Shenzhen Chainway Information Technology Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/03/02 Subject; Request for Confidentiality FCC ID: 2AC6AC61UHF To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chenshurong Title: Manager

Letter of Authorization Company: Shenzhen Chainway Information Technology Co.,Ltd. Address: 9F Building2,Daqian Industrial Park,District 67, XingDong Community,Xin’an street,Ba o’an District,Shenzhen,Guangdong,China Product Name: C61 UHF Model Number: C61 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Chenshurong Date: 2021/03/09 Title: Manager Signature of applicant:

RFIF ANT

FCC RF Exposure FCC ID: 2AC6AC61UHF Applicant: Shenzhen Chainway Information Technology Co.,Ltd. Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: C61 UHF Refer Standard: FCC Part 2.1091: Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands) FCC MPE Limited: Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Test Data Predication of MPE limit at a given distance Where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Antenna Gain information Antenna Gain: 4dBi Conducted Output Power Results Test Channel Frequency (MHz) RF Power(dBm) 1 902.75 28.24 26 915.25 28.72 50 927.25 28.86 Calculation results: pass Frequency (MHz) RF distance(cm) Result (mW/cm2) Limit (mW/cm2) 902.75 20 0.33 0.602 915.25 20 0.37 0.610 927.25 20 0.38 0.618

Report No.: SET2021-01832 P Page 1 of 39 RF TEST REPORT Report No.: SET2021-01832 Product Name: C61 UHF FCC ID: 2AC6AC61UHF Model No. : C61 Applicant: Shenzhen Chainway Information Technology Co.,Ltd. Address： 9F Building2,Daqian Industrial Park,District 67, XingDong Commu nity,Xin’an street,Bao’an District,Shenzhen,Guangdong,China Dates of Testing: 01/21/2019 — 02/25/2021 Issued by: CCIC Southern Testing Co., Ltd. Lab Location: Electronic Testing Building, No. 43 Shahe Road, Xili Street, Nanshan District, Shenzhen, Guangdong, China. Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 39 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approval. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2021-01832 CCIC-SET/ TRF:IRF(2019-05-23) Page 2 of 39 Test Report Product Name ....................... : C61 UHF Brand Name .......................... : CHAINWAY Trade Name ........................... : CHAINWAY Applicant ............................... : Shenzhen Chainway Information Technology Co.,Ltd. Applicant Address ................ : 9F Building2,Daqian Industrial Park,District 67, XingDong Community,Xin’an street,Bao’an District,Shenzhen,Guang dong,China Manufacturer......................... : Shenzhen Chainway Information Technology Co.,Ltd. Manufacturer Address ......... : 9F Building2,Daqian Industrial Park,District 67, XingDong Community,Xin’an street,Bao’an District,Shenzhen,Guang dong,China Test Standards ...................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10:2013：American National Standard for Testing Unlicensed Wireless Devices Test Result ............................ : PASS Tested by ............................. : 2021.02.25 Vincent, Test Engineer Reviewed by ......................... : 2021.02.25 Chris You, Senior Engineer Approved by ......................... : 2021.02.25 Shuangwen Zhang, Manager Report No.: SET2021-01832 CCIC-SET/ TRF:IRF(2019-05-23) Page 3 of 39 Table of contents RF TEST REPORT .......................................................................................................................... 1 1. GENERAL INFORMATION .................................................................................................... 4 1.1. EUT Description ....................................................................................................................... 4 1.2. Test Standards and Results ........................................................................................................ 5 1.3. Description of Test Mode .......................................................................................................... 6 1.4. Facilities and Accreditations ..................................................................................................... 7 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 8 2.1. Antenna requirement ................................................................................................................. 8 2.2. Number of Hopping Frequency ................................................................................................ 9 2.3. Peak Output Power.................................................................................................................. 11 2.4. Bandwidth ............................................................................................................................... 12 2.5. Carried Frequency Separation ................................................................................................. 15 2.6. Dwell time ............................................................................................................................... 17 2.7. Conducted Spurious Emissions ............................................................................................... 21 2.8. Conducted Band Edge ............................................................................................................. 24 2.9. Conducted Emission ............................................................................................................... 27 2.10. Radiated Band Edges and Spurious Emission ........................................................................ 31 3. LIST OF MEASURING EQUIPMENT ................................................................................. 39 Change History Issue Date Reason for change 1.0 2021.02.25 First edition Report No.: SET2021-01832 CCIC-SET/ TRF:IRF(2019-05-23) Page 4 of 39 1. General Information 1.1. EUT Description EUT Type C61 UHF Hardware Version A117_MB_V1 Software Version c61_v11_ea_b253a0e_20200429 Power Supply DC 5V Frequency Range 902MHz~928MHz Operating Range 902.75MHz~927.25MHz Number of channel 50 Modulation Type DSB-ASK Antenna Type Internal Antenna Antenna Gain 4dBi Report No.: SET2021-01832 CCIC-SET/ TRF:IRF(2019-05-23) Page 5 of 39 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (ISM band radiators) for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 15 Subpart C 2017 Radio Frequency Devices 2 ANSI C63.10 2013 American National Standard for Testing Unlicensed Wireless Devices Test detailed items/section required by FCC rules and results are as below: No. Standard(s) Section Description Result FCC 1 15.203 Antenna Requirement PASS 2 15.247(a) Number of Hopping Frequency PASS 3 15.247(b) Peak Output…
