Document Classification: Public OM247-FIT Fitting Tool & Key Fob Safety Guide User Safety and Regulations Page 2Document Classification: Public This guide contains basic regulatory and safety information. Document Number: 94-0175-01 Revision: 1.0 Issue Date: 16/06/2014 About This Manual Page 3Document Classification: Public Operational Warnings Important information on safe and efficient operation. Read this information before using the device. For safe and efficient use of the device, observe the guidelines outlined below. Environmental Specification 10% to 90% relative humidity Operational Temperature range -20°C to +60°C (AC Power Adaptor: RH 20% to 85%, Operating Temperature 0 to 40°C) Operation The equipment must be used by a SERVICE PERSON. Battery Charging (Fitting Tool Only) When not in use, disconnect the battery charger from both the device and the mains electricity supply. To halt charging, remove the charging clip from the device. User Safety Page 4Document Classification: Public „Do not disassemble, open, crush, deform or puncture the product. „Do not modify, remanufacture, attempt to insert foreign objects, expose to fire, explosion, or any other hazards. „Only use an approved AC power adaptor with the Fitting Tool. Use of an unapproved charger may present a risk of fire, explosion, leakage or other hazard. Approved AC Power Adaptor Source: G4SMTL Model: @3A-181WP06 Part Number: 39-0023-3 Input Rating: 100-240V VAC, 50-60Hz, 600mA Output Rating: 6VDC, 3A Product Handling Page 5Document Classification: Public This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: „Reorient or relocate the receiving antenna. „Increase the separation between the equipment and receiver. „Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. „Consult the dealer or an experienced radio/TV technician for help. FCC Statements Page 6Document Classification: Public FCC Statements (continued) Modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment under FCC rules. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. These products meet the FCC Radiofrequency Emission Guidelines and are certified with the FCC as: FCC ID: 2ACGBFIT915 FCC ID: 2ACGBPID915 The FCC ID is located on a label on the rear face of the product. Page 7Document Classification: Public We hereby declare that these products are in conformance to all essential requirements of the R&TTE Directive 1999/5/ EC. The products are marked with the ‘CE’ symbol and can be used throughout the European Community. This indicates compliance with the R&TTE Directive 1999/5/ EC and meets the relevant parts of the following technical specifications: „EN 301 489-1 v1.6.1:2005 „EN 300-220-2 v2.1.1 EU Regulatory Conformance This symbol indicates that this product should be recycled and not be disposed of in unsorted municipal waste. This product should be returned to the supplier for correct disposal.

TRL 51F047 iss04

TRL 51F050 iss04 G4S Monitoring Technologies 3 Centurion Court Meridian East Meridian Business Park Leicester LE19 1TP REQUEST FOR CONFIDENTIALITY IN ACCORDANCE WITH FCC RULE 0.459 30/05/2014 TRaC GLOBAL LTD. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: Certification Application FCC ID: 2ACGBPID915 To Whom It May Concern: Please be advised that G4S monitoring Technologies Ltd request that the following information is to be held permanently confidential on behalf of G4S Monitoring technologies Ltd. • Track and Component Layout drawings • Technical documents: OM247 PID3 - System Overview • Block diagrams • Schematics • BOMs • Internal Photographs G4S monitoring Ltd have spent substantial effort in developing this product, in particular some of the tamper features are not available in competitor products. Having the information easily available to competitors would negate any advantage they have achieved by developing these features. The application contains technical information which G4S Monitoring Technologies deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. The product is a sealed device (welded in production) and a non-consumer device serviceable only by the grantee. Thank you for your attention to this matter. Yours faithfully G4S Monitoring Technologies Ltd

TRL 51F050 iss04 G4S Monitoring Technologies 3 Centurion Court Meridian East Meridian Business Park Leicester LE19 1TP DECLARATION OF SIMILARITY Date 30/05/2014 TRaC GLOBAL LTD. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: Declaration of Similarity FCC ID: 2ACGBPID915 To Whom It May Concern: Please be advised that the models PID3 and Key Fob (FOB3) are electronically identical, all RF measurements and test results are exactly the same. The differences between the models are the shape and colour of the plastic case: PID3 is grey and has extra plastic wings that attach to a kevlar strap that is installed on the offender, FOB3 is red and carried by an officer on a chain attached to his person Thank you for your attention to this matter. Yours faithfully G4S Monitoring Technologies Ltd

