一、产品简介 本产品BL-11A蓝牙插卡耳机（支持MP3音频格式）；支持FM收音 机；有音频输入、可以单独的做为有线耳机（手机耳机、电脑耳机、 MP3耳机）使用；TF卡；可作为移动U盘使用。数据下载等功能集合 于一体。 为了更好的享用本产品优越的性能，并确保使用的安全，延长使用 寿命，请在使用本产品前仔细阅读说明书并妥善保管以便操作，请阅 读随机说明书。 二、功能介绍 【蓝牙功能】 【TF内存卡MP3播放】 【FM收音功能】 【数据下载】 【耳机外拉音频输入，关机状态下可以输入】 【利用USB数据线连接电脑，存取机内TF卡内资料，兼具U盘功能】 三、耳机佩戴方式 有开关的一边‘R’为右声道，另一边‘L’为左声道，双手托住左右边从上 向下护住耳朵。 四、使用方法 1、开机：打开开机键，提示蓝灯闪 2、进入匹配：在开机状态下蓝灯慢闪，自动语音提示，进入蓝牙 状态，配对后语音提示蓝灯长亮，蓝牙连接成功。 3、TF卡功能：蓝牙状态对接按M键，切换到TF卡模式，然后插入MP3 文件试听，绿灯慢闪。 4、TF卡模式按M： 进入收音模式短按M键播放键进入自动收音绿 灯快闪自动收音完毕绿灯慢闪按上下键可以选台。 5、播放/暂停当在播放的时候，按II暂停播放，在暂停时按此键继 续播放，来电时按此按键接电话。 6、音量加按+键增加音量。 7、音量减按-键降低音量。 8、上一首按<键播放上一首曲目。 9、下一首按>键播放下一首曲目。 五、Technical parameters 头戴式蓝牙耳机 六、注意事项 1、首次使用，先充满电。 2、注意防水防潮； 3、请在电脑USB接口上充电，或输出为5V充电器充电； 4、长期不用使用，请一周充放电一次。 七、常见问题处理 八、随机配件 1、音频线一条 2、数据线一条 九、售后服务与支持 如果您购买的产品出现非人为损坏的问题，请退回给我们或 经销商保修。 十、警告 1、必须选择正规厂家生产认证过的充电器。 2、如果产品长期（超过1年）不用，请对其充电。 五、技术参数 FM频段 支持格式/容量TF卡MP3 机型 接收范围 BL-11 87.5-108MHZ 参数 蓝牙规范 通讯距离 频率响应 喇叭输出功率 信噪比 失真度 播放时间 充电时间 FM频段 支持格式/容量 工作电压 工作电流 双声道机机输出 喇叭直径 喇叭抗阻 输入接口 2.1 10M 80Hz-20KHz 10mW ≥80dB ≤5.0% 8 2.5 87.5-108MHz MP3 3.5V-4.2V 30mA 125mA+125 mA 40mm 32Ω USB/3.5+4P/ 5V/1000mA 3.7V300HA 充电接口 电池规格 接口 聚合物 插TF卡 音效切换 播放/暂停/接电话 上一曲/音量大 下一曲/音量小 开机/关机 音频输入插座 USB充电接口 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Insert TF card Audio switch Play/pause/Telephone Previous song/Loud Next song/Volume is low Power on/off Audio input socket USB charging interface 八、Accessories: 13.5mm Aux line; 2USB Cable. 九、Service and support If your device is not performing as it should, please take it to your local service providers or dealer for service. 十、Warning: 1、you must select a regular factory productio certified Chargers. 2、if the product long-term(over 1 year)don’t have to please its charging 六、ADVICE 1Using for the first time, fully charge. 2waterproof; 3Please charging on the USB port of the computer , or the output of 5V charger; 4unused for long periods, charge and discharge once a week. 七、Frequently asked questions FaultReasonResolution Charge in time Change TF card or audio files Repeat plug or change cable Power Down Incompatible Audio Format Connector mistake or unworkable cables Will not turn on Not read TF Card No devices 故障现象 可能原因 排除方法 及时充电 更换TF卡或更换可支持 格式文件 重复插拨设备或更换延长线， 直到电脑找到新硬件为止 电量不足 歌曲格式不支持 USB接口未插好或者接 触不良或者延长线不良 无法开机 无法播放TF卡 系统无法检测到设备 一、Product brief The product card bluetooth BL-11A headphones(MP3 audio format), supports FM radio; has an audio input, you can independently MP3 headphone) se TF card can be used as amobile u disk. Collection of data downloading functions in one. In order to better enjoy the superior performance of this product and ensure the safety of use, longevity, please read these instructions carefully before using the appliance and save it for future use and reference, regarding the specific operations, consult the random instructions. 二、Function introduction “bluetooth” “TF memory card MP3 player” “FM radio feature” “Data download” “Headphones external audio input, shutdown state can input” “Using the USB data cable to connect the computer, access TF card information, both the u” 三、Headset mode The side with switch”R”is right channel,the other side “L”is left channel.Hold your ear with your hands hold the left and right side, from top to bottom. 