2ADR3U1603G Mobile Phone

Unnecto™ Primo 3G User Manual 1 Primo 3G User Manual Contents: FOR YOUR SAFETY ............................................................................................................................. 2 ABOUT YOUR PHONE ......................................................................................................................... 3 GETTING STARTED ............................................................................................................................ 4 BASIC FUNCTIONS .............................................................................................................................. 4 CONTACTS ............................................................................................................................................ 5 WRITING A MESSAGE ........................................................................................................................ 5 BLUETOOTH ......................................................................................................................................... 5 SIM CARD SETTINGS .......................................................................................................................... 5 PHONE SETTINGS ................................................................................................................................ 5 SECURITY .............................................................................................................................................. 6 NETWORK SETTINGS......................................................................................................................... 7 FCCCAUTION ........................................................................................................................................ 8 Specifications of Battery and Charger Battery: Li-ion 3.7 V|800 mAh|2.96 Wh Max Charging Voltage: 4.2 V Charger: Input: 100-240 VAC|50/60 Hz|700 mA Output: DC 5.0 V|700 mA Unnecto™ Primo 3G User Manual 2 For Your Safety 1. Road Safety Always keep your hands free to operate the vehicle while driving. Park the vehicle before using your phone. 2. Turning off phone for air travel Using of wireless telephones in aircraft may disrupt the operation of the aircraft. It is dangerous and illegal. Please insure the phone is turned off before going aboard. 3. Turn off phone in hospitals Follow any restrictions or rules. Switch off the phone near medical equipment. 4. Turn off phone when refueling Switch off the phone at a gas station. 5. Switch off phones near blast points Don’t use the phone where blasting is in progress. Observe restrictions and follow any regulations or rules. 6. Enhancements and Batteries Use only the approved enhancements and batteries. Do not connect incompatible products. 7. Emergency Calls Ensure the phone is switched on. Enter the emergency number, and then press the call key. Do not end the call until the permission. Unnecto™ Primo 3G User Manual 3 1. About your phone Unnecto™ Primo 3G User Manual 4 2. Getting started 2.1 Installing the SIM card Press and hold the power/ending key to turn off the phone. Remove the battery cover and then the battery. Insert the SIM card into the card holder. Ensure that the metal contacts face the phone. Re-install the battery. Place the battery cover onto the back of your phone and slide it forward until the latch catches the cover. Note: A SIM card can be easily damaged if its metal contacts become scratched. Therefore, take special care when holding or inserting it and keep it away from children. 2.2 Charging the battery The battery is not fully charged when first unpacked. It takes three charging- discharging cycles for the battery to reach its peak performance. Charge a battery according to the following steps:  Connect the charger to the connection jack of the phone in the proper direction, and connect the charger to a main socket.  The phone displays "Charger Connected!" and starts charging after properly connected. The battery icon dynamically displays the charging process. In switch-off state, the phone dynamically displays the charging process.  When the battery is fully charged, the charging process stops automatically, and the battery icon indicates full grid on the screen. After the battery is fully charged, remove the charger from the phone and socket as soon as possible. 3. Basic Functions 3.1 Power on and off Press and hold at top of power key to turn on/off the phone. 3.2 Make a call Enter the phone number including the area code. Press Call key to make a call. 3.3 Make an extension call When making an extension call, press “*” key several times to get “P” that is a prefix of extension numbers. It will dial automatically after several seconds since you dialed the telephone number. 3.4 Make an international call Enter the country code, the area code and the phone number, press call key. “+” is needed when input country code, and it can be got by pressing the “*” key several times. Unnecto™ Primo 3G User Manual 5 4. Contacts The phone provides two kinds of storage media: SIM card and phone. The phone can store 300 entries. The capacity of Contacts on your SIM card depends on the type of SIM card provided by your network operator. 5. Writing a message New SMS Create a new message. Enter text. You may press the menu key (Options) and select the required items, including insert template, add contact info, and save to Drafts. You may press the send button when the message is ready to send. 6. Bluetooth Power on the Bluetooth by entering the Applications menu. Bluetooth visibility: Allow you to find all other Bluetooth hands-free devices within the allowable scope of Bluetooth, and list all items; you may connect and match the hands-free device in the list (the Bluetooth connection icon would appear in the status column on the top of screen). Paired device: It would display the history records of various devices connected to the Bluetooth for the foll…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 UNNECTO HOLDING LIMITED 2015.11.18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, UNNECTO HOLDING LIMITED (client’s company name) hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: 3G Mobile Phone model name: U160 FCC ID: 2ADR3U160 Sincerely, Client’s signature : VILSON PR Client’s name / title: PRODUCT MANAGER Applicant company：UNNECTO HOLDING LIMITED address： 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 UNNECTO HOLDING LIMITED 11/27/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADR3U160 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : VILSON PR Client’s name & title :Manager Contact information / address: UNNECTO HOLDING LIMITED 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK

Project No: STS1511028 U160 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1511028 Photo 3 Photo 4 Project No: STS1511028 Photo 5 Photo 6 Project No: STS1511028 Photo 7 Photo 8 Project No: STS1511028 Photo 9 Photo 10