G4S Monitoring Technologies Ltd Issue Date: 30/05/2014 Version: 1.0 Document Owner: Fiona Farrer Current Date: 02/06/14 Page 1 of 5 PID3 & Key Fob (FOB3) External 915MHz Photographs COPYRIGHT STATEMENT PID3 & FOB3 915MHz External Photographs Page 2 of 5 This document and the information contained therein is the property of G4S Monitoring Technologies Ltd. It must not be reproduced in whole or part or otherwise disclosed without prior written consent of the G4S Monitoring Technologies Ltd Quality Manager or Quality Director. PID3 & FOB3 915MHz External Photographs Page 3 of 5 Contents 1 External ................................................................................................................. 4 1.1 External View: Front PID3 ........................................................................................................ 4 1.2 External View: Front FOB3 ....................................................................................................... 4 1.3 External View: Rear PID3 ......................................................................................................... 5 1.4 External View: Rear FOB3 ....................................................................................................... 5 PID3 & FOB3 915MHz External Photographs Page 4 of 5 1 External 1.1 External View: Front PID3 1.2 External View: Front FOB3 PID3 & FOB3 915MHz External Photographs Page 5 of 5 1.3 External View: Rear PID3 1.4 External View: Rear FOB3

G4S Monitoring Technologies Ltd Issue Date: 30/05/2014 Version: 1.0 Document Owner: Fiona Farrer Current Date: 02/06/14 Page 1 of 4 Document Classification: CONFIDENTIAL PID3 & FOB3 915MHz FCC Label Position COPYRIGHT STATEMENT This document and the information contained therein is the property of G4S Monitoring Technologies Ltd. It must not be reproduced in whole or part or otherwise disclosed without prior written consent of the G4S Monitoring Technologies Ltd Quality Manager or Quality Director. PID3 & FOB3 915MHz FCC Label Position Page 2 of 4 Document Classification: CONFIDENTIAL Contents 1 Label Position ........................................................................................................ 3 2 Heading 1 .............................................................................................................. 3 2.1 External View: Rear PID3 ......................................................................................................... 3 2.2 External View: Rear FOB3 ....................................................................................................... 4 PID3 & FOB3 915MHz FCC Label Position Page 3 of 4 Document Classification: CONFIDENTIAL 1 Label Position The FCC labels are affixed to the rear faces of both the PID3 & FOB3 in place of the representative labels seen in these pictures 2 Heading 1 2.1 External View: Rear PID3 PID3 & FOB3 915MHz FCC Label Position Page 4 of 4 Document Classification: CONFIDENTIAL 2.2 External View: Rear FOB3

G4S Monitoring Technologies Ltd +/- 1 +0.25 -0 +0.10 -0 +0.05 -0 +0 -0.25 +0 -0.10 +0 -0.05 X X.X X.XX 2:1 A 1245 A 2145 A4 NW 01 96-0184-4 A-700-MP POLYESTER SILVER THERMAL TRANSFER PRINTED AS DRAWING FCC RCM PID LABEL DRAWING 28/04/14 Document Classification: CONFIDENTIAL NOTES - 1. DIMENSIONS FOR INSPECTION PURPOSES ONLY. FOR ALL OTHER DIMENSIONS REFER TO - 96-0184-4 FCC RCM PIDGMT LABEL DRAWING.AI 2. PRINTED ON ADVANCED LABELS A-700-MP SILVER THERMAL TRANSFER POLYESTER LABEL STOCK 104μm THICK P/N 96-0018-4. 3. PRINTED COLOURS: TEXT AND LOGOS BLACK. 4. BACKED WITH 20μm #310 ACRYLIC ADHESIVE. 5. USE TRUE TYPE FONT: ARIEL SIZE 8 POINT. PIDGMTXXXXXX PIDGCS443732 FCC ID: 2ACGBPID915 1.0 3.0 25.0 PID CODE128 BARCODE S/N FONT ARIAL 8 POINT ON CL 4.0 7.0 10.0 7.0 FFC ID FONT ARIAL 5 POINT ON CL SYMBOL MUST BE A MINIMUM OF 5MM TALL

G4S Monitoring Technologies Ltd +/- 1 +0.25 -0 +0.10 -0 +0.05 -0 +0 -0.25 +0 -0.10 +0 -0.05 X X.X X.XX 2:1 A 1245 A 2145 A4 NW 02 96-0189-4 A-700-MP POLYESTER SILVER THERMAL TRANSFER PRINTED AS DRAWING FCC RCM KEY FOB LABEL DRAWING 28/04/14 Document Classification: CONFIDENTIAL NOTES - 1. DIMENSIONS FOR INSPECTION PURPOSES ONLY. FOR ALL OTHER DIMENSIONS REFER TO - 96-0189-4 FCC RCM KEYGMT LABEL DRAWING.AI 2. PRINTED ON ADVANCED LABELS A-700-MP SILVER THERMAL TRANSFER POLYESTER LABEL STOCK 104μm THICK P/N 96-0018-4. 3. PRINTED COLOURS: TEXT AND LOGOS BLACK. 4. BACKED WITH 20μm #310 ACRYLIC ADHESIVE. 5. USE TRUE TYPE FONT: ARIEL SIZE 8 POINT. 0203/06/14KEY FCCID TO MATCH PIDNW38276 KEYGMTXXXXXX PIDGCS443732 FCC ID: 2ACGBPID915 KEY FOB 1.0 3.0 25.0 CODE128 BARCODE S/N FONT ARIAL 8 POINT ON CL 4.0 7.0 7.0 FFC ID FONT ARIAL 5 POINT ON CL SYMBOL MUST BE A MINIMUM OF 5MM TALL 10.0