四、Application method: 1. Start up :press the power button,and the blue indicator lamp flash up; 2. Entering the matching system:under the state of power-on,the blue indicator flash up slowly and automatic sound hints,goes into the Bluetooth state.After matching, voice prompts the blue lamp goes on for a long time , the Bluetooth connection set up successfully. 3. Function of TF card:Press “M” key under the state of Bluetooth connection,then switch the mode of TF card, then plug in an MP3 player and audition,the green lamp flash up slowly. 4. Press “M”key under the mode of TF card:enter into radio mode, press PAUSE briefly then enter into radio automatic.the green lamp flash up quickly.After the automatic radio the green lamp flash up slowly,pree UP and DOWN keys to choose the channel. 5. PLAY/PAUSE:when the radio is playing ,press”M”stop playing ; when the radio is suspended,press “ II”begin playing;when a call come in ,press “M”the call will be accepted! 6. Volume downPress-is for volume down. 7. PreviousPress<is for previous music. 8. NextPress>is for next music. Bluetooth Specification RF Range Frequency Response Loudspeaker Output Signal To-Noise Distortion Playback Time Charging Time 2.1 10m 80Hz-20KHz 10mW 80dB 5.0% 8 hours 2.5 hours FM Format Supported/Capacity Headphone Model Ranges TF Card Voltage Current Work Time Stereo Output Loudspeader Diameter Resistance BL-11 87.5-108MHZ MP3 3.5V-4.2Vv3 30mA 15H 125mW+125mW 40mm 32Ω USB3.5mm 3.5-4P Stereo/Mic Charge Battery 5V/1000mA 3.7V/300mAH Socket Li-ion Battery Interfaces Headset Bluetooth Headset FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is sub…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Worldlinks Communications, L.L.C. 2014-11-22 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, __ Worldlinks Communications, L.L.C._ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Bluetooth headphone Trade Name： N/A Model Name： R-555 Serial Model： YX-BT-H14 FCC ID： 2ADNIR-555 Sincerely, Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Worldlinks Communications, L.L.C. 2014/11/22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADNIR-555 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

Worldlinks Communications, L.L.C. Model Difference FCC ID: 2ADNIR-555 Model : R-555, YX-BT-H14 All the model are the same circuit and RF module,except the model name and colour.Regards, Client’s signature Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Bluetooth headphone Model NO.: R-555 FCC ID: 2ADNIR-555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Antenna

FCC ID : 2ADNIR-555 RF EXPOSURE EVALUATION METHOD FCC ID: 2ADNIR-555 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. BT 3.0 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 3.061 2.023 CH39 2441 3.504 2.241 CH78 2480 3.066 2.026 2Mbps CH00 2402 2.357 1.721 CH39 2441 2.927 1.962 CH78 2480 2.573 1.808 3Mbps CH00 2402 2.541 1.795 CH39 2441 3.006 1.998 CH78 2480 2.641 1.837 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 FCC ID : 2ADNIR-555 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] BT 3.0 Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 1Mbps CH00 2.5~4.5 4.5 2.818 5 2.402 0.874 3 CH39 2.5~4.5 4.5 2.818 5 2.441 0.881 3 CH78 2.5~4.5 4.5 2.818 5 2.480 0.888 3 2Mbps CH00 1.5~3.5 3.5 2.239 5 2.402 0.694 3 CH39 1.5~3.5 3.5 2.239 5 2.441 0.700 3 CH78 1.5~3.5 3.5 2.239 5 2.480 0.705 3 3Mbps CH00 1.5~3.5 3.5 2.239 5 2.402 0.694 3 CH39 1.5~3.5 3.5 2.239 5 2.441 0.700 3 CH78 1.5~3.5 3.5 2.239 5 2.480 0.705 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT-BT 3.0 FCC ID: 2ADNIR-555 Product： Bluetooth headphone Trade Name： N/A Model Name： R-555 Serial Model： YX-BT-H14 Report No.