2AC88-GLMU19A02Smart phone

1. WIFI联网指示灯2. 电量指示灯 3. 信号指示灯4. 强度指示灯 5. 插卡位置 6. 电源键 7. 恢复出厂设置8. Type-C接口 1. Wi-Fi LED Indicator 2. Battery LED Indicator 3. Signal LED Indicator4. Strength LED Indicator 5. Handle position for opening 6. Power button 7. Reset button8. Type-C(Input) 功能说明 插卡说明 产品简介 操作流程 注意事项 客服联系方式 进出口管制 儿童健康 交通安全 操作环境 指示灯类型 状 态说 明 WIFI联网指示灯 电量指示灯 长亮 可以上网 灭不可以上网，等待灯亮 闪烁 正在联网中 信号指示灯 亮强度指示灯（4）显示的为信号强度 亮 强度指示灯（4）显示的为电池电量 闪烁 联网异常 持续闪烁 充电中 1. 开机：长按电源键3秒开机。 2. 关机：长按电源键5秒关机。 3. 重启：长按电源键14秒重启。 4. 恢复出厂设置：长按恢复出厂设置按键5秒。 5. 电量和信号显示：短按电源键，先显示电量强度3秒，再显示信号 强度3秒。 手册中或包装上设备的功能描述以及图片仅供参考，您的设备可能与此不 同，请以实物为准。 本手册描述的产品及其附件的某些特性和功能，取决于当地网络的设计和 性能，以及您安装的软件。某些特性和功能可能由于当地网络运营商或网络服 务供应商不支持，或者由于当地网络的设置，或者您安装的软件不支持而无法 实现。因此，本手册中的描述可能与您购买的产品或其附件并非完全一一对应。 深圳市优克联新技术有限公司保留随时修改本手册中任何信息的权利， 无需进行任何提前通知。 在使用和操作本设备前，请阅读并遵守下面的注意事项，以免出现危险 或非法情况，并确保本设备性能最佳。 若需将此产品手册描述的产品（包含但不限于产品中的软件及技术数据 等）出口、再出口或者进口，您应遵守适用的进出口管制法律法规。 本设备及其配件可能包含一些小零件，请将其放置在儿童接触不到的地 方。儿童可能无意损坏本设备及其配件，或吞下小零件导致窒息或其他危险。 驾车时请勿持握本设备，并遵守所在地区或国家的相关规定。请勿将设 备放在汽车安全气囊上方或安全气囊展开后能够触及的区域内。否则当安全 气囊膨胀时，设备就会受到很强的外力推动而对车内人员造成严重伤害。无 线设备可能干扰飞机的飞行系统，请遵守航空公司的相关规定，在禁止使用 无线设备的地方，请关闭该设备。 医疗设备 环境保护 无承担说明 在明文规定禁止使用无线设备的医疗和保健场所，请遵守该场所的规定， 并关闭本设备。本设备产生的无线电波可能会影响植入式医疗设备或个人医 用设备的正常工作，如起搏器、 植入耳蜗、 助听器等。若您使用了这些医用 设备，请向其制造商咨询使用本设备的限制条件。 请遵守有关设备、电池及其配件处理的本地法令，并支持回收行动。请 勿将设备、电池及其配件作为普通的生活垃圾处理。 品牌：GlocalMe 型号: GLMU19A02 产品清单：整机1 台，说明书1 本，数据线1 条， 卡针1个 技术参数： • 尺寸： 126*66*10mm • LTE FDD：B1/2/3/4/5/7/8/9/12/13/17/18/19/20/25/26/28/66 • LTE TDD：B34/38/39/40/41(194M) • WCDMA： B1/2/4/5/6/8/9/19 • GSM： 850/900/1800/1900 • WiFi协议： IEEE802.11b/g/n • Type-C接口 • 电量：3000mAh • 输入：DC 5V 2A 请勿在多灰、潮湿、肮脏或靠近磁场的地方进行充电或使用本设备，以 免引起设备内部电路故障。雷雨天气时，请勿使用设备，以免受到雷击或其 它伤害。有明文规定禁止使用无线设备的场所，请关闭本设备。建议在环境 温度为 0°C ~ + 35°C的情况下使用。请勿在温度过高或过低的环境中使用本 设备。请将设备或其配件放置在通风、阴凉、无阳光直射的地方，请勿将设 备包裹密封或在设备上覆盖毛巾及放置其它物品，请勿将设备放置在盒子或 箱子中使用，以免散热不良导致设备损坏。 电磁辐射比吸收率（SAR） 本手册中的内容均“如是”提供，除非适用法要求，深圳市优克联新技术 有限公司对本手册中的所有内容不提供任何明示或暗示的保证，包括但不限 于适销性或者适用于某一特定目的的保证。 