2ACYESK-MH60TG-A1Point-to-Multipoint wireless V-Band system

MultiHaul™ TG Wireless 60 GHz L2 SDN Mesh for Multi-Gigabit Ethernet Installation, Operation and Maintenance Manual MHTG-I&O-01, Issue A03 February 2021 This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. 2 Trademarks Siklu, the Siklu logo, and MultiHaul™ are all trademarks of Siklu Communication Ltd. All other product names and trademarks mentioned in this document are trademarks or registered trademarks of their respective companies. Copyrights Copyright © 2021 Siklu Communication Ltd. All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without the prior written consent of Siklu. Disclaimers The information contained in this document is subject to change without notice. Siklu assumes no responsibility for any errors that may appear. Siklu makes no warranties, expressed or implied, by operation of law or otherwise, relating to this document, the products or the computer software programs described herein. This document was originally written in English. Please refer to the English language version for a full and accurate description of all products and services described herein. This document is proprietary and confidential. No part of this document may be disclosed in any manner to a third party without prior written consent. © Siklu Communication Ltd 2021 All rights reserved. 3 1. Introduction Contents 1. Introduction ................................................................................................................................................................... 5 1.1 Scope ....................................................................................................................................................................... 5 1.2 Applicable Products and Releases........................................................................................................................... 5 1.3 Audience .................................................................................................................................................................. 5 1.4 Conventions ............................................................................................................................................................. 5 1.5 List of Abbreviations................................................................................................................................................. 6 2. Safety and Regulatory Notices ....................................................................................................................................... 7 2.1 General .................................................................................................................................................................... 7 2.2 FCC Regulatory Statements ...................................................................................................................................... 7 2.3 Canada Regulatory Statements ................................................................................................................................ 7 2.4 EU Regulatory Notes .............................................................................................................................................. 10 3. MultiHaul™ TG Overview ............................................................................................................................................. 11 4. Installing the MultiHaul™ TG Units ............................................................................................................................. 13 4.1 Preparing the Site .................................................................................................................................................. 13 4.1.1 Physical and Environmental Requirements .................................................................................................... 13 4.1.2 Cabling Requirements ..................................................................................................................................... 14 4.1.3 Node Orientation ............................................................................................................................................ 15 4.2 MultiHaul™ TG Package Contents.......................................................................................................................... 15 4.3 Unpacking the MultiHaul™ TG Units ..................................................................................................................... 15 4.4 Required Tools ....................................................................................................................................................... 15 4.5 Mounting and Aligning the MultiHaul™ TG Node on a Pole .................................................................................. 16 4.6 Mounting the MultiHaul™ TG Node on a Wall ...................................................................................................... 22 4.7 Mounting and Aligning the MultiHaul™ TG TU on a Pole or Wall .......................................................................... 23 4.8 Connecting Cables ................................................................................................................................................. 24 4.8.1 Connecting the Cables to the MultiHaul™ TG Node ....................................................................................... 24 4.8.2 Connecting the Cables to the MultiHaul™ TG TU ........................................................................................... 25 4.8.3 Weatherproofing the Cables ...............................................................................................…

Text truncated - open the document above for the full version.

RF_160, Issue 04 (On manufacturer’s company letter heading) Declaration of Authorization We Name: Siklu Communication Ltd. Address: 43 HaSivim street . City: Petach Tikva 49517. Country: Israel . Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. . Address: Harakevet Industrial Zone .. City: Binyamina 30500 .. Country Israel . is authorized to apply for Certification of the following product(s): Product description: Point-to-Multipoint wireless V-Band system Type designation: MH-N366-CCS-PoE-MWB Trademark: MultiHaul . Validity/ expiry date February 08, 2022 on our behalf. Date: February 09, 2021.. City: Petach Tikva .. Name: Baruch Schwarz.. (2) Function: CO-Founder, HW and System Director.... Signature:  . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Siklu Communication Ltd. 43 Hasivim St., 2 nd Floor, Petach Tikva, ISRAEL 49517 Tel: 03-9214015 Fax: 03-9214162 February 08, 2021 To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of a MultiHaul™ Terragraph Point-to-Multipoint wireless V-Band system operating in 57-66GHz, FCC ID: 2ACYESK-MH60TG-A1 Dear Gentlemen, Please find attached our application for certification of a MultiHaul™ Terragraph Point-to-Multipoint wireless V-Band system operating in 57-66GHz, FCC ID: 2ACYESK-MH60TG-A1, prepared in accordance with FCC Rules, parts 2 and 15 section 15.255. The product testing and this application for certification were performed by Hermon Laboratories, which is recognized and accredited by FCC, Test Firm Registration Number is 927748, Designation Number is IL1001. Hermon Labs responsible person is Mr. Michael Nikishin, tel: 011 972 4626 8440, fax:011 972 4628 8277, e-mail: [email protected]. We hope this application satisfies your requirements. Please send an invoice to Hermon Labs. Sincerely, Baruch Schwarz, CO-Founder, HW and System Director Siklu Communication Ltd.