Label 3G Mobile Phone Model name: U160 FCC ID: 2ADR3U160 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

Project No: STS1511028 U160 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT Antenna GSM Antenna Project No: STS1511028 Photo 3 Photo 4 Project No: STS1511028 Photo 5 Photo 6 Project No: STS1511028 Photo 7 Photo 8

FCC ID : 2ADR3U160 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2ADR3U160 Maximum measured transmitter power. BT The Worst Case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 2.871 3±1 0 2.441 2.931 3±1 0 2.480 3.801 3±1 0 Remark: The worst case gain of the antenna is 0dBi. 0 dBi logarithmic terms convert to numeric result is nearly 0 (2.402GHz) -4dbm=1.937mw (2.441GHz) -4dbm=1.964mw (2.480GHz) -4dbm=2.399mw BT: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.937/5*√2.402=0.6004≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.964/5*√2.441=0.6137≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.399/5*√2.480=0.7556≤3.0 Threshold at which no SAR required is 0.7556 ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1511028F02 Issued for UNNECTO HOLDING LIMITED 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Product Name: 3G Mobile Phone Brand Name: unnecto ™ Model No.: U160 Series Model: N/A FCC ID: 2ADR3U160 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 49 Report No.: STS1511028F02 TEST RESULT CERTIFICATION Applicant’sname............ UNNECTO HOLDING LIMITED Address ................................. : 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Manufacture's Name ............ : TEM MOBILE LIMITED Address ................................. : No 1708,Cangsong building,Tairan 6 Road,Futian Shenzhen,China Product description Product name ........................ : 3G Mobile Phone Brand name ........................... : unnecto ™ Model and/or type reference .............................................. : U160 Ratings ................................... DC 5V/700mA Standards ............................. : FCC Part 15.247 Test procedure ........................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 05 Nov. 2015 ~12 Nov. 2015 Date of Issue .......................................... : 13 Nov. 2015 Test Result .............................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 49 Report No.: STS1511028F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 TEST SETUP 15 3.1.4 EUT OPERATING CONDITIONS 15 3.1.5 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 18 3.2.1 RADIATED EMISSION LIMITS 18 3.2.2 TEST PROCEDURE 19 3.2.3 DEVIATION FROM TEST STANDARD 19 3.2.4 TEST SETUP 20 3.2.5 EUT OPERATING CONDITIONS 21 3.2.6 TEST RESULTS 22 4. CONDUCTED SPURIOUS EMISSIONS 28 4.1 REQUIREMENT 28 4.2 TEST PROCEDURE 28 4.3 TEST SETUP 28 4.4 EUT OPERATION CONDITIONS 28 4.5 TEST RESULTS 29 5. NUMBER OF HOPPING CHANNEL 33 5.1 APPLIED PROCEDURES / LIMIT 33 5.2 TEST PROCEDURE 33 5.3 TEST SETUP 33 5.4 EUT OPERATION CONDITIONS 33 Page 4 of 49 Report No.: STS1511028F02 Table of Contents Page 5.5 TEST RESULTS 34 6. AVERAGE TIME OF OCCUPANCY 35 6.1 APPLIED PROCEDURES / LIMIT 35 6.2 TEST PROCEDURE 35 6.3 TEST SETUP 35 6.4 EUT OPERATION CONDITIONS 35 6.5 TEST RESULTS 36 7. HOPPING CHANNEL SEPARATION MEASUREMEN 38 7.1 APPLIED PROCEDURES / LIMIT 38 7.2 TEST PROCEDURE 38 7.3 TEST SETUP 38 7.4 EUT OPERATION CONDITIONS 38 7.5 TEST RESULTS 39 8. BANDWIDTH TEST 41 8.1 APPLIED PROCEDURES / LIMIT 41 8.2 TEST PROCEDURE 41 8.3 TEST SETUP 41 8.4 EUT OPERATION CONDITIONS 41 8.5 TEST RESULTS 42 9. PEAK OUTPUT POWER TEST 44 9.1 APPLIED PROCEDURES / LIMIT 44 9.2 TEST PROCEDURE 44 9.3 TEST SETUP 44 9.4 EUT OPERATION CONDITIONS 44 9.5 TEST RESULTS 45 10. ANTENNA REQUIREMENT 47 10.1 STANDARD REQUIREMENT 47 10.2 EUT ANTENNA 47 Page 5 of 49 Report No.: STS1511028F02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 13 Nov. 2015 STS1511028F02 ALL Initial Issue Page 6 of 49 Report No.: STS1511028F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(b)(1) Peak Output Power PASS -- 15.247(c) Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious Emission PASS -- 15.247(a)(iii) Number of Hopping Frequency PASS -- 15.247(a)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 7 of 49 Report No.: STS1511028F02 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 8 of 49 Report No.: STS1511028F02 2. GENE…

Text truncated - open the document above for the full version.

U160 DSS&DTS Setup photo DSS&DTS conduction DSS&DTS radiation L DSS&DTS radiation H
