2ACEVF2BRIOF25Mobile phone

1 CONTENT 1. WARNINGS ...................................................................... - 1 - 2. GETTING STARTED ....................................................... - 2 - 3. YOUR PHONE .................................................................. - 3 - 3.5 KEYPAD DEFINITION ................................................. - 3 - 4. FILE MANAGER ............................................................. - 3 - 5. PHONE BOOK ................................................................. - 4 - 6.1GAMES THE PHONE OFFERS INTERESTING GAMES, FOR DETAILED OPERATION, PLEASE VIEW GAME OPERATION SPECIFICATION .............................. - 4 - 7. CALL CENTER ................................................................ - 4 - 8. MESSAGING .................................................................... - 4 - 11 SETTINGS ..................................................... - 7 - - 1 - 1. Warnings Not following these simple guidelines may be dangerous or illegal. Read the complete user guide for further information. TURN ON SAFELY Do not turn on the phone when wireless phone is prohibited or when it may cause interference or danger. ROAD SAFETY Obey all road safety laws. Always use both of your hands to operate the vehicle while driving. INTERFERENCE All wireless phones may be sensitive to interference, which may affect performance. TURN OFF IN HOSPITALS Follow all restrictions. Turn off the phone near medical equipment. TURN OFF ON AIRCRAFTS Follow all restrictions. Wireless devices can cause interference on aircrafts. TURN OFF WHEN REFUELING Do not use the phone at/near refueling stations. Do not use near fuel or chemicals. USE SENSIBLY Only qualified personnel may install or repair this product. ENHANCEMENTS AND BATTERIES Use only appropriate enhancements and batteries. Do not connect incompatible products. WATER-RESISTANCE Your phone is not water-resistant. Keep it dry. BACKUP COPIES Remember to make back-up copies or keep a written record of all important information stored in your phone. - 2 - CONNECTING TO OTHER DEVICES When connecting to any external device, read its user guide for detailed safety instructions. Do not connect with incompatible products. 2. Getting Started 2.1 SIM Card Installation When you subscribe to a cellular network, you will receive a plug-in SIM card complete with your subscription details, such as your PIN, and available optional services. Caution: Do not bend or scratch your SIM card. Avoid exposing your SIM card to static electricity, water, or dirt. Tips：Face the gold color contact point of SIM card towards the cell phone and push the SIM card into the slot. 2.2 Battery Installation Caution: Install according to the illustration above to avoid breaking the battery connectors. 2.3 Charging the Battery Insert the charger; the flash symbol on the charger plug must face upwards. Connect the charger to a standard wall outlet and the battery power icon in the up-right corner of the screen will start scrolling. When the battery bar stops scrolling, the battery charge is complete. Press the two sides of the charger plug and disconnect the charger from the phone. 2.4 T-flash Card Insert the T-Flash card into phone. This will expand the Flash memory of the phone. Tap Multimedia menu, you can browse MP3, MP4, picture, etc. 2.5 USB Cable - 3 - You can transfer and store files, such as MP3, MP4 and pictures from PC, through USB cable, to the U-disk in phone or identified SD card that is inserted. 3. Your Phone 3.1 Making a Call In standby mode, press numerical keys to input phone number to dial phone number. When you finish inputting phone number, press the dial key, SIM2 key to make a call. If you're making a long distance call, add the area code preceding the telephone number. During a call, you can press navigation keys to adjust volume. Press left soft key to access Options. 3.2 Emergency Service You can dial an emergency call without the SIM card. Contact your service provider to get the emergency call number. 3.3 Answering a Call When you receive a call, the phone will ring or vibrate and will display an incoming call indicator. Press the dial key, key to answer. Press left soft key to access options. 3.4 Rejecting/Ending a Call Press end key to reject an incoming call or end current call. 3.5 Keypad Definition ·CENTER key: To enter main menu ·Dial key: Dial the number or answer calls ·End key: Cancel or reject calls; by long pressing can turn on/off the phonemethod in editing mode 4. File Manager Enter this menu; you can check the files store on T-flash card. Press left soft key, you can do options. - 4 - 5. Phone book You can store contacts' personal information and numbers while also search for previously stored contacts. Press left soft key to access Options. 6.Fun&Games 6.1Games The phone offers interesting games, for detailed operation, please view game operation specification 7. Call center In the call history menu, you can check dialed calls, received calls, missed calls, rejected calls, delete all, check call time, call cost, and GPRS counter. 8.Messaging 8.1 Write message Please setup the correct message center number before creates the message. Enter into the create message sub-menu to create the message, press “confirm” key to enter into the “Options” menu. You can access the Send to, Insert template, Insert number, Insert name, Insert bookmark, Save to Drafts, Input method, Add Input Method on the text editing and set operations 8.2 Inbox Enter into the inbox sub-menu to check the received message in the SIM card 1, SIM card 2.Press “OK” key to enter into the menu. The information you can Reply, Call sender, Forward, Delete, Delete all, Use number, Advanced, Edit options operation 8.3Drafts The drafts box storage the SMS which not yet ready to send, you can revise and send again. - 5 - 8.4Outbox Enter into the Outbox to view the message which you save in the phone (SIM card1/ SIM card 2/ Phone), also included failed to sent message…

Text truncated - open the document above for the full version.

