802.11ac/ax(160MHz) U-NII-2A: 5260-5320MHz for 802.11ac/ax(20MHz); 5270-5310MHz for 802.11ac/ax(40MHz); 5290MHz for 802.11ac/ax(80MHz); 5250MHz for 802.11ac/ax(160MHz) U-NII-2C: 5500-5700MHz for 802.11ac/ax(20MHz); 5510-5670MHz for 802.11ac/ax(40MHz); 5530-5610MHz for 802.11ac/ax(80MHz); 5570MHz for 802.11ac/ax(160MHz) U-NII-3: 5745-5825 MHz for 802.11ac/ax(20MHz); 5755-5795 MHz for 802.11ac/ax(40MHz); 5775MHz for 802.11ac/ax(80MHz) Integral Panel Antenna gain: 8dBi; External (Screw on) Cassegrain Antenna gain: 25dBi; R=20cm When a number of sources at different frequencies, and/or broadband sources, contribute to the total exposure, it becomes necessary to weigh each contribution relative to the MPE. To comply with the MPE, the fraction of the MPE in terms of E 2 , H 2 (or power density) incurred within each frequency interval should be determined and the sum of all such fractions should not exceed unity. In order to ensure compliance with the MPE for a controlled environment, the sum of the ratios of the power density to the corresponding MPE should not exceed unity. That is Max. Conducted Power Max. Conducted Power Antenna Gain Max. EIRP Power Separation Distance Evaluation Result Power density Limits (dBm)(dBm)(dBi)(dBm)(cm)(mW/cm2 )(mW/cm2) 112.04 211.72 113.89 213.94 114.29 213.94 120.55 220.2 13.89 23.96 10.27 2-0.41 1-0.13 2-0.28 13.89 24.27 1PASS WLAN 5.8G7.092532.09200.3222371PASS WLAN 5.6G2.812527.81200.12004 1PASS WLAN 5.3G2.952527.95200.1241911PASS WLAN 5.2G6.942531.94200.310652 Ant 1PASSWLAN 5.8G23.39831.39200.273913 WLAN 5.3G16.93824.93200.06184 WLAN 5.2G14.89820 BandVerdict WLAN 5.6G17.13825.13200.064806 1PASS 1PASS PASS 0.03873122.89 1 Signature: Date: 2022-07-17 NAME AND TITLE (Please print or type): Alex/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

Datasheet Integrated Radio with Modular Antenna Options The C6x radio’s native 8 dBi gain can be increased to 12, 16, 20 or 25 dBi using modular, X-series, twist-on antennas, offering the ease and simplicity of integrated radios, but with so much more flexibility. Noise Just Met Its Match The link reliability of the C6x starts with the high isolation design of the X-series antennas—but there’s so much more that’s new. Based on Wi-Fi 6E OFDMA technologies, the C6x reduces in-band noise impact across the operating channel with dramatically smaller 2 MHz resource units (RU) sizes instead of legacy OFDM solutions, where any noise impacted the full channel. Incredible Speed and PTMP Scale Previous OFDM technologies limited the scale of client deployments and the ability to deploy in dense, noisy areas. In PTMP client deployments, the C6x pairs together with new multi-user OFDMA scheduling and beamforming technologies on the A6 access point to enable massive subscriber scaling, advanced noise management, and access to the new low-noise 6 GHz band 1 . Carrier Grade While the C6x rugged IP67 design is built to withstand the elements, carrier-grade management capabilities with Airspan ACP and MMP enable operators to deploy and monitor with ease. Together with next- gen RF noise fighting features and new low-noise 6 GHz band support, C6x leads the way in dependable connectivity. Super Flexible, Super Fast, Super Value Gigabit PTMP Client and PTP With Modular Antennas Building on the popular X-series family of modular directional antenna options for flexible distance deployments, the new rugged C6x sets a new bar for affordable speed and interference reduction. With the latest in Wi-Fi 6E OFDMA technologies, and access to new 6 GHz bands 1 , the C6x achieves extremely low latency speeds of up to 1.75 Gbps and high reliability with new noise fighting features. Supporting the Wi-Fi 5/6/6E standards, the C6x can be deployed as a standard Wi-Fi interoperable client, and provide smooth transitioning in the field for legacy Mimosa and standard Wi-Fi deployments. The C6x can be used as a PTMP (point-to-multipoint) client