ATAN0219 ATAK51005-V1 User's Guide Introduction This user’s guide provides setup and usage instructions for the Car Access Reference System (CARS) featuring Remote Keyless Entry (RKE), Passive Entry/Passive Start (PEPS) and vehicle Immobilization (IMMO) functionality, based on the Microchip’s GEN2 communication protocols. It offers a complete car access system for various car access products and its evaluation. The reference designs are both scalable and configurable through either the PC application or source code modifications, enabling adaptation of the basic hardware and software building blocks to meet the most recent requirements for specialized systems. Features • Full Car Access System Capability: – Vehicle IMMO – Multichannel RF RKE – LF PEPS • Open System Software: – Open Immobilizer Protocol (AOIP) immobilizer stack using AES-128 – RKE RF rolling code using AES-128 – PEPS protocol with a high-precision 3D localization using AES-128 – Scalable and configurable – PC Graphical User Interface (GUI) for system visualization and viewing data communication • Body Computer Emulation using the SAMC21J18A XplainedPro (XPRO) Evaluation Board MICROCHIP CONFIDENTIAL FOR RELEASE ONLY UNDER NON-DISCLOSURE AGREEMENT (NDA) © 2020 Microchip Technology Inc. User Guide DS50003051A-page 1 Table of Contents Introduction.....................................................................................................................................................1 Features ........................................................................................................................................................ 1 1.Quick References....................................................................................................................................4 1.1.Reference Documentation............................................................................................................4 1.2.Hardware Prerequisites................................................................................................................4 2.Kit Overview............................................................................................................................................5 2.1.Immobilizer Block......................................................................................................................... 5 2.2.RKE Block....................................................................................................................................5 2.3.PEPS Block..................................................................................................................................6 3.Kit Setup..................................................................................................................................................7 4.CARS Kit PC Evaluation Utility............................................................................................................... 9 4.1.Programming Kit Software........................................................................................................... 9 4.2.Determining the ATSAMC21-XPRO Virtual COM Port Number...................................................9 4.3.COM Port and Baud Rate Settings............................................................................................ 10 4.4.Initial Configuration of the CARS Kit PC Evaluation Utility ........................................................10 5.System Operation................................................................................................................................. 13 5.1.Immobilizer Operation................................................................................................................13 5.2.Remote Keyless Entry Operation...............................................................................................14 5.2.1.RKE Operation.............................................................................................................14 5.3.PEPS Operation.........................................................................................................................15 5.3.1.System Configuration Window Overview.....................................................................15 5.3.2.PEPS Message Status Window Overview...................................................................17 5.3.3.Identifying FOBS within LF Range...............................................................................19 5.3.4.Fob Calibration Overview............................................................................................ 19 5.3.5.Fob Calibration Process ............................................................................................. 20 5.3.6.PEPS Wake-up Functionality.......................................................................................29 5.3.7.PEPS Communication.................................................................................................30 6.Programming Instructions..................................................................................................................... 33 6.1.Programming the ATA5702 on the ATAB5702A Fob Board....................................................... 33 6.2.Programming the ATA5831 on the ATA5831-XPRO Board........................................................35 6.3.Programming the SAMC21J18A on the ATSAMC21-XPRO Board........................................... 37 7.XPRO USB Driver Installation...............................................................................................................40 8.Document Revision History...................................................................................................................41 The Microchip Website.................................................................................................................................42 Product Change Notification Service................................…

Text truncated - open the document above for the full version.