IED CONEXION VIRTUAL S.A. DE C.V. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for (FCC ID: 2ACEVF2BRIOF25) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory ----------------------------- Client’s signature Client’s name / title : Federico Duran Camargo / Manger Contact information / address : lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico

IED CONEXION VIRTUAL S.A. DE C.V. SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 IED CONEXION VIRTUAL S.A. DE C.V. SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2014/05/14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACEVF2BRIOF25 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Bom and tune up The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------- Client’s signature Client’s name / title : Federico Duran Camargo / Manger Contact information / address : lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Mobile phone Model: BRIO F25 FCC ID: 2ACEVF2BRIOF25 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label

TEST REPORT Report Reference No. ..................... : TRE14050119 R/C: 49343 Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Hans Hu Date of issue ..................................... : May 20, 2014 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ........................... : IED CONEXION VIRTUAL S.A. DE C.V Address............................................. : lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico Test specification: Standard ........................................... : ANSI C95.1–1999 47CFR §2.1093 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Mobile phone Trade Mark ....................................... : F2 mobile Manufacturer .................................... : Shenzhen Kaliho Technology Development Limited Model/Type reference ....................... : BRIO F25 Listed Models .................................. : / Operation Frequency ......................... GSM850/PCS1900/WLAN2450 Modulation Type ................................ GSM:GMSK /WLAN:CCK,OFDM/BT:GFSK Ratings.............................................. : DC 3.70V Result ................................................ : PASS Report No.: TRE14050119 Page 2 of 93 Issued:2014-05-20 T E S T R E P O R T Test Report No. : TRE14050119 May 20, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile phone Model /Type : BRIO F25 Listed Models : / Applicant : IED CONEXION VIRTUAL S.A. DE C.V Address : lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico Manufacturer : Shenzhen Kaliho Technology Development Limited Address : Rm1901, Block A, The Stars Plaza, Huaqiang North Rd., Futian District, Shenzhen, China Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE14050119 Page 3 of 93 Issued:2014-05-20 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Statement of Compliance 5 2.4. Equipment under Test 6 2.5. Short description of the Equipment under Test (EUT) 6 2.6. EUT configuration 6 2.7. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. SAR Limits 8 3.5. Equipments Used during the Test 8 4. SAR MEASUREMENTS SYSTEM CONFIGURATION 9 4.1. SAR Measurement Set-up 9 4.2. DASY5 E-field Probe System 10 4.3. Phantoms 11 4.4. Device Holder 11 4.5. Scanning Procedure 12 4.6. Data Storage and Evaluation 12 4.7. Tissue Dielectric Parameters for Head and Body Phantoms 14 4.8. Tissue equivalent liquid properties 15 4.9. System Check 15 4.10. SAR measurement procedure 17 5. TEST CONDITIONS AND RESULTS 21 5.1. Conducted Power Results 21 5.2. Simultaneous TX SAR Considerations 23 5.3. SAR Measurement Results 25 5.4. SAR Measurement Variability 26 5.5. Measurement Uncertainty (300MHz-3GHz) 27 5.6. System Check Results 29 5.7. SAR Test Graph Results 35 6. CALIBRATION CERTIFICATE 47 6.1. Probe Calibration Ceriticate 47 6.2. D835V2 Dipole Calibration Ceriticate 58 6.3. D1900V2 Dipole Calibration Ceriticate 66 6.4. D2450V2 Dipole Calibration Ceriticate 74 6.5. DAE4 Calibration Ceriticate 82 7. TEST SETUP PHOTOS 85 8. EXTERNAL PHOTOS OF THE EUT 90 Report No.: TRE14050119 Page 4 of 93 Issued:2014-05-20 1. TEST STANDARDS The tests were performed according to following standards: IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. KDB 447498 D01 Mobile Portable RF Exposure v05r01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01: SAR Measurement Requirements for 100 MHz to 6 GHz KDB865664 D02 SAR Reporting v01: RF Exposure Compliance Reporting and Documentation Considerations FCC Part 2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices KDB648474 D04 SAR Handsets Multi Xmiter and Ant v01: SAR Evaluation Considerations for Wireless Handsets. KDB941225 D03 Test Reduction GSM_GPRS_EDGE V01 : Recommended SAR Test Reduction Procedures for GSM/GPRS/EDGE KDB248227: SAR measurement procedures for 802.112abg transmitters Report No.: TRE14050119 Page 5 of 93 Issued:2014-05-20 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : May 11, 2014 Testing commenced on : May …

Text truncated - open the document above for the full version.

