2ACGI-TX900MHH900MHz digital handheld microphone

VOLUME/CHANNEL ADJUSTMENT On OFF position, press and hold the button “B” and turn on the transmitter. Press the button “A” to scroll through the channel numbers (01-25). Press the button “B” to adjust the volume level. SAMPLING RATE SWITCH On OFF position, press and hold the button “A” and turn on the transmitter. When there is “HI” icon on the display, it means that the device sampling rate is set at 16KHz; When there is none, it means that it is set at 8KHz. Do it again to switch the sampling rate. ON/OFF Switch Button “A” Button “B” This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Audio Resource Group, Inc. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Audio Resource Group, Inc. FCC ID : 2ACGI-TX900MHH FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Signatory 2015-03-18 Name : Rick Allerdings Company: Audio Resource Group, Inc. Adress : 405 Main Ave W, Suite 4G, West Fargo, ND58078,US Tel. : 701-540-07501 Fax : 701-540-0750 Email : [email protected]

Audio Resource Group, Inc Date: 03/18/2015 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Alpha Product Testing Laboratory Address Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, Shenzhen, China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name 900MHz digital handheld microphone Model Name ARG-TX900M-HH, RAW-TX900M-HH, ARG-TX900M-HH-X, RAW- TX900M-HH-X, ARG-TX900M-HH-XX, RAW-TX900M-HH-XX, ARG- TX900M-HH-XXX, RAW-TX900M-HH-XXX Brand Name ARG FCC ID 2ACGI-TX900MHH . Signatory Name : Rick Allerdings Company: Audio Resource Group, Inc. Adress : 405 Main Ave W, Suite 4G, West Fargo, ND58078,US Tel. : 701-540-07501 Fax : 701-540-0750 Email : [email protected]

20mm 10mm FCC ID: 2ACGI-TX900MHH Audio Resource Group, Inc Model name: 900MHz digital handheld microphone Model No.: ARG-TX900M-HH Label Location

Antenna

FCC ID: 2ACGI-TX900MHH RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: Frequency (GHz) Distance (mm) Power (dBm) Power (mW) Cal. Density (mW/mm) Exclusion Threshold (mW/mm) 0.903 5 10 10.00 1.90 ≤3.0 0.915 5 10 10.00 1.91 ≤3.0 0.927 5 10 10.00 1.93 ≤3.0 Then, as a result, SAR evaluation is not required

Page 1 of 36 Report No.: T1850075 01 TEST REPORT FCC ID: 2ACGI-TX900MHH Applicant : Audio Resource Group, Inc Address : 405 Main Ave W, Suite 4G, West Fargo, ND58078, USA Equipment Under Test (EUT): Name : 900MHz digital handheld microphone Model : ARG-TX900M-HH,RAW-TX900M-HH, ARG-TX900M-HH-X,RAW-TX900M-HH-X, ARG-TX900M-HH-XX,RAW-TX900M-HH-XX, ARG-TX900M-HH-XXX, RAW-TX900M-HH-XXX In Accordance with: FCC PART 15, SUBPART C : 2014 (Section 15.247) Report No : T1850075 01 Date of Test : January 30, 2015 to February 26, 2015 Date of Issue : March 13, 2015 Test Result : PASS In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Alpha Product Testing Laboratory Or test done by Alpha Product Testing Laboratory Approvals in connection with, distribution or use of the product described in this report must be approved by Alpha Product Testing Laboratory Approvals in writing. Page 2 of 36 Report No.: T1850075 01 TABLE OF CONTENT 1 General Information ------------------------------------------------------------------------------------ 3 1.1 Description of Device (EUT) --------------------------------------------------------------------- 3 1.2 Description of Test Facility ----------------------------------------------------------------------- 4 2 EMC Equipment List ------------------------------------------------------------------------------------ 4 3 Test Procedure ------------------------------------------------------------------------------------------- 5 4 Summary of Measurement ---------------------------------------------------------------------------- 6 4.1 Summary of test result ---------------------------------------------------------------------------- 6 4.2 Test connection ------------------------------------------------------------------------------------- 6 4.3 Assistant equipment used for test ---------------------------------------------------------------- 7 4.4 Test mode ------------------------------------------------------------------------------------------- 7 4.5 Test Conditions ------------------------------------------------------------------------------------- 7 4.6 Measurement Uncertainty (95% confidence levels, k=2)------------------------------------- 7 5 Spurious Emission ----------------------------------------------------------------------------------- 8 5.1 Radiation Emission -------------------------------------------------------------------------------- 8 6 POWER LINE CONDUCTED EMISSION ------------------------------------------------------- 15 6.1 Conducted Emission Limits(15.207) ---------------------------------------------------------- 15 6.2 Test Setup ----------------------------------------------------------------------------------------- 15 6.3 Test Procedure ------------------------------------------------------------------------------------ 16 6.4 Test Results --------------------------------------------------------------------------------------- 16 7 Conducted Maximum Output Power ----------------------------------------------------------- 17 7.1 Test limit ------------------------------------------------------------------------------------------ 17 7.2 Test Procedure ------------------------------------------------------------------------------------ 17 7.3 Test Setup ----------------------------------------------------------------------------------------- 17 7.4 Test Results --------------------------------------------------------------------------------------- 17 8 PEAK POWER SPECTRAL DENSITY ---------------------------------------------------------- 18 8.1 Test limit ------------------------------------------------------------------------------------------ 18 8.2 Method of measurement ------------------------------------------------------------------------ 18 8.3 Test Setup ----------------------------------------------------------------------------------------- 18 8.4 Test Results --------------------------------------------------------------------------------------- 18 9 Bandwidth ---------------------------------------------------------------------------------------------- 21 9.1 Test limit ------------------------------------------------------------------------------------------ 21 9.2 Method of measurement ------------------------------------------------------------------------ 21 9.3 Test Setup ----------------------------------------------------------------------------------------- 21 9.4 Test Results --------------------------------------------------------------------------------------- 21 10 Band Edge Check ------------------------------------------------------------------------------------ 24 10.1 Test limit ------------------------------------------------------------------------------------------ 24 10.2 Test Procedure ------------------------------------------------------------------------------------ 24 10.3 Test Setup ----------------------------------------------------------------------------------------- 24 10.4 Test Result ---------------------------------------------------------------------------------------- 24 11 Antenna Requirement ------------------------------------------------------------------------------ 27 11.1 Standard Requirement --------------------------------------------------------------------------- 27 11.2 Antenna Connected Construction -------------------------------------------------------------- 27 11.3 Result ---------------------------------------------------------------------------------------------- 27 12 Photographs of Test Setup ----------------------------------------------------------------------- 28 12.1…