FCC, Request for non-disclosure Date: 19-Oct-10 RF_501, Issue 7 Page 1 of 1 Company Name: Siklu Communication Ltd. Address: 43 HaSivim street City: Petach Tikva 49517 Country: Israel To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2ACYESK-MH60TG-A1 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: The above information may assist competitors in understanding the system archtecture and major components, which may hurt our competitive advantage and help competitors with designing competing products Planned Release Date STC: 180 days from the grant date (notes 2, 3, 4, 5). If no date is given, 45 days from grant date will be used. Date: February 08, 2021 Name and signature of applicant: Baruch Schwarz Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 1 of 4 EXTERNAL PHOTOGRAPHS This document contains 3 photographs Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 2 of 4 Photograph No.1 MH-N366-CCS-PoE-MWB front view Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 3 of 4 Photograph No.2 MH-N366-CCS-PoE-MWB rear side view Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 4 of 4 Photograph No.3 MH-N366-CCS-PoE-MWB side view

Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 1 of 1 LABEL The label is affixed on the side of the radio unit as shown below. The label material is PVC with a permanent adhesive. Label location

Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 9 photographs Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 2 of 8 Photograph No.1 MH-N366-CCS-PoE-MWB RF module top side view Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 3 of 8 Photograph No.2 MH-N366-CCS-PoE-MWB main board top side view Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 4 of 8 Photograph No.3 MH-N366-CCS-PoE-MWB RF module bottom side view Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 5 of 8 Photograph No.4 MH-N366-CCS-PoE-MWB main board bottom side view (Modem module) Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 6 of 8 Photograph No.5 MH-N366-CCS-PoE-MWB GPS module Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 7 of 8 Photograph No.6 MH-N366-CCS-PoE-MWB GPS module second side Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 Page 8 of 8 Photograph No.7 MH-N366-CCS-PoE-MWB case internal view