在法律允许的范围内，深圳市优克联新技术有限公司在任何情况下，都 不对因使用本手册相关内容而产生的任何特殊的、附带的、间接的及继发性 的损害进行赔偿，也不对任何利润、数据、商誉或预期节约的损失进行赔偿。 因软件版本的不断更新，设备的操作界面会与说明书有细微差异，具体请以 本产品电磁辐射比吸收率（SAR)最大值小于2.0W/kg,符合国家标准 GB 21288-2007的要求。 维护和保养 请保持设备及其配件干燥。请勿使用微波炉等外部加热设备对其进行干 燥处理。请勿使设备及其配件受到强烈的冲击或震动，以免损坏设备及其配 件，或者导致电池燃烧或爆炸。 请勿在温度过高或过低区域，放置本设备及其配件，否则可能导致设备、 电池和充电器故障、着火或爆炸。 请不要使用烈性化学制品、清洗剂或强洗涤剂清洁设备或其配件。清洁 和维护前请先关机，并断开充电器与设备的连接。 请勿擅自拆卸设备及配件，否则该设备及配件将不在本公司保修范围之内。 易燃易爆区域 在加油站或靠近易燃物品、化学制剂的地方，请勿使用本设备，并遵守 所有图形或文字的指示。在燃油或化学制剂存放和运输区或易爆场所内及周 围，设备可能引起爆炸或起火。请勿将设备及其配件与易燃液体、气体或易 爆物品放在同一箱子中存放或运输。 使用电池和充电器 产品中有毒有害物质或元素的名称及元素 实际体验为准。 漏液，请不要使皮肤或眼睛接触到漏出的液体；若沾到皮肤或眼睛上，请立即 用清水冲洗，并到医院进行医疗处理。如果电池在使用、充电或保存过程中有 异常发热等异常现象，请停止使用。若充电器电源线已经损坏，请勿继续使用， 以免发生触电或火灾。请勿把设备扔到火里，否则会导致电池起火和爆裂。用 错误型号电池更换会有爆炸危险，务必按照说明处置用完的电池。 用户必须选用3C强制性认证的合格充电器（输出为5V 2A的充电器）当 充电完毕或者不充电时，请断开与设备的连接并从电源插座上拔掉充电器。请 勿将电池或设备放置在加热设备的周围，如微波炉、烤箱或散热器等。电池过 热可能引起爆炸。 请勿拆解或改装电池，以免引起电池漏液、过热、起火或爆裂。如果电池 12345678 Copyright © 2018 uCloudlink All Rights Reserved 此产品以及相关系统受优克联专利技术保护，详情请查阅 https://www.ucloudlink.com/patents 快速入门指南 1 2 3 4 6 5 7 8 1. U3支持插入实体SIM卡，使用实体SIM 卡上网。只能插入Nano-SIM卡（小卡） ，如果是标准的SIM大卡或Micro-SIM(中 卡)则需要剪卡。 2. 拔卡时请用取卡针将卡槽顶出，根据图 示方向放入SIM卡，若使用过程中出现异 常可联系售后客服处理。 3. 设备不支持带PIN码的SIM卡，如需使 用此类SIM卡，请先解除PIN码。 1、账号注册：扫描右边二维码下载GlocalMe APP， 安装完成后，注册账号并登录； 2、设备绑定：使用APP扫描设备背面的二维码绑定 设备； 3、购买套餐：在GlocalMe APP里选择购买合适的套 餐或直接充值到余额； 4、设备开机：长按开机键3秒开机； 5、连接设备：待设备WIFI指示灯常亮后，打开手机 WIFI设置，选择GlocalMe WIFI连接（WIFI账号和密 码详见设备背面，如右图所示） 6、设备管理：连接上设备WIFI后，在手机浏览器地 址栏输入“192.168.43.1”，输入账号密码即可进入管 理页面（初始账号密码如右图所示） 深圳市优克联新技术有限公司 官网：www.glocalme.com 客服热线： +852-8191-2660/+86 400-699-1314 (数字键1转售前服务，数字键3转售后服务 邮件：技术与售后问题，邮件联系我们 [email protected] 地址：中国深圳市南山区学府路深圳软年产业基地1栋A座3层 该操作系统仅支持官方提供的系统更新,若用户刷第三方的ROM系统 或采用任何破解的方式修改系统软件,可能会导致系统不稳定,可能会 带来安全风险或危险,用户需要为类似行为承担责任。 Copyright © 2018 uCloudlink All Rights Reserved IMEI:123456789012345 SSID: GlocalMe_0000 PWD: 000000000 User Manual 1 2 3 4 6 5 7 8 front panel Function Introduction Local SIM 1. Power on：Press power button for 3 seconds. 2. Power off：Press power button for 5 seconds. 3. ResetPress power button for 18 seconds. 