2ADR3U905-13G Mobile Phone

Unnecto ™ Air 5.5 User Manual 1 Contents Safety Precautions ............................................................................................................................. 2 Overview ........................................................................................................................................... 3 Installing and Removal of the SIM Card ............................................................................................... 3 Installing and Removal of the Micro SD Card ....................................................................................... 3 Battery Use ........................................................................................................................................ 4 Battery Charging ................................................................................................................................ 4 Starting your device for the first time ................................................................................................. 4 Dialing Calls ....................................................................................................................................... 4 SIM Management .............................................................................................................................. 4 Mobile Networks ............................................................................................................................... 4 Wireless Update ................................................................................................................................ 4 Play Store .......................................................................................................................................... 4 FCC Caution ....................................................................................................................................... 5 Specifications of Battery and Charger Battery: Li-ion 3.8 V∣2500 mAh 9.5Wh Max Charging Voltage: 4.35 V Charger: Input: 100-240 VAC∣50/60 Hz ∣180 mA Output: DC 5.0 V∣1000 mA Unnecto ™ Air 5.5 User Manual 2 Safety Precautions Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual. ROAD SAFETY Do not use the phone while you are driving. Park the vehicle before using your phone. SWITCH OFF IN AIRCRAFT Mobile device may cause harmful interference so turn off your mobile device before boarding an airplane. SWITCH OFF IN HOSPITALS Follow any restrictions or rules. Switch off the phone near medical equipment. SWITCH OFF WHEN REFUELING Switch off the phone at a refueling point or any fuel or chemicals places. SWITCH OFF NEAR BLASTING POINT Don’t use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules. INTERFERENCE All wireless phones may be susceptible to interference, which could affect the performance. USE NORMALLY Use in the normal position explained in the product documentation. Don’t touch the antenna unnecessarily. ENHANCEMENTS AND BATTERIES Use only the approved enhancements and batteries. Do not connect incompatible products. EMERGENCY CALLS Turn on your phone and keep it in service areas, dial emergency phone numbers and then press send key to make a call. KEEP AWAY FROM CHILDREN Keep your phone and its accessories away from children. Unnecto ™ Air 5.5 User Manual 3 1. Overview 1 - Volume Keys 6 - Receiver 2 - Earphone Jack 7 - Power Key 3 - Front Camera 8 - Back Camera 4 - Capacitive Buttons 9 - Flash Light 5 - Micro USB Port 10 - Back Cover 2. Installing and Removal of the SIM Card  Switch off the phone and remove the battery.  Insert the SIM Card into the designated SIM 1 or SIM 2 slot.  To remove the SIM Card; turn off the phone; remove the battery; then remove the SIM Card from the SIM Card slot. 3. Installing and Removal of the Micro SD Card  Turn off phone before inserting or removing the Micro SD Card.  To insert, slide the Micro SD Card into the Micro SD Card slot (Micro SD Card facing up), located inside the back of the phone.  To remove, pull the Micro SD Card out of the slot. Unnecto ™ Air 5.5 User Manual 4 4. Battery Use - Installation and Removal of the Battery  Turn off the phone before removing the battery.  Remove the back cover to access the battery.  Place the battery into the phone; aligning the battery pins to the phone’s pins.  To remove the battery, lift up the crease on the corner of the phone. 5. Battery Charging  Plug the provided charger into a standard wall outlet.  Plug the Micro USB charger into the USB port of the phone.  When the phone is fully charged; unplug the charger from the standard wall outlet and from the phone.  If the phone automatically powers off or the battery indictor is low; then you should immediately charge the phone. 6. Starting your device for the first time  Make sure one or two SIM cards are inserted before powering on the phone.  Make sure the battery is charged for at least 30 minutes before the phone is powered on.  Create or sign in an existing Google account for access to the Android features. 7. Dialing Calls  Press the Phone Icon on the phone.  Input the phone number; press the dial key to make the call.  Default call setting is on “Always ask”. For outgoing calls, a prompt will ask you to select SIM 1 or SIM 2. The default can be changed in the SIM Management Settings. 8. SIM Management  SIM Management is located in Settings.  You are able to manage SIM 1 and/or SIM 2 Call, Data, and Roaming preferences. 9. Mobile Networks  Mobile Networks are located in Settings-> More...-> Mobile Network  This setting allows you to select the preferred SIM Card for the 3G Data connection. 10. Wireless Update  Wireless Updates are located in settings-> About Phone ->Wireless Update.  If available, this will update the phone’s firmware. 11. Play Store  Create or sign in an existing account for…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 UNNECTO HOLDING LIMITED 2015.11.16 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, UNNECTO HOLDING LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: 3G Mobile Phone model name: U905-1 FCC ID: 2ADR3U905-1 Sincerely, Client’s signature : VILSON PR Client’s name / title: PRODUCT MANAGER Applicant company: UNNECTO HOLDING LIMITED address: 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 UNNECTO HOLDING LIMITED 11/27/2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADR3U905-1 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : VILSON PR Client’s name & title :Manager Contact information / address: UNNECTO HOLDING LIMITED 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK

Project No: STS1510035 U905-1 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1510035 Photo 3 Photo 4 Project No: STS1510035 Photo 5 Photo 6 Project No: STS1510035 Photo 7 Photo 8 Project No: STS1510035 Photo 9

Label 3G Mobile Phone Model name: U905-1 FCC ID: 2ADR3U905-1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

Project No: STS1510035 U905-1 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI/GPS ANTENNA GSM/WCDMA ANTENNA Project No: STS1510035 Photo 3 Photo 4 Project No: STS1510035 Photo 5 Photo 6 Project No: STS1510035 Photo 7 Photo 8 Project No: STS1510035 Photo 9 Photo 10

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1510035H01 Issued for UNNECTO HOLDING LIMITED 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Product Name: 3G Mobile Phone Brand Name: unnecto ™ Model No.: U905-1 Series Model: N/A FCC ID: 2ADR3U905-1 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.229 W/kg Body:1.101 W/kg S T L A B S Page 2 of 99 Report No.: STS1510035H01 Test Report Certification Applicant’s name ................. : UNNECTO HOLDING LIMITED Address ................................. : 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Manufacture's Name ............ : ShenZhen UNI-ONE ELECTRONIC CO.,LTD Address ................................. : 5/F,Bldg A2,Kexing Science Park,Keyuan Rd.,Hi-Tech Park Shenzhen China Product description Product name ........................ : 3G Mobile Phone Trademark ........................... : unnecto ™ Model and/or type reference : U905-1 Serial Model： N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 20 Oct. 2015 Date of Issue .......................................... : 21 Oct. 2015 Test Result.............................................. : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 99 Report No.: STS1510035H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Antenna Location Sketch 13 7.1 SAR TEST EXCLUSION CONSIDER TABLE 14 8. EUT Test Position 16 8.1 Define Two Imaginary Lines On The Handset 16 8.2 Hotspot mode exposure position condition 17 9. Uncertainty 18 9.1 Measurement Uncertainty 18 9.2 System validation Uncertainty 20 10. Conducted Power Measurement 22 11. EUT And Test Setup Photo 26 11.1 EUT Photo 26 11.2 Setup Photo 29 12. SAR Result Summary 35 12.1 Head SAR 35 12.2 Body SAR And Hotspot 36 13. Equipment List 40 Appendix A. System Validation Plots 41 Appendix B. SAR Test Plots 53 Appendix C. Probe Calibration And Dipole Calibration Report 99 Page 4 of 99 Report No.: STS1510035H01 1. General Information 1.1 EUT Description Equipment 3G Mobile Phone Brand Name unnecto ™ Model No. U905-1 Serial Model N/A FCC ID 2ADR3U905-1 Model Difference N/A Adapter Input: AC100-240V, 0.18A, 50/60 Hz Output: DC 5V, 1000mA Battery Rated Voltage: 3.8V Charge Limit: 4.35V Capacity: 2500mAh Hardware Version U11_MB_V0.3 Software Version UNI_S841N_0.1.150922 Frequency Range GSM 850:824.2 ~ 848.8 MHz PCS1900:1850.2 ~ 1909.8 MHz WCDMA II:1852.4~1907.6 MHz WCDMA V:826.4~846.6 MHz WLAN 802.11 b/g/n(HT20):2412~2462 MHz WLAN 802.11 n(HT40):2422~2452 MHz Bluetooth:2402~2480 MHz Transmit Power(Average): GSM 850: 31.83dBm GSM 1900: 25.53dBm WCDMA II: 21.94dBm WCDMA V: 22.54dBm 802.11b: 14.8dBm 802.11g: 12.3dBm 802.11 n(HT20): 12.3dBm 802.11 n(HT40): 12.6dBm Bluetooth: 0.899dBm Max. Reported SAR(1g): Head: GSM 850: 0.051 W/kg GSM 1900: 0.105 W/kg WCDMA II: 0.219 W/kg WCDMA V: 0.059 W/kg WIFI: 0.229 W/kg Body: GSM 850: 0.155 W/kg GSM 1900: 0.800 W/kg WCDMA II: 1.101 W/kg WCDMA V: 0.098 W/kg WIFI: 0.142 W/kg Operating Mode: GSM: GSM Voice, GPRS EDGE Class 12; WCDMA: RMC, HSDPA, HSUPA Release 6; WLAN: 802.11 b/g/n; Bluetooth: V4.0 + EDR (GFSK +π/4DQPSK+8DPSK) Antenna Specification: GSM/WCDMA: PIFA Antenna BT/WIFI: PIFA Antenna Hotspot Mode: Support DTM Mode: Not Support Page 5 of 99 Report No.: STS1510035H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park,No.190, Chongqing Road, Fuyong, Baoan District, Shenzhen, Guangdong, China CNAS Registration No.: L7649 FCC Registration No.: 842334; IC Registration No.: 12108A-1 Page 6 of 99 Report No.: STS1510035H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r01 RF Exposure Reporting 7 FCC KDB 941225 D01 SAR Measurement Procedures …

Text truncated - open the document above for the full version.

