2ACYNA014302Expert Care baby monitor

Instruction Manual 2 Thank you for purchasing our BC-62 baby monitor. Your unit has been manufactured and checked under the strictest possible quality control to ensure that each monitor leaves the factory in perfect condition. If in the unlikely event you find any defects or have any problem, please contact your dealer, our branch or service center. Please read this manual carefully to obtain maximum performance & extend - ed service life from the unit. Features - Full digital technique operating in the 902.000MHz---928.000MHz with zero interference - Automatic search and hop to free channel - Operating range of 800m in open space - Low radiating power (only 8% of normal DECT and 40% of ECO DECT) - Automatic power reduction system further reduce radiation level to half when baby unit and parent unit are close to each other - Night light with adjustable intersity on baby’s unit - Audio and visual alert for out-of-range on parent unit - LED level meter on parent unit - Low battery warning on both baby and parent unit - Adjustable microphone sensitivity on baby unit - Vibration alert on parent unit 3 WARNING The BC-62 baby monitor should not be regarded as a medical device. Premature babies or those considered to be at risk should be under the supervision of your doctor or health personnel. Direct supervision of your baby at a regular interval by a responsible adult is strongly recommended in addition to using the BC-62. DIGITAL TECHNOLOGY AND APRS This baby monitor employs full digital technology with zero interference. The unit can automatically select free channel or hop to free channel during communication to avoid interference from other electronic devices. In addition, thanks to the Automatic Power Reduction System (APRS) which senses the distance between baby and parent unit and automatically reduces the emission power from baby unit when the two units are in close vicinity. The level of radiation to baby is greatly reduced. 4 POWER SUPPY (A) Baby Unit 1. Operation from batteries Pr ess down the lock button and slide open the battery door in direction as shown. Insert three pieces AAA size (UM-4) alkaline batteries into the compart - ment. Observe correct polarities indication. N.B. For best performance, do not mix use old and new batteries or alkaline and rechargeable batteries. 2. Operation using AC adapter The baby unit can be operated on AC mains using the supplied 5V AC adapter. Connect the output plug of AC adapter to USB port 12 of the baby unit, make sure the polarity is correct. The battery will be cut off once the AC adapter’s output plug is inserted into the USB port 12 . 12 2. Charging up the Lithium rechargable battery Connect the output plug of the supplied 5V AC adapter to the USB port 22 of the unit, make sure the polarity is correct. With the parent unit being switched off, the power on icon 1 8 will start flashing red, indicating the battery is being charged. Once the battery is fully charged up (normally it takes around 3 hours), the indicator 18 turns steady green. Now the parent unit can be switched on for operation. Either you can disconnect the AC adaptor or keep connecting will cause no damage to the battery. In the latter case, when the battery is being consumed and voltage falls to a certain level, the AC adapter will automatically start charging up the battery again. 5 (B) Parent unit 1. Operation from battery pack T he Li polymer battery pack is already installed in the unit. To exchange battery pack, press and open the battery cover, remove the belt clip in the direction as shown, take out the battery pack and disconnect from socket. Note : Before using the parent unit for the first time, charge up the Li battery pack for at least three hours. Besure to switch off the unit before charging. Even without the Li battery pack being installed, the unit can still operate normally once connecting to the AC adapter, while the power on icon will always stay steady green. CAUTION : BESURE THE BATTERY IN THE PARENT UNIT IS RECHARGEABLE TYPE BEFORE CONNECTING TO AC ADAPTER, OTHERWISE EXPLOSION MAY RESULT. 22 18 6 CONTROLS LAYOUT 7 8 6 1 11 2 4 18 19 17 13 14 16 15 22 20 21 5 3 12 9 10 BABY UNIT PARENT UNIT 1 2 3 4 5 6 7 8 9 10 11 Power On/Off button Microphone Sensitivity Down adjustment button Microhone Sensitivity Up adjustment button Night Light intensity adjustment button Night Light VOX control button Night Light Power On/Battery low icon Transmit icon Night Light VOX icon Micophone always ON icon Microphone USB port Power On/Off button Volume down button Volume up button Vibration button Visual level meter/Out-of-range icon Power On/Battery Low/Charging icon Vibration icon Speaker mute icon Speaker USB port 12 13 14 15 16 17 18 19 20 21 22 Model:A014302 IC:12292A-A014302 7 PAIRING This process is to match the parent unit with baby unit so that they can communicate with each other while no other devices (even baby monitor of identical model) can interfere with you or receiving your signal. The baby and parent unit are already paired with factory preset code when they are shipped from factory. However, we recommend to perform pairing again in case interference is experienced: 1. First press and hold the button 15 of parent unit. 2. Press the power ON-OFF button 13 and wait until the power on icon 18 starts flashing green. Release both buttons 13 & 15 . 3. Now press and hold the button 11 of baby unit. 4. Press the power ON-OFF button 1 and wait until the power on icon 7 starts flashing green. Release both buttons 1 & 11 . 5. Now short press the power ON-OFF button 1 of baby unit. 6. If pairing is successful, the power on icons 18 & 7 on both baby & parent unit should stop flashing, at the same time, 2 beep sound will be heard from the parent unit. 7. Long press buttons 1 & 13 to switch off both baby and parent units and then switch them on again, the baby monitor is now ready for operation. 8. In case the baby and parent unit cannot communicate with each other, …
