2ADHKWBZ450Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio

© 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 1 PIC32CX-BZ2 and WBZ45 Family High-performance 2.4 GHz Multi-protocol Wireless MCUs and Modules, supporting Bluetooth Low Energy and 802.15.4 protocols with 32-bit ARM ® Cortex ® -M4F, 2 Msps 12-bit ADC Data Sheet Introduction The PIC32CX-BZ2 family is a general purpose, low-cost, 32-bit Microcontroller (MCU) family of devices supporting multi-protocol wireless interfaces (Bluetooth ® and Zigbee ® ), hardware-based security accelerator, transceiver and Power Management Unit (PMU). The WBZ45 Module is a series of fully RF-certified wireless modules that contain the PIC32CX-BZ2 wireless MCUs with the following antenna options: • PCB Antenna • u.FL Connector for External Antenna In addition to the Bluetooth Low Energy (Bluetooth 5.2) and Zigbee (Zigbee 3.0) wireless protocol support, the PIC32CX-BZ2 devices and the WBZ45 modules also support a rich set of standard MCU peripherals, such as Analog-to-Digital Converter (ADC), Serial Peripheral Interface (SPI), Inter-Integrated Circuit (I 2 C), Quad I/O Serial Peripheral Interface (QSPI), Universal Asynchronous Receiver-Transmitter (UART) and Serial Wire Debug (SWD). PIC32CX-BZ2 SoC Family Features The following section lists the PIC32CX-BZ2 SoC related features: Operating Conditions of MCUs • 1.9V to 3.6V, -40°C to +125°C, DC to 64 MHz – AEC Q100 Grade 1 qualified Core: 64 MHz ARM ® Cortex ® -M4 • 3.35 Coremark ® /MHz • 4 KB Combined Instruction Cache and Data Cache • 8-Zone Memory Protection Unit (MPU) • Thumb ® -2 Instruction Set • Digital Signal Processing ASE Rev 2 • Nested Vector Interrupt Controller (NVIC) • Embedded Trace Module (ETM) with Instruction Trace Stream • Core Sight Embedded Trace Buffer (ETB) • Trace Port Interface Unit (TPIU) • IEEE ® 754-Compliant Floating Point Unit (FPU) PIC32CX-BZ2 and WBZ45 Family © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 2 Memories • 1 MB On-Chip Self-Programmable Flash with: – Error Correction Code (ECC) – Prefetch module to speed up Flash accesses – 20-years of data retention support • 32 KB NVR Flash (8 Sectors) – Private/public boot code and data – NV calibration data • 128 KB Multi-Port Programmable QoS SRAM Main Memory – 64 KB of Error Correction Code (ECC) RAM option • Up to 4 KB of Tightly Coupled Memory (TCM) • Up to 8 KB Backup SRAM • Single 32-bit Backup Register System • Power-on Reset (POR) and Brown-out Detect (BOD) • Internal and External Clock Options • External Interrupt Controller (EIC) • Up to four External Interrupts • One Non-maskable Interrupt • 2-pin Serial Wire Debug (SWD) Programming, Test and Debugging Interface Supported Connectivity Standards • Complies with: – Bluetooth v5.2 – IEEE 802.15.4, Zigbee 3.0 – ETSI EN 300 328 and EN 300 440 Class 2 – FCC CFR47 Part 15 and ARIB STD-T66 Power Supply • Integrated PMU with: – Buck (DC-DC/switching) mode; supports High Power (PWM) and Low Power (PSK) mode – MLDO (linear) mode • On-board 1.2V Voltage Regulator (CLDO) • Power-on Reset (POR) and Brown-out Detect (BOD) on 3.3V and 1.2V Rails • Run, Idle, Dream, Sleep, Deep Sleep and Extreme Deep Sleep Modes • Sleep Walking Peripherals • Embedded Buck/LDO Regulator Supporting On-the-Fly (OTF) Selection 2.4 GHz RF Transceiver • Integrated 2.4 GHz Ultra-low Power RF Transceiver shared among Bluetooth, Zigbee Modems, Link (MAC) Controllers and Proprietary Modulation Schemes • Integrated 16 MHz ±20 ppm Crystal Oscillator (External Low Cost Crystal) • Two PA Design Architecture (LPA (+4 dBm) and MPA (+12 dBm)) to Improve TX Power Efficiency PIC32CX-BZ2 and WBZ45 Family © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 3 • Low RBOM Two-port TRX RFFE Architecture – Integrated balun (single-ended RF output) and TRX switch • Hardware Radio Arbiter with Programmable QoS: – Resolution per packet level – Time-division coexistence between Bluetooth and 802.15.4 – Based on shared transceiver and antenna – Maintains connections of 802.15.4 and Bluetooth simultaneously Bluetooth • Bluetooth Low Energy 5.2 Certified • Up to +12 dBm Programmable Transmit Output Power • Typical Receiver Power Sensitivity: – -95 dBm for Bluetooth Low Energy 1 Mbps – -92 dBm for Bluetooth Low Energy 2 Mbps – -102 dBm for Bluetooth Low Energy 125 Kbps – -99 dBm for Bluetooth Low Energy 500 Kbps – Digital RSSI indicator (-50 dBm to -90 dBm) • Bluetooth Supported Features: – 2M uncoded PHY – Long range (Coded PHY) – Channel selection algorithm #2 – Advertising extensions, offloads CPU with hardware-based scheduler – High duty cycle non-connectible advertising – Data length extensions – Secure connections – Privacy upgrades (with hardware white-list support) • ECDH P256 Hardware Engine for Link Key Generation when Bluetooth Pairing • AES128 Hardware Module for Real-Time Bluetooth Payload Data Encryption • Preprogrammed MAC Address • Bluetooth Qualification Test Facility (BQTF) Certification • Bluetooth Low Energy Profiles: – Bluetooth Low Energy peripheral and central roles – Bluetooth Low Energy APIs for application layer to implement standard or customize GATT based profiles/ services – Microchip Transparent UART Service – Battery Service – Device Information Service – Custom Service – Multi-link and multi-role • Bluetooth Low Energy Services: – Provisioning – Over-the-Air (OTA) update (also known as DFU) – Advertisement/Beacon – Personalized configuration – Alert notification service 802.15.4/Zigbee Modulation Scheme • 802.15.4/Zigbee Physical Layer Service Unit (PSDU) Data Rate: 250 Kbps PIC32CX-BZ2 and WBZ45 Family © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 4 • Programmable RX Mode – -103 dBm RX sensitivity in the Continuous mode – -98 dBm sensitivity in RPC mode – RPC mode provides lower power consumption in RX mode to support California Green Energy Specification at the…