Ref : A CR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK, No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2015 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2015 Checked by : Jérôme LUC Product Manager 9/19/2015 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2015 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2015Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1510035F01 Issued for UNNECTO HOLDING LIMITED 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Product Name: 3G Mobile Phone Brand Name: unnecto ™ Model No.: U905-1 Series Model: N/A FCC ID: 2ADR3U905-1 Test Standard: FCC Part 22H and 24E S T L A B S 2 of 113 Report No.: STS1510035F01 Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name ................. : UNNECTO HOLDING LIMITED Address ................................. : 13/F HARBOUR COMMERCIAL BUILDING 122-124 CONNAUGHT ROAD CENTRAL SHEUNG WAN HK Manufacture's Name ............ : ShenZhen UNI-ONE ELECTRONIC CO.,LTD Address ................................. : 5/F,Bldg A2,Kexing Science Park,Keyuan Rd.,Hi-Tech Park Shenzhen China Product name ........................ : 3G Mobile Phone Brand name ......................... : unnecto ™ Model and/or type reference .. : U905-1 Standards ............................. : FCC Part 22H and 24E Test procedure ........................... : TIA 603 C This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of performance of tests .................. : 12 Oct. 2015 ~22 Oct. 2015 Date of Issue .......................................... : 23 Oct. 2015 Test Result .............................................. : Pass 3 of 113 Report No.: STS1510035F01 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 PRODUCT DESCRIPTION 7 2.2 RELATED SUBMITTAL(S) / GRANT (S) 8 2.3 SPECIAL ACCESSORIES 8 2.4 EUT CONFIGURATION 8 2.5 EUT EXERCISE 8 2.6 CONFIGURATION OF EUT SYSTEM 8 2.7 MEASUREMENT INSTRUMENTS 9 3. DESCRIPTION OF TEST MODES 10 4. OUTPUT POWER 11 4.1 CONDUCTED OUTPUT POWER 11 4.2 PEAK-TO-AVERAGE RADIO (PAR) OF TRANSMITTER 16 4.3 RADIATED OUTPUT POWER 21 5. SPURIOUS EMISSION 25 5.1 SPURIOUS EMISSION 25 5.2 RADIATED SPURIOUS EMISSION 27 6. FREQUENCY STABILITY 33 6.1 MEASUREMENT METHOD 33 6.2 PROVISIONS APPLICABLE 34 6.3 MEASUREMENT RESULT 35 7. OCCUPIED BANDWIDTH 40 7.1 MEASUREMENT METHOD 40 7.2 PROVISIONS APPLICABLE 40 7.3 MEASUREMENT RESULT 40 8. EMISSION BANDWIDTH 43 8.1 MEASUREMENT METHOD 43 8.2 PROVISIONS APPLICABLE 43 8.3 MEASUREMENT RESULT 43 9. BAND EDGE 46 9.1 MEASUREMENT METHOD 46 9.2 PROVISIONS APPLICABLE 46 9.3 MEASUREMENT RESULT 46 4 of 113 Report No.: STS1510035F01 APPENDIX I 47 TEST PLOTS FOR CONDUCTED SPURIOUS EMISSION 47 TEST PLOTS FOR OCCUPIED BANDWIDTH (99%) 77 EMISSION BANDWIDTH (-26DBC) 77 APPENDIX III 101 TEST PLOTS FOR BAND EDGES 101 APPENDIX IV 113 PHOTOS OF TEST SETUP 113 5 of 113 Report No.: STS1510035F01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 23 Oct. 2015 STS1510035F01 ALL Initial Issue 6 of 113 Report No.: STS1510035F01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of ansi C63.10: 2009; TIA 603 C and fcc cfr 47 rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057 Item Number Item Description FCC Rules 1 Output Power Conducted output power 22.913(a) / 24.232 (b) Radiated output power 2 Spurious Emission Conducted spurious emission 2.1051 / 22.917 / 24.238 Radiated spurious emission 3 Frequency Stability 2.1055 /24.235 4 Occupied Bandwidth 2.1049 (h)(i) 5 Emission Bandwidth 22.917(b) / 24.238 (b) 6 Band Edge 22.917(b) / 24.238 (b) NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% 7 of 113 Report No.: STS1510035F01 2. GENERAL INFORMATION 2.1 PRODUCT DESCRIPTION A major technical description of EUT is described as following: Product Designation: 3G Mobile Phone Hardware version: U11_MB_V0.3 Software version: UNI_S841N_0.1.150922 FCC ID: 2ADR3U905-1 Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V UMTS FDD Band IV Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Max RF Output Power: GSM850:32.07dBm,GSM1900:28.72dBm WCDMA Band V:26.05dBm,WCDMA Band II:25.37dBm Type of Emission: GSM(850):317KGXW: GSM(1900):323KGXW GPRS(850):320KGXW; GPRS(1900):321KGXW EDGE(850):318KG7W: EDGE(1900):319KG7W WCDMA850:4M69F9W WCDMA1900:4M70F9W…

Text truncated - open the document above for the full version.

U905-1 PCE Setup photo PCE radiation L PCE radiation H