radio, or PTP 2 (point-to-point) backhaul. Need more information? Contact the Mimosa sales team by visiting mimosa.co/contact-us. GHz 5.150- 6.425 IP67 Latency ms 1 OFDMA Gbps 1.75 IP AFC 4 6 GHz • Datasheet • C6x 2 Specifications Performance •Max Throughput: 1.75 Gbps IP aggregate UL/DL (2402 Mbps PHY) •Wireless Protocols: WiFi Interop; Auto-TDD (future release); PTMP TDMA (future release) •Modes: Default mode: PTMP client, 1.75 Gbps License key purchase modes: PTP Backhaul 2 Radio •MIMO & Modulation: 2x2, PTMP MU-MIMO client support, OFDMA, BPSK-1024QAM •Bandwidth: 20/40/80/160 MHz channels, tunable to 5 MHz increments •Frequency Range: PTP/PTMP: 5150–6425 MHz 1 3 (restricted by country of operation) •Max Output Power: 27 dBm •Sensitivity (MCS 0): -87 dBm @ 80 MHz -90 dBm @ 40 MHz -93 dBm @ 20 MHz Power •Max Power Consumption: 20 W •System Power Method: Passive PoE •PoE Power Supply: Passive POE compliant, 48–56 V (PoE injector not included) Physical •Dimensions: Height: 178mm (5”) Width: 113mm (4.5”) Depth: 67mm (2.6”) •Weight: 0.7 kg (1.54 lbs) •RF Connector Type: X-series twist-on •Enclosure Characteristics: Die-cast aluminum, UV stabilized paint, with outdoor UV stable plastic radome lens •Mounting: Dual attached pole mount straps •Grounding: Ground lug Environmental •Outdoor Ingress Protection Rating: IP67 •Operating Temperature: -40°C to +55°C (-40°F to 131°F) •Operating Humidity: 5 to 100% condensing •Operating Altitude: 4,420 m (14,500’) maximum •Shock and Vibration: ETS 300-019-2-4 class 4M5 Regulatory and Compliance •Approvals: FCC Part 15.407; IC RSS210; CE (RED, EMCD, LVD, RoHS); ETSI 301 893/302 502 •RoHS Compliance: Ye s •Safety: EN 62638-1 Features •Gigabit Ethernet: 10/100/1000-BASE-T •Management Services: MMP support; Netconf (future support); SNMPv2c/v3; Syslog; HTTPS; HTML 5 based Web GUI; IPv4 and IPv6 •Smart Spectrum Management: Active scan monitors/logs ongoing RF interference across all channels (no service impact); Dynamic auto-optimization of channel and bandwidth use •Security: AES; RADIUS; 802.1x authorization •QoS: WiFi Interop Mode WMM; SRS mode supports 4 user configurable QoS levels supporting both CBWFQ and PQ •VLAN: Q-in-Q, double tagging, management VLAN, PTMP per client VLAN 1 Outdoor 6 GHz availability varies by country regulations. USA/FCC may only allow PTMP client mode. 2 Additional purchase of a PTP license key required for PTP operation. 3 Automatic Frequency Coordination database support via firmware update, once formally approved by the FCC • Datasheet • C6x 3 ProductC6x (no antenna) N5-X12 (horn) N5-X16 (horn) N5-X20 (dish) N5-X25 (dish) Gain8 dBi12 dBi16 dBi20 dBi25 dBi PolarizationDual-slant 45ºDual-slant 45ºDual-slant 45ºDual-slant 45ºDual-slant 45º Beamwidth, Symmetric (3 dB) 58º38º22º12º8º Front-to-Back Ratio (min) 21 dB29 dB50 dB35 dB40 dB Front-to-Side Ratio (min) 21 dB27 dB43 dB37 dB> 45 dB Weight0.7 kg (1.54 lbs) 0.16 kg (0.35 lbs) 0.61 kg (1.35 lbs) 0.77 kg (1.70 lbs) 0.98 kg (2.15 lbs) DimensionsHeight: 178 mm (5”) Width: 113 mm (4.5”) Depth: 67 mm (2.6”) Diameter: 76 mm (2.99”) Depth: 67 mm (2.63”) Diameter: 160 mm (6.29”) Depth: 116 mm (4.57”) Diameter: 270 mm (10.63”) Depth: 83 mm (3.27”) Diameter: 429 mm (16.89”) Depth: 116 mm (4.57”) MountDual-pole clamps Mimosa N5-X twist-on Mimosa N5-X twist-on Mimosa N5-X twist-on Mimosa N5-X twist-on Wind Survivability 200 km/h (125 mph) 200 km/h (125 mph) 200 km/h (125 mph) 200 km/h (125 mph) 200 km/h (125 mph) Wind Loading 2.79 kg @ 160 km/h (6.14 lbs @ 100 mph) 3.27 kg @ 160 km/h (7.20 lbs @ 100 mph) 5.13 kg @ 160 km/h (11.30 lbs @ 100 mph) 14.55 @ 160 km/h (32.07 lbs @ 100 mph) 36.26 kg @ 160 km/h (79.95 lbs @ 100 mph) N5-X Modular Antenna Options • Datasheet • C6x 4 Native, Built-In (8 dBi) Gain (dBi) Frequency (dBi) Port 1 Port 2 N5-X12 (12 dBi) Gain (dBi) Frequency (dBi) Port 1 Port …

Text truncated - open the document above for the full version.