Text truncated - open the document above for the full version.

PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 757 36.6.4 Synchronization Not applicable. PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 758 36.7 Register Summary OffsetNameBit Pos.76543210 0x00CTRLA 7:0CFBS[2:0]AESMODE[2:0]ENABLESWRST 15:8 XORKEYKEYGENLODSTARTMODECIPHERKEYSIZE[1:0] 23:16 CTYPE[3:0] 31:24 0x04CTRLB7:0 GFMULEOMNEWMSGSTART 0x05INTENCLR7:0 GFMCMPENCCMP 0x06INTENSET7:0 GFMCMPENCCMP 0x07INTFLAG7:0 GFMCMPENCCMP 0x08DATABUFPTR7:0 INDATAPTR[1:0] 0x09DBGCTRL7:0 DBGRUN 0x0A ... 0x0B Reserved 0CKEYWORD0 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 10KEYWORD1 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 14KEYWORD2 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 18KEYWORD3 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 1CKEYWORD4 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 20KEYWORD5 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 24KEYWORD6 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 28KEYWORD7 7:0KEYWORD[7:0] 15:8KEYWORD[15:8] 23:16KEYWORD[23:16] 31:24KEYWORD[31:24] 0x2C ... 0x37 Reserved 0x38INDATA 7:0INDATA[7:0] 15:8INDATA[15:8] 23:16INDATA[23:16] 31:24INDATA[31:24] 3CINTVECTV0 7:0INTVECTV[7:0] 15:8INTVECTV[15:8] 23:16INTVECTV[23:16] 31:24INTVECTV[31:24] PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 759 ...........continued OffsetNameBit Pos.76543210 40INTVECTV1 7:0INTVECTV[7:0] 15:8INTVECTV[15:8] 23:16INTVECTV[23:16] 31:24INTVECTV[31:24] 44INTVECTV2 7:0INTVECTV[7:0] 15:8INTVECTV[15:8] 23:16INTVECTV[23:16] 31:24INTVECTV[31:24] 48INTVECTV3 7:0INTVECTV[7:0] 15:8INTVECTV[15:8] 23:16INTVECTV[23:16] 31:24INTVECTV[31:24] 0x4C ... 0x5B Reserved 0x5CHASHKEY0 7:0HASHKEY[7:0] 15:8HASHKEY[15:8] 23:16HASHKEY[23:16] 31:24HASHKEY[31:24] 0x60HASHKEY1 7:0HASHKEY[7:0] 15:8HASHKEY[15:8] 23:16HASHKEY[23:16] 31:24HASHKEY[31:24] 0x64HASHKEY2 7:0HASHKEY[7:0] 15:8HASHKEY[15:8] 23:16HASHKEY[23:16] 31:24HASHKEY[31:24] 0x68HASHKEY3 7:0HASHKEY[7:0] 15:8HASHKEY[15:8] 23:16HASHKEY[23:16] 31:24HASHKEY[31:24] 0x6CGHASH0 7:0GHASH[7:0] 15:8GHASH[15:8] 23:16GHASH[23:16] 31:24GHASH[31:24] 0x70GHASH1 7:0GHASH[7:0] 15:8GHASH[15:8] 23:16GHASH[23:16] 31:24GHASH[31:24] 0x74GHASH2 7:0GHASH[7:0] 15:8GHASH[15:8] 23:16GHASH[23:16] 31:24GHASH[31:24] 0x78GHASH3 7:0GHASH[7:0] 15:8GHASH[15:8] 23:16GHASH[23:16] 31:24GHASH[31:24] 0x7C ... 0x7F Reserved 0x80CIPLEN 7:0CIPLEN[7:0] 15:8CIPLEN[15:8] 23:16CIPLEN[23:16] 31:24CIPLEN[31:24] 0x84RANDSEED 7:0RANDSEED[7:0] 15:8RANDSEED[15:8] 23:16RANDSEED[23:16] 31:24RANDSEED[31:24] PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 760 36.8 Register Description Registers can be 8, 16, or 32 bits wide. Atomic 8-, 16- and 32-bit accesses are supported. In addition, the 8-bit quarters and 16-bit halves of a 32-bit register, and the 8-bit halves of a 16-bit register can be accessed directly. Some registers are optionally write-protected by the Peripheral Access Controller (PAC). Optional PAC write protection is denoted by the “PAC Write-Protection” property in each individual register description. See Register Access Protection from Related Links. Some registers are enable-protected, meaning they can only be written when the peripheral is disabled. Enable- protection is denoted by the "Enable-Protected" property in each individual register description. Related Links 36.5.8. Register Access Protection PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 761 36.8.1 Control A Name: CTRLA Offset: 0x00 Reset: 0x00000000 Property: PAC Write-Protection, Enable-protected Bit 3130292827262524 Access Reset Bit 2322212019181716 CTYPE[3:0] Access R/WR/WR/WR/W Reset 0000 Bit 15141312111098 XORKEYKEYGENLODSTARTMODECIPHERKEYSIZE[1:0] Access R/WR/WR/WR/WR/WR/WR/W Reset 0000000 Bit 76543210 CFBS[2:0]AESMODE[2:0]ENABLESWRST Access R/WR/WR/WR/WR/WR/WR/WR/W Reset 00000000 Bits 19:16 – CTYPE[3:0] Counter Measure Type ValueNameDescription XXX0 CTYPE1 disabledCountermeasure1 disabled XXX1 CTYPE1 enabledCountermeasure1 enabled XX0X CTYPE2 disabledCountermeasure2 disabled XX1X CTYPE2 enabledCountermeasure2 enabled X0XX CTYPE3 disabledCountermeasure3 disabled X1XX CTYPE3 enabledCountermeasure3 enabled 0XXX CTYPE4 disabledCountermeasure4 disabled 1XXX CTYPE4 enabledCountermeasure4 enabled Bit 14 – XORKEY XOR Key Operation ValueDescription 0 No effect 1 The user keyword gets XORed with the previous keyword register content. Bit 13 – KEYGEN Last Key Generation ValueDescription 0 No effect 1 Start Computation of the last NK words of the expanded key Bit 12 – LOD Last Output Data Mode ValueDescription 0 No effect 1 Start encryption in Last Output Data mode Bit 11 – STARTMODE Start Mode Select PIC32CX-BZ2 and WBZ45 Family Advanced Encryption Standard (AES) © 2023 Microchip Technology Inc. and its subsidiaries Draft Advance Information Data Sheet A-page 762 ValueNameDescription 0 Manual ModeStart Encryption / Decryption in Manual mode 1 Auto ModeStart Encryption / Decryption in Auto mode Bit 10 – CIPHER Cipher Mode Select ValueDescription 0 Decryption 1 Encryption Bits 9:8 – KEYSIZE[1:0] Encryption Key Size ValueNameDescription 0 128-bit Key128-bit Key for Encryption / Decryption 1 192-bit Key192-bit Key for Encryption / Decryption 2 256-bit Key256-bit Key for Encryption / Decryption 3 ReservedReserved Bits 7:5 – CFBS[2:0] Cipher Feedback Block Size ValueNameDescription 0 128-b…

Text truncated - open the document above for the full version.

Page 1 of 1 Authority to Act as Agent Date: 2022-12-08 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint __________TUV Taiwan_______ to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with ____Applicant Name and Address_________. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: __December 8, 2022__ Agreement is valid for 12 months from the above date. By: __________________________ HRUSHIKESH VASUKI __ __ (Signature) (Print name) Director-Marketing & Applications _ 480-792-0762_ ______ (Title) (Telephone) On behalf of: Microchip Technology Inc._ ____ (Company Name)

MS-0044715 Page 1 of 1 Revision 0 Date: 2022.12.08 Subject: Confidentiality Request for FCC ID: 2ADHKWBZ450 and IC: 20266-WBZ450 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent User’s Manual*** Short Term n/a Test Setup Short Term n/a External Photos _Microchip Technology Inc._ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: HRUSHIKESH VASUKI / Director-Marketing & Applications (Signature) (Print name/Title)

Applicant/Grantee Microchip Technology Inc. FCC ID: 2ADHKWBZ450 Section 15.212 Modular Transmitters / X Request for Modular Approval Request for Limited Modular Approval Requirements Device Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements must have the radio frequency circuitry must be shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. The module has its own RF shielding.” Shield Can is employed on the board structure, please see exhibition External Photo, the emission measurement was conducted without further shielding added. Y 2 The module shall have buffered modulation/data input(s) (if such inputs are provided) to ensure that the module will comply with the requirements set out in the applicable RSS standard under conditions of excessive data rates or over-modulation. All modulation and data input(s) are buffered.” The EUT has buffered data inputs, it is integrated on the RF chip Y 3 The module shall have its own power supply regulation on the module. This is to ensure that the module will comply with the requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. Requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. Output power is controlled by the RF Chip and de-coupled from supply voltage variations. Frequencies are determined by Crystal Y 4 The module shall comply with the provisions for external power amplifiers and antennas detailed in this standard. The Equipment certification submission shall contain a detailed description of the configuration of all antennas that will be used with the module. The antenna is part of the module Y 5 The module shall be tested for compliance with the applicable standard in a stand- alone configuration, i.e. the module must not be inside another device during testing. The modular transmitter was tested in a stand-alone configuration via a UART Interface. Y 6 The module shall comply with the Category I equipment labelling requirements. In the exhibition OEM manual, there are Instructions given to the OEM on how to label the end product. Y 7 The modular transmitter complies with all specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer will provide adequate instructions along with the module to explain any such requirements. A copy of these instructions is included in this application for equipment authorization: Instructions in User Manual Y 8a Address compliance with the Commission's RF exposure limits in Sections 1.1310 and 2.1093. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). Please refer the Maximum Permissible Exposure Information. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured. Signature Name/Title: HRUSHIKESH VASUKI / Director-Marketing & Applications Company Name: Microchip Technology Inc. Date: 08.12.2022