The MultiHaul™ TG system marks the release of Siklu’s 3rd generation point to multipoint 60GHz products, with Terragraph certification. The solution consists of Nodes operating over millimetre waves in a redundant mesh topology which connect a suite of Terminal Units (TU). The MultiHaul™ TG family of products brings the advantages of mmWave spectrum – multi- gigabit capacity, immunity to interference and massive amounts of available spectrum - to an easy to deploy solution with the addition of L2 SDN mesh, enabled by Siklu’s SmartHaul™ Runner application, for stress-free coverage extension and multi-path reliability. MultiHaul™ TG Node, N366, is the ideal solution for scalable deployments across neighbourhoods and business environments. A Wide Range of Applications  Fixed 5G Wireless Access, Gigabit to the Home, the MDU and the Enterprise  Wi-Fi Hotspot Backhaul  Security / Safe City Networks  Smart City Business Services, Municipal networks  Small Cell Backhaul High Capacity and Flexibility for Dense Deployments The MultiHaul™ TG Nodes operate with 4 independent sectors over the millimetre wave spectrum using narrow beams. This confers several advantages including multi- gigabit capacity in dense deployments. With 4 independent high-gain beam-forming antennas, a multitude of network topologies can be realized to optimize coverage, capacity and performance. Always-On Mission Critical Networks When you can’t afford to lose a video stream, critical safe city sensor data or any other mission critical data, you need a wireless network that’s as reliable and secure as fiber. With maximal immunity to interference and hacker-proof links with embedded AES encryption, MultiHaul™ TG delivers a network you can count on. An additional layer of reliability is available through the L2 self-organizing (SON) capabilities enabled by SmartHaul™ Runner, enabling automatic reorganization and rerouting around site failures. Simple Integrated Future-safe Multi-Functional Node Wireless infrastructure should be simple, and future proof. Organizations want to quickly deploy a single box across the target neighbourhood, knowing that this infrastructure will address the needs of self-backhaul, distribution, local services, redundancy, SLA enforcement, with enough horse power to scale the bandwidth and accommodate new features over the foreseeable future, achieving a long and useful life time. Fiber Quality with Wireless Flexibility Siklu’s millimetre wave radios successfully combine the capacity of fiber with the flexibility, speed of deployment and low TCO of wireless networks. That is what makes them the world’s best-selling millimetre wave radios every year since 2011. They provide rock solid performance, even in very dense networks or under severe weather conditions, in thousands of networks around the globe. Highly Secure and Physically Immune Beams The narrow beamwidth confers several advantages including immunity to interference and network jamming. In contrast to wide-beam wireless systems that need to use multiple strategies to perform in dense areas. Multiple subscribers and services can be connected with complete isolation based on physical port, VLAN ID and/or a Terminal Unit. Ready Set Go The plug and play integrated node is designed for an easy single person installation. The patent-pending scanning antennas automatically aligns with other Nodes or with TUs. For buildings with difficult roof-top access, a single Node is installed on its roof to serve multiple locations. MULTIHAUL™ TG NODE N366 Complete 360-degree coverage in one unit for Terragraph deployments Rev G 1 The main specifications of the MultiHaul™ TG Nodes are outlined in the following table. Topologies Point to Point, Point to Multi-point, Self-Backhaul L2 SDN Mesh. Sector(s) 4x 90° sector, for 360° coverage, Horizontal scanning: 90° per sector, Vertical scanning: 40°. Frequency & Duplexing 57-66GHz, TDD/TDMA. Network synchronization On-board GPS Channels & Width 4x non-overlapping channels, 2160MHz wide, Any sector any of 4 channels, for optimal RF performance. Modulation & Coding 10 levels of adaptive coding and modulation. Radio OTA Rate (over the air) Up to 4,600 Mbps per sector. Aggregate Throughput > 3,800 Mbps per sector, > 16 Gbps per node. System Gain (link budget) 110dB (Node to Node/TU, including antenna gain). Typical Reach (Node to Node/TU) 890ft. / 270m., Detailed performance calculations - see Siklu’s online link budget calculator: lbc.siklu.com. Interfaces 3 ports: 1x RJ-45 10/5/2.5/1GbE with PoE-In, 1x RJ-45 1GbE with PoE-Out (35W), 1x SFP+ 10GbE. Ethernet Features IEEE 802.1d transparent bridging, Provider bridge - VLAN & VLAN stacking. Security AES 128-bits OTA, GUI over HTTPS, CLI over SSH. Management & Provisioning In-band, Out-of-band management, Web GUI (one-pane configuration of local and remote units) & Embedded CLI, NETCONF. Conformance Radio: US FCC 47 CFR Part 15.255; EN 303 722, EMC: US FCC 47 CFR Part 15; EN 301 489, Safety: UL/IEC 62368-1; UL/IEC 60950-22. Terragraph Terragraph certified. Power PoE, 55W no POE-Out, 90W with 35W POE-Out (PoE-In: IEEE 802.3bt or passive; PoE-Out: IEEE 802.3bt) Environmental Operating Temperature: -49° ÷ +131°F (-45° ÷ +55°C); Ingress Protection Rating: IP67. Dimensions 9.4 x 7.3 in. / 236 x 186 mm. (height x diameter). Weight 7.9 lbs. / 3.6 Kg. MULTIHAUL™ TG NODE - N366 60GHz 4-Sector wireless L2 SDN mesh Node Specifications

