Kontakt.io PUCK Beacon User Manual Introduction and Maintenance PUCK Beacon works constantly and broadcasts Bluetooth signal constantly. Device is ready to be used in an ‘out of the box’ manner. Device is ready to perform since programmed and assembled. In case of possible malfunctioning users are advised to contact technical support to get assistance and replacement of devices not working and still under warranty. Contact to support: [email protected] The manufacturer and device name are mentioned on the original box that device arrives in. Size of the device: Φ50x 20.5mm; 50mm diameter, 20.5mm height Installation PUCK beacon can be installed using any type of adhesives materials. In the box there is installation tape added to the product. For installation on glass surface automotive class glue is required. Features -Technology in device: Bluetooth 5.0 compliant -Accelerometer - three-axis accelerometer MEMS, 1Hz to 5.3kHz ODR WARNING PUCK Beacon contains electronic elements and batteries (2x ER14250) which should be properly disposed. If beacon needs to be utilised, please contact the manufacturer technical support first. FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure condition without restriction