4. Restore Factory Settings：Press reset button for 5 seconds. 5. Battery Capacity and Signal Strength：Press the power button, the battery capacity will be shown in the first 3 seconds, then the signal strength will be shown afterwards. Wi-Fi LED Indicator Battery LED Indicator On Ready for internet connection Off No internet connection Flashing Service connecting Signal LED Indicator On Flashing Service Error Flashing Charging Status Remarks LED Indicator Type The signal strength is shown by strength LED indicator (4) On The battery capacity is shown by strength LED indicator (4) 1. Local SIM is supported by U3, Only insert Nano-SIM card (small card). 2. Use a needle to pull out the SIM cards as shown in the picture below. Please contact customer service if any issue encountered 3. U3 device does not support SIM cards with PIN code, if you want to use this type of SIM cards, please unlock the PIN code first. Product Introduction Brand：GlocalMe Model No.: GLMU19A02 Box Content: Device, User Manual Type-C Cable SIM Removal tool Technical Specification • LTE FDDB1/2/3/4/5/7/8/9/12/13/17/18/19/20/25/26/28/66 LTE TDDB34/38/39/40/41(194M) • Size: 126*66*10mm • • WCDMA B1/2/4/5/6/8/9/19 • GSM 850/900/1800/1900 • CDMA/EVDO: BC0 BC1 • Wi-Fi: IEEE802.11b/g/n • Type-C (Input) • Battery Capacity: 3000mAh • Power Input: DC 5V 2A Warning communications. However, there is no guarantee that interference will not occur during installation. If the device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is suggested to try to correct the interference by the following measures: --Reorient or relocate the receiving antenna. --Increase the distsnce between the equipment and receiver. --Connect the equipment to an outlet on a different circuit to the receiver. --Consult the manufacturer or an experienced radio/TV technician for help. Information on the disposal and recycling of the device This symbol (with or without a solid bar) on the device…

