2ADAT-TCAS4TCAS4 Torquemeter

HBM: Business Document Mounting instructions Special torque transducer TCAS4 / MPZ2001066B HBM: Business Document Directory 1 Safety Instructions ........................................................................................................................................ 3 2 Markings used ............................................................................................................................................... 1 2.1 Symbols on the transducer .................................................................................................................. 1 2.2 The markings used in this document ................................................................................................. 2 3 Application...................................................................................................................................................... 2 4 Structure and mode of operation ................................................................................................................ 3 5 Mechanical installation ................................................................................................................................. 5 5.1 Important precautions during installation .......................................................................................... 5 5.2 Conditions on site ................................................................................................................................. 6 5.3 Installation orientation .......................................................................................................................... 6 5.4 Installation options ................................................................................................................................ 6 5.4.2 Installation with subsequent stator mounting ........................................................................ 8 5.5 Mounting the rotor ................................................................................................................................. 9 5.6 Installing the stator .............................................................................................................................. 12 6 General information .................................................................................................................................... 15 6.2 EMC protection.................................................................................................................................... 15 6.3 Evaluation unit ..................................................................................................................................... 17 6.4 Supply voltage ................................................................................................................................... 20 6.5 Use of EMI suppressor ...................................................................................................................... 21 7 Shunt signal ................................................................................................................................................. 23 8 Functionality testing .................................................................................................................................... 24 9 Maintenance ................................................................................................................................................ 25 10 Dimensions of the rotor and stator antenna ........................................................................................... 26 11 Specifications .............................................................................................................................................. 27 12 Declaration of conformity ........................................................................................................................... 28 HBM: Business Document 1 Safety Instructions FCC Compliance & Advisory Statement Important Any changes or modification not expressly approved in writing by the party responsible for compliance could void the user’s authority to operate the device. Where specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The FCC identifier or the unique identifier, as appropriate, must be displayed on the device. Model Measuring range FCC ID TCA 3,5 kN·m 2ADAT-TCAS4 Label example with FCC ID. Fig 1.1: Location of the label on the stator of the device HBM: Business Document Model: TCAS4 FCC ID: 2ADAT-TCAS4 IC: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Fig. 1.2 Example of the label Appropriate use The torque transducer is used exclusively for torque, angle of rotation and power measurement tasks within the load limits stipulated in the specifications. Any other use is not the designated use. Stator operation is only permitted when the rotor and stator antenna are coupled. The torque flange may only be installed by qualified personnel in compliance with the specifications and with the safety requirements and regulations of these mounting instructions. It is also essential to observe the applicable legal and safety regulations for the application concerned. The same applies to the use of accessories. The torque flange is not intended for use as a safety component. Please also refer to the se…

Text truncated - open the document above for the full version.

