2ACVFK-15Walkie Talkie

Walkie Talkie User Guide US LAMP LOCK WARNING:CHOKING HAZARD -- Small parts. Not for children under 3 years. Quick Start 1. Insert the battery: Take off the belt clip, use your finger to open the battery cover and insert the batteries, then close the lid. 2. Turn on the device: Hold down the power button for 3 seconds to turn the devices on/off, a BEEP sound will be played to confirm. Both radios must be tuned to the same channel/privacy code to communicate. for example (07, CTCSS 11) can only work with (07, CTCSS 11) , but not (07, DCS 11). 3. Set main channel and privacy code: Press the MENU button once, the main channel flashes, then press the up or down button to set a number, then quickly press the MENU button once again, the CTCSS code flashes, then press the up or down button to set a number, then press the PTT button to confirm your setting. 4. Push to talk(PTT): Press and hold the PTT button until you finish speaking into the microphone, then release the PTT button and wait for your partner to reply. CAUTION Read this operating instruction carefully before using your two way radio, including the part on Product Safety and Important Notice. 1 2 3 4 5 6 7 8 10 9 11 1 2 13 14 15 16 1 2 Backlit LCD Display 7 9 . Antenna . 3. Easy 4. 5. 6. . 8. 10. 11. . Pairing Button NOAA/Scan Button Down Button Microphone Menu/Power Button External Speaker/ Microphone/Charge Jack Speaker Up/LAMP Button Call/Lock Button 12. 13. 14. 15. PTT(Pull to talk) Button Wrist Strap Connection Belt Clip Battery Compartment 16. Battery Door Latch Read this operating instruction carefully before using your two way radio, including the part on Product Safety and Important Notice. CAUTION LAMP LOCK FeaturesFeatures • 22 Channels • 142 Privacy Codes (38 CTCSS codes/104 DCS codes) • Hands-Free Operation (VOX) • Scan Channels,privacy codes • Backlit LCD Display • Call Alert Ten selectable tones • Button Lock • Speaker/Microphone/ Jack • Roger Beep Selectable On/Off • LED Flashlight • Battery/Power Saver • Keystroke Tones • Battery Level Indicator • Low Battery Audible Alert • Auto Squelch • Belt Clip •Easy Pairing Product Features Maximum range may vary and is based on unobstructed line of sight communication- - under ideal conditions. Backlit LCD Display 1.Battery Level Indicator 2.Lock Icon 3.Call Tone Icon 4.Roger Beep Icon 5.Transmit/Receive Icon 6.Scan Icon 7.VOX Icon 8.Hi Low Power Icon/ 9.Key Tone Icon 10.DCS CTCSS Privacy Code Numbers/ 11.Channel Numbers 1 2 3 4 5 6 7 8 9 10 11 Installing Batteries To install or replace batteries: 1. 2. 3. Remove the belt clip by pulling the tab and sliding it up. Pull the battery door lock tab up to release the battery cover. Insert 3 "AA" batteries. Put the battery cover back into place. Snap the lock tab and belt clip back into place. Product Features Channel Frequency(MHz) Channel Frequency(MHz) 1462.562512467.6625 2462.587513467.6875 3462.612514467.7125 4462.637515462.5500 5462.662516462.5750 6462.687517462.6000 7462.712518462.6250 8467.562519462.6500 9467.587520462.6750 10467.612521462.7000 11467.637522462.7250 1.Do not mix old and new batteries 2.Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries. 1 5 4 3 2 LAMP LOCK Turning on Your Radio Press and hold the Menu/Power button until you hear a series of audible tones indicating the radio is on.Your radio is now in Standby mode,ready to receive transmissions. The radio is always in Standby mode except when the PTT, Call or Menu/Power buttons are pressed. Battery Low When battery power is low, the final bar in the Battery Low icon will blink and an audible tone will sound twice before the radio shuts off. Your batteries should be replaced or recharged, if using rechargeable batteries. The radio will display flashing battery icon while charging. Battery Low For charging radios (A/Batteries:Just for batteries and a dpater packaging option) , . . . 1.To charge a single radio simply insert the connector directly into the charge jack located on the bottom of the radio The radio will display flashing battery icon while charging Recommends your radio be turned off while being charged dpater Auto Battery Save If there are no transmissions within 6 seconds,the radio will automatically switch to Battery Save mode and the Power Saver icon will displayed. This will not affect the radio’s ability to receive incoming transmissions. 1. Press and hold the PTT button. 2. With the microphone about two inches (2.5-5 cm) from your mouth, speak in a normal voice. 3. Release thebutton when you are finished talking and listen for a response. You cannot receive incoming calls while pressing thebutton. Both radios must be tuned to the same channel/privacy code to communicate. PTT PTT Communicating with Another Person LAMP LOCK LAMP LOCK LAMP LOCK With the radio on, select any of the 22 channels by pressing Menu and the Up or Down button. Both radios must be tuned to the same channel to communicate. To Select a Channel Release thebutton to receive incoming transmissions. Your radio is always in Standby mode while theor Call buttons are not pressed. PTT PTT Listening for a Response Press the Up orat the standby mode. A double beep sound is used to indicate the minimum and maximum volume levels (01 through 08). Down button To Adjust Volume Channel Number Listening Volume Level LAMP LOCK LAMP LOCK Press and release the Call button. The other person will hear a two second call tone. This tone is used only to establish voice communications.See page 8 on how to select between ten call tone settings. Call Button The Lock function locks the Up, Down, Scan and Menu/Power buttons to prevent accidental operation. To turn the lock on or off: Press and hold the Call/Lock button for two seconds. A double beep sound is used to confirm your lock on or off request. When in Lock mode,the Lock icon will be displayed. – Lock Function Lock Icon LAMP LOCK By scrolling through the MENU function, you will be able to select or turn on p…