： NTEK-2014NT10301862F Prepared for Worldlinks Communications, L.L.C. 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA Prepared by NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 67 Report No.:NTEK-2014NT10301862F TEST RESULT CERTIFICATION Applicant’s name ................. : Worldlinks Communications, L.L.C. Address ................................. : 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA Manufacture's Name ............ : SHENZHEN DA YI XIN TECHNOLOGY CO.,LTD. Address ................................. : 4/F, No 13, Ganglian Industrial Park, Hongxing Community, Songgang Street, Bao'an District, Shenzhen Product description Product name ........................... : Bluetooth headphone Model and/or type reference : R-555 Serial Model： YX-BT-H14 Standards ............................. : FCC Part15.247: 01 Oct. 2013 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 30 Oct. 2014 ~20 Nov. 2014 Date of Issue ........................................... : 20 Nov. 2014 Test Result ............................................... : Pass Testing Engineer : Denny Huang Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 67 Report No.:NTEK-2014NT10301862F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . NUMBER OF HOPPING CHANNEL 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.1.1 TEST PROCEDURE 25 4.1.2 DEVIATION FROM STANDARD 25 4.1.3 TEST SETUP 25 4.1.4 EUT OPERATION CONDITIONS 25 4.1.5 TEST RESULTS 26 5 . AVERAGE TIME OF OCCUPANCY 27 5.1 APPLIED PROCEDURES / LIMIT 27 Page 4 of 67 Report No.:NTEK-2014NT10301862F Table of Contents Page 5.1.1 TEST PROCEDURE 27 5.1.2 DEVIATION FROM STANDARD 27 5.1.3 TEST SETUP 28 5.1.4 EUT OPERATION CONDITIONS 28 5.1.5 TEST RESULTS 29 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 35 6.1 APPLIED PROCEDURES / LIMIT 35 6.1.1 TEST PROCEDURE 35 6.1.2 DEVIATION FROM STANDARD 35 6.1.3 TEST SETUP 35 6.1.4 EUT OPERATION CONDITIONS 35 6.1.5 TEST RESULTS 36 7 . BANDWIDTH TEST 42 7.1 APPLIED PROCEDURES / LIMIT 42 7.1.1 TEST PROCEDURE 42 7.1.2 DEVIATION FROM STANDARD 42 7.1.3 TEST SETUP 42 7.1.4 EUT OPERATION CONDITIONS 42 7.1.5 TEST RESULTS 43 8 . PEAK OUTPUT POWER TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 TEST PROCEDURE 49 8.1.2 DEVIATION FROM STANDARD 49 8.1.3 TEST SETUP 49 8.1.4 EUT OPERATION CONDITIONS 49 8.1.5 TEST RESULTS 50 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 56 9.1 DEVIATION FROM STANDARD 56 9.2 TEST SETUP 56 9.3 EUT OPERATION CONDITIONS 56 9.4 TEST RESULTS 57 10 . ANTENNA REQUIREMENT 65 10.1 STANDARD REQUIREMENT 65 10.2 EUT ANTENNA 65 11 . EUT TEST PHOTO 66 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 67 Report No.:NTEK-2014NT10301862F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 67 Report No.:NTEK-2014NT10301862F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 67 Report No.:NTEK-2014NT10301862F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT uipment Bluetooth headphone Trade Name N/A Model Name R-555 Serial Model YX-BT-H14 Model Difference All the model are the same circu…