040197.1C-fc_2020-11-03_GEN.docx FO160_Letter_de_141 1/1 EMCCons DR. RAŠEK GmbH & Co. KG Certification Department Stoernhofer Berg 15 · 91364 Unterleinleiter · Germany Certification Department Register AG Bamberg HRA 10957 Boelwiese 8, 91320 Ebermannstadt, Germany Part of EMCCons DR. RAŠEK GmbH & Co. KG Register AG Bamberg HRB 5336 T: +49 9194 7273-888 Geschaeftsfuehrer/Managing Directors: Nathalia A. M. Rašek-Abach, F: +49 9194 7273-889 Dr.-Ing. Andreas Abach E: [email protected], www.emcc.de UST ID/VAT ID: DE 260 532 877 D-U-N-S: # 340880233 Oberbank AG Nuremberg, Germany, EUR BIC: OBKLDEMX IBAN: DE77 7012 0700 1081 1606 89 Volksbank Forchheim, Germany, EUR BIC: GENODEF1FOH IBAN: DE22 7639 1000 0000 1246 99 Raiffeisen-Volksbank Erlangen, Germany, EUR BIC: GENODEF1ER1 IBAN: DE75 7636 0033 0002 6207 31 UniCredit Bank AG Erlangen, Germany, EUR BIC: HYVEDEMM417 IBAN: DE20 7632 0072 1040 2931 39 UniCredit Bank AG Erlangen, Germany, USD BIC: HYVEDEMM417 IBAN: DE49 7632 0072 0021 2508 72 ZERTIFIZIERUNGSSTELLE/ CERTIFICATION DEPARTMENT SACHVERSTÄNDIGENBÜRO/ TECHNICAL EXPERTS BENANNTE STELLE/NOTIFIED BODY 2014/30/EU (EMC Directive) BRD: BNetzA-bS-07/61-02, EU # 0678 BENANNTE STELLE/NOTIFIED BODY 2014/53/EU (RE Directive) BRD: BNetzA-bS-02/51-54, EU # 0678 USA: FCC Conformity Assessment Body BNetzA-CAB-02/21-101 CANADA: IC Conformity Assessment Body BNetzA-CAB-03/22-52 JAPAN: Registered Foreign Conformity Assessment Body BNetzA-CAB-07/25-53 Federal Communications Commission 7435 Oakland Mills Rd Columbia, MD 21046 USA Ihr Ansprechpartner/Your Contact: Guenther Proelss T: +49 9194 7263-814 F: +49 9194 7263-889 E: [email protected] Ihre Kontaktdaten/Your Details T: - F: - E: - Ihr Zeichen/Your Reference Unser Zeichen/Our Reference Datum/Date T: +49 9194 7263-888 | F: -889 FCC ID: 2ADAT-TCAS4 Pg/aw-040197.1C/fc 2020-11-03 E: [email protected] | www.emcc.de Subject: TCB justification for Post Market Surveillance according to KDB 610077 D01 FCC ID: 2ADAT-TCAS4 Dear Madam/Sir This letter is the justification to not keep a production sample on hand is acceptable for FCC ID: 2ADAT-TCAS4. The company Hottinger Baldwin Messtechnik GmbH showed satisfactorily the production run of its Torque Transducer is very limited in quantity. Therefore we determine they may not be required to maintain a sample on hand as specified in “KDB 610077 D01 TCB Post Market Surveillance v06r01” from June 26, 2015. If you have any queries, please do not hesitate to contact EMCCons DR. RAŠEK GmbH & Co. KG. Sincerely, Günther Prölß

Managing Director: Andreas Hüllhorst – Chairman of the Board: Eoghan O’Lionaird Registered at Darmstadt HRB 1147 HBM: public External Pictures TCAS4 FCC ID: 2ADAT-TCAS4 IC: Rotor – side A including rotor antenna Rotor – side B Managing Director: Andreas Hüllhorst – Chairman of the Board: Eoghan O’Lionaird Registered at Darmstadt HRB 1147 HBM: public Stator

Managing Director: Andreas Hüllhorst – Chairman of the Board: Eoghan O’Lionaird Registered at Darmstadt HRB 1147 HBM: public LABEL FCC ID: 2ADAT-TCAS4 IC: Position: - on the Stator unit of the System Managing Director: Andreas Hüllhorst – Chairman of the Board: Eoghan O’Lionaird Registered at Darmstadt HRB 1147 HBM: public Schriftgröße/n - Font size/s FCC ID bzw. CI Code min. 8 Punkte [*pt] = ~2,8 mm Stellungnahme - Statement Text min. 5 Punkte [*pt] = ~1,8 mm *DTO-Punkte / 1 pt = 0,35 27 mm Abmessungen – Dimension [mm] B = 45.0 +2 H = 23.0 +2 R = 1.0 ±0,2 Material: self-adhesive polyester security film, 60 μm Color: silver, matt coated Adhesive: Permanent adhesive Temperature range: -40 ° C to +150 ° C Characteristics: weather resistant, sea water, resistant to many solvents, weak acids and alkalis 8 5