Preliminary 1 Revision 0.1 (07/2021) EV73R53A Regulatory Compliance Information Revision 0.1 Jul’ 2021 Preliminary 2 Revision 0.1 (07/2021) This document contains the Regulatory Compliance information which will be part of the EV73R53A (ATA5291-XPRO) datasheet and related documents shared with customers. Preliminary 3 Revision 0.1 (07/2021) 1.0 Usage Instructions This equipment (EV73R53A/ATA5291-XPRO) is an evaluation board of the ATAK51005-V1 kit. It is not directly marketed or sold to the general public through retail; it is only sold through authorized distributors or through Microchip. Using this equipment requires a significant engineering expertise towards understanding of the tools and relevant technology, which can be expected only from a person who is professionally trained in the technology. The user must comply with all the instructions provided by the Grantee, which indicate installation and/or operating conditions necessary for compliance. 2.0 Antenna Considerations The following table provides details about the approved antenna. Part Number Manufacturer Antenna type ATAB-LFTX-V4.0 Microchip Ferrite rod 3.0 Regulatory Approval This equipment has received regulatory approval for the following countries:  United States/FCC ID: 2ADHK73R53  Canada/ISED: o IC ID: 20266-73R53 o HVIN: EV73R53A  European Union/CE 3.1.0 United States This equipment has been approved for use in the United States under Federal Communications Commission (FCC) CFR47 Telecommunications, Part 15 Subpart C “Intentional Radiators”. 3.1.1 Labeling and User Information The FCC ID label has been permanently affixed to equipment on the top silkscreen layer of the board and is visible, as well as, legible to the user. Due to the size of the equipment, the following compliance statements are included in the user manual: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Any changes or modifications to this equipment not expressively approved by the Grantee could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver. Preliminary 4 Revision 0.1 (07/2021)  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Additional information on labeling and user information requirements for Part 15 devices can be found in KDB Publication 784748, which is available at the FCC Office of Engineering and Technology (OET) Laboratory Division Knowledge Database (KDB) https://apps.fcc.gov/oetcf/kdb/index.cfm. 3.1.2 Approved Antenna Types To maintain compliance in the United States, only the antenna type that has been tested shall be used. Testing of this equipment was performed with the antenna type listed in the Antenna Considerations section above. 3.1.3 Helpful Websites  Federal Communications Commission (FCC): https://www.fcc.gov/  FCC Office of Engineering and Technology (OET) Laboratory Division Knowledge Database (KDB): https://apps.fcc.gov/oetcf/kdb/index.cfm. 3.2.0 Canada This equipment has been approved for use in Canada under Innovation, Science and Economic Development Canada (ISED, formerly Industry Canada) Radio Standards Specification (RSS) RSS- 210. 3.2.1 Labeling and User Information The ISED ID label has been permanently affixed to the equipment on the top silkscreen layer of the board and is visible, as well as, legible to the user. Due to the size of the equipment, the following compliance statement is included in the user manual: This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference; 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. 3.2.2 Approved Antenna Types To maintain compliance in Canada, only the antenna type that has been tested shall be used. Testing of this equipment was performed with the antenna type listed in the Antenna Considerations section above. 3.2.3 Helpful Websites  Industry Canada: Preliminary 5 Revision 0.1 (07/2021) http://www.ic.gc.ca/ 3.3.0 European Union This equipment has been assessed for use in European Union (EU) countries under the Radio Equipment Directive (RED) 2014/53/EU, European Telecommunications S…

Text truncated - open the document above for the full version.

Microchip Technology Incorporated 2355 West Chandler Blvd. Chandler, AZ 85224-6199 Main Office 480-792-7200 Fax 480-899-9210 Authority to Act as Agent D ate: 26 May 2020 TUV Rheinland Group 762 Park Avenue Youngsville, NC 27596 To Whom It May Concern: I appoint TÜV Rheinland Taiwan Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with Microchip Technology Inc. / 2355 West Chandler Blvd., Chandler, AZ 85224-6199, USA F or TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: Permanent By : Steve Caldwell (Signature) (Print Name) Title : Vice President Telephone : 480-792-7464 On behalf of : Microchip Technology Inc. (Company Name)

Microchip Technology Incorporated 2355 West Chandler Blvd. Chandler, AZ 85224-6199 Main Office 480-792-7200 Fax 480-899-9210 Date: 2021-03-03 Subject: Confidentiality Request for FCC ID: 2ADHK73R53 and IC: 20266-73R53 ; Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent User’s Manual Microchip Technology Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: Steve Caldwell, Vice President, WSG (Print name/Title) Confidentiality Letter

Appendix EP Photo Documentation Page 1 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Appendix EP Photo Documentation Page 2 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Appendix EP Photo Documentation Page 3 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A

Preliminary 1 Revision 0.1 (06/2021) EV73R53A Label and Label Location Revision 0.1 Jun’ 2021 Preliminary 2 Revision 0.1 (06/2021) This document contains the Label and Label Location information for the EV73R53A (ATA5291-XPRO). Preliminary 3 Revision 0.1 (06/2021) Label is affixed to the top silkscreen layer of the board and is located as shown in the following:

Appendix EP Photo Documentation Page 4 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Appendix EP Photo Documentation Page 5 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Antenna Appendix EP Photo Documentation Page 6 of 6 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A

Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN216SHF(P15C-125kHz) 001 Auftrags-Nr.: Order no.: 238492924 Seite 1 von 22 Page 1 of 22 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2020-10-19 Auftraggeber: Client: Microchip Technology Inc. 2355 West Chandler Blvd. Chandler, AZ 85224-6199, USA Prü fgegenstand: Test item: ATA5291-XPRO Bezeichnung / Typ-Nr.: Identification / Type no.: EV73R53A Auftrags-Inhalt: Order content: FCC Part 15C Test report Prü fgrundlage: Test specification: FCC 47CFR Part 15: Subpart C Section 15.207 and 15.209 Wareneingangsdatum: Date of sample receipt: 2020-10-20 Prü fmuster-Nr.: Test sample no: A002935351-002 A002935351-004 Prü fzeitraum: Testing period: 2020-11-11 - 2020-11-27 Ort der Prü fung: Place of testing: EMC/RF Taipei Testing Site Prü flaboratorium: Testing laboratory: Taipei Testing Laboratories Prü fergebnis*: Test result*: Pass überprü ft von: reviewed by: Jack Chang genehmigt von: authorized by: Brenda Chen Datum: Date: 2020-12-16 Ausstellungsdatum: Issue date: 2020-12-16 Stellung / Position: Senior Project Manager Stellung / Position: Senior Project Manager Sonstiges / Other: Zustand des Prü fgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prü fbericht bezieht sich nur auf das o.g. Prü fmuster und darf ohne Genehmigung der Prü fstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prü fzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland Taiwan Ltd. 11F., No. 758, Sec. 4, Bade Rd., Taipei 105, Taiwan, R.O.C. Mail: [email protected] ∙ Web: www.tuv.com Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN216SHF(P15C-125kHz) 001 Seite 2 von 22 Page 2 of 22 TEST SUMMARY Report Section FCC Clause Test Item Result 5.1.1 15.203 Antenna Requirement Pass 5.1.2 15.215(c) Occupied Bandwidth Pass 5.1.3 15.209 Radiated Spurious Emissions Pass 5.2.1 15.207 Mains Conducted Emission Pass Note: Determining compliance based on the results of the compliance measurement, not taking into account measurement instrumentation uncertainty. Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN216SHF(P15C-125kHz) 001 Seite 3 von 22 Page 3 of 22 Contents HISTORY OF THIS TEST REPORT .............................................................................. 4 1. GENERAL REMARKS ............................................................................................. 5 1.1 COMPLEMENTARY MATERIALS ............................................................................... 5 1.2 DECISION RULE OF CONFORMITY ........................................................................... 5 2. TEST SITES .......................................................................................................... 6 2.1 TEST LABORATORY .............................................................................................. 6 2.2 TEST FACILITY ...................................................................................................... 6 2.3 TRACEABILITY ...................................................................................................... 7 2.4 CALIBRATION ....................................................................................................... 7 2.5 MEASUREMENT UNCERTAINTY ............................................................................... 7 3. GENERAL PRODUCT INFORMATION ......................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................... 8 3.2 SYSTEM DETAILS AND RATINGS ............................................................................. 8 3.3 NOISE GENERATING AND NOISE SUPPRESSING PARTS ............................................ 9 3.4 SUBMITTED DOCUMENTS ....................................................................................... 9 4. TEST SET-UP AND OPERATION MODES ................................................................. 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION .......................................................... 10 4.2 TEST OPERATION AND TEST SOFTWARE............................................................... 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ............................................. 11 4.4 TEST SETUP DIAGRAM ........................................................................................ 12 5. TEST RESULTS ................................................................................................... 13 5.1 TRANSMITTER REQUIREMENT & TEST SUITES ....................................................... 13 5.1.1 Antenna Requirement ............................................................................................................. 13 5.1.2 Occupied Bandwidth ............................................................................................................... 14 5.1.3 Radiated Spurious Emissions ................................................................................................. 16 5.2 MAINS EMISSIONS............................................................................................... 21 5.2.1 Mains Conducted Emissions ...................…

Text truncated - open the document above for the full version.

Appendix SP Photo Documentation Page 1 of 3 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Photographs of the Test Set-Up Photograph 1: Set-up for Spurious Emissions (Front View) Photograph 2: Set-up for Spurious Emissions (Back View 1) Appendix SP Photo Documentation Page 2 of 3 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Photograph 3: Set-up for Spurious Emissions (Back View 2) Photograph 4: Set-up for AC Mains (Front View) Appendix SP Photo Documentation Page 3 of 3 CN216SHF(P15C-125kHz) 001, CN21V2PU(RSS210-125kHz) 001 Product: ATA5291-XPRO Type Identification: EV73R53A Photograph 5: Set-up for AC Mains (Back View)