Siklu Communication Ltd. FCC ID: 2ACYESK-MH60TG-A1 Page 1 of 1 Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 The calculation was done to confirm required safe distance for fixed device. Limit for power density for general population/uncontrolled exposure is 1 mW/cm 2 for 1500 -100000 MHz frequency range: Limit for power density for occupational exposure is 5 mW/cm 2 for 1500 -100000 MHz frequency range. The power density P (mW/cm 2 ) = P T / 4 r 2 , where P T is the maximum equivalent isotropically radiated power (EIRP), measured value is 40.46 dBm. which is equal to 11117 mW. The minimum safe distance “r” for general population/uncontrolled exposure, where RF exposure does not exceed FCC permissible limit, is r = sqrt { PT / (Px4)} = sqrt {11117 / 12.56} = 29.75 cm. The minimum safe distance “r” for occupational exposure, where RF exposure does not exceed FCC permissible limit, is r = sqrt { PT / (Px4)} = sqrt {11117 / 5 x 12.56} = 13.3 cm. The information note about safe distance shall be provided in the User Manual.

Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 92 Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47 CFR part 15 section 15.255 and subpart B; RSS-210 issue 10 Annex J, RSS-Gen issue 5 FOR: Siklu Communication Ltd. MultiHaul™ Terragraph Point-to-Multipoint wireless V-Band system operating in 57-66GHz Model: MH-N366-CCS-PoE-MWB FCC ID: 2ACYESK-MH60TG-A1 IC: 12353A-MH60TGA1 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Page 2 of 92 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Support and test equipment .......................................................................................................................................... 5 6.4 Changes made in the EUT ............................................................................................................................................ 5 6.5 Test configuration .......................................................................................................................................................... 6 6.6 Transmitter characteristics ............................................................................................................................................ 7 7 Transmitter tests............................................................................................................................................................ 8 7.1 Transmitter power test ................................................................................................................................................... 8 7.2 Occupied bandwidth test ............................................................................................................................................. 18 7.3 Field strength of emissions .......................................................................................................................................... 26 7.4 Out of band radiated emissions above 40 GHz up to 200 GHz ................................................................................... 37 7.5 Frequency stability test ................................................................................................................................................ 72 7.6 Conducted emissions .................................................................................................................................................. 75 7.7 Antenna requirements ................................................................................................................................................. 78 8 Emission tests according to 47CFR part 15 subpart B requirements .......................................................................... 79 8.1 Conducted emissions .................................................................................................................................................. 79 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 82 10 APPENDIX B Measurement uncertainties ................................................................................................................... 84 11 APPENDIX C Test laboratory description ................................................................................................................... 85 12 APPENDIX D Specification references ....................................................................................................................... 85 13 APPENDIX E Test equipment correction factors ......................................................................................................... 86 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 92 Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Page 3 of 92 1 Applicant information Client name: Siklu Communication Ltd. Address: 43 Hasivim street, Petach-Tikva 49517, Israel Telephone: +972 3921 4015 Fax: +972 3921 4162 E-mail: [email protected] Contact…

Text truncated - open the document above for the full version.

Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Test specification: FCC Section 15.215(c), RSS-210 section J.4(c), RSS-Gen section 6.7, Occupied bandwidth Test procedure: 47 CFR, Section 2.1049, ANSI C63.10, Section 9.3 Test mode: Compliance Verdict: PASS Date(s): 11-Mar-20 Temperature: 25 ºC Relative Humidity: 43 % Air Pressure: 1015 hPa Power: 48 VDC Remarks: Page 23 of 92 Plot 7.2.7 The 6dBc and 99% occupied bandwidth FREQUENCY: 62.64 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 3 Plot 7.2.8 The 6dBc and 99% occupied bandwidth FREQUENCY: 62.64 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 4 Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Test specification: FCC Section 15.215(c), RSS-210 section J.4(c), RSS-Gen section 6.7, Occupied bandwidth Test procedure: 47 CFR, Section 2.1049, ANSI C63.10, Section 9.3 Test mode: Compliance Verdict: PASS Date(s): 11-Mar-20 Temperature: 25 ºC Relative Humidity: 43 % Air Pressure: 1015 hPa Power: 48 VDC Remarks: Page 24 of 92 Plot 7.2.9 The 6dBc and 99% occupied bandwidth FREQUENCY: 64.80 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 1 Plot 7.2.10 The 6dBc and 99% occupied bandwidth FREQUENCY: 64.80 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 2 Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Test specification: FCC Section 15.215(c), RSS-210 section J.4(c), RSS-Gen section 6.7, Occupied bandwidth Test procedure: 47 CFR, Section 2.1049, ANSI C63.10, Section 9.3 Test mode: Compliance Verdict: PASS Date(s): 11-Mar-20 Temperature: 25 ºC Relative Humidity: 43 % Air Pressure: 1015 hPa Power: 48 VDC Remarks: Page 25 of 92 Plot 7.2.11 The 6dBc and 99% occupied bandwidth FREQUENCY: 64.80 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 3 Plot 7.2.12 The 6dBc and 99% occupied bandwidth FREQUENCY: 64.80 GHz MODULATION: 16QAM ENVELOPE POINT: 6 dBc ENVELOPE POINT: 99% ANTENNA # 4 Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Test specification: FCC Section 15.255(d)(2), RSS-210 section J.3, Out of band radiated emissions below 40 GHz Test procedure: 47 CFR, Section 2.1053; ANSI C63.10, Section 9.13 Test mode: Compliance Verdict: PASS Date(s): 16-Nov-20 Temperature: 23 ºC Relative Humidity: 58 % Air Pressure: 1010 hPa Power: 48 VDC Remarks: Page 26 of 92 7.3 Field strength of emissions 7.3.1 General This test was performed to measure field strength of fundamental and spurious emissions from the EUT. Specification test limits are given in Table 7.3.1. Table 7.3.1 Radiated spurious emissions limits Frequency range, MHz Field strength at 3 m, dB(V/m)* Within restricted bands Peak Quasi Peak Average 0.009 – 0.090 148.5 – 128.5 NA 128.5 – 108.5** 0.090 – 0.110 NA 108.5 – 106.8** NA 0.110 – 0.490 126.8 – 113.8 NA 106.8 – 93.8** 0.490 – 1.705 NA 73.8 – 63.0** NA 1.705 – 30.0* 69.5 30 – 88 40.0 88 – 216 43.5 216 – 960 46.0 960 - 1000 54.0 1000 – 40000 74.0 NA 54.0 *- The limit for 3 m test distance was calculated using the inverse square distance extrapolation factor as follows: Lim S2 = Lim S1 + 40 log (S 1 /S 2 ), where S 1 and S 2 – standard defined and test distance respectively in meters. **- The limit decreases linearly with the logarithm of frequency. Note: The above field strength limits applied from the lowest radio frequency generated in the device, without going below 9 kHz up to the tenth harmonic of the highest fundamental frequency but not exceeding 40 Ghz for intentional radiators operated below 10 GHz and up to the fifth harmonic of the highest fundamental frequency but not exceeding 100 Ghz for intentional radiators operated above 10 GHz. Report ID: SIKRAD_FCC.40852 Date of Issue: 8-Feb-21 Test specification: FCC Section 15.255(d)(2), RSS-210 section J.3, Out of band radiated emissions below 40 GHz Test procedure: 47 CFR, Section 2.1053; ANSI C63.10, Section 9.13 Test mode: Compliance Verdict: PASS Date(s): 16-Nov-20 Temperature: 23 ºC Relative Humidity: 58 % Air Pressure: 1010 hPa Power: 48 VDC Remarks: Page 27 of 92 7.3.2 Test procedure for spurious emission field strength measurements in 9 kHz to 30 MHz band 7.3.2.1 The EUT was set up as shown in Figure 7.2.1, energized and the performance check was conducted. 7.3.2.2 The specified frequency range was investigated with antenna connected to spectrum analyzer/ EMI receiver. To find maximum radiation the turntable was rotated 360 0 and the measuring antenna was rotated around its vertical axis. 7.3.2.3 The worst test results (the lowest margins) were recorded in Table 7.3.3 and shown in the associated plots. 7.3.3 Test procedure for spurious emission field strength measurements above 30 MHz 7.3.3.1 The EUT was set up as shown in Figure 7.2.2, Figure 7.2.3, energized and the performance check was conducted. 7.3.3.2 The specified frequency range was investigated with antenna connected to spectrum analyzer/ EMI receiver. To find maximum radiation the turntable was rotated 360 0 , the measuring an…