Managing Director: Andreas Hüllhorst – Chairman of the Board: Eoghan O’Lionaird Registered at Darmstadt HRB 1147 HBM: public Internal Pictures TCAS4 FCC ID: 2ADAT-TCAS4 IC: Rotor

EMtrE. trR. RAÉEK PAGEl OF 28 TEST REPORT # EMCC -O40L97 .LC, 2020-11-03 EQUIPMENT UNDERTEST: Trade Name: Type: Serial Number(s): Equipment Class: FCC ID: Manufacturer: Address: TCAS4 / MPZ2OOIO66B MP220010668 2435400L2 Low Power Transceiver 2ADAT-TCAS4 Hottinger Baldwin Messtechnik GmbH lm Tiefen See 45 64293 Darmstadt GERMANY Janis Butz +49 675L 803-8483 [email protected] 47 CFR S 15.203, 5 15.207, $ 15.209 Approved: Name: Phone: E-Mail: RELEVANT STANDARD(S) : MEASUREMENTPROCEDURE:: ANSlC63.L0-2013 TEST REPORT PREPARED BY: Wolfgang Kiss EMCCons DR. RASEK GmbH & Co. KG Boelwiese 8 9L320 Ebermannstadt Germany Phone: +49 9194 7 262-332 Fax: +4991947262-199 E-Mai l: [email protected] Tested (- P !r*L Wolfgang Kiss Reinhard Sauerschell EMCCons On. nnSef GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany ( DAKKS Telephone: +4991,947262-0 Telefax: +499L947262-199 Mail: [email protected] Web: http://www.emcc.de Deutsche Akkred¡tierun8sstelle 040197.7C D-PL-12067-01-04 Test Report # EMCC-040197.1C Page 2 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C CONTENTS PAGE 0 REVISION HISTORY 3 1 GENERAL INFORMATION 4 Purpose 4 1.1 Limits and Reservations 4 1.2 Test Laboratory 4 1.3 Customer 4 1.4 Manufacturer 4 1.5 Dates and Test Location 5 1.6 Ordering Information 5 1.7 Climatic Conditions 5 1.8 2 PRODUCT DESCRIPTION 6 Equipment Under Test (EUT) 6 2.1 Intended Use 7 2.2 EUT Peripherals/Simulators 7 2.3 Mode of operation during testing and test setup 7 2.4 Modifications required for compliance 7 2.5 3 TEST RESULTS SUMMARY 8 4 DETAILED TEST RESULTS 9 Antenna Requirement 9 4.1 AC Power Line Conducted Emissions 10 4.2 Radiated Emissions 14 4.3 5 TEST INSTRUMENTS 26 6 MEASUREMENT UNCERTAINTY 27 7 LIST OF ANNEXES 28 Test Report # EMCC-040197.1C Page 3 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C 0 REVISION HISTORY Project number Issue date Chapter Description 040197.1C 2020-11-03 n.a. Initial issue Test Report # EMCC-040197.1C Page 4 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C 1 GENERAL INFORMATION Purpose 1.1 The purpose of this report is to show compliance with the 47 CFR § 15.203, § 15.207, § 15.209 requirements applicable to intentional radiators. Limits and Reservations 1.2 The test results in this report apply only to the particular equipment under test (EUT) as declared in this report. This test report shall not be reproduced except in full without the written permission of EMCCons DR. RAŠEK GmbH & Co. KG. Test Laboratory 1.3 Test Laboratory: EMCCons DR. RAŠEK GmbH & Co. KG Accreditation No.: D-PL-12067-01-04 