RADIO TEST REPORT FCC ID: 2ACEVF2BRIOF25 Product： Mobile phone Trade Name： F2 mobile Model Name： BRIO F25 Serial Model： N/A Report No.： BZT140520F03 Prepared for IED CONEXION VIRTUAL S.A. DE C.V. lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico Prepared by BZT Testing Technology Co., Ltd Add. : Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. Page 2 of 56 Report No.: BZT140520F03 ` TEST RESULT CERTIFICATION Applicant’s name ................. : IED CONEXION VIRTUAL S.A. DE C.V. Address ................................. : lztacalco MZ 146 LT 4 D Col. La Florida de Ciudad Azteca C.P. 55120. Municipio, Ecatepec de Morelos, Edo. De Mexico Manufacture's Name ............ : Shenzhen Kaliho Technology Development Limited Address ................................. : Rm1901, Block A, The Stars Plaza, Huaqiang North Rd., Futian District, Shenzhen, China Product description Product name ........................... : Mobile phone Model and/or type reference : BRIO F25 Serial Model ............................. : N/A Standards ............................. : FCC Part 22H and 24E Test procedure .............................. : ANSI C63.4-2003 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT, personal only, and shall be noted in the revision of the document. Date of Test .......................................... : Date (s) of performance of tests ............. : May 06, 2014 ~ May 20, 2014 Date of Issue ........................................ : May 20, 2014 Test Result ............................................ : Pass Page 3 of 56 Report No.: BZT140520F03 ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . TEST RESULT 12 3.1 ANTENNA REQUIREMENT 12 3.1.1 STANDARD REQUIREMENT 12 3.1.2 EUT ANTENNA 12 3.2 OUTPUT POWER 13 3.2.1 CONDUCTED OUTPUT POWER 13 3.2.2 RADIATED OUTPUT POWER 14 3.3 SPURIOUS EMISSION 17 3.3.1 CONDUCTED SPURIOUS EMISSION 17 3.3.2 RADIATED SPURIOUS EMISSION 19 3.4 FREQUENCY STABILITY 22 3.4.1 MEASUREMENT METHOD 22 3.4.2 PROVISIONS APPLICABLE 22 3.5 OCCUPIED BANDWIDTH 25 3.5.1 MEASUREMENT METHOD 25 3.5.2 PROVISIONS APPLICABLE 25 3.5.3 MEASUREMENT RESULT 25 3.6 EMISSION BANDWIDTH 26 3.6.1 MEASUREMENT METHOD 26 3.6.2 PROVISIONS APPLICABLE 26 3.6.3 MEASUREMENT RESULT 26 3.7 BAND EDGE 27 3.7.1 MEASUREMENT METHOD 27 3.7.2 PROVISIONS APPLICABLE 27 3.7.3 MEASUREMENT RESULT 27 APPENDIX I 28 APPENDIX II 46 APPENDIX III 52 Page 4 of 56 Report No.: BZT140520F03 ` Table of Contents Page 4 . EUT TEST PHOTO 56 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 56 Report No.: BZT140520F03 ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Item Number Item Description Rules Result 1 Output Power Conducted Output Power 22.913(a) / 24.232 (b) RSS-132(5.4) SRSP-503(5.1.3) Pass Radiated Output Power 2 Spurious Emission Conducted Spurious Emission 2.1051 / 22.917 / 24.238 RSS-132(5.5) RSS-133 (6.5) Pass Radiated Spurious Emission 3 Frequency Stability 2.1055 /24.235 RSS-132(5.3) RSS-133(6.3) Pass 4 Occupied Bandwidth 2.1049 (h)(i) Pass 5 Emission Bandwidth 22.917(b) / 24.238 (b) RSS-132(5.5.1) RSS-133(6.5.1) Pass 6 Band Edge 22.917(b) / 24.238 (b) RSS-132(5.5.1) RSS-133(6.5.1) Pass Page 6 of 56 Report No.: BZT140520F03 ` 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 7 of 56 Report No.: BZT140520F03 ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Mobile phone Trade Name F2 mobile Model Name BRIO F25 OEM Brand/Model Name N/A Model Difference N/A Frequency: GSM 850 MHz;:824.2-848.4MHz PCS 1900 MHz: 1850.2-1909.8MHz Output Power: GSM850(Class 4) : 1.403 W (31.47dBm) GPRS850(Multislot Class 8) : 1.205 W (30.81 dBm) GSM1900 (Class 1) : 0.869 W (29.39dBm) GPRS1900 (Multislot Class 8) : 0.681 W (28.33 dBm) Type of Modulation GMSK Antenna Type FIFA Antenna Power Source DC Voltage supplied from battery Power Rating DC 3.7V from battery Connecting I/O Port(s) Please refer to the User's Manual Products Covered N/A EUT Modification(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 8 of 56 Report No.: BZT140520F03 ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. For Radiated Emission Final Test Mode Description GSM850 TX1 PCS1900 TX2 GPRS850 TX3 GPRS1900 TX4 Note: (1)During the testing, the EUT (GSM Dual Band GPRS Dig…

Text truncated - open the document above for the full version.

Page 41 of 42 Report No.: BZT140520F01 10. EUT TEST PHOTO Radiated Measurement Photos Page 42 of 42 Report No.: BZT140520F01 Conducted Measurement Photos