Report No.: S22051400107001 Version.1.2 Page 1 of 123 FCC RADIO TEST REPORT FCC ID: 2ABZJ-100-00111 Product： C6x Trade Mark： Model Name： C6x Family Model： iBridge C6x Report No.： S22051400107001 Prepared for Mimosa Networks, Inc. 777 Yamato Road, Boca Raton, FL 33431 USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao'an District, Shenzhen 518126 P.R.China. Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S22051400107001 Version.1.2 Page 2 of 123 TEST RESULT CERTIFICATION Applicant’s name ................. : Mimosa Networks, Inc. Address ................................. : 777 Yamato Road, Boca Raton, FL 33431 USA Manufacturer's Name .......... : Mimosa Networks, Inc. Address ................................. : 777 Yamato Road, Boca Raton, FL 33431 USA Product description Product name ........................... : C6x Model and/or type reference ............................................... : C6x Family Model ............................. : Standards ............................. : FCC Part15.407 Test procedure ............................... : ANSI C63.10-2013; KDB 789033 D02 General UNII Test Procedures New Rules v02r01 KDB 662911 D01 Multiple Transmitter Output v02r01 KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 KDB 905462 D04 Operational Modes for DFS Testing New Rules v01 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements/ the Industry Canada requirements.. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 14 May. 2022 ~ 17 Jul. 2022 Date of Issue ........................................... : 19 Jul. 2022 Test Result ............................................... : Pass Testing Engineer : (Cheng Jiawen) Authorized Signatory : (Alex Li) Report No.: S22051400107001 Version.1.2 Page 3 of 123 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 FACILITIES AND ACCREDITATIONS 7 1.2 MEASUREMENT UNCERTAINTY 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 11 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 14 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 15 3 . TEST REQUIREMENTS 17 3.1 CONDUCTED EMISSION MEASUREMENT 17 3.1.1 APPLICABLE STANDARD 17 3.1.2 CONFORMANCE LIMIT 17 3.1.3 TEST CONFIGURATION 17 3.1.4 TEST PROCEDURE 17 3.1.5 TEST RESULTS 18 3.2 RADIATED EMISSION MEASUREMENT 34 3.2.1 APPLICABLE STANDARD 34 3.2.2 CONFORMANCE LIMIT 34 3.2.3 MEASURING INSTRUMENTS 34 3.2.4 TEST CONFIGURATION 35 3.2.5 TEST PROCEDURE 36 3.2.6 TEST RESULTS (9KHZ – 30 MHZ) 37 3.2.7 TEST RESULTS (30MHZ – 1GHZ) 38 3.2.8 TEST RESULTS (1GHZ-18GHZ) 54 3.2.9 TEST RESULTS (18GHZ-40GHZ) 70 3.2.10 SPURIOUS EMISSION IN RESTRICTED BAND 4.5GHZ~5.150 GHZ& 5.350GHZ~5460GHZ AND BANDEDGE 86 3.3 POWER SPECTRAL DENSITY TEST 109 3.3.1 APPLIED PROCEDURES / LIMIT 109 3.3.2 TEST PROCEDURE 110 3.3.3 DEVIATION FROM STANDARD 110 3.3.4 TEST SETUP 110 3.3.5 EUT OPERATION CONDITIONS 110 3.3.6 TEST RESULTS 111 3.4 26DB & 99% EMISSION BANDWIDTH 112 3.4.1 APPLIED PROCEDURES / LIMIT 112 Report No.: S22051400107001 Version.1.2 Page 4 of 123 Table of Contents Page 3.4.2 TEST PROCEDURE 112 3.4.3 EUT OPERATION CONDITIONS 113 3.4.4 TEST RESULTS 113 3.5 MINIMUM 6 DB BANDWIDTH 114 3.5.1 APPLIED PROCEDURES / LIMIT 114 3.5.2 TEST PROCEDURE 114 3.5.3 DEVIATION FROM STANDARD 114 3.5.4 TEST SETUP 114 3.5.5 EUT OPERATION CONDITIONS 114 3.5.6 TEST RESULTS 115 3.6 MAXIMUM CONDUCTED OUTPUT POWER 116 3.6.1 PPLIED PROCEDURES / LIMIT 116 3.6.2 TEST PROCEDURE 117 3.6.3 DEVIATION FROM STANDARD 117 3.6.5 EUT OPERATION CONDITIONS 117 3.6.6 TEST RESULTS 118 3.6.7 MASTER MODE ELEVATION ANGLE ABOVE 30 DEGREES MAXIMUM E.I.R.P. EVALUATION: 119 3.7 OUT OF BAND EMISSIONS 120 3.7.1 APPLICABLE STANDARD 120 3.7.2 TEST PROCEDURE 120 3.7.3 DEVIATION FROM STANDARD 121 3.7.4 TEST SETUP 121 3.7.5 EUT OPERATION CONDITIONS 121 3.7.6 TEST RESULTS 121 3.8 SPURIOUS RF CONDUCTED EMISSIONS 122 3.8.1CONFORMANCE LIMIT 122 3.8.2MEASURING INSTRUMENTS 122 3.8.3TE…

Text truncated - open the document above for the full version.