FCC Test Firm Registration No.: 368753 Address of Labs I, II, III EMCCons DR. RAŠEK GmbH & Co. KG and Head Office: Boelwiese 8 91320 Ebermannstadt GERMANY Address of Labs IV and V: EMCCons DR. RAŠEK GmbH & Co. KG Stoernhofer Berg 15 91364 Unterleinleiter GERMANY Phone: +49 9194 7262-0 Fax: +49 9194 7262-199 E-Mail: [email protected] Web: www.emcc.de Customer 1.4 Company Name: Hottinger Baldwin Messtechnik GmbH Street: Im Tiefen See 45 City: 64293 Darmstadt Country: GERMANY Name: Mr Janis Butz Phone: +49 6151 803-8483 Fax: +49 6151 803-98483 E-Mail: [email protected] Manufacturer 1.5 Company Name: Hottinger Baldwin Messtechnik GmbH Street: Im Tiefen See 45 City: 64293 Darmstadt Country: GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] Test Report # EMCC-040197.1C Page 5 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Dates and Test Location 1.6 Date of receipt of EUT: 2020-09-24 Test Date: CW 40/2020 Test Location: Lab IV Ordering Information 1.7 Purchase Order: D29-4500736805/2000 Date: 2020-07-24 Vendor-Number: 806266 Climatic Conditions 1.8 Date Temperature Relative Humidity Air Pressure Lab Customer attended tests -- °C % hPa -- -- 2020-09-29 21 43 976 IV No 2020-09-30 22 49 976 IV No 2020-10-01 22 47 965 IV No Test Report # EMCC-040197.1C Page 6 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C 2 PRODUCT DESCRIPTION Equipment Under Test (EUT) 2.1 The following data is based on customer’s information. Manufacturer: Hottinger Baldwin Messtechnik GmbH Trade Name: TCAS4 / MPZ2001066B Type: MPZ2001066B Serial No(s): 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Nominal Transmit Frequency: 15.7 kHz; 10.7 MHz Modulation: 15.7 kHz unmodulated, 10.7 MHz FM Power Supply: 24 VDC Ports: Signal and supply – 4 pole Lemo (Type EHG 1B) connector Antenna: Fixed magnetic antenna and integrated loop antenna (axis in horizontal direction) No of variants: None Equipment category: Table top equipment Remarks: None Test Report # EMCC-040197.1C Page 7 of 28 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Intended Use 2.2 The following information was delivered by the customer. The EUT is a complete measuring system to measure torque on a rotating shaft. The standard use is inside a test stand. EUT Peripherals/Simulators 2.3 The EUT was tested connected with - Power supply TRIO-PS/1AC/24DC/5 (Phoenix Contact) - Axon System Control Unit J1 CS10M - Axon Stator Unit J1 Mode of operation during testing and test setup 2.4 The equipment under test (EUT) was operated during the tests under the following conditions: Normal operation: The rotor of the EUT was fixed and there was no torque applied to the EUT. The EUT axis was in horizontal direction and connected to the Axon System Control Unit J1 CS1…

