2ADAO-KHWPO400F001Lanyard tag

Kontakt.io Lanyard Tag User Manual Introduction and Maintenance Lanyard Tags constantly broadcast Bluetooth signals for tracking purposes The device is ready to be used in an ‘out of the box’ manner. The device is ready to perform as soon as it is programmed and assembled. In case of possible malfunctioning, users are advised to contact technical support to get assistance and replacement of devices not working and still under warranty. Contact to support: [email protected] Physical characteristics The manufacturer and device name are mentioned on the original box the device arrives in. Size of the device: 42.3 mm x 31 mm; 11mm height Device casing is factory-sealed and cannot be opened. Usage Lanyard Tag is designed to be used as a neck-wearable device for people. Lanyard Tag has a neck-string attached. Features - Technology in device: Bluetooth 5.0 compliant radio WARNING Lanyard Tag contains electronic elements and a battery (CR2032) which should be properly disposed of. If a beacon needs to be utilized, please contact the manufacturer technical support first. FCC Caution This device complies with part 15 of applicable FCC Rules. Its operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure condition without restriction.

Rev 11/20/07 (Kontakt Micro-Location Sp. z o.o.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ADAO-KHWPO400F001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Joanna Wolczanska)

(Kontakt Micro-Location Sp. z o.o.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/09/22 SUBJECT: FCC Application for FCC ID: 2ADAO-KHWPO400F001 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Joanna Wolczanska)

External Photos

Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. FCC ID: 2ADAO-KHWPO400F001 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion GFSK （1M） 2.4802.931.963±14.002.51<50.791143.00YES GFSK （2M） 2.4803.042.013±14.002.51<50.791143.00YES Conclusion: For the max result : 0.79114＜3.0, the SAR testing is not required.

No.：BCTC/RF-EMC-00 5 Page 1 of 47 Edition：A.1 TEST REPORT Report No.: BCTC2009000142E Applicant: Kontakt Micro-Location Sp. z o.o. Product Name: Lanyard tag Product Type: KHWPO400F001 Tested Date: Sep. 02, 2020 Issued Date: Sep. 09, 2020 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2009000142E No.：BCTC/RF-EMC-00 5 Page 2 of 47 Edition：A.1 FCC ID: 2ADAO-KHWPO400F001 Compiled by: Reviewed by: Approved by: Willem Wang Eric Yang Zero Zhou/Manager The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Lanyard tag Trademark: Lanyard tag Product Type: KHWPO400F001 Prepared For: Kontakt Micro-Location Sp. z o.o. Address: ul. Stoczniowcow 3, 30-709 Krakow, Poland Manufacturer: Shenzhen Minew Technologies Co., Ltd Address: 3rd Floor, I Bulding, Gangzhilong Science Park, Qinglong Road, LonghuaDistrict, Shenzhen City, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Sample Received Date: Sep. 02, 2020 Sample tested Date: Sep. 02, 2020 to Sep. 092020 Issue Date: Sep. 09, 2020 Report No.: BCTC2009000142E Test Standards FCC Part15.247 ANSI C63.10-2013 Test Results PASS Remark: This is Bluetooth BLE radio test report. Report No.: BCTC2009000142E No.：BCTC/RF-EMC-00 5 Page 3 of 47 Edition：A.1 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................. 5 2. TEST SUMMARY ...................................................... 6 3. MEASUREMENT UNCERTAINTY........................................ 7 4. PRODUCT INFORMATION AND TEST SETUP ............................ 8 4.1 Product Information ..................................................... 8 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 9 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................. 9 4.6 table of parameters of text software setting ................................ 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................. 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 EUT operating Conditions .............................................. 13 6.5 Test Result ........................................................... 14 7. RADIATED EMISSIONS ............................................... 15 7.1 Block Diagram Of Test Setup ........................................... 15 7.2 Limit ................................................................. 16 7.3 Test procedure ........................................................ 17 7.4 EUT operating Conditions .............................................. 18 7.5 Test Result ........................................................... 19 8. RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION .......................................................... 23 8.1 Block Diagram Of Test Setup ........................................... 23 8.2 Limit ................................................................. 23 8.3 Test procedure ........................................................ 24 8.4 EUT operating Conditions .............................................. 24 8.5 Test Result ........................................................... 25 9. POWER SPECTRAL DENSITY TEST ................................... 26 9.1 Block Diagram Of Test Setup ........................................... 26 9.2 Limit ................................................................. 26 9.3 Test procedure ........................................................ 26 9.4 EUT operating Conditions .............................................. 26 9.5 Test Result ........................................................... 27 10. BANDWIDTH TEST ................................................... 31 10.1 Block Diagram Of Test Setup .......................................... 31 10.2 Limit ................................................................ 31 Report No.: BCTC2009000142E No.：BCTC/RF-EMC-00 5 Page 4 of 47 Edition：A.1 10.3 Test procedure ....................................................... 31 10.4 EUT operating Conditions ............................................. 31 10.5 Test Result .......................................................... 32 11. PEAK OUTPUT POWER TEST ......................................... 36 11.1 Block Diagram Of Test Setup .......................................... 36 11.2 Limit ................................................................ 36 11.3 Test procedure ....................................................... 36 11.4 EUT operating Conditions ............................................. 36 11.5 Test Result .......................................................... 37 12. 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE ................... 38 12.1 Block Diagram Of Test Setup .......................................... 38 12.2 Limit ................................................................ 38 12.3 Test procedure ....................................................... 38 12.4 EUT operating Conditions ............................................. 38 12.5 T…

Text truncated - open the document above for the full version.

Radiated Measurement Photos