Text truncated - open the document above for the full version.

ShenzhenChangTaiWeiElectronicCO.,LTD 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ShenzhenChangTaiWeiElectronicCO.,LTD Address:5/F.,6Block,XinGuIndustrialzone,GuShuVillage,XiXiangTown,BaoAnDistrict, ShenzhenCity,China ProductName:WalkieTalkie FCCID:2ACVFK-15 Model(s):K15 2.911(d)(5)(i)EquipmentType We,[ShenzhenChangTaiWeiElectronicCO.,LTD](“theapplicant”)certifythattheequipment forwhichauthorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:YUYONGJIEDate:2024-08-19 TitleandCompanyname:CEO/ShenzhenChangTaiWeiElectronicCO.,LTD NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenChangTaiWeiElectronicCO.,LTD 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:ShenzhenChangTaiWeiElectronicCO.,LTD Address:5/F.,6Block,XinGuIndustrialzone,GuShuVillage,XiXiangTown,BaoAnDistrict, ShenzhenCity,China ProductName:WalkieTalkie FCCID:2ACVFK-15 Model(s):K15 2.911(d)(5)(ii)Applicantfiling We,[ShenzhenChangTaiWeiElectronicCO.,LTD](“theapplicant”)certifythat,asofthedateof thefilingoftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE 2 ,establishedpursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunications equipment. Yourssincerely, Name:YUYONGJIEDate:2024-08-19 TitleandCompanyname:CEO/ShenzhenChangTaiWeiElectronicCO.,LTD NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenChangTaiWeiElectronicCO.,LTD Address：5/F.,6Block,XinGuIndustrialzone,GuShuVillage,XiXiangTown,BaoAnDistrict, ShenzhenCityChinaFRN:0023749732 Date:2024-08-05 FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2ACVFK-15 (“ShenzhenChangTaiWeiElectronicCO.,LTD”)certifiesthat,asofthedateofthefilingof theapplication,(JOCAustraliaInc)isourdesignatedU.S.agentforserviceofprocessfor the abovereferencedFCCID.(“ShenzhenChangTaiWeiElectronicCO.,LTD”)acceptsto maintainanagentfornolessthanoneyearafterthegranteehasterminatedallmarketing andimportationorthe conclusionofanyCommission-relatedproceedinginvolvingtheequipment. (JOCAustraliaInc)accepts,asofthedateofthefilingoftheapplication,theobligationofthe designatedU.S.agentforserviceofprocessfortheabovereferencedFCCID. DesignatedU.S.AgentInformation: Name:JOCAustraliaInc FRN:0033379421 Address:CASTLETONSTSTE665,CITYOFINDUSTRYCA,CA91748United States ContactPerson:Benjamin.Smith/VicePresident Tel.:+1(626)341-3408 Email:[email protected]/[email protected] Sincerely, ShenzhenChangTaiWeiElectronicCO.,LTDJOCAustraliaInc Name:YONGJIEYUName:Benjamin.Smith Title:CEOTitle:VicePresident Date:2024-08-05Date:2024-07-15