Text truncated - open the document above for the full version.

PAGE 1 OF 3 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 040197.1C Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 1 TO TEST REPORT # EMCC-040197.1C, 2020-11-03 PHOTOGRAPHS OF TEST SETUP EQUIPMENT UNDER TEST: Trade Name: TCAS4 / MPZ2001066B Type, Serial Number(s): MPZ2001066B, 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Manufacturer: Hottinger Baldwin Messtechnik GmbH Address: Im Tiefen See 45 64293 Darmstadt GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR § 15.203, § 15.207, § 15.209 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 1 Photograph A1-1: Conducted emissions 2 Photograph A1-2: Radiated emissions 9 kHz – 30 MHz at 3 m distance at SAC 2 Photograph A1-3: Radiated emissions 30 - 150 MHz at 3 m distance 3 Annex 1 to Test Report # EMCC-040197.1C Page 2 of 3 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A1-1: Conducted emissions Photograph A1-2: Radiated emissions 9 kHz – 30 MHz at 3 m distance at SAC Annex 1 to Test Report # EMCC-040197.1C Page 3 of 3 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A1-3: Radiated emissions 30 - 150 MHz at 3 m distance

PAGE 1 OF 4 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 040197.1C Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 2 TO TEST REPORT # EMCC-040197.1C, 2020-11-03 EXTERNAL PHOTOGRAPHS OF EQUIPMENT UNDER TEST EQUIPMENT UNDER TEST: Trade Name: TCAS4 / MPZ2001066B Type, Serial Number(s): MPZ2001066B, 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Manufacturer: Hottinger Baldwin Messtechnik GmbH Address: Im Tiefen See 45 64293 Darmstadt GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR § 15.203, § 15.207, § 15.209 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 2 Photograph A2-1: EUT on wooden support connected to stator unit 2 Photograph A2-2: Detail on stator and rotor 2 Photograph A2-3: EUT with stator unit connected with connection cable and ferrite with 3 turns 3 Photograph A2-4: Stator unit, type JX-SR70T 4 Photograph A2-5: Label of stator unit, type JX-SR70T 4 Annex 2 to Test Report # EMCC-040197.1C Page 2 of 4 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A2-1: EUT on wooden support connected to stator unit Photograph A2-2: Detail on stator and rotor Annex 2 to Test Report # EMCC-040197.1C Page 3 of 4 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A2-3: EUT with stator unit connected with connection cable and ferrite with 3 turns Annex 2 to Test Report # EMCC-040197.1C Page 4 of 4 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A2-4: Stator unit, type JX-SR70T Photograph A2-5: Label of stator unit, type JX-SR70T

PAGE 1 OF 5 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 040197.1C Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 3 TO TEST REPORT # EMCC-040197.1C, 2020-11-03 PHOTOGRAPHS OF ANCILLARY EQUIPMENT EQUIPMENT UNDER TEST: Trade Name: TCAS4 / MPZ2001066B Type, Serial Number(s): MPZ2001066B, 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Manufacturer: Hottinger Baldwin Messtechnik GmbH Address: Im Tiefen See 45 64293 Darmstadt GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR § 15.203, § 15.207, § 15.209 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 3 Photograph A3-1: Axon control unit J1 CS 10M, view 1 2 Photograph A3-2: Axon control unit J1 CS 10M, view 2 2 Photograph A3-3: Axon control unit J1 CS 10M, serial number 41105 3 Photograph A3-4: Connection cable Axon control unit to stator unit with ferrites 3 Photograph A3-5: Detail on ferrite Würth 742 711 31 at connector to the Axon control unit 4 Photograph A3-6: Detail on ferrite VITROPERM 500F, Type T60006-L2063-W517 4 Photograph A3-7: Power supply TRIO-PS/1AC/24DC/5 5 Photograph A3-8: Power supply TRIO-PS/1AC/24DC/5, front view 5 Annex 3 to Test Report # EMCC-040197.1C Page 2 of 5 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A3-1: Axon control unit J1 CS 10M, view 1 Photograph A3-2: Axon control unit J1 CS 10M, view 2 Annex 3 to Test Report # EMCC-040197.1C Page 3 of 5 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A3-3: Axon control unit J1 CS 10M, serial number 41105 Photograph A3-4: Connection cable Axon control unit to stator unit with ferrites Annex 3 to Test Report # EMCC-040197.1C Page 4 of 5 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A3-5: Detail on ferrite Würth 742 711 31 at connector to the Axon control unit Photograph A3-6: Detail on ferrite VITROPERM 500F, Type T60006-L2063-W517 Annex 3 to Test Report # EMCC-040197.1C Page 5 of 5 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A3-7: Power supply TRIO-PS/1AC/24DC/5 Photograph A3-8: Power supply TRIO-PS/1AC/24DC/5, front view