Text truncated - open the document above for the full version.

Rev 11/20/07 HONGKONG UCLOUDLINK NETWORK TECHNOLOGY LIMITED Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AC88-GLMU19A02 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanently confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Operational Description.pdf PCB Layout PCB Layout Schematics.pdf PCB Placement Part Placement Schematics.pdf Tune up Procedurer Tune up Procedurer.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, Pursuant to DA04- 1705 June 15, 2004 of the Commission’s public notice, Wahoo Fitness LLC. requests short-term Confidentiality of following sections of this application for a period of 45 days after grant is issued. Exhibit Type File Name External Photographs External Photographs.pdf Internal Photographs Internal Photographs.pdf Test Photo User manual Test Photo.pdf User manual.pdf Sincerely, (signature) Tan Zhu

HONGKONG UCLOUDLINK NETWORK TECHNOLOGY LIMITED Suite 603, 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Kowloon, Hong Kong \\192.168.1.251\szctc\06 工程部\02 RF项目部\2019年案件\11月\CTC191108-013 优克联 4G Wireless Data Terminal FCC IC\1.资料\1.3 申请资料 \FCC\FCC letter\POA_Letter_140225.docx Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2019-12-25 SUBJECT: FCC Application for ( 2AC88-GLMU19A02) To Whom It May Concern: We, the undersigned, hereby authorize _ Harry Li_ _ at _ CTC Laboratories, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by _ Harry Li_ on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Printed Name: Tan Zhu Signature:

External Photographs

Label Location Label：

Internal Photographs GSM / WCDMA / LTE main antenna WIFI + diversity antenna

CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Te c h Park, Longhua District, Shenzhen, Guangdong, China Tel: +86-755- 27521059 Fax: +86-755- 27521011 Http://www.sz-ctc.com.cn TEST REPORT Report No. ··························: CTC20192260E01 FCC ID ·······························: 2AC88-GLMU19A02 Applicant····························: HONGKONG UCLOUDLINK NETWORK TECHNOLOGY LIMITED Address·······························: Suite 603, 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Kowloon, Hong Kong, China, China Manufacturer························: HONGKONG UCLOUDLINK NETWORK TECHNOLOGY LIMITED Address·······························: Suite 603, 6/F, Laws Commercial Plaza, 788 Cheung Sha Wan Road, Kowloon, Hong Kong, China Product Name······················: 4G Wireless Data Terminal Trade Mark···························: GlocalMe Model/Type reference·············: GLMU19A02 Listed Model(s) ····················: -- Standard·····························: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample...: Nov. 25, 2019 Date of testing.......................: Nov. 26, 2019 to Dec. 02, 2019 Date of issue.........................: Dec. 15, 2019 Result.................................: PASS Compiled by: (Printed name+signature) Torny Fang Supervised by: (Printed name+signature) Eric Zhang Approved by: (Printed name+signature) Walter Chen Testing Laboratory Name......: CTC Laboratories, Inc. Address...............................: 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China This test report may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CTC. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CTC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. The test report merely correspond to the test sample. Page 2 of 77 Report No.: CTC20192260E01 CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Table of Contents Page 1. TEST SUMMARY ....................................................................................................................................................... 3 1.1. TEST STANDARDS .......................................................................................................................................................... 3 1.2. REPORT VERSION .......................................................................................................................................................... 3 1.3. TEST DESCRIPTION ........................................................................................................................................................ 4 1.4. TEST FACILITY .............................................................................................................................................................. 5 1.5. MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 1.6. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2. GENERAL INFORMATION .......................................................................................................................................... 7 2.1. CLIENT INFORMATION ................................................................................................................................................... 7 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 7 2.3. OP E R AT I O N S TAT E ......................................................................................................................................................... 8 2.4. MEASUREMENT INSTRUMENTS LIST ................................................................................................................................. 9 3. TEST ITEM AND RESULTS ........................................................................................................................................ 11 3.1. CONDUCTED EMISSION ................................................................................................................................................ 11 3.2. RADIATED EMISSION ................................................................................................................................................... 14 3.3. BAND EDGE EMISSIONS ............................................................................................................................................... 42 3.4. BANDWIDTH .............................................................................................................................................................. 59 3.5. PEAK OUTPUT POWER ................................................................................................................................................ 69 3.6. POWER SPECTRAL DENSITY .................................................................................................................................…

Text truncated - open the document above for the full version.

EUT TEST PHOTOS Radiated Emission Below 1G Above 1G Conducted Emissions

EUT TEST PHOTOS Radiated Emission Below 1G Above 1G