A RADIO TEST REPORT FOR G4S Monitoring Technologies LTD ON OM247 PID3 915MHz 10-0164-4 DOCUMENT NO.TRA-016455WUS3 Total number of pages: 37 TRaC Wireless Test Report : TRA-016455WUS3 Applicant : G4S Monitoring Technologies Ltd. Apparatus : OM247 PID3 915MHz 10-0164-4 Specification(s) : CFR47 Part 15.249 Purpose of Test : Certification FCCID : 2ACGBPID915 Authorised by : : Radio Product Manager Issue Date : 30 th May 2014 Authorised Copy Number : PDF TRaC Global Test Report: TRA-016455WUS3 3 Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes Relating To The Assessment 7 1.7 Deviations from Test Standards 7 Section 2: Measurement Uncertainty 8 2.1 Measurement Uncertainty Values 8 Section 3: Modifications 10 3.1 Modifications Performed During Assessment 10 Appendix A: Formal Emission Test Results 11 A1 Transmitter Intentional Emission Radiated 12 A2 Transmitter Bandwidth 13 A3 Radiated Electric Field Emissions 14 A4 Unintentional Radiated Emissions 17 Appendix B: Supporting Graphical Data 19 Appendix C: Additional Test and Sample Details 25 Appendix D: Additional Information 31 Appendix E: Calculation of the duty cycle correction factor 32 Appendix F: Photographs and Figures 33 Appendix G: MPE Calculation 36 TRaC Global Test Report: TRA-016455WUS3 4 Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by: TRaC Global [X] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [ ] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: A Longley Report author: A Longley This report must not be reproduced except in full without prior written permission from TRaC Global. TRaC Global Test Report: TRA-016455WUS3 5 1.2 Tests Requested By This testing in this report was requested by: G4S Monitoring Technologies Ltd. 3 Centurion Court Meridian Business Park Leicester LE19 1TP United Kingdom 1.3 Manufacturer As Above 1.4 Apparatus Assessed The following apparatus was assessed between 25 th March 2014 – 19 th May 2014: OM247 PID3 915MHz 10-0164-4 The above device is an ankle monitor containing a Radio Transceiver operating on 2 fixed frequencies (915.25 & 927.6 MHz) in the 902 – 928 MHz band. TRaC Global Test Report: TRA-016455WUS3 6 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result Title 47 of the CFR: Part 15 Subpart (c) Intentional Emission Field Strength 15.249 (a) ANSI C63.10:2009 Pass Intentional Emission Band Occupancy 15.215 (c) ANSI C63.10:2009 Pass Spurious Emissions Radiated <1000MHz 15.209 & 15.249 (a) (d) ANSI C63.10:2009 Pass Unintentional Radiated Spurious Emissions 15.109 ANSI C63.10:2009 Pass Abbreviations used in the above table: ANSI C 63.10:2009 is outside the scope of the laboratories UKAS accreditation. CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions TRaC Global Test Report: TRA-016455WUS3 7 1.6 Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing was performed under the following environmental conditions: Temperature : 17 to 23 °C Humidity : 45 to 75 % Barometric Pressure : 86 to 106 kPa All dates used in this report are in the format dd/mm/yy. This assessment has been performed in accordance with the requirements of CFR47 Part 2 & RSS-Gen. 1.7 Deviations from Test Standards There were no deviations from the standards tested to. TRaC Global Test Report: TRA-016455WUS3 8 Section 2: Measurement Uncertainty 2.1 Measurement Uncertainty Values For the test data recorded in accordance with note (iii) of Section 2.1 the following measurement uncertainty was calculated: Radio Testing – General Uncertainty Schedule All statements of uncertainty are expanded standard uncertainty using a coverage factor of 1.96 to give a 95% confidence where no required test level exists. [1] Adjacent Channel Power Uncertainty in test result = 1.86dB [2] Carrier Power Uncertainty in test result (Power Meter) = 1.08dB Uncertainty in test result (Spectrum Analyser) = 2.48dB [3] Effective Radiated Power Uncertainty in test result = 4.71dB [4] Spurious Emissions Uncertainty in test result = 4.75dB [5] Maximum frequency error Uncertainty in test result (Fr…