PAGE 1 OF 7 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 040197.1C Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 4 TO TEST REPORT # EMCC-040197.1C, 2020-11-03 OPERATIONAL DESCRIPTION FOR MODIFICATION OF THE CURRENT CONSUMPTION EQUIPMENT UNDER TEST: Trade Name: TCAS4 / MPZ2001066B Type, Serial Number(s): MPZ2001066B, 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Manufacturer: Hottinger Baldwin Messtechnik GmbH Address: Im Tiefen See 45 64293 Darmstadt GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR § 15.203, § 15.207, § 15.209 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 DOCUMENTATION LIST ANNEX 4 Document A4-1: Power control of the power oscillator J1-CSXXM 2 Document A4-2: Description how to reduce the power of the power oscillator J1-CSXXM 7 Annex 4 to Test Report # EMCC-040197.1C Page 2 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Document A4-1: Power control of the power oscillator J1-CSXXM Annex 4 to Test Report # EMCC-040197.1C Page 3 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Annex 4 to Test Report # EMCC-040197.1C Page 4 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Annex 4 to Test Report # EMCC-040197.1C Page 5 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Annex 4 to Test Report # EMCC-040197.1C Page 6 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Annex 4 to Test Report # EMCC-040197.1C Page 7 of 7 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Document A4-2: Description how to reduce the power of the power oscillator J1-CSXXM The following description was delivered by the customer. 1. Evaluation Unit gemäß der Ihnen vorliegenden Anleitung aufschrauben 2. Das Potentiometer im Uhrzeigersinn entsprechend verdrehen bis sich am Netzteil bei 24V DC Versorgung eine Stromaufnahme von 0,6A einstellt. Momentan sollten hier 0,76A anliegen. 3. Kontrolle an der Evaluation unit, ob beide linken LEDs leuchten. 4. Wenn ja, bitte das Shuntsignal (rechter Kippschalter) auslösen. Anschließend sollte sich die Volt Anzeige auf der Evaluation Unit auf ca. 5,1V einstellen. Ist dies der Fall, funktioniert die Telemetrie noch ordnungsgemäß. Andernfalls müsste man die Stromstärke wieder erhöhen. 5. Bitte erneut ihre Testmessung durchführen.

PAGE 1 OF 3 EMCCons DR. RAŠEK GmbH & Co. KG Boelwiese 8 91320 Ebermannstadt Germany 040197.1C Telephone: +49 9194 7262-0 Telefax: +49 9194 7262-199 Mail: [email protected] Web: http://www.emcc.de ANNEX 1 TO TEST REPORT # EMCC-040197.1C, 2020-11-03 PHOTOGRAPHS OF TEST SETUP EQUIPMENT UNDER TEST: Trade Name: TCAS4 / MPZ2001066B Type, Serial Number(s): MPZ2001066B, 243540012 Application: Low Power Transceiver FCC ID: 2ADAT-TCAS4 Manufacturer: Hottinger Baldwin Messtechnik GmbH Address: Im Tiefen See 45 64293 Darmstadt GERMANY Phone: +49 6151 803-8483 E-Mail: [email protected] RELEVANT STANDARD(S) : 47 CFR § 15.203, § 15.207, § 15.209 MEASUREMENT PROCEDURE: : ANSI C63.10-2013 ILLUSTRATION LIST ANNEX 1 Photograph A1-1: Conducted emissions 2 Photograph A1-2: Radiated emissions 9 kHz – 30 MHz at 3 m distance at SAC 2 Photograph A1-3: Radiated emissions 30 - 150 MHz at 3 m distance 3 Annex 1 to Test Report # EMCC-040197.1C Page 2 of 3 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A1-1: Conducted emissions Photograph A1-2: Radiated emissions 9 kHz – 30 MHz at 3 m distance at SAC Annex 1 to Test Report # EMCC-040197.1C Page 3 of 3 Issue Date: 2020-11-03 Test on Hottinger Baldwin Messtechnik GmbH MPZ2001066B to 47 CFR § 15.203, § 15.207, § 15.209 © EMCCons DR. RAŠEK GmbH & Co. KG 040197.1C Photograph A1-3: Radiated emissions 30 - 150 MHz at 3 m distance