3-Jan-23 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Certification and Engineering Bureau ISED Canada 3701 Carling Avenue (Building 94) Ottawa, Ontario K2H 8S2 IC ID: 20266-WBZ450 FCC ID: 2ADHKWBZ450 Models: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Declaration on Similarity All models are identical to each other in the circuit design, PCB layout and use of component sources except for the change highlighted in table below. The output power configuration is fixed by software settings; No change in the RF section of the SoC. The Trust&GO is a pre-configured and pre-provisioned secure element of Microchip’s family of security focused devices. The module variants integrate Trust&GO option The differences are in the model numbers and in the digital data interface. Model Number Description WBZ450PE Module with PCB antenna WBZ450PC Module with PCB antenna and Trust&Go chip WBZ450UE Module with u.FL connector for external antenna WBZ450UC Module with u.FL connector for external antenna and Trust&Go chip Hrushikesh Vasuki / Director, Business Unit General Manager, Wireless Solutions Group

Appendix EP Photographs of EUT Page 1 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Onboard PCB Appendix EP Photographs of EUT Page 2 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Appendix EP Photographs of EUT Page 3 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Appendix EP Photographs of EUT Page 5 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC uFL Appendix EP Photographs of EUT Page 6 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Appendix EP Photographs of EUT Page 7 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC

HVIN and FCC ID variants WBZ450PE WBZ450PC WBZ450UE WBZ450UC

Appendix EP Photographs of EUT Page 4 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC ECC Non-ECC Onboard PCB Appendix EP Photographs of EUT Page 8 of 8 CN22R1FG(P15C-BLE) 001 CN22R1FG(P15C-ZigBee) 001 CN22R1FG(FCC-MPE) 001 CN229FW8(RSS247-BLE) 001 CN229FW8(RSS247-ZigBee) 001 CN229FW8(ISED-MPE) 001 Product: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Type Identification: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC ECC Non-ECC uFL

Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN22R1FG(FCC-MPE) 001 Auftrags-Nr.: Order no.: 238523042 Seite 1 von 11 Page 1 of 11 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-11-30 Auftraggeber: Client: Microchip Technology Inc. 2355 West Chandler Blvd. Chandler, Arizona 85224-6199, United States Prü fgegenstand: Test item: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Bezeichnung / Typ-Nr.: Identification / Type no.: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Auftrags-Inhalt: Order content: FCC Certification Prü fgrundlage: Test specification: IEEE Std C95.1 47 CFR §2.1091 47 CFR §1.1310 KDB 447498 D01 Wareneingangsdatum: Date of sample receipt: 2021-09-17, 2022-04-12 Prü fmuster-Nr.: Test sample no: A003241915-001~004 A003130881-007~010 Prü fzeitraum: Testing period: 2022-4-30 - 2022-7-10, 2022-7-19 - 2022-8-29 Ort der Prü fung: Place of testing: EMC/RF Taipei Testing Site Prü flaboratorium: Testing laboratory: Taipei Testing Laboratories Prü fergebnis*: Test result*: Pass zusammengestellt von: compiled by: Ryan Chen genehmigt von: authorized by: Brenda Chen Datum: Date: 2022-08-31 Ausstellungsdatum: Issue date: 2022-08-31 Stellung / Position: Senior Project Manager Stellung / Position: Senior Project Manager Sonstiges / Other: Zustand des Prü fgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prü fbericht bezieht sich nur auf das o.g. Prü fmuster und darf ohne Genehmigung der Prü fstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prü fzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland Taiwan Ltd. 11F., No. 758, Sec. 4, Bade Rd., Taipei 105, Taiwan, R.O.C. Mail: [email protected] ∙ Web: www.tuv.com Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN22R1FG(FCC-MPE) 001 Seite 2 von 11 Page 2 of 11 Contents HISTORY OF THIS TEST REPORT .............................................................................. 3 1 GENERAL REMARKS ............................................................................................. 4 1.1 COMPLEMENTARY MATERIALS ............................................................................... 4 1.2 DECISION RULE OF CONFORMITY ........................................................................... 4 2 TEST SITES .......................................................................................................... 5 2.1 TEST FACILITIES ................................................................................................... 5 2.2 TEST FACILITY ...................................................................................................... 5 3 GENERAL PRODUCT INFORMATION ......................................................................... 6 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................... 6 3.2 RATINGS AND SYSTEM DETAILS ............................................................................. 6 4 MAXIMUM PERMISSIBLE EXPOSURE EVALUATION .................................................... 8 4.1 INTRODUCTION ..................................................................................................... 8 4.2 REFERENCE LEVELS ............................................................................................. 8 4.3 CLASSIFICATION OF THE ASSESSMENT METHODS.................................................. 10 5 TEST RESULTS ................................................................................................... 11 5.1 MPE-BASED EXEMPTION..................................................................................... 11 APPENDIX EP - PHOTOGRAPHS OF EUT Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN22R1FG(FCC-MPE) 001 Seite 3 von 11 Page 3 of 11 HISTORY OF THIS TEST REPORT Report No. Description Date Issued CN22R1FG(FCC-MPE) 001 Original Release 2022-08-31 Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN22R1FG(FCC-MPE) 001 Seite 4 von 11 Page 4 of 11 1 General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix EP - Photographs of EUT 1.2 Decision Rule of Conformity The decision rule of conformity of this test report is following the requirements of the requested standard in the quotation, and agreed among testing laboratory and manufacturer (applicant) to exclude the consideration of Measurement Uncertainty, unless it is required by the specific standard. Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN22R1FG(FCC-MPE) 001 Seite 5 von 11 Page 5 of 11 2 Test Sites 2.1 Test Facilities Taipei Testing Laboratories 11F. No.758, Sec. 4, Bade Rd., Songshan Dist. Taipei City 105 Taiwan (R.O.C.) 2.2 Test Facility Taipei Testing Laboratories No.458-18, Sec. 2, Fenliao Rd., Linkou Dist., New Taipei City 244 Taiwan (R.O.C.) Prü fbericht - Produkte Test Report - Products Prü fbericht - Nr.: Test Report No. CN22R1FG(FCC-MPE) 001 Seite 6 von 11 Page 6 of 11 3 General Product Information 3.1 Product Function and Intended Use The EUT is Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Ra…

Text truncated - open the document above for the full version.

Prü fbericht - Produkte Test Report - Products Prü fbericht-Nr.: Test report no.: CN22R1FG(P15C-BLE) 001 Auftrags-Nr.: Order no.: 238523042 Seite 1 von 41 Page 1 of 41 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-11-30 Auftraggeber: Client: Microchip Technology Inc. 2355 West Chandler Blvd. Chandler, Arizona 85224-6199, United States Prü fgegenstand: Test item: Wireless MCU module with BLE 5.2 compliant and Zigbee 3.1 Radio Bezeichnung / Typ-Nr.: Identification / Type no.: WBZ450PE, WBZ450UE, WBZ450PC, WBZ450UC Auftrags-Inhalt: Order content: FCC Part 15C Test repo…

Text truncated - open the document above for the full version.