ShenzhenChangTaiWeiElectronicCO., LTD Office of EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 USA Date: 2024-08-19 Subject;Requestfor Long Term Confidentiality FCC ID:2ACVFK-15 To WhomIt May Concern, Pursuantto the provisionsof the Commission’s rules Title 47 Sections§0.457 and §0.459,we are requestingthe Commissionto withholdthe followingattachment(s)as confidential documentsfrom public disclosureindefinitely. Thesedocumentscontaindetailedsystemand equipmentdescriptionsand are consideredas proprietaryinformationin operationof the equipment.The public disclosureof these documents might be harmfulto our companyand would give competitorsan unfair advantagein the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understandingthat all measurementtest reports,FCC ID label formatand correspondenceduringthe certificationreviewprocesscannotbe grantedas confidential documentsand this informationwill be availablefor public reviewonce the grant of equipment authorizationis issued. Sincerely, Signature: Name:YU YONGJIE Title: CEO

ShenzhenChangTaiWeiElectronicCO.,LTD 5/F.,6Block,XinGuIndustrialzone,GuShuVillage,XiXiang Town,BaoAnDistrict,ShenzhenCity,China AgentAuthorization Company:ShenzhenChangTaiWeiElectronicCO.,LTD Address:5/F.,6Block,XinGuIndustrialzone,GuShuVillage,XiXiangTown, BaoAnDistrict,ShenzhenCity,China ProductName:WalkieTalkie ModelNumber(s):K15 ProductDescription:WalkieTalkie WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2024-08-19 Name:YUYONGJIE Title:CEO Company:ShenzhenChangTaiWeiElectronicCO.,LTD

Page 1 of 4 Appendix B: Photographs of EUT Product: Walkie Talkie Model: K15 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: K15 Label: Size: L*W= 28*20mm Walkie Talkie Model:K15 Made In China 3xAA LR6,1.5V FCC ID:2ACVFK-15 Made by Shenzhen ChangTaiWei Electronic CO., LTD Address:G513,Wisdom Valley,YinTian Road, XiXiang,BaoAn,ShenZhen,China Charging Rated Input:5VDC/2A

Page 1 of 4 Appendix B: Photographs of EUT Product: Walkie Talkie Model: K15 Internal Photos Antenna Page 2 of 4 Page 3 of 4 Page 4 of 4

