2ADR3U40514G MOBILE PHONE

Unnecto™ Swift User Manual 1 Swift LTE User Manual Contents: FOR YOUR SAFETY................................................................................. 2 ABOUT YOUR PHONE ............................................................................ 3 INSTALLING AND REMOVING THE SIM CARD ........................................ 4 INSTALLING AND REMOVING THE MICRO SD CARD .............................. 4 INSTALLING AND REMOVING THE BATTERY........... ............................... 4 CHARGING THE BATTERY ...................................................................... 4 FIRST TIME STARTUP ............................................................................. 4 DIALING OUT ........................................................................................ 5 SIM MANAGEMENT .............................................................................. 5 MOBILE NETWORKS .............................................................................. 5 PLAY STORE .......................................................................................... 5 FCC CAUTION ........................................................................................ 6 Specifications of Battery and Charger Battery: Li-ion 3.7 V|1600 mA |5.92Whh Max Charging Voltage: 4.2 V Charger: Input: 100-240 VAC|50/60 Hz|150 mA Output: DC 5.0 V|700 mA Unnecto™ Swift User Manual 2 For Your Safety Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual. 1. Road Safety Always keep your hands free to operate your vehicle while driving. Park your vehicle before using your phone. 2. Turning off your phone for air travel Use of wireless telephones in an aircraft may disrupt the operation of the aircraft. It is dangerous and illegal. Please ensure that the phone is turned off before going aboard. 3. Turn off your phone in hospitals Follow any restrictions or rules. Switch off your phone near medical equipment. 4. Turn your phone when refueling Switch off your phone at a gas station. 5. Switch off phones near blast points Don’t use your phone where blasting is in progress. Observe restrictions and follow any regulations or rules. 6. Interference All wireless phones may be susceptible to interference, which could affect the performance. 7. Use Normally Use in the normal position explained in the product documentation. Don’t touch the antenna unnecessarily. 8. Enhancements and Batteries Use only the approved enhancements and batteries. Do not connect incompatible products. 9. Emergency Calls Ensure that the phone is switched on. Enter the emergency number, and then press the call key. Do not end the call until given permission. 10. Keep Away from Children Keep your phone and its accessories away from children. Unnecto™ Swift User Manual 3 1. About your phone 1 -Volume Keys 6- Receiver 2 - Earphone Jack 7 - Power Key 3 - Front Camera 8-Back Camera 4 - Capacitive Buttons 9 - Flash Light 5 - Micro USB Port 10 - Back Cover Unnecto™ Swift User Manual 4 2. Installing and Removing the SIM Card  Switch off the phone and remove the battery.  Insert the SIM Card into the designated SIM 1 or SIM 2 slot.  To remove the SIM Card; turn off the phone; remove the battery; then remove the SIM Card from the SIM Card slot. 3. Installing and Removing the Micro SD Card  Turn off phone before inserting or removing the Micro SD Card.  To insert, slide the Micro SD Card into the Micro SD Card slot (Micro SD Card facing up), located inside the back of the phone.  To remove, pull the Micro SD Card out of the slot. 4. Installing and Removing the Battery  Turn off the phone before removing the battery.  Remove the back cover to access the battery.  Place the battery into the phone; aligning the battery pins to the phone’s pins.  To remove the battery, lift up the crease on the corner of the phone. 5. Charging the Battery  Plug the provided charger into a standard wall outlet.  Plug the Micro USB charger into the USB port of the phone.  When the phone is fully charged; unplug the charger from the standard wall outlet and from the phone.  If the phone automatically powers off or the battery indictor is low; then you should immediately charge the phone. 6. First Time Startup  Make sure one or two SIM cards are inserted before powering on the phone.  Make sure the battery is charged for at least 30 minutes before the phone is powered on.  Create or sign in an existing Google account for access to the Android features. Unnecto™ Swift User Manual 5 7. Dialing Out  Press the Phone Icon on the phone.  Input the phone number; press the dial key to make the call.  Default call setting is on “Always ask”. For outgoing calls, a prompt will ask you to select SIM 1 or SIM 2. The default can be changed in the SIM Management Settings. 8. SIM Management  SIM Management is located in Settings.  You are able to manage SIM 1 and/or SIM 2 Call, Data, and Roaming preferences. 9. Mobile Networks  Mobile Networks are located in Settings  More  Mobile Network  This setting allows you to select the preferred SIM Card for the 3G Data connection. 10. Play Store  Create or sign in an existing account for access to the Play Store.  Play Store is used to download/update Applications to the phone. Unnecto™ Swift User Manual 6 FCC Caution Labeling requirements: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Information to user: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro…