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com SAR TEST REPORT FCC ID. ............................ : 2ACVFK-15 Test Report No. ............... : TCT240726E011 Date of issue ................... : Aug. 16, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ChangTaiWei Electronic CO., LTD Address ........................... : 5/F., 6 Block, XinGu Industrial zone, GuShu Village, XiXiang Town, BaoAn District, Shenzhen City, China Manufacturer's name ... : Shenzhen ChangTaiWei Electronic CO., LTD Address ........................... : 5/F., 6 Block, XinGu Industrial zone, GuShu Village, XiXiang Town, BaoAn District, Shenzhen City, China Product Name ................. : Walkie Talkie Trade Mark ...................... : N/A Model/Type reference..... : K15 SAR Max. Values..............: 0.30 W/Kg (1g) for head;0.45 W/Kg (1g) for Body-worn Date of receipt of test item ......................................... : Jul. 26, 2024 Date (s) of performance of test ................................... : Jul. 26, 2024 ~ Aug. 16, 2024 Tested by (+signature) ... : Karl WANG Check by (+signature) .... : Beryl Zhao Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240726E011 Page 2 of 66 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. General Product Information .................................................................................................. 3 1.1. EUT description .................................................................................................................................................................... 3 1.2. Model(s) list .......................................................................................................................................................................... 3 2. Test standard ........................................................................................................................... 4 3. Facilities and Accreditations .................................................................................................. 4 3.1. Facilities ................................................................................................................................................................................ 4 3.2. Location ................................................................................................................................................................................ 4 4. Test Result Summary .............................................................................................................. 5 5. RF Exposure Limit................................................................................................................... 6 6. SAR Measurement System Configuration ............................................................................. 7 6.1. SAR Measurement Set-up .................................................................................................................................................... 7 6.2. E-field Probe ......................................................................................................................................................................... 8 6.3. Phantom ................................................................................................................................................................................ 8 6.4. Device Holder ....................................................................................................................................................................... 9 6.5. Data Storage and Evaluation ............................................................................................................................................. 10 6.6. Position of the wireless device in relation to the phantom ............................................................................................. 11 6.7. Tissue Dielectric Parameters ............................................................................................................................................. 14 6.8. Tissue-equivalent Liquid Properties ................................................................................................................................. 15 6.9. System Check ..................................................................................................................................................................... 16 7. Measurement Procedure....................................................................................................... 17 8. Conducted Output Power ..................................................................................................... 20 9. Exposure Position Consideration ........................................................................................ 21 9.1. EUT Antenna Location ....................................................................................................................................................... 21 9.2. Test Position Consideration .............................................................................................................................................. 21 10. SAR Test Results Summary ................................................................................................. 22 10.1. Head 1g SAR Dat…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2ACVFK-15 Test Report No. ............... : TCT240726E009 Date of issue ................... : Aug. 16, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ChangTaiWei Electronic CO., LTD Address ........................... : 5/F., 6 Block, XinGu Industrial zone, GuShu Village, XiXiang Town, BaoAn District, Shenzhen City, China Manufacturer's name ... : Shenzhen ChangTaiWei Electronic CO., LTD Address ........................... : 5/F., 6 Block, XinGu Industrial zone, GuShu Village, XiXiang Town, BaoAn District, Shenzhen City, China Standard(s) ..................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part95 Product Name ................. : Walkie Talkie Trade Mark ...................... : N/A Model/Type reference..... : K15 Rating(s).......................... : Adapter Information: Model: SJL608 Input: AC 100-220V, 50/60Hz, 0.3A Max Output: DC 5V, 2.1A Rechargeable NlMH Batteries DC 1.2V*3 Date of receipt of test item ......................................... : Jul. 26, 2024 Date (s) of performance of test ................................... : Jul. 26, 2024 ~ Aug. 16, 2024 Tested by (+signature) ... : Brews XU Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240726E009 Page 2 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 4 2. Test Result Summary .............................................................................. 5 3. General Information ................................................................................. 6 3.1. Test environment and mode ................................................................................. 6 3.2. Description of Support Units ................................................................................ 7 3.3. Configuration of Tested System .......................................................................... 8 3.4. Measurement Results Explanation Example ....................................................... 8 4. Facilities and Accreditations .................................................................. 9 4.1. Facilities ................................................................................................................. 9 4.2. Location ................................................................................................................. 9 4.3. Measurement Uncertainty ..................................................................................... 9 5. Test Results and Measurement Data ................................................... 10 5.1. FRS frequency accuracy ..................................................................................... 10 5.2. FRS transmit power ............................................................................................. 14 5.3. FRS authorized bandwidth ................................................................................. 16 5.4. FRS modulation limits ......................................................................................... 20 5.5. Emission Mask and Radiated Spurious Emission ............................................ 24 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT240726E009 Page 3 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Walkie Talkie Model/Type reference........... : K15 Sample Number....................: TCT240726E009-0101 Operation Frequency ........... : 462.5626MHz - 462.7125MHz (1-7 channel) 467.5626MHz - 467.7125MHz (8-14 channel) 462.5500MHz - 462.7250MHz (15-22 channel) Channel Separation ............. : 12.5KHz Maximum Output Power to Antenna ................. : 31.37dBm 99% Occupied Bandwidth ............................. : 9.77KHz Emission Designator ........... : 10K0F3E Type of Modulation............... : FM Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : -2.97dBi Rating(s)................................ : Adapter Information: Model: SJL608 Input: AC 100-220V, 50/60Hz, 0.3A Max Output: DC 5V, 2.1A Rechargeable NlMH Batteries DC 1.2V*3 Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240726E009 Page 4 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1.3. Operation Frequency Channel: Frequency (KHz) Channel: Frequency (MHz) 1 462.5625 12 467.6625 2 462.5875 13 467.6875 3 462.6125 14 467.7125 4 462.6375 15 462.5500 5 462.6625 16 462.5750 6 462.6875 17 462.6000 7 462.7125 18 462.6250 8 467.5625 19 462.6500 9 467.5875 20 462.6750 10 467.6125 21…

Text truncated - open the document above for the full version.

Page 1 of 1 Appendix A: Photographs of Test Setup Product: Walkie Talkie Model: K15 Radiated Emission